Specification Sheet
Part Number:
111-85850
1-Piece Cable Tie/Arrowhead Mount, 8.9" Long, 50lb, Mounting Hole Dia. .27"–.28", PA66HS, Black,
100/pkg
Article Number
111-85850
Type
T50MD7
Color
Black (BK)
Features & Benefits
•
An all-in-one bundling and fixing solution reduces costs. •
Disc provides secure
insertion and minimizes access of dust, dirt and water.
Quantity Per
pcs.
Product Description
The Domed Push Mount Tie provides a tight, rattle-free installation and acts as
a seal to kieep out dust and debris. One-piece mounting ties offer a complete
solution by both bundling cable and at the same time providing a mounting
solution.
Short Description
1-Piece Cable Tie/Arrowhead Mount, 8.9" Long, 50lb, Mounting Hole Dia.
.27"–.28", PA66HS, Black, 100/pkg
Global Part Name
T50MD7-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225.0
Length L (Imperial)
9.0
Length L (Metric)
225.0
Fixation Method
Arrowhead
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.20
Width W (Metric)
5.0
Bundle Diameter Min (Imperial)
0.39
Bundle Diameter Min (Metric)
10.0
Bundle Diameter Max (Imperial)
2.32
Bundle Diameter Max (Metric)
59.0
Thickness T (Imperial)
0.06
Thickness T (Metric)
1.5
Panel Thickness Min(Imperial)
0.03
Panel Thickness Max(Imperial)
0.08
Panel Thickness Min (Metric)
1.2
Panel Thickness Max (Metric)
2.0
Mounting Hole Diameter D (Imperial)
0.27 - 0.28
Mounting Hole Diameter D (Metric)
6.8 - 7.2 mm
Mounting Hole Diameter D Min (Imperial)
0.27
Mounting Hole Diameter D Max (Imperial)
0.28
Mounting Hole Diameter D Max (Metric)
7.2
Disc Diameter(Metric)
16.0
Disc Diameter (Imperial)
0.63
Material
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HS
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
100
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
1.91
