Soho
Balanced Flue Gas Fireplace
A
A
D
B
A.
Optional black onyx pebbles
B.
Optional multi-colored pebbles
C
C. Black onyx pebbles and reflective panels
D. Multi-colored pebbles and reflective panels
Top photo: Soho shown with optional Studio black mesh front
and standard log set
Cover photo: Soho shown with optional Studio brushed
stainless steel glass front and black onyx pebbles
Redefine the way you think about fireplaces—where they should be located and how they should
look. The small, square shape and shallow depth of Soho allows for creative installations as big as your
imagination. The clean design merges simplicity and elegance.
Define your fire with a black, brushed stainless steel or glass facade
•
Traditional logs, modern black onyx or multi-colored pebbles allow you to create the combination
•
of art and fire to accent your décor
Traditional black mesh front
with standard logs
Studio brushed stainless steel mesh
front with optional black onyx pebbles
Studio black mesh front with
standard logs
Studio brushed stainless steel
glass front with standard logs
Studio black mesh front with
horizontal stainless overlay and
optional multi-colored pebbles
Detail of Studio brushed stainless
steel glass front
Soho
The fusion of technology, innovation and design
Deluxe Control
REM-DLX-CE
Controls the temperature of your room by turning the fireplace
on and off when it reaches a set temperature.
Manual or thermostat mode
•
Program desired temperature
•
Digital display
•
Celsius or Fahrenheit readings
•
Timer
•
Time display
•
Child safety lock
•
Includes wall bracket
•
Soho Specifications
740
643
945
742
105
56
115
832
292
586
292
279
142
Ø168
940
96
57
GAS LINE
ACCESS
ELECTRICAL
ACCESS
1118
292
752
219
76
www.heatnglo.com/products/global/index.asp
MODEL HEIGHT FRONT WIDTH BACK WIDTH DEPTH VIEWING AREA mJh INPUT kWh OUTPUT
SOHO-N-CE
SOHO-P-CE
SOHO-B-CE
Actual Framing Actual Framing Actual Framing Actual Framing
945 1118 740 752 586 752 292 292
490 x 450
NG
LPG
BG
14.4
12.6
12.6
NG
LPG
BG
2.9
2.7
2.7
Top View
Front ViewLeft Side View
Dimensions above are in millimeters and for reference only. We recommend measuring individual units at installation. Assumes the use of 13mm gyprock.
Refer to installation manual for detailed specifications on installing this product. Heat & Glo reserves the right to update units periodically. The flame and ember appearance may vary
based on the type of fuel burned and the venting configuration used. Photos in this brochure may vary in color and dimension [size] from the actual product.
Right Side View
Framing
Soho Features
IntelliFire ignition system provides fuel savings and easy operation
•
Top venting allows installation flexibility
•
•
Zero clearance provides ease of installation and cost savings
Heat management system allows you to adjust the flame height
•
and heat output up to 40%
•
Realistic ceramic fiber campfire style logs (or optional pebbles)
Balanced flue technology provides a sealed combustion chamber,
•
maintaining indoor air quality
Energy saving efficiency up to 77% with the authenticity of a
•
traditional fire
Multifunction remote offers true convenience, providing
•
temperature, flame height and start time control
Ceramic glass
•
•
170mm top venting
CE approved
•
IntelliFire Ignition System
Our state-of-the-art ignition system eliminates a continuously
burning pilot light and does not require electricity, reducing gas
consumption and lowering operating costs. Never again will you
manually light a pilot or bend down to start your fireplace.
For complete information and valuable assistance on this model,
please contact us at:
Convenient Operation
Operate the fireplace, adjust the flame height and view the current
room temperature all from the comfort of your chair. Whether you
wish to have the fire greet you in the morning for that first cup of
coffee or warm the room prior to your arrival home at night, simply
program the start time and temperature — the Deluxe remote will do
the rest. To protect the little ones, each remote is equipped with a child
safety start and a wall bracket should you wish to locate the remote out
of reach.
Balanced Flue Gas Fireplace
A completely sealed system, Heat & Glo balanced flue gas fireplaces
draw 100% of combustion air from the outdoors and exhaust all
combustion by-products back outside, with no affect on indoor air
quality. In addition, cold air drafts are eliminated and heat output
is maximized. No electricity, power venting or fan are required to
operate, eliminating the need for a conventional chimney and allowing
for installation in nearly any room of the home.
Top Vent
EXHAUST
GAS
OUTSIDE
AIR FOR
CONVECTIVE
HEAT
RADIANT
HEAT
CONVECTION
AIR INTAKE
COMBUSTION
OUTSIDE
WALL
HNG-0093I-0207
