Heitronic 35962 User guide

GB Installation and operating instructions

Heitronic

®

D-75203 Königsbach

-

Stein

Garden light
Art. no. 35962

Congratulations for deciding to buy our article.
Our article is made out of sturdy, high value materials and will provide you with attractive lighting. The
article consists of a stable housing with a connection cable. It can be used both indoors and outdoors.

Please read through the installation and operation instructions carefully and keep these in a
safe place for later reference.

We do not accept any liability for damage to persons or property caused by not following the
instructions, or improper use or for changes made to the product.

Packaging contents:

 1 light with accessories
 Installation and operating instructions

Technical Data:

Protecti

Article Connection

Luminant

klasse

35962

Heiconnect

12V 

III LED x max. 3W,MR 16, GU 5,3 IP 67

Before Installation:

 The article may only be used outside of the packaging.
 Take the parts carefully out of the packaging.
 Make sure, before using the lighting system that it has not been damaged during

transportation. The lighting system may not be operated if the cable or electrical parts are
damaged. Every piece of defective safety equipment has to be replaced. Repairs may only be
done by a specialist electrician.

 Keep the packaging material well away from children and household pets. Danger of

suffocation!

 Be careful. The packaging contains small parts which can be swallowed by small children.

Safety and warning notice:

 Commissioning is strictly forbidden if there’s damage to the lights, plug or the supply line.
 Never make your own repairs to faulty parts. Repairs must be done by trained specialists.
 Never let children play unattended near the lights or other electrical devices.
 Never expose the lights to a direct water jet (garden hose, or high pressure cleaner, for

example) and never immerse the lights into water or other liquids!

 Do not expose the light to extreme heat or exposed flames.
 The entire product must not be changed or modified. Changes made to the lighting set lead to

invalidation of the guarantee (warranty).

Degree
of
protecti
on

Care and maintenance:

Installation instructions Art. No
r. 35962 Page 1 of 2 Status 05.2013

 You must make sure that the power supply has been disconnected before cleaning.
 Use a dry or a slightly moist cloth for cleaning.
 Never use chemicals or abrasives for cleaning. Do not use road salt in the winter.

H. Vollmer GmbH
Allmendring 29

Disposal:

Heitronic

®

 Used electronic devices must be brought back to public collection points and must not be

disposed of as household waste.

Installation:

 Perform all handling operations on the luminant in a state without current.
 Place the article in the place of choice while observing the safety and warning notes. Make

sure that no water can collect at the location.

 Make sure that there are no obstacles to trip over in the accessible area when laying the

cable.

 The cable must not be buried in the ground and must be kept free from leaves and dirt if

necessary.

 Check the whole system at regular intervals for tightness, functionality and possible damage.
 Check the proper connections once again.
 The rating plate must not be removed.

Changing the luminant:

 Only use a luminant which is specified in the technical data. The use of other luminants can

lead to overheating.

 The power supply has to be disconnected before changing the luminant.
 The light must be allowed to cool off over a sufficient period of time if it changed immediately

after it has failed.

 Start by removing the top plate and safety glass. Remove the faulty luminant. Carefully insert

the new luminant into the holder and check that it is properly seated. Do not use force or
excessive pressure.

 Continue by installing the top plate with the safety glass. Make sure you have a faultless,

clean seal and sealing surface when you reassemble the components. Make sure that the
seal and the top plates are properly seated . Faulty lamp covers have to be replaced
immediately.

 Reconnect the voltage supply.

H. Vollmer GmbH
Allmendring 29
D-75203 Königsbach-Stein

Installation instructions Art. No
r. 35962 Page 2 of 2 Status 05.2013
