HellermannTyton 109-00007 Specification Sheet

Specification Sheet
Part Number:
109-00007
Q Tie, 7.7" Long, 18lb Tensile Strength, PA66, Natural, 100/pkg
109-00007
Type
Q18L
Color
Natural (NA)
Features & Benefits
• Open-head design with easily detectable slot opening allows for swift and
easy insertion • Pre-lock feature allows for a temporary hold • The large ribbed
tail permits an ergonomic installation • Two rails on the strap ensure guidance
through the cable tie head
Quantity Per
bag
Product Description
Q-Ties have a distinctive open-style head, a pre-lock function, and a large
ribbed tail. The easily detectable slot opening offered with the tail and tie head
provides ease of placement when working with gloves or for blind applications
with limited view of the installation. The pre-lock feature allows for temporary
holding of cable and wire bundles, permitting additional cables and wires to be
placed without destroying the cable tie. Q-Ties can be tensioned by hand or
with one of HellermannTyton’s mechanical cable tie application tools.
Short Description
Q Tie, 7.7" Long, 18lb Tensile Strength, PA66, Natural, 100/pkg
Global Part Name
Q18L-PA66-NA
Minimum Tensile Strength (Imperial)
18.0
Minimum Tensile Strength (Metric)
80
Length L (Imperial)
7.7
Length L (Metric)
195
Identification Plate Position
none
Releasable Closure
No
Tie Closure
plastic pawl
Variant
Inside Serrated
Width W (Imperial)
0.1
Width W (Metric)
2.6
Bundle Diameter Min (Imperial)
0.06
Bundle Diameter Min (Metric)
2.0
Bundle Diameter Max (Imperial)
2.0
Bundle Diameter Max (Metric)
50.0
Thickness T (Imperial)
0.039
Thickness T (Metric)
1.0
Material
Polyamide 6.6 (PA66)
Material Shortcut
PA66
Flammability
UL 94 V2
Halogen free
Yes
Operating Temperature (Metric)
-40°F to +185°F (-40°C to +85°C)
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
Certification/Specification WEB
UL | ANSI/UL 1565 UL | ANSI/UL 746B UL | ANSI/UL 62275
UL Listed (US and Canada)
Yes
UL Listed (US
Yes
Package Quantity(Imperial)
100
Package Quantity (Metric)
100
Customs Number
3926909988
Content Unit(BMEcat)
pcs.
