Page 1
Type 20
Near- / Midfield Studio Monitor
Product Info
Page 2
Type 20 // Product Info
FEATURES
The HEDD Type 20 is a fully-fl edged 3-way-system stu ed into a sleek and
small footprint cabinet. It gives you the best of both monitoring worlds:
convenient dimensions to easily fi t the speakers into compact recording,
mastering, or sophisticated home studios and the complete skillset of a
full-range midfi eld monitoring system.
The Type 20 is based around a strong, rubber-coated cabinet, that incorporates our self-designed Honeycomb-sandwich woofers (7“ bass / 4“
midrange) and the HEDD Air Motion Transformer tweeter for the most
alive and accurate high frequency reproduction. Three 300W D-Class
ICEpower modules work in the amp section of these analog speakers. The
sound of this ultra-compact monitor is just magic: pristine, powerful and
e ortless with all the advantages you get from a dedicated 3-way-system.
The Type 20 can be noted for its wonderful clarity in the midrange, offering better dynamics and an increased three-dimensionality across its
sound stage. With a frequency spectrum ranging from 50kHz all the way
down to 32Hz, the Type 20 can manage the most complex and challenging
audio situations. It o ers you analog monitoring with digital expansion at
the highest level.
The Type 20 incorporates the versatlile HEDD Bridge system. Besides
standard analog connections (XLR/RCA), you can insert optional inputcards for AES3-, USB2-, and even Dante / AES67-functionality into the
free slot on the backpanel of the speaker.
• Frequency response: 32Hz – 50kHz
(Crossover: 250Hz / 2500Hz)
• 3x 300W ICEpower amps from Denmark
• Max. SPL: ≥120dB
• XLR & RCA inputs
• HEDD Bridge modular inputcard-system
for digital connectivity ( AES3, Dante /
AES67)
• Solid unibody-like cabinet with a modern
matt-black rubber fi nish
• Input Gain
-30dB … +6dB / ±4dB)
• High (±4dB at 20kHz) and Low (±4dB at
50Hz) shelf controls
• Universal Mains (85V – 265V)
• W: 358mm x H: 280mm x D: 338mm
• Weight: 15kg
• Made in Germany
AES3/EBU
Series ONE
Type 20
Near-/ Midfi eld Studio Monitor
www.hedd.audio // [email protected]
