Specification Sheet
Part Number:
106-00110
Power Pack CPK with Control Box, 1/pkg
Article Number
106-00110
Type
Power pack CPK with control box
Color
Gray (GY)
Features & Benefits
•
Independent tensioning drive provides unequalled tensioning control and
repeatability. •
Software makes it easy to manage bundling tension and speed,
track performance, troubleshoot issues and log data. •
Versatile enough to be
used by hand, on a benchtop, suspended overhead or in fully automated
environments - to perform wherever you need it. •
Powerpack collects
production data on USB memory stick to analyze on a PC later.
Quantity Per
carton
Product Description
This accessory has the same functionality as item 106-00100 but with the
added connectors for using the AT2000 CPK automatic cable tying tool in fully
automated applications – robotics and PLCs, for example. In addition to routing
power to the tool, this accessory collects the production data and information
that can then be analyzed on a PC to fine-tune processes. An onboard USB
port is used to offload data to USB drive. The Power Pack CPK with Control
Box also has the socket necessary to add an optional foot pedal.
Short Description
Power Pack CPK with Control Box, 1/pkg
Global Part Name
Power pack CPK with control box-GY
Length L (Metric)
285
Width W (Imperial)
2.56
Width W (Metric)
65.0
Cable Ties
T18RA50, T18RA5000
Cycle Time
0.8–1.2 sec. depending on quality and force
Power supply unit
Electrical
Wattage
50
Height H (Metric)
245
Tension Setting Tools
Adjustable
Power Supply
Power pack CPK
Tension Force
Adjustable
Reach Complaint(Article 33)
Yes
ROHS Complaint
Yes
