Heat & Glo SFE-ST INSTALLER/CONSUMER SAFETY INFORMATION
TM
Model: SFE-ST
INSTALLER/CONSUMER SAFETY
INFORMATION
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND USING APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, AN ELECTRICAL SHOCK
OR FIRE MAY RESULT, CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
TM
BUILDER BOX
FOR YOUR SAFETY
SERVICE MUST BE PERFORMED BY
A QUALIFIED SERVICE AGENCY.
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
C
US
Homeowner’s Installation & Operating Manual
Note: The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
ANSI / UL1598-2004
INSTALLER: DO NOT DISCARD THIS MANUAL -- LEAVE FOR HOME OWNER
TUV Listed as SFE-ST
1 Hearth & Home Technologies Inc. • SFE-ST • 4050-510 Rev A • 05/08
Congratulations!
Congratulations on selecting a Simplifyre electric fi replace.
The unit you have selected is designed to provide the utmost
in safety, reliability and effi ciency.
As the owner of a new fi replace, you’ll want to read and
carefully follow all of the instructions contained in this
owner’s manual. Pay special attention to all cautions and
warnings.
TABLE OF CONTENTS
Please read the installation & operation instructions before
using this appliance.
1 Important Instructions 3
A. Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
B. Locating Your Electric Appliance . . . . . . . . . . . 3
C. Clearance to Combustibles . . . . . . . . . . . . . . . 3
D. Framing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
E. Hardwire Electrical Connections . . . . . . . . . . . . 4
F. Electrical Specifi cations . . . . . . . . . . . . . . . . . . 4
G. Wall Switch Connections . . . . . . . . . . . . . . . . . 4
H. Finishing and Trim . . . . . . . . . . . . . . . . . . . . . . 5
This owner’s manual should be retained for future reference.
We suggest you keep it with your other important documents
and product manuals.
Your new Simplifyre electric fi replace will give you years of
durable use and trouble-free enjoyment.
Welcome to the Hearth & Home Technologies family of
fi replace products!
2 Operating Instructions 6
A. Remote Control . . . . . . . . . . . . . . . . . . . . . . . . 6
B. Remote Control Initialization . . . . . . . . . . . . . . . 6
C. Control Usage . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Service Instructions 7
A. Replacing the Light Bulb . . . . . . . . . . . . . . . . . . 7
B. Screen Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 7
C. Maintenance of Motors . . . . . . . . . . . . . . . . . . . 7
4 Service Parts 7
5 Warranty 8
2 Hearth & Home Technologies Inc. • SFE-ST • 4050-510 Rev A • 05/08
1
1
Important Instructions
WARNING! Risk of Fire!
DO NOT:
• install or operate damaged appliance
• modify appliance
• operate the appliance without fully assembling all
components
The following actions are strictly prohibited:
• Installation other than as instructed by Hearth & Home
Technologies Inc.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies Inc.
Hearth & Home Technologies Inc. disclaims any responsibility
for, and the warranty and agency listing will be voided by the
above actions.
WARNING! Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner’s information manual
provided with this appliance. For assistance or additional
information consult a qualifi ed installer, service agency or
your dealer.
NOTICE! This appliance is not intended for use as a primary
heat source and should not be factored as such in residential
heating calculations.
A. Unpacking
Remove the carton and retain the remote transmitter and
installation document located in the top foam.
The retaining brackets holding the front doors must be
removed.
Retaining Brackets
WARNING! Risk of Electric Shock! This product should
never be installed near water.
WARNING! DO NOT use this appliance if any part has been
under water. Immediately call a qualifi ed service technician
to inspect and to replace any part of the electrical system if
necessary
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fi re, electric shock
and injury to persons, including the following:
• This appliance is intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate appliance
where it may fall into a bathtub or other water container.
• Use this appliance only as described in this manual. Any
other use not recommended by the manufacturer may
cause fi re, electric shock, or injury to persons.
• Always use ground fault protection where required by
electrical code.
• Always disconnect power before performing any cleaning,
maintenance.
• To prevend a possible fi re, do not burn wood or other
materials in this appliance.
• To prevent electric shock or fi re, always use a qualifi ed
electrician should new circuits or outlets be required.
• SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
Remove Retaining Brackets Holding Front Doors
B. Locating Your Electric Appliance
Your new electric appliance may be installed virtually
anywhere in your home. However, when choosing a location
ensure that the general instructions are followed. For best
results, install out of direct sunlight.
Power supply service must be either completed or
placed within the appliance prior to fi nishing to avoid
reconstruction.
C. Clearance to Combustibles
Sides . . . . . . . . . . . . . . . . . . . . . . . . . . .0 in. (0 mm)
Floor . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 in. (0 mm)
Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 in. (0 mm)
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 in. (0 mm)
3 Hearth & Home Technologies Inc. • SFE-ST • 4050-510 Rev A • 05/08
