OWNER
S MANUAL
Split Type Room Air Conditioner
SMA/SMH Series
Please read the operating instructions and safety precautions carefully and thoroughly
before installing and operating your room air conditioner.
CONTENTS
SAFETY PRECAUTIONS .......................................................................................
PARTS NAMES .....................................................................................................
OPERATING TEMPERATURE ..............................................................................
MANUAL OPERATION .........................................................................................
ADJUSTING AIR FLOW DIRECTION.....................................................................
HOW THE AIR CONDITIONER WORKS................................................................
OPTIMAL OPERATION ..........................................................................................
MAINTENANCE.......................................................................................................
OPERATION TIPS .................................................................................................
TROUBLESHOOTING TIPS...................................................................................
Read This Manual
Inside you will find many helpful hints on how to use and maintain your
air conditioner properly. Just a little preventative care on your part can
save you a great deal of time and money over the life of your air conditioner.
You'll find many answers to common problems in the chart of troubleshooting
tips. If you review the chart of Troubleshooting Tips first, you may not need
to call for service.
1
3
4
4
5
6
6
7
9
11
CAUTION
!
Contact an authorized service technician for repair or maintenance of this unit.
Contact the installer for installation of this unit.
The air conditioner is not intended for use by young children or invalids
without supervision.
Young children should be supervised to ensure that they do not play with the
air conditioner.
Installation work must be performed in accordance with the national
electrical codes
by authorized personnel only.
and local
Safety Precautions
To prevent injury to the user or other people and property damage, the following
instructions must be followed.
Incorrect operation due to ignoring of instructions may cause harm or damage. The
seriousness is classified by the following indications.
WARNING
!
CAUTION
!
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to property.
Meanings of symbols used in this manual are as shown below.
Never do this.
!
!
Connect with the power
properly.
Otherwise, it may cause electric
shock or fire due to heat
generation.
!
Keep firearms away.
It may cause fire.
Always do this.
Do not operate or stop the
unit by switching on or off
the power.
It may cause electric shock or fire
excess
due to heat generation.
Do not operate with wet
hands or in damp
environment.
It may cause electric shock.
WARNING
!
Do not near flammable
operate unit
gas or combustibles, such as
gasoline, benzene, thinner, etc.
It may cause an explosion or fire.
Do not direct airflow at
room occupants only.
This could damage your health.
!
Always ensure effective
grounding.
No may cause electric
grounding
shock.
!
Disconnect the power if
strange sounds, smell, or
smoke comes from it.
It may cause fire and electric
shock.
!
Ventilate room before operating air
conditioner if there is a gas leakage from
another appliance.
It may cause explosion, fire and, burns.
Do not allow water to run
into electric parts.
It may cause failure of machine
or electric shock.
Do not drink water drained
from air conditioner.
It contains contaminants and
could make you sick.
!
Always install circuit
breaker and a dedicated
power circuit.
No installation may cause fire
and electric shock.
Do not open the unit
during operation.
It may cause electric shock.
Do not disassemble or modify unit.
It may cause failure and electric shock.
1
When the air filter is to be
removed, do not touch the
metal parts of the unit.
CAUTION
!
Do not clean the air
conditioner with water.
!
Ventilate the room well when
used together with a stove,
etc.
It may cause an injury.
!
When the unit is to be
cleaned, switch off, and turn
off the circuit breaker.
Do not clean unit when
power is on as it may cause
fire and electric shock, it may
cause an injury.
!
Stop operation and close
the window in storm or
hurricane.
Operation with windows
opened may cause wetting
of indoor and soaking of
household furniture.
Do not use strong detergent
such as wax or thinner. Use
a soft cloth for cleaning.
Water may enter the unit and
An oxygen shortage may occur.
degrade the insulation. It may
cause an electric shock.
Do not put a pet or house
plant where it will be
Do not use for special
purposes.
exposed to direct air flow.
This could injure the pet or
plant.
Do not use this air conditioner to
preserve precision devices, food,
pets, plants, and art objects.
It may cause deterioration of
quality, etc.
!
Do not place obstacles
around air-inlets or inside
of air-outlet.
It may cause failure of
appliance or accident.
!
Ensure that the installation bracket of
the outdoor appliance is not damaged
due to prolonged exposure.
!
Turn off the main power
switch when not sing the
unit for a long time.
It may cause failure of product
or fire.
!
Always insert the filters
securely. Clean filter once
every two weeks.
u
Appearance may be
deteriorated due to change
of product color or
If bracket is damaged, there
is concern of damage due to
falling of unit.
scratching of its surface.
!
Use caution when unpacking and installing.
Sharp edges could cause injury.
!
Operation without filters may
cause failure.
If water enters the unit, turn the unit off and
disconnect the power, contact a qualified
service technician.
2
PARTS NAMES
INDOOR UNIT
3
Air inlet
4
5
Air outlet
2 1
6
8
7
OUTDOOR UNIT
9
Air inlet
Air outlet
10
DISPLAY PANEL
NOTE:
The display pa nel on the indoor uni t
look like one of f ollowing:will
12
INDOOR UNIT
1
Front panel frame
2
Front panel
3
Air filter
4
Horizontal air flow grille
5
Vertical air flow louver
6
Room temperature sensor
7
Display panel
8
Infrared signal receiver
9
Remote controller
10
Drain hose, refrigerant connecting pipe
11
Connective cable
12
Stop valve
DISPLAY PANEL
OPERATION indicator:
The indicator flashes once every second
11
after power is on and illuminates when the
air conditioner is in operation.
TIMER indicator:
The indicator illuminates when TIMER is set ON.
PRE-DEF. Indicator
This indicator illuminates when the air conditioner
starts defrosting automatically or when the Anticold air function is activated in heating operation.
AUTO indicator:
This indicator flashes when the air conditioner
is in AUTO operation.
ECON indicator:
This indicator illuminates while the air conditioner
is in economic operation.
(For cooling& heating model only)
:
TIMER
OPERATION
PRE-DEF
Infrared signal receptor
OPERATION
Infrared signal receptor
AUTO
ECON
TIMER
PRE-DEF
Note:
All the pictures in this manual are for explanation
purpose only. They may be slightly different from
the air conditioner you purchased.
3
OPERATING TEMPERATURE
Mode
Temperature
Room temperature
Outdoor temperature
CAUTION:
1. If air conditioner is used outside of the above conditions, certain safety protection
features may come into operation and cause the unit to function abnormally.
2. Room relative humidity less than 80%. If the air conditioner operates in excess of this
figure, the surface of the air conditioner may attract condensation. Please sets the vertical
air flow louver to its maximum angle (vertically to the floor), and set HIGH fan mode.
3. Optimum performance will be achieved within these operating temperature.
Cooling operation
Heating operation
63 F ~ 9 0 F 32 F ~ 8 6 F
64 F ~ 1 13 F
19 F ~ 7 5 F
Drying operation
63 F ~ 9 0 F
52 F ~ 1 10 F
MANUAL OPERATION
Manul operation can be used temporarily in case you can not find the remote controller or
its batteries are exhausted.
1
Open and lift the front panel up to an angle until
it remains fixed with a clicking sound.
2
Push the button until the AUTO indicator is lit,
the unit will work in forced AUTO mode (the
default setting temperature is 75F).
3
Close the panel firmly to its original position.
Manual
control button
AUTO/COOL
Manual
control button
(For 16000Btu/h Models)
Manual
control button
control button
(For 16000~21000Btu/h Models)
COOL
AUTO
Manual
AUTO/COOL
COOL
AUTO
CAUTION:
Once you push the manual button, the operation
mode is shifted in an order as: AUTO, COOL, OFF.
Push the manual button until the OPERATION
indicator flashes rapidly (five times per second),
the unit now is operating in forced COOL
mode. This is used for testing purposes only, .
When the OPERATION indicator goes off, the
air conditioner is OFF.
To restore the remote controller operation, use the
remote controller directly.
1
Open and lift the front panel up to an angle
until it remains fixed with a clicking sound.
2
Push the AUTO button and the air conditioner
will run in AUTO mode.
3
Close the panel firmly to its original position.
NOTE:
The "COOL" mode on the control board is only
provided for testing purposes.
4
ADJUSTING AIR FLOW DIRECTION
Lever
Adjust the air flow direction
even
room temperatures.
to maximize comfort and provide
Adjust the horizontal louver using the remote controller.
Adjust the vertical louver manually.
Adjusting the Vertical Air Flow Direction (up - down)
The air conditioner automatically adjusts the vertical air
flow direction in accordance with the operating mode.
To set the vertical air flow direction
Perform this function while the unit is in operation.
TEMP
CLOCK
C
SPEED
MODE
FAN
SPEED
ON
OFF
TEMP
Keep pressing the AIR DIRECTION button on the remote
controller to move the louver to the desired direction.
Adjust the vertical air flow direction to the desired direction.
In subsequent operations, the vertical air flow is
automatically set in the direction to which you adjusted
the louver by pressing the AIR DIRECTION button.
To set the horizontal air flow direction (left - right)
Adjust the vertical louver manually using the lever on the
left or right side of the vertical louver arm (Depending on
model). Take care not to catch fingers on the fan, horizontal
louver or to damage vertical louvers. When the air
conditioner is in operation and the horizontal louver is in
a specific position, move the lever at left (or right, depending
on model) end of the air outlet to the desired position.
To automatically swing the air flow direction (up - down)
Perform this function while the air conditioner is in operation.
Press the SWING button on the remote controller.
To stop the function, press the SWING button again.
Press AIR DIRECTION button to lock louver in desired
position.
CAUTION
!
The AIR DIRECTION and SWING buttons will be disabled when the air
conditioner is not in operation (including when the TIMER is set).
Do not operate the air conditioner for long periods the air flow
with
ON
direction set downward in cooling or dry mode. Otherwise,
condensation
may occur on the surface of the horizontal
louver causing moisture to drop on to the floor or on furnishings.
Do not move the horizontal louver manually. Always use the AIR
DIRECTION or SWING button. If you move this louver manually, it
may malfunction during operation. If the louver malfunctions, stop
the air conditioner once and restart it.
When the air conditioner is started immediately after it was stopped,
the horizontal louver might not move for approximately 10 seconds.
Open angle of the horizontal louver should not be set too small, as
COOLING or HEATING performance may be impaired due to too
restricted air flow area.
Do not operate unit with horizontal louver in closed position.
When the air conditioner is connected to power (initial power), the
horizontal louver may generate a sound for 10 seconds, this is a
normal operation.
5
HOW THE AIR CONDITIONER WORKS
ECONOMIC (SLEEP) operation
Set
Tempe ratur e
1.8 F
1 hou r
Cooling
ECONOMIC (SLEEP) operation
Set
Tempe ratur e
1 hour
Heating
Cooling
Fan only
Room
temperature
set temperature
DRYING operation
Cooling
1.8 F
1.8 F
1 hou r
1 hour
Fan only
1.8 F
Time
Cooling
AUTOMATIC OPERATION
When you set the air conditioner in AUTO mode, it will
automatically select cooling, heating(cooling/heating
models only), or fan only operation depending on what
temperature you have selected and the room temperature.
The air conditioner will control room temperature
automatically round the temperature point set by you.
If the AUTO mode is uncomfortable, you can select
desired conditions manually.
ECONOMIC(SLEEP) OPERATION
When you push ECONO (SLEEP) button on remote
controller during cooling, heating( ),
or AUTO operation ,
the air conditioner will automatically
increase (cooling) or decrease (heating) per hour.
heat/cool models
1.8 F
The set temperature will be steady 2 hours later. The fan
speed will be automatically controlled. This feature can
maintain the most comfortable temperature and save more
energy for you.
DRYING OPERATION
The dry mode will automatically select the drying
operation based on the difference between the set
temperature and the actual room temperature.
The temperature is regulated while dehumidifying by
repeating turning on and off of the cooling operation or
fan
only. The fan speed indicator will display AUTO and
speed
low will be used.
OPTIMAL OPERATION
To achieve optimal performance, please note the following:
Adjust the air flow direction correctly so that it is not directed on people.
Adjust the temperature to achieve the highest comfort level. Do not adjust the unit
to excessive temperature levels.
Close doors and windows on COOL or HEAT modes, or performance may be reduced.
Use TIMER ON button on the remote controller to select a time you want to start
your air conditioner.
Do not put any object near air inlet or air outlet, as the efficiency of the air conditioner
may be reduced and the air conditioner may stop running.
Clean the air filter periodically, otherwise cooling or heating performance may be reduced.
Do not operate unit with horizontal louvre in closed position.
6
MAINTENANCE
WARNING
Thinner
Household
Drain
Cleaner
No
It is necessary to stop the air conditioner and disconnect the power supply before cleaning.
Cleaning the indoor unit and remote
controller
CAUTIONS
Use a dry cloth to wipe the indoor unit and
remote
controller.
A cloth dampened with cold water may be used
the indoor unit if it is very dirty.
on
The front panel of the indoor unit can be removed
and cleaned with water. Then wipe it with a dry cloth.
Do not use a chemically treated cloth or duster to
clean the unit.
Do not use benzine, thinner, polishing powder, or
similar solvents for cleaning. These may cause
the plastic surface to crack or deform.
Cleaning the air filter
A clogged air filter reduces the cooling efficiency of this
unit. Please clean the filter once every 2 weeks.
1. Lift the indoor unit panel up to an angle until it stops
with a clicking sound.
2. Take hold of the handle of the air filter and lift it up
slightly to take it out from the filter holder, then
pull it downwards.
Filter Handle
3. Remove the AIR FILTER from the indoor unit.
Clean the AIR FILTER once two weeks.
Clean the AIR FILTER with a vacuum cleaner
or water, then dry it up in cool place.
7
MAINTENANCE
Air fr esh ening
filt er
4. Remove the air freshening filter from its support frame
(The installation and removing method of the air
freshening filter is different depending on the models,
see the pictures marked and on the left.
Clean the air freshening filter at least once a month,
and replace it every 4-5 months.
Clean it with vacuum cleaner, then dry it in cool
place.
5. Install the air freshening filter back into position.
6. Insert the upper portion of air filter back into the unit
taking care that the left and right edges line up
correctly and place filter into position.
Air freshening filter
Maintenance
If you plan to idle the unit for a long time, perform the
following:
(1) Operate the fan for about half a day to dry the
inside of the unit.
(2) Stop the air conditioner and disconnect power.
Remove the batteries from the remote controller.
(3) The outdoor unit requires periodic maintenance
and cleaning. Do not attempt to do this yourself.
Contact your dealer or servicer.
Checks before operation
Check that the wiring is not broken off or disconnected.
Check that the air filter is installed.
Check if the air outlet or inlet is blocked after the
air conditioner has not been used for a long time.
CAUTIONS
Do not touch the metal parts of the unit when
removing the filter. Injuries can occur when
handling sharp metal edges.
Do not use water to clean inside the air conditioner.
Exposure to water can destroy the insulation,
leading to possible electric shock.
When cleaning the unit, first make sure that the
power and circuit breaker are turned off.
8
OPERATION TIPS
The following events may occur during normal operation.
1.
Protection of the air conditioner.
Compressor protection
The compressor can't restart for 3 minutes after it stops.
Anti-cold air (Cooling and heating models only)
The unit is designed not to blow cold air on HEAT mode, when the indoor heat exchanger is in
one of the following three situations and the set temperature has not been reached.
A) When heating has just starting.
B) Defrosting.
C) Low temperature heating.
The indoor or outdoor fan stop running when defrosting (Cooling and heating models only).
Defrosting (Cooling and heating models )
Frost may be generated on the outdoor unit during heat cycle when outdoor temperature is low
and humidity is high resulting in lower heating efficiency of the air conditioner.
During this condition air conditioner will stop heating operation and start defrosting automatically.
The time to defrost may vary from 4 to 10 minutes according to the outdoor temperature and
the amount of frost buildup on the outdoor unit.
2.
A white mist coming out from the indoor unit
A white mist may generate due to a large temperature difference between air inlet and air outlet
on COOL mode in an indoor environment that has a high relative humidity.
A white mist may generate due to moisture generated from defrosting process when the air
conditioner restarts in HEAT mode operation after defrosting.
only
3.
Low noise of the air conditioner
You may hear a low hissing sound when the compressor is running or has just stopped running.
This sound is the sound of the refrigerant flowing or coming to a stop.
You can also hear a low "squeak" sound when the compressor is running or has just stopped
running. This is caused by heat expansion and cold contraction of the plastic parts in the unit
when the temperature is changing.
A noise may be heard due to louver restoring to its original position when power is first turned on.
4.
Dust is blown out from the indoor unit.
This is a normal condition when the air conditioner has not been used for a long time or during first
use of the unit.
5.
A peculiar smell comes out from the indoor unit.
This is caused by the indoor unit giving off smells permeated from furniture,
or smoke.
The air conditioner turns to FAN only mode from COOL or HEAT (For cooling and
6.
heating models only) mode.
When indoor temperature reaches the temperature setting on air conditioner, the compressor will
stop automatically, and the air conditioner turns to FAN only mode. The compressor will start again
when the indoor temperature rises on COOL mode or falls on HEAT mode (For cooling and heating
models only) to the set point.
from building material,
9
7. Dripping water may generate on the surface of the indoor unit when cooling in a high
relatively humidity (relative humidity higher than 80%). Adjust the horizontal louver to
the maximum air outlet position and select HIGH fan speed.
Heating mode (For cooling and heating models only)
8.
The air conditioner draws in heat from the outdoor unit and releases it via the indoor unit
during heating operation. When the outdoor temperature falls, heat drawn in by the air
conditioner decreases accordingly. At the same time, heat loading of the air conditioner
increases due to larger difference between indoor and outdoor temperature. If a
comfortable temperature can't be achieved conditioner, we suggest you use a
supplementary heating device.
Auto-restart function
9.
Power failure during operation will stop the unit completely.
For the unit without Auto-restart feature, when the power restores, the OPERATION indicator
on the indoor unit starts flashing. To restart the operation, push the ON/OFF button on the
remote controller. For the unit with Auto-restart feature, when the power restores, the unit
restarts automatically with all the previous settings preserved by the memory function.
10. Lightning or a car wireless telephone operating nearby may cause the unit to malfunction.
Disconnect the unit power and then re-connect again. Push the ON/OFF button on the
remote controller to restart operation.
by the air
10
Troubleshooting tips
Malfunctions and Solutions
Stop the air conditioner immediately if one of the following faults occur. Disconnect the
power and contact the nearest customer service center.
OPERATION indicator or other indicators flash rapidly (5 times every second) and
this flash can't be fixed by disconnecting the power, and then connect it in again.
Trouble
Fuse blows frequently or circuit breaker trips frequently.
Other objects or water penetrate the air conditioner.
The remote controller won't work or works abnormally.
Other abnormal situations.
Malfunctions
Unit does not
start
Unit not cooling
or heating
(Cooling/ heating
models only)
room very well
while air flowing
out from the air
cond tioneri
Cause
Power cut Wait for power to be restored.
Fuse may have blown.
Battery in Remote controller may
have been exhausted.
The time you have set with timer
is incorrect.
Inappropriate temperature
setting.
Air filter is blocked.
Doors or Windows are open.
Air inlet or outlet of indoor or
outdoor unit has been blocked.
Replace the fuse.
Replace the battery.
Wait or cancel timer setting.
Set temperature correctly. For
detailed method please refer to
" "Using remote control section.
Clean the air filter.
Close the doors or windows.
Clear obstructions away first, then
restart the unit.
What should be done?
Compressor 3 minutes
protection has been activated.
If the trouble has not been corrected, please contact a local dealer or the nearest customer
service center. Be sure to inform them of the detailed malfunctions and unit model.
Wait.
Notes: Do not attempt to repair the unit yourself.
Always consult an authorised service provider.
11
Design, material, performance data and components
subject to change without notice.
1900 Wellworth Ave., Jackson, Michigan 49203 Ph. 517-787-2100 Fax 517-787-9341
THE QUALITY LEADER IN CONDITIONING AIR
www.heatcontroller.com
Loading...
