Specification Sheet
Part Number:
113-00061
1-Piece Cable Tie/Screw Mount, 8.5" Long, .2" Hole, 1.8" Max Bundle Dia, 50lb, PA66HIRHSUV, Black,
1000/pkg
Article Number
113-00061
Type
T50MRX
Color
Black (BK)
Features & Benefits
• Reinforcement ribs between the screw mount and cable tie head provide
additional strength for added bundle stabilty and security. • Simple one piece
design for quick and easy installation. • Secures with a screw or bolt.
Quantity Per
bag
Product Description
Screw mount cable ties fasten to existing holes to provide a fixing point to
secure and route wire and cable bundles.
Short Description
1-Piece Cable Tie/Screw Mount, 8.5" Long, .2" Hole, 1.8" Max Bundle Dia,
50lb, PA66HIRHSUV, Black, 1000/pkg
Global Part Name
T50MRX-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
255.0
Length L (Imperial)
8.0
Length L (Metric)
203.2
Fixation Method
Fixing hole
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.2
Width W (Metric)
4.7
Bundle Diameter Max (Imperial)
1.8
Bundle Diameter Max (Metric)
45.0
Height H (Imperial)
.24
Height H (Metric)
6.0
Mounting Hole Diameter D (Imperial)
0.2
Mounting Hole Diameter D (Metric)
5.2 mm
Mounting Hole Diameter D Max (Metric)
5.2
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
ROHS Complaint
Yes
Package Quantity(Imperial)
1000
Package Quantity (Metric)
1000
Customs Number
3926909988
