Specification Sheet
Part Number:
110-70084
EVO 7SP Mechanical Hand Tool, Short hand span 3.1", 1/pkg
Article Number
110-70084
Type
EVO7SP
Color
Black (BK)
Features & Benefits
• Patent-pending Tension/Lock/Cut Technology (TLC) technology delivers a
“true” flush cut for a safer installation with no protrusions to damage
neighboring components. • The advanced operating system of the TLC
technology provides operational reliability and durability resulting in fewer
repairs and an extended lifespan; eases wear and tear on tool components. •
Contoured soft trigger and air-cushion handle keeps the wrist in an upright,
neutral position providing greater operator control; minimizes slippage. •
Lightweight tool with the most technologically-advanced ergonomic design for
reducing work-related risks such as fatigue and injury that effect productivity. •
Available in two trigger spans, Standard 3.5” (90 mm) and Short 3.1 (80 mm),
to accommodate different hand sizes for better operator command with less
force and fatigue. • Operating function offers 33 precise pre-set, easy-to-read
settings (with ¼” increments) that reduce subjectivity or the need for fine
tuning. • Tension lock-in mechanism eliminates operator ability to change
tension setting for critical applications. • The greater tension range satisfies a
variety of applications with just one tool. • Wide tapered tie entry allows for
easy insertion of each tie for improving productivity and streamlining the
process of moving from one tie to another quickly. • Revolutionary tool that can
be used to fasten all variations of HellermannTyton’s 18 – 80 pound cable ties
selected as suitable for any application or situation.
Quantity Per
EA
Product Description
HellermannTyton's EVO7 mechanical hand tool was ergonomically designed to
reduce the risks of repetitive stress injuries to operators while concurrently
increasing productivity. The EVO 7 Tension/Lock/Cut Technology delivers
performance, safety and comfort for the operators. Available in a standard grip
span (EVO 7) or short grip span (EVO 7SP), for smaller hands. Additional
accessories are available.
Short Description
EVO 7SP Mechanical Hand Tool, Short hand span 3.1", 1/pkg
Global Part Name
EVO7SP-MET/PL-BK
Technical Description
Short Hand Span 3.1" (80mm)
Cable Ties
T18, T30, T40, T50, T80, IT18, IT50
Tension Setting Tools
Adjustable
Cable Tie Width Max (Imperial)
0.19
