Hearthland Memphis Pro, Memphis Select, Memphis Advantage, Memphis Pro Built - In Installation Instruction

Made in the

USA

www.hearthlandproducts.coM 888.883.2260

Memphis Wood Fire Grills

™

Revolutionizing Outdoor Cooking!

™

Memphis Grills continue to revolutionize outdoor cooking! Memphis Wood Fire Grills are

3-in-1 Outdoor Cooking Centers. They combine the following wood-fired appliances:

• High-Temperature Grill

• Low ’n’ Slow Smoker

• High Performance Convection Oven

No other pellet, gas, charcoal, or propane grill on the market today can accurately claim
to have the full convection capabilities that Memphis offers. Superior craftsmanship,
versatile capabilities, and advanced Intelligent Temperature Control (ITC) truly put
Memphis in a class of its own.

versatilitY

Expand your kitchen to the outside!
Unlike ordinary grills, high-end
3-in-1 Memphis Grills have true
convection capabilities, as well
as grilling and smoking features.
Bake a pie, sear a steak, cook
a wood-fired pizza, or smoke a
brisket. As an additional cooking
source, Memphis Grills make holidays and
other gatherings easier and more enjoyable!

intelligent teMperature control

Eliminate constant tending to the fire or overcooking your
food from direct or indirect heat. Fueled by 100% natural

wood pellets, our one-touch Intelligent Temperature Control

(ITC) automatically maintains your desired temperature

(180 to 650 degrees*) — just like an indoor oven! The precision

and dependability of the ITC

allow for year-round,
all-weather cooking — even
in the most inclement
weather conditions.

* Temperature range varies by model.

wood-fired flavor

Enjoy the delicious wood-fired flavors that restaurants provide, in the
comfort of your own backyard! The ITC and automatic fueling system cook
with 100% natural wood pellets to produce a multitude of savory flavors. From
a mild smoked taste to hints of cherry, hickory, or maple, a variety of wood flavors
are available that will suit any preference. You'll be amazed at the taste difference
compared to traditional gas or charcoal grills.

Wood-Fired Pizza Oven Capabilities

Baking and roasting

Bake bread, pizza, cookies, or even a pie with our
consistent oven temperatures and even heat circulation.
Or roast any type or cut of meat to absolute perfection!

searing

Sear meats first to seal in precious juices and
enhance their flavor. Choose between the
Memphis Pro, which achieves temperatures
of 650 degrees, the Memphis Advantage,
which reaches 600 degrees, and the
Memphis Select, which ranges to 500 degrees.

sMoking

For maximum flavor and tenderness, simply set the ITC
to “smoke mode” and select the desired temperature
(from 180 to 295 degrees) to create succulent ribs,
briskets, and roasts.

heavY-dutY steel, QualitY

environMentallY friendlY

Cooking with 100% natural wood pellets is safer and
more environmentally conscientious than using more
traditional products. Unlike such fossil fuels as natural gas

and propane that contribute to climate change, our

pellets are always made from renewable resources.

true convection
cooking

Prepare flavorful and juicy foods without

constantly tending the grill. And because all

Memphis Wood-Fired Grills are true convection
ovens, no rotisserie is needed. Grill chamber design,
advanced engineering, and convection fans circulate heat
evenly and provide the consistent temperatures required
for convection oven performance. Other brands may claim
to have convection oven capabilities, but Memphis Grills
can accurately backup that claim with engineering facts.

construction, and Made in the usa!

Our superior craftsmanship and strict adherence to manufacturing standards guarantee products with unbeatable
reliability and durability in any climate or weather condition. All Memphis Wood Fire Grills are designed, engineered
and manufactured in the USA and are backed by a 5-year limited warranty.

Memphis Pro

™

Memphis Advantage

™

Memphis Select

™

Memphis PRO ™ Built-In

Intelligent Temperature Control (ITC) with

Auto Start. Simply press ON, set the desired

temperature from 180 to 650 degrees, relax, and

leave the work to your Memphis Pro. ITC comes

standard and makes Memphis the intelligent choice.

MeMphis pro specifications (Standard Configuration)

™

Memphis Pro

Made in the

5-Year Limited Warranty

USA

Product

Code

VG0001S 304 Stainless Steel 562 sq. in. 834 sq. in. 3,905 cub. in. 216 lb. H47" x W57" x D29" 180–650º F

VG0001 Charcoal Metallic Painted 562 sq. in. 834 sq. in. 3,905 cub. in. 216 lb. H47" x W57" x D29" 180–650º F

Description

Cooking

Surface

Cooking Surface

with Optional Grates

Cubic Inch

Cooking Area

Unit

Weight

Dimensions

Temperature

Range

feature specifications

Material   

Heavy-Duty Double Wall and
Sealed Construction

Temperature Controls

One-Touch Digital Intelligent
Temperature Control (Standard)

Grill Grate

.312" Diameter 304 Stainless
Steel Rods

Fuel System

Automatic Dual Auger Self-Feeding
Pellet Fuel System

Convection Fan System

Dual Fan Combustion/
Convection System

Hopper Capacity

16 lb. Wood Pellet Dual Bin Hopper

Grill Construction

Sealed and Insulated Dual Walls
Throughout Entire Cooking Area

Wheels

4 Heavy-Duty Locking Casters

options

VG4000 Small Cooking Grate (2 per kit)

VG4001 Large Cooking Grate (2 per kit)

VGCOVER-1 Memphis Pro Grill Cover

Dual Fan Convection System
provides convection cooking
and even heat circulation for
tender and juicy results.

Sealed and insulated double wall
construction provides superior
heat retention and consistent
temperatures in all weather
conditions.

16 lb. high-capacity wood
pellet hopper with two 8
lb. dual fuel bins. Satisfy
any culinary preference by
automatically mixing a
variety of flavors.

Memphis Advantage

Intelligent Temperature Control (ITC) with Auto

Start. Simply press ON, set the desired temperature

from 200 to 600 degrees, relax, and leave the work

to your Memphis Advantage. ITC comes standard

and makes Memphis the intelligent choice.

5-Year Limited Warranty

MeMphis advantage specifications (Standard Configuration)

™

Made in the

USA

Product

Code

VG0050

Material

feature specifications

Heavy-Duty Double
Wall Construction

Temperature Controls

One-Touch Digital Intelligent
Temperature Control (Standard)

Description

Charcoal Metallic Painted
with Side Shelves

Cooking

Surface

427 sq. in. 970 sq. in. 4,510 cub. in. 195 lb. H47" x W44.5" x D29" 200–600º F

Grill Grate

.312" Diameter 304 Stainless
Steel Rods

Fuel System

Automatic Single Auger Self-Feeding
Pellet Fuel System

options

VG4000 Small Cooking Grate (2 per kit)

VG4001 Large Cooking Grate (2 per kit)

VGCOVER-3 Memphis Grill Cover with Side Shelves

Cooking Surface

with Optional Grates

Cubic Inch

Cooking Area

Convection Fan System 

Single Fan Combustion/
Convection System

Hopper Capacity

12 lb. Wood Pellet Hopper

Unit

Weight

Dimensions

Grill Construction

Double Wall Grill Body, with Sealed
Dual Wall Hood

Wheels

4 Heavy-Duty Locking Casters

Temperature

Range

Single Fan System for
even heat distribution
throughout the cooking area.
The Memphis Advantage’s
convection cooking produces
flavorful and succulent results,
with no rotisserie.

Dual walls enable year-round
grilling. Enjoy delicious wood­fired flavors in all seasons — even
if it’s snowing.

Large 12 lb. hopper capacity
accommodates hours of
overnight smoking.

™

Memphis Select

Intelligent Temperature Control (ITC) with

Auto Start. Simply press ON, set the desired

temperature from 200 to 500 degrees, relax, and

leave the work to your Memphis Select. ITC comes

standard and makes Memphis the intelligent choice.

Made in the

5-Year Limited Warranty

* Memphis Select shown with optional side shelves.

USA

MeMphis select specifications (Standard Configuration)

Product

Code

VG0070 Charcoal Metallic Painted 427 sq. in. 699 sq. in. 3,750 cub. in. 132 lb. H46" x W26" x D31" 200–500º F

Description

Cooking
Surface

Cooking Surface

with Optional Grates

Cubic Inch

Cooking Area

Unit

Weight

Dimensions

Temperature

Range

feature specifications

Material

Heavy-Duty Steel Construction

Temperature Controls 

One-Touch Digital Intelligent
Temperature Control (Standard)

Grill Grate 

Porcelain-Coated Cooking Grates

Fuel System 

Automatic Single Auger Self-Feeding
Pellet Fuel System

Convection Fan System 

Single Fan Combustion/
Convection System

Hopper Capacity 

Up to 12 lb. of Wood Pellets

Grill Construction 

Single Wall Construction

Wheels

Convenient Caster System

options

VG0740 Memphis-Select L/R Side Shelf Kit

(Total Dimensions

VG4000 Small Cooking Grate (2 per kit)

VGCOVER-2 Memphis Grill Cover without Side Shelves

VGCOVER-3 Memphis Grill Cover with Side Shelves

H46" x W26" x D31" )

Single Fan System for even
heat distribution throughout
the cooking area. The
Memphis Select's convection
cooking produces flavorful
and succulent results, with
no rotisserie.

Single wall, heavy-duty
construction for durable
long-term grilling.

Large 12 lb. hopper capacity
accommodates hours of
overnight smoking.

Memphis PRO ™ Built-In

Intelligent Temperature Control (ITC) with Auto

Start. Simply press ON, set the desired temperature

from 180 to 650 degrees, relax, and leave the work

to your Memphis Built-In. ITC comes standard

and makes Memphis the intelligent choice.

5-Year Limited Warranty

MeMphis pro Built-in specifications (Standard Configuration)

Made in the

USA

Product

Code

VGB0001S 304 Stainless Steel 562 sq. in. 834 sq. in. 3,905 cub. in. 216 lb. H27" x W28" x D29" 180–650º F

VGB0001 Charcoal Metallic Painted 562 sq. in. 834 sq. in. 3,905 cub. in. 216 lb. H27" x W28" x D29" 180–650º F

Description

Cooking

Surface

Cooking Surface

with Optional Grates

Cubic Inch

Cooking Area

Unit

Weight

Dimensions

Temperature

Range

feature specifications

Material   

Heavy-Duty Double Wall and
Sealed Construction

Temperature Controls

One-Touch Digital Intelligent
Temperature Control (Standard)

The Memphis Pro Built-In has the same
performance features as the Memphis Pro.
Please refer to the Memphis Pro page
for more details.

Grill Grate

.312" Diameter 304 Stainless
Steel Rods

Fuel System

Automatic Dual Auger Self-Feeding
Pellet Fuel System

ITC Control Location

Requires 110 /120 V AC

Convection Fan System

Dual Fan Combustion/
Convection System

Hopper Capacity

16 lb. Wood Pellet Dual Bin Hopper

Control Cable Way

Grill Construction

Sealed and Insulated Dual Walls
Throughout Entire Cooking Area

A=30" B=15.4" C=23" D=8" E=5" F= 3–12" G=6" Minimum Clearance F=18" Minimum Clearance

Memphis Wood Fire Grills

At a Glance

™

Product

Code

Description ITC

Convection

Fan System

Grill

Construction

Cooking
Surface

Cooking

Surface with

Optional

Grates

Cubic Inch

Cooking

MeMphis pro specifications (Standard Configuration)

VG0001S

VG0001

Stainless

Steel

Charcoal

Metallic

Yes 2

Yes 2

Heavy-Duty Double Wall
and Sealed Construction

Heavy-Duty Double Wall
and Sealed Construction

562 sq. in. 834 sq. in. 3,905 cub. in. 16 lb. 216 lb.

562 sq. in. 834 sq. in. 3,905 cub. in. 16 lb. 216 lb.

MeMphis advantage specifications (Standard Configuration)

VG0050

Charcoal

Metallic w/

Side Shelves

Yes 1

Heavy-Duty Double

Wall Construction

427 sq. in. 970 sq. in. 4,510 cub. in. 12 lb. 195 lb.

MeMphis select specifications (Standard Configuration)

VG0070

Charcoal

Metallic

Painted

Yes 1

Heavy-Duty

Steel Construction

427 sq. in. 699 sq. in. 3,750 cub. in. 12 lb. 132 lb.

MeMphis pro Built-in specifications (Standard Configuration)

VGB0001S

VGB0001

Stainless

Steel

Charcoal

Metallic

Painted

Yes 2

Yes 2

all Models designed, engineered, and Manufactured in the usa

Heavy-Duty Double Wall
and Sealed Construction

Heavy-Duty Double Wall
and Sealed Construction

562 sq. in. 834 sq. in. 3,905 cub. in. 16 lb. 185 lb.

562 sq. in. 834 sq. in. 3,905 cub. in. 16 lb. 185 lb.

Made in the

USA

Area

Hopper

Unit

Weight

All grills require 110/120V power with ground.

Dimensions

H47

" x W57" x D29"

H47

" x W57" x D29"

H47

" x W44.5" x D29"

H46

" x W26" x D31"

H27

" x W28" x D29"

H27

" x W28" x D29"

Temp

Range

180–650º F

180–650º F

200–600º F

200–500º F

180–650º F

180–650º F

Available From:

enhance flavors and Your grill

perforMance with natures waY BBQ pellets

• 100% Renewable Hard Wood Pellets

• Available in Your Choice of 7 Delicious Flavors
(All Purpose, Adler, Apple, Cherry, Hickory, Maple, Mesquite)

• Safe, Portable, and Easy-to-Use 20 lb. Bags

hearthland products, llc 9111 grand avenue south BlooMington, Mn 55420

888.883.2260 www.hearthlandproducts.coM

Product specifications are subject to change. MVG0009_C
