Specification Sheet
Part Number:
111-85560
1-Piece Cable Tie/Arrowhead Mount with Wings, 4"L, 18lb, 0.18 - 0.19" Mtg Hole, PA66UV, Black, 100/bag
Article Number
111-85560
Type
T18RSF
Color
Black (BK)
Features & Benefits
•
Two piece assembly allows the mount to slide along the strap ensuring proper
orientation. •
Arrowhead style mount provides low insertion and high extraction
force. •
Arrowhead disc protects against dirt and other impurities.
Quantity Per
bag
Product Description
Wing design helps stabilize the tie in high vibration applications. One-piece
mounting ties offer a complete solution by both bundling cable and
simultaneously providing a mounting solution. HellermannTyton's one-piece
mounting ties offer the ideal combination of high specification materials and
superior design to suit the mounting and bundling needs of complex
applications.
Short Description
1-Piece Cable Tie/Arrowhead Mount with Wings, 4"L, 18lb, 0.18 - 0.19" Mtg
Hole, PA66UV, Black, 100/bag
Global Part Name
T18RSF-PA66UV-BK
Minimum Tensile Strength (Imperial)
18.0
Minimum Tensile Strength (Metric)
80
Length L (Imperial)
4.0
Length L (Metric)
100
Fixation Method
Arrowhead
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.1
Width W (Metric)
2.5
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
0.6
