Specification Sheet
Part Number:
121-83378
Product Image
Kabelrap Tie, 13.3" Long, 176lb Tensile Strength, PA46, Gray, 50/pkg
Article Number
121-83378
Type
KR8/33
Color
Gray (GY)
Features & Benefits
• Kabelrap tie offers a smooth strap providing secure assembly without
damaging cables or hoses. • Curved head design provides full circumferential
compression which offers vibration resistance.
Quantity Per
pcs.
Product Description
The patented Kabelrap cable tie design offers a smooth strap which is locked
into place with a glass fiber reinforced pin. The curved head design provides
full circumferential compression around the bundle or harness. Once applied
with the required KR6/8 manual tool, the tie offers a secure and vibration
resistant assembly.
Short Description
Kabelrap Tie, 13.3" Long, 176lb Tensile Strength, PA46, Gray, 50/pkg
Global Part Name
KR8/33-PA46-GY
Minimum Tensile Strength (Imperial)
176.0
Minimum Tensile Strength (Metric)
785.0
Length L (Imperial)
13.3
Length L (Metric)
337.0
Fixation Method
Cable Tie
Identification Plate Position
none
Releasable Closure
No
Tie Closure
fibreglass pin
Variant
No Serration
Width W (Imperial)
0.32
Width W (Metric)
8.0
Bundle Diameter Min (Imperial)
0.32
Bundle Diameter Min (Metric)
8.0
Bundle Diameter Max (Imperial)
3.4
Bundle Diameter Max (Metric)
86.0
Thickness T (Imperial)
0.094
Thickness T (Metric)
2.4
Material
Polyamide 4.6 (PA46)
Material Shortcut
PA46
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +302°F (-40°C to +150°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
50
Package Quantity (Metric)
50
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
4.43
