Specification Sheet
Part Number:
111-01563
Solar Tie, 18.4" Long, 45lb Tensile Strength, PA12, Black, 100/pkg
Article Number
111-01563
Type
T50XL(US)
Color
Black (BK)
Features & Benefits
•
PA12 cable ties deliver excellent UV, chemical and moisture resistance.
•
Inside serrations provide strong grip on cables and wire bundles. •
Easy
application either manually or with a tensioning tool. •
Bent tail ensures a quick
and simple installation.
Quantity Per
bag
Product Description
This inside serrated cable tie is manufactured from PA12, which provides
excellent UV, chemical and moisture resistance to allow for a longer lifespan in
outdoor use. PA12 material absorbs slightly less moisture than PA11, yet is
equally resistant to metal oxides. HellermannTyton T-Series Cable Ties feature
inside serrations to provide a positive hold on wire and cable bundles. The
head design guarantees high tensile strength and a low insertion force. The
bent tail allows quick and simple installation by hand. For high-volume
applications, tensioning tools are available to ensure consistent and safe
installation.
Short Description
Solar Tie, 18.4" Long, 45lb Tensile Strength, PA12, Black, 100/pkg
Global Part Name
T50XL(US)-PA12-BK
Minimum Tensile Strength (Imperial)
45.0
Minimum Tensile Strength (Metric)
200.0
Length L (Imperial)
18.4
Length L (Metric)
467.6
Identification Plate Position
none
Releasable Closure
No
Variant
Inside Serrated
Width W (Imperial)
0.19
Width W (Metric)
4.8
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
1.5
Bundle Diameter Max (Imperial)
5.28
Bundle Diameter Max (Metric)
134.0
Material
Polyamide 12 (PA12)
Material Shortcut
PA12
Flammability
UL 94 HB
Operating Temperature (Metric)
-40°F to +203°F (-40°C to +95°C)
ROHS Complaint
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
100
Customs Number
3926909988
