Heatstar MH8CFLEX User Manual
NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!
OPERATING INSTRUCTIONS AND OWNER’S MANUAL
PORTABLE BUDDY
FLEX COOKER
Model # MH8CFLEX
PORTABLE PROPANE COOKER FOR
RECREATIONAL USE
FOR US AND CANADA SALE
LANGUAGES INCLUDED:
• ENGLISH
• SPANISH
• FRENCH
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has no
odor.
Using it in an enclosed space can
kill you.
FOR YOUR SAFETY
If you smell gas:
• Do not attempt to light appliance.
• Extinguish any open flames.
• Disconnect from fuel supply.
FOR YOUR SAFETY
Never use this appliance in
an enclosed space such as a
camper, tent, car or home.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO
OTHERS. Read and follow all instructions. Place instructions in a safe place for future
reference. Do not allow anyone who has not read these instructions to assemble, light,
adjust or operate the cooker.
www.mrheater.com 800-251-0001
78543
NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!
WARNING:
Early signs of carbon monoxide
poisoning resemble the flu,
with headache, dizziness and/or
nausea. If you have these signs,
cooker may not be working
properly. Get fresh air at once!
Have cooker serviced.
WARNINGS
Every time unit is connected,
connection must be checked for
leaks in one or more ways: Apply
soapy water to connection, look
for bubbles, listen for hiss of
escaping gas, feel for extreme
cold, smell for rotten egg odor.
WARNING:
Do not use if leaking!
WARNING:
This product can expose you to
chemicals including lead and
lead compounds, which are
known to the State of California
to cause cancer and birth defects
or other reproductive harm. For
more information visit www.
P65Warnings.ca.gov
WARNING:
FIRE OR EXPLOSION HAZARD
If you smell gas:
1. Do not attempt to light
appliance.
2. Extinguish any open
flame.
3. Disconnect fuel supply.
4. Leave the area
immediately.
5. Allow gas to dissipate 5
minutes before relighting
the appliance.
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
Failure to follow these
instructions could result
in fire or explosion, which
could cause property
damage, personal injury, or
death.
WARNING:
Any changes to this cooker or its
controls can be dangerous.
CONTENTS
2 Warnings
3 General Safety Instructions
3 General Information
4 Operation
Lighting
Shutdown
Maintenance
6 Troubleshooting
7 Parts List
8 Ordering Parts/Warranty
WARNING:
Fuels used in liquefied propane
gas appliances, and the products
of combustion of such fuel,
can expose you to chemicals
including benzene, which is
known to the state of California
to cause cancer and cause birth
defects or other reproductive
harm, for more information go
to www.P65Warnings.ca.gov
WARNING:
Can only be used with Buddy
FLEX heater.
Mr. Heater | Portable Buddy Flex Cooker Operating Instructions and Owner’s Manual
2
Do not attempt to connect
directly to any fuel supply.
Always disconnect cooker when
WARNING:
WARNING:
not in use.
NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!
SAFETY INSTRUCTIONS
GENERAL SAFETY
INSTRUCTIONS
• Due to high temperatures, the
appliance should be located out of
traffic and away from combustible
materials.
• Children and adults should be
alerted to the hazard of high surface
temperatures and should stay away to
avoid burns or clothing ignition.
• Do not leave this cooker unattended
while it is in operation. Keep children
and pets away from the cooker at all
time.
• Do not place clothing or other
flammable material on or near the
appliance.
• If cooking grate is removed for
servicing the appliance, it must be
replaced prior to operating the cooker.
• The appliance should be inspected
before each use. Clean cooker
frequently to avoid grease
accumulation and possible grease fires.
The control compartments, burner
and circulating air passageways of
the appliance must be kept clean, see
MAINTENANCE.
• DO NOT use this cooker if any part
has been under water. Immediately
call a qualified service technician to
inspect the cooker and to replace any
part of the control system and any gas
control, which has been under water.
• When used without adequate
combustion and ventilation air, this
cooker may give off excessive CARBON
MONOXIDE, an odorless, poisonous
gas.
WARNING: Early signs of carbon
monoxide poisoning resemble the
flu, with headache, dizziness, and/or
nausea. If you have these signs, the
cooker may not be working properly.
Get fresh air at once! Have cooker
serviced.
Some people - pregnant women,
persons with heart or lung disease,
anemia, those under the influence of
alcohol, those at high altitudes - are
more affected by carbon monoxide
than others.
• When cooker is placed on the ground,
make sure the ground is level and
keep any objects at least 8 inches from
the front of the cooker.
ODOR FADING ‑ NO ODOR
DETECTED
• Some people cannot smell well. Some
people cannot smell the odor of the
man-made chemical added to propane
(LP) gas. You must determine if you
can smell the odorant in these fuel
gases.
• Learn to recognize the odor of
propane (LP) gas. Local propane (LP)
gas dealers will be more than happy to
give you a scratch and sniff pamphlet.
Use it to become familiar with the fuel
gas odor.
• Smoking can decrease your ability
to smell. Being around an odor for
a period of time can affect your
sensitivity to that particular odor.
Odors present in animal confinement
buildings can mask fuel gas odor.
• The odorant in propane (LP) gas
is colorless and the intensity of
its odor can fade under some
circumstances.
• If there is an underground leak, the
movement of gas through the soil can
filter the odorant.
• Propane (LP) gas odor may differ
in intensity at different levels. Since
propane (LP) gas is heavier than air,
there may be more odor at lower
levels.
• Always be sensitive to the slightest
gas odor. If you continue to detect
any gas odor, no matter how small,
treat it as a serious leak. Immediately
go into action as discussed previously.
Specifications
Model No. MH8CFLEX
Input (Btu/Hr) 5,500-8000
Gas Type Propane (LP)
Clearance To Combustibles
Top 18” (46 cm)
Front 8”( 21 cm)
Sides 8”( 21 cm)
Rear 8”( 21 cm)
ATTENTION ‑ CRITICAL
POINTS TO REMEMBER!
• Propane (LP) gas has a distinctive
odor. Learn to recognize these odors.
(Reference Fuel Gas Odor and Odor
Fading sections above.
• Even If you are not property trained in
the service and repair of the cooker,
ALWAYS be consciously aware of the
odors of propane (LP) gas.
• If you have not been properly trained
in repair and service of propane (LP)
gas then do not attempt to light
cooker, perform service or repairs, or
make any adjustments to the cooker
on the propane (LP) gas fuel system.
• A periodic sniff test around the cooker
or at the heater’s joints; i.e. hose,
connections, etc., is a good safety
practice under any conditions. If you
smell even a small amount of gas,
CONTACT YOUR FUEL GAS SUPPLIER
IMMEDIATELY. DO NOT WAIT!
GENERAL INFORMATION
• The LP-gas cylinder(s) used with a
stove shall be constructed and marked
in accordance with the specifications
for LP-gas cylinders of the U.S.
Department of Transportation or
Transport Canada, the Standard for
Cylinders, Spheres and Tubes for the
Transportation of Dangerous Goods,
CAN/CSA B339.
• Use only VAPOR WITHDRAWAL
propane supply. If there is any
question about vapor withdrawal, ask
your propane dealer.
• FOR OUTDOOR USE ONLY!
Operating Instructions and Owner’s ManualMr. Heater | Portable Buddy Flex Cooker
3
NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!
1
2
Ignition Button
Lighting Instructions
ALWAYS ATTACH OR DETACH
CYLINDER TO HEATER OUTDOORS
AWAY FROM FLAMES, OTHER IGNITION
SOURCES, AND ONLY WHEN COOL
TO TOUCH. NEVER SMOKE WHEN
ATTACHING OR REMOVING PROPANE
CYLINDER OR MAKING REMOTE
CONNECTIONS!
IMPORTANT: The cooker must not be
exposed to flammable vapors or liquids
during lighting.
1. Follow instructions in Buddy Flex
Heater manual to attach cooker to
OPERATION
heater (as shown in Figure 1) and to
pre-light the heater.
IMPORTANT:Check quick connection
for leaks with soapy water. DO NOT
USE ANY EXPOSED FLAME TO CHECK
FOR LEAKS.
2. Push control knob slightly and rotate to
“LOW/START” position. See Figure 2.
3. Push down and hold control knob in
while pressing ignition button.
4. Hold control knob down for 5-30
seconds to activate thermocouple,
until burner sustains flame.
5. Once flame is sustained, rotate control
knob to adjust flame to desired
setting.
Shutdown Instructions
1. To shut off cooker, shut off the heater
gas supply first, then rotate the cooker
control knob to the “OFF” position.
• Do not operate, store or remove
cylinder near flammable items or
ignition sources.
• LP-GAS CYLINDERS MUST BE
DISCONNECTED FROM HEATER WHEN
NOT IN USE!
Pulse Ignition
The Pulse Ignition Button is located to
the left of the control knob. Refer to
Figure 2.
Open the battery cover located on the
bottom of the cooker to install
the “AAA” battery (included).
Transporting Cooker
Your Buddy Flex Heater and Buddy Flex
Cooker are specially designed to easily
move around as a single unit.
To attach the cooker to the heater:
1. Place the heater on top of the cooker
as shown in Figure 3.
2. Lift up engagement flap to engage
each rail and then fold it down to
secure the cooker to the heater.
See Figure 4.
Figure 1
Mr. Heater | Portable Buddy Flex Cooker Operating Instructions and Owner’s Manual
4
Figure 2
Figure 3Figure 4
NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!
Thermocouple
Electrode
MAINTENANCE
Maintenance
• Always keep the cooker area clear
and free from combustible materials,
gasoline and other flammable vapors
and liquids.
• Keep the vent areas (slots in the
bottom and top of the cooker) clear at
all times.
IMPORTANT: The cooker and its
surroundings should be kept clean and
free of dust.
• The burner should be bright orange
(with a slight blue color around the
border, a red-orange haze that is visible
on the burner material is acceptable)
and without a noticeable flame.
• If the burner has a noticeable flame,
cleaning may be required. Use the
following procedure to inspect the
casing assembly and main burner
assembly.
Cleaning Instructions (Refer to
Exploded Parts on Page 6):
IMPORTANT: Allow cooker to
thoroughly cool before performing any
maintenance.
1. Inspect the interior of casing for
accumulation of dust, lint or spider
webs. If necessary, clean the interior
of the casing assembly with a vacuum
cleaner or compressed air (max 30
psi). Do not damage any components
within the casing assembly when you
are cleaning.
2. The exterior of the cooker can be
cleaned with a damp cloth. Avoid the
direct use of any aerosol or spray-on
cleaners. Do not use abrasive materials
or cleaners on the decals or control
knob.
OFFSEASON
• If the cooker is to left “OFF” for a
considerable period of time, the
propane (LP) gas supply to the heater
and cooker should be turned off as
close to the gas source as possible.
In the case of portable use, the gas
should be turned off at the propane
(LP) gas supply cylinder.
• If the cooker is put into storage, make
sure to disconnect the propane (LP)
gas cylinder from heater.
• When the LP-gas cylinder is not
disconnected from the heater, the
heater, cooker and cylinder must be
located outdoors, in a well-ventilated
space, out of the reach of children,
and must not be stored in a building,
garage, or any other enclosed area.
• Storage of the cooker indoors is
permissible only if the cooker is
disconnected and removed from
the heater. Cylinders must be stored
outdoors, in a well-ventilated space,
out of the reach of children, and must
not be stored in a building, garage, or
any other enclosed area.
Figure 5
WARNING: Always inspect
propane cylinder and cooker propane
connections for damage, dirt, and debris
before attaching propane cylinder. Do
not use if head of cylinder is damaged,
punctured or deteriorated.
CAUTION: After turning cooker off,
metal cooking grate will remain hot.
Allow to thoroughly cool before storing.
CAUTION: Clean stove frequently to
avoid grease accumulation and possible
grease fires.
Operating Instructions and Owner’s ManualMr. Heater | Portable Buddy Flex Cooker
5
NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!
SYMPTOM
• Spark electrode does not produce spark.
CAUSE
1. Spark electrode broken. 1. Replace electrode assembly. See Service Dealer.
2. Igniter wire may not be attached to spark electrode. 2. Attach igniter wire. See Service Dealer.
3. Igniter wire damaged. 3. Replace igniter wire. See Service Dealer.
4. Ignition module is defective. 4. Replace ignition module. See Service Dealer.
REMEDY
SYMPTOM
• Spark electrode produces spark but cooker does not light.
CAUSE
1. No gas to cooker. 1. Connect cooker to heater and follow instructions in Buddy
2. “LOW/START” Position not properly aligned. 2. Adjust knob until it can be depressed for burner ignition.
REMEDY
FLEX Heater manual to provide gas to cooker.
SYMPTOM
• Cooker keeps shutting “OFF” during normal operation.
CAUSE
TROUBLESHOOTING
1. Pilot on heater has been extinguished. 1. Follow instructions to relight the heater and cooker.
REMEDY
• For additional assistance or information, please call Technical services.
Mr. Heater | Portable Buddy Flex Cooker Operating Instructions and Owner’s Manual
6
NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!NEVER LEAVE THE COOKER UNATTENDED WHILE BURNING!
WARRANTY AND PARTS ORDERING
PORTABLE BUDDY
FLEX COOKER
Model # MH8CFLEX
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions
in a safe place for future reference. Do not allow anyone who has not read these
instructions to assemble, light, adjust or operate the cooker.
WARNING:
USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULDCAUSEINJURYOR
DEATH. REPLACEMENT PARTS ARE ONLY AVAILABLE DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY
A QUALIFIED SERVICE AGENCY.
WARNING:
THIS PRODUCT IS A COOKER. IT IS CERTIFIED TO ANSI INTERNATIONAL REQUIREMENT SECTION Z21.72-2019 • CSA 11.2-2019,
“PORTABLE TYPE GAS CAMP STOVES”. NEVER USE HAND-MADE OR THIRD PARTY ACCESSORIES OR ATTACHMENTS WITH
THIS COOKER; THIS IS EXTREMELY DANGEROUS AND MAY RESULT IN PERSONAL INJURY OR DEATH TO YOU OR OTHERS.
PARTS ORDERING INFORMATION
PURCHASING: Accessories may be purchased at any Mr. Heater local dealer or direct from the factory
FOR INFORMATION REGARDING SERVICE
Please call Toll-Free 800-251-0001
Or visit www.mrheater.com
Our office hours are 8:00 AM – 5:00 PM, EST, Monday through Friday.
Please include the model number, date of purchase, and description of problem in all communication.
LIMITED WARRANTY
Mr. Heater, Inc. warrants its cookers and accessories to be free from defects in material and workmanship for a period of 1 year
from date of purchase. Mr. Heater, Inc. will repair or replace this product free of charge if it has been proven to be defective
within the 1-year period, and is returned at customer expense with proof of purchase to Mr. Heater, Inc. within the warranty
period. DISCLAIMER: This warranty does not cover any product that: a) has been subject to misuse or neglect; b) has been used
in a manner inconsistent with the warnings and instructions contained in the owner’s manual; or c) has been used with hand-
made or third party accessories or attachments. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
Mr. Heater, Inc. reserves the right to make changes at any time, without notice or obligation, in colors, specifications, accessories,
materials and models.
PRODUCT REGISTRATION: Thank you for your purchase.
Please log in to http://www.egiregistration.com to register your product.
ENERCO INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001
Mr. Heater is a registered trademark of Enerco Group, Inc.
© 2020, Enerco/Mr. Heater. All rights reserved
Mr. Heater | Portable Buddy Flex Cooker Operating Instructions and Owner’s Manual
8
Loading...
