Operating Instructions
4 X1 HDMI Swit
ch with r
emote,
Su
p
port 3D,
4KX2K, P
IP
Operati
ng Instruction
4 by 1 HDMI Switcher with Auto Switching
Manual Version:Release 0414
Page 2
Operating Instructions
1
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.
I
n
troduction
The HDMI 4 by 1 Switcher with Auto Switching has a high speed digital performance connection
between four sources and a video display without signal degradation. It allows up to four Ultra High
Denition 4K x 2K or Full HD 1080p sources to be routed to one Ultra HD display. This product supports
resolutions up to 4K x 2K (3840 x 2160@30Hz). Deep Color, 3DTV pass-through, PIP(picture in picture),
and lossless audio formats such as LPCM 7.1, Dolby® TrueHD, and DTS-HD® Master Audio™ are also
supported. Each Ultra Hi-Def source can be switched to the display using the front panel push-button
controls, the included IR remote.
F
ea
tur
e
s
Switch four Ultra Hi-Def sources to one Ultra HD display
Supports resolutions up to Ultra HD 4K x 2K (3840 x 2160 @ 30Hz) and 1080p @ 120 Hz, and 1080P
3D @ 60 Hz Full HD
Incorporates instaPrevue technology, supports PIP(picture in picture)
Supports Deep color up to 36-bit color at 1080p 60Hz
Automatically switch to the most recently connected source.
Supports LPCM 7.1, Dolby
®
TrueHD, Dolby Digital
®
Plus, and DTS-HD
®
Master Audio™
Support HDMI input/output cable 10 to 15 meters at 1080p/8-bit resolution
CEC pass-through
Page 3
Operating Instructions
2
Specif
icatio
ns
P
a
ckag
e Contents
HDMI 4 by 1 switcher
5V DC power supply adaptor
Remote control
User Manual
Operating Temperature Range
-5 to +35 (+23 to +95 )℃ ℃
Operating Humidity Range 5 to 90%RH (No Condensation)
Bandwidth frequency
10.2Gbps
Input ports 4x HDMI (female)
Output port 1x HDMI (female)
Resolution outputs
up to 4K x 2K (3840 x 2160 @ 30Hz)
Dimensions (LxWxH) 113.5x61.5x25mm
Power consumption 3W(MAX)
Transmission Distance
15m(Maximum)over standard HDMI cable/26AWG
Net Weight 210g
Page 4
Operating Instructions
3
P
anel De
s
c
r
i
p
tion
F
r
ont
P
a
nel
①HDMI output port
②HDMI input ports
③Power input
④Indicator of power input
⑤Input Select Button
⑥IR receiver windows
⑦Indicator of HDMI output
⑧Indicator of HDMI inputs
Page 5
Operating Instructions
4
R
e
m
o
te De
s
c
rip
t
i
o
n
Button “5” for PIP fuction (picture in picture)①
N
o
t
e:
Press button "5" you can see picture in picture on TV.
3) Power up all units, the switch, sources and displays.
Please refer to Connection Diagram 2.
C
o
n
n
ect
i
ng and
o
p
e
r
a
t
ing
1) Connect the HDMI input sources into HDMI switch
2) Connect the HDMI switch with the display.
Connection Diagram 1 (Support 4Kx2K)
PC
HDMI Out
STB XBOX Blu-ray
HDMI In
CEC pass through
4K TV
Page 6
Operating Instructions
5
Connection Diagram 2 (Support PIP)
1). Press button "5" ,you can see picture in picture on TV. Press button and to select
source, after you select one picture, you have to press button “5” again to show display.
2).PIP function only can support 1080p.
CEC pass through
4K TV
TV 1
TV 2
TV 3
TV 4
PIP(picture in picture)
Button for source selection
Button for PIP function
PC
HDMI Out
STB XBOX Blu-ray
HDMI In
Page 7
Operating Instructions
6
S
a
f
et
y
i
nfo
r
m
a
tio
n
safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture
PR
ODUCT S
E
RVI
C
E
1) D
a
ma
g
e requir
i
n
g se
rv
ic
e
:
The unit should be serviced by qualied service personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in performance;
(e)The unit has been dropped or the cabinet damaged.
2) S
ervicing Personnel: Do not attempt to service the unit beyond that described in these operating
instructions. Refer all other servicing to authorized servicing personnel.
3) R
eplacem
e
nt p
art
s: When parts need replacing ensure the servicer uses parts specied by the
manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes may
result in re, electric shock, or other hazards.
4) S
a
fety check:
After repairs or service, ask the servicer to perform safety checks to conrm that the unit is
in proper working condition.
WARR
A
N
T
Y
If your product does not work properly because of a defect in materials or workmanship, our Company
(referred to as "the warrantor" ) will , for the length of the period indicated as below, (
Parts(2)Year ,Labor(90)
D
a
ys)
which starts with the date of original purchase ("Limited Warranty period"), at its option either(a) repair
your product with new or refurbished parts, or (b) replace it with a new of a refurbished product. The decision
to repair or replace will be made by the warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must mail-in your product during the
warranty period. This Limited Warranty is extended only to the original purchaser and only covers product
purchased as new. A purchase receipt or other proof of original purchase date is required for Limited Warranty
service.
M
ail-In Service
When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in the original
carton. Include a letter detailing the complaint and provide a day time phone and/or email address where you
can be reached.
Page 8
Operating Instructions
7
LIMITED WARRANTY LIMITS AND EXCLUSIONS
1) This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT
COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages
which occurred in shipment, or failures which are caused by products not supplied by warrantor,or failures
which result from accidents,misuse,abuse,neglect, mishandling, misapplication, alteration, faulty installation,
set-up adjustments, misadjustment of consumer controls, improper maintenance, power line surge, lightning
damage, modication, or service by anyone other than a Factory Service center or other Authorized Servicer, or
damage that is attributable to acts of God.
2) THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY COVERAGE".THE
WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRNTY. (As examples, this excludes damages
for lost time, cost of having someone remove or re-install an installed unit if applicable, travel
to and from the
service, loss of or damage to media or images, data or other recorded content. The items listed are not
exclusive, but are for illustration only.)
3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY.
