Specification Sheet
Part Number:
111-01671
Article Number
111-01671
Type
TAS120M
Color
Black (BK)
Features & Benefits
• UV resistant materials contain an inhibitor that prolongs the life of the tie in
outdoor environments. • One-piece design reduces installation time. • Outside
serrations prevent cable damage.
Quantity Per
bag
Product Description
Aerial Support Ties feature a built-in spacer to separate cables from the
support wire and prevent abrasion. A one-piece design, combining the tie and
spacer into one part, reduces installation time and inventory costs. The outside
serrations along the strap prevent damage to cables. Formulated from a
special nylon blend, these ties are specifically suited for long-term outdoor use.
The bent tail allows for quick and simple installation by hand.
Short Description
Aerial Support Tie, 12.4" Long, PA66HIRHSUV, Black, 500/bag
Global Part Name
TAS120M-PA66HIRHSUV-BK
Minimum Tensile Strength (Imperial)
120
Minimum Tensile Strength (Metric)
535
Length L (Imperial)
12.4
Length L (Metric)
270.0
Fixation Method
Others
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Outside Serrated
Width W (Imperial)
0.5
Width W (Metric)
12.7
Bundle Diameter Max (Imperial)
2.7
Bundle Diameter Max (Metric)
70.0
Thickness T (Metric)
1.58
Cable Tie Head Width (Imperial)
1.3
Height H (Imperial)
.76
Height H (Metric)
19.0
Material
Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV)
Material Shortcut
PA66HIRHSUV
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +230°F (-40°C to +110°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Package Quantity(Imperial)
500
Package Quantity (Metric)
500
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
