Specification Sheet
Part Number:
109-00107
Q Tie, 11.4" Long, 50lb Tensile Strength, PA66HS, Black, 100/pkg
Article Number
109-00107
Type
Q50I
Color
Black (BK)
Features & Benefits
•
PA66HS cable ties are heat stabilized for excellent heat resistance.
•
Open-head design with easily detectable slot opening allows for fast and easy
insertion. •
Pre-lock feature allows for a temporary hold while preparing bundle.
•
Large ribbed tail ensures simple, ergonomic installation.
Quantity Per
bag
Product Description
Q-Ties have a distinctive open-style head, a pre-lock function, and a large
ribbed tail. The easily detectable slot opening offered with the tail and tie head
provides ease of placement when working with gloves or for blind applications
with limited view of the installation. The pre-lock feature allows for temporary
holding of cable and wire bundles, permitting additional cables and wires to be
placed without destroying the cable tie. Q-Ties can be tensioned by hand or
with one of HellermannTyton’s mechanical cable tie application tools.
Short Description
Q Tie, 11.4" Long, 50lb Tensile Strength, PA66HS, Black, 100/pkg
Global Part Name
Q50I-PA66HS-BK
Minimum Tensile Strength (Imperial)
50.0
Minimum Tensile Strength (Metric)
220
Length L (Imperial)
11.4
Length L (Metric)
290.0
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.19
Width W (Metric)
4.7
Bundle Diameter Min (Imperial)
0.12
Bundle Diameter Max (Imperial)
3.0
Bundle Diameter Max (Metric)
75.0
Thickness T (Imperial)
0.06
Thickness T (Metric)
1.5
Material
Polyamide 6.6 heat stabilized (PA66HS)
Material Shortcut
PA66HS
Flammability
UL 94 V2
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +221°F (-40°C to +105°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
UL | ANSI/UL 746B UL | ANSI/UL 62275 UL | ANSI/UL 1565
UL Listed (US and Canada)
Yes
UL Listed (US
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
100
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
