Page 1
Specification Sheet
Part Number:
111-05350
2-Piece Cable Tie/Fir Tree Mount, 11.8"L, Mnt Hole Dia .256"-.276", 30lb, PA66HIRHS, Black, 500/pkg
Article Number
111-05350
Type
T50IFT7
Color
Black (BK)
Features & Benefits
•
Friction tab inside the fir tree allows the tie to sit in mount without falling out
prior to installation. •
Fir tree provides low insertion effort yet demonstrates high
extraction resistance. •
Disc feature prevents rattling in high-vibration
applications and protects against debris ingress.
Quantity Per
bag
Product Description
HellermannTyton’s fir tree mounts provide a secure grip in a mounting hole.
The mount can slide along the cable tie to adjust orientation as needed. Fir
tree mounts are designed to provide a low insertion force and high extraction
force. This mount is sold as an assembly with the cable tie.
Page 2
Short Description
2-Piece Cable Tie/Fir Tree Mount, 11.8"L, Mnt Hole Dia .256"-.276", 30lb,
PA66HIRHS, Black, 500/pkg
Global Part Name
T50IFT7-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
225
Length L (Imperial)
11.8
Length L (Metric)
305.0
Fixation Method
Fir Tree
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.18
Width W (Metric)
4.6
Bundle Diameter Min (Imperial)
0.158
Bundle Diameter Min (Metric)
5.0
Bundle Diameter Max (Imperial)
3.3
Page 3
Bundle Diameter Max (Metric)
85.0
Thickness T (Metric)
1.2
Height H (Imperial)
0.0472
Height H (Metric)
1.2
Panel Thickness Min(Imperial)
0.031
Panel Thickness Max(Imperial)
0.276
Panel Thickness Min (Metric)
0.8
Panel Thickness Max (Metric)
7.0
Mounting Hole Diameter D (Imperial)
0.26 - 0.28
Mounting Hole Diameter D (Metric)
6.5 - 7.0 mm
Mounting Hole Diameter D Min (Imperial)
0.256
Mounting Hole Diameter D Max (Imperial)
0.276
Mounting Hole Diameter D Max (Metric)
7.0
Disc Diameter(Metric)
16.0
Disc Diameter (Imperial)
0.63
Material
Polyamide 6.6 heat stabilized (PA66HS)
Page 4
Material Shortcut
PA66HS
Material Cable Tie
Polyamide 6.6 heat stabilized (PA66HS)
Flammability
UL 94 V2
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
Weight (Metric)
2
