Specification Sheet
Part Number:
115-06960
1-Piece Cable Tie/Arrowhead Mount, 9.0" Length, 2.0" Bundle Diameter, PA66, Black, 1,000/pkg
Article Number
115-06960
Type
RT50SFK
Color
Black (BK)
Features & Benefits
•
An all-in-one bundling and fixing solution reduces costs. •
High-specification
materials and superior design suit the fixing and bundling needs of complex
applications. •
Releasable to provide quick access to bundles.
Quantity Per
bag
Product Description
One-piece mounting ties offer a complete solution by bundling cables while at
the same time providing a mounting solution. This tie features an extended
pawl, allowing the user to release the tie for bundle maintenance. Push mount
ties offer the ideal combination of high specification materials and superior
design to suit the mounting and bundling needs of complex applications.
Short Description
1-Piece Cable Tie/Arrowhead Mount, 9.0" Length, 2.0" Bundle Diameter, PA66,
Black, 1,000/pkg
Global Part Name
RT50SFK-PA66-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
9.0
Length L (Metric)
225
Fixation Method
Arrowhead
Identification Plate Position
none
Releasable Closure
Yes
Width W (Imperial)
0.2
Width W (Metric)
5.0
Bundle Diameter Min (Imperial)
0.24
Bundle Diameter Min (Metric)
6.0
Bundle Diameter Max (Imperial)
2.0
Bundle Diameter Max (Metric)
50.0
Thickness T (Imperial)
0.055
Thickness T (Metric)
1.4
Height H (Imperial)
0.24
Height H (Metric)
6
Panel Thickness Min(Imperial)
0.31
Panel Thickness Max(Imperial)
0.03
Panel Thickness Min (Metric)
0.8
Panel Thickness Max (Metric)
3.0
Mounting Hole Diameter D (Imperial)
0.25 - 0.28
Mounting Hole Diameter D (Metric)
6.4 - 7.0 mm
Mounting Hole Diameter D Min (Imperial)
0.26
Mounting Hole Diameter D Max (Imperial)
0.275
Mounting Hole Diameter D Max (Metric)
7.0
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
1.93
