HDMI/USB KVM Extender
Over Cat5e/6
VER:1.1
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this
manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge
protection systems is highly recommended in order to
life of your equipment.
protect and extend the
Table of Contents
1. Introduction
2. Features
3. Package Contents
...................................................................................................
..........................................................................................................
......................................................................................
1
2
3
3
4. Specifications
5. Operation Controls and Functions
5.1 Transmitter Panel
5.2 Receiver Panel
6. Connection Diagram
...............................................................................................
.........................................................
.......................................................................................
............................................................................
.................................................................................
...............
1. Introduction
The HDMI/USB KVM Extender can extend high definition HDMI and USB
signals up to 164ft/50m over a single Cat5e/6 cable with zero latency. It
supports HDMI 1.4b and USB 2.0 standards. Two-way POC (Power over
Cable) function allows either TX or RX be powered by a single 12V@1A power
supply. It’s an ideal product for cyber bar and KVM extender markets.
2
4
6
6
7
9
2. Features
HDMI 1.4b, HDCP 1.4 and DVI compliant
Video resolutions up to 1080p@60Hz
HDMI audio pass through
Zero latency and uncompressed transmission technology
USB 2.0 Full-speed transmission and routing
12V POC (Power over Cable) function supported
3. Package Contents
1 x Transmitter
1 x Receiver
1 x User Manual
1 x DC 12V/1A Power Adapter
3
4. Specifications
Technical
HDMI Compliance HDMI 1.4b
HDCP Compliance HDCP 1.4
USB Compliance USB 2.0
Video Resolutions
Transmission Range: HD [1080p@60Hz 24-bit color] up to 50m [164ft]
Color Depth 8-bit
HDMI Audio F ormats LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+
ESD Protection
Connections
Transmitter
Input
Output
720x576p50,720x480p60,640x480p60/75,800x600p6 0/75,
1024x768p60/75,1280x1024p60,1680x1050p60,1280x72 0p25/30/
50/60,1920x1080p25/30/5 0/60
Human body model — ±8kV (air-gap disc
discharge)
1x HDMI Type A [19-pin female]
1x USB-B [USB B type]
1x HDMI Type A [19-pin female]
1x CAT [RJ45]
harge) & ± 4kV (contact
4
Receiver
Input 1x CAT [RJ45]
Output
1x HDMI Type A [19-pin female]
2x USB-A [USB A type]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 109mm [W]x76.5mm [D]x25.4mm [H]
Weight TX:213g RX:212g
Power Supply
Power Consumption TX:1.92W (Max) RX:1.68W (Max)
Operation
Temperature
Storage temperature -4 - 140°F / - 20 - 60°C
Relative Humidity 20 - 90% RH (no condens ation)
Input: AC100 - 240V 50/60Hz
Output: DC 12 V/1A (US/EU standards, CE/FCC/UL certified)
32 - 104°F / 0 - 40°C
5
5. Operation Controls and Functions
5.1 Transmitter Panel
HDMIPOWER USB
1
3
2
5
4
6 7 8
POWER: System power indicator.
2
H
DMI: Input HDMI signal indicator LED. On means there is an active
signal.
3
SB: USB status indicator LED, no USB signal being transmitted will show
U
slow flashing, when USB signal being transmitted will show quick flashing.
6
DC 12V: Connect to a 12V DC power supply. No needs to connect another
4
power supply if receiver is powered by an external 12V DC power supply.
POC function allows you to power on Tx or Rx on any side )
DMI IN: Connect to HDMI source device such as Blue-ray player or
H
5
Set-Top box with an HDMI cable.
DMI OUT: Connect to HDMI display device for local display.
H
6
C
AT5e/6 (POC): Connect to receiver box CAT port through a CAT5e/6
7
cable length up to 164ft/50m.
SB IN: Connect to PC USB host port.
U
8
5.2 Receiver Panel
HDMIPOWER USB
1
3 4
2
DC 12V H DMI OUT CAT 5e/6 (P OC)
5
7
6 7 8
POWER: System power indicator.
2
DMI: HDMI output connection indicator LED. On means there is an
H
active HDMI display device be connected.
3
SB: USB status indicator LED, no USB signal being transmitted will
U
show slow flashing, when USB signal being transmitted shows quick
flashing.
C 12V: Connect to a 12V DC power supply. No needs to connect
D
4
another power supply if your transmitter box is powered by an external
12V DC power supply. (POC function allows you to power on Tx or Rx
on any side )
5
H
DMI OUT: Connect to HDMI display device.
AT5e/6 (POC): Connect to transmitter box CAT port through a
C
6
CAT5e/6 cable length up to 164ft/50m.
U
SB Keyboard: Connect to USB keyboard or a USB slave device;
7
SB Mouse: Connect to USB mouse or a USB slave device;
U
8
8
6. Connection Diagram
PC
9
DC 12V HDMI OUT CAT5e/6 (PO C)
