Heat Seal SW-3614S User Manual

MODEL SW-3614

SEMI-AUTOMATIC
BUNDLER

EASY TO OPERATE, RELIABLE,
ECONOMICAL BUNDLING

Semi-Automatic Bundler

Shown in Stainless Steel (SW-3614S)

DEPENDABLE SEMI-AUTOMATIC BUNDLER

FEATURES

Control Panel

• RS-3 Digital Controller For Easy Set Up and
Operation

• Single Plug 115V Power Supply with GFCI

• Heavy Duty Circuit Breaker On / Off Switch

• E-Z Access Drop Down Service Panel

Seal Area

• Large 36” W Seal Bar And 14” H Opening

• Heavy Duty Hot Knife Seal System With Film
Clamps

• Two Button Air Operated Seal Head

• Dual Magnetic Hold Down With Adjustable
Pressure And Dwell Time.

Conveyor Features

• Roller Infeed Conveyor

• Posi-Trac Power Take Away Conveyor

Other Features

• Power Assisted Top And Bottom Film Unwind

• Heavy Duty Adjustable Levelers And Locking

Casters

• Stainless Steel Model Available

• Also Available With 24” Wide Seal Bar
(SW-2414)

Heat Seal LLC | 4580 East 71st Street Cleveland, OH 44125 USA | Voice: [phone] | Fax: [phone] | www.heatsealco.com

REVISED 2011

Semi Automatic Bundler

MODEL SW-3614

Machine Specications

Film Capacity 36” Wide (91.4 cm)

Seal Width 36” (91.4 cm)

Max Package 13” H (33 cm)
Height

Overall 48” L, 40” W, 77” H

Dimensions

Working Height 35” (89 cm)

Power 115 Volts, 15 Amps
Requirements Single Circuit with Ground

Air Requirements 1-2 cu. ft. per minute @ 80 psi

(122 cm L, 102 cm W, 196 cm H)

Machine Footprint

Options

• Manual Roller Bed Outfeed

• Product Guides

• Export Wiring/220 Volt, 8 Amps

Heat Seal LLC | 4580 East 71st Street Cleveland, OH 44125 USA | Voice: [phone] | Fax: [phone] | www.heatsealco.com

• 18” H Seal Bar Opening

• Stainless Steel Construction

REVISED 2011
