1×4 HDMI Splitter
User Manual
Page 2
Dear customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this manual for
future reference.
Ⅰ. INTRODUCTION
1×4 HDMI splitter distributes 1 HDMI source to 4 HDMI displays simultaneously. It offers HD video
solution for super market; shopping Mall; HDTV, STB, DVD and projector factory; data control center;
information distribution; conference room presentation; education and training, corporation show room,
luxurious house, etc.
Page 3
SPECIFICATIONS:Ⅱ
Input Video Signal 0.5 -1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Max Single Link Range 1920X1200, 1080P
HDMI Resolutions 480i/576i/480p/576p/720p/1080i/1080P
DVI Resolutions 480p/576i/576p/720p/1080i/1080p
HDMI Version HDMI 1.3
Bandwidth Up to 225MHz
EDID Duration 6 seconds
Power supply DC 5V@2A
Page 4
Ⅲ. CONNECTION AND OPERATION:
ⅰ). Connect the HDMI input source and output devices into the HDMI Splitter.
*please refer to the Connection Image.
ⅱ). Connect the DC 5V power supply into the splitter. Please make sure no other voltage power supply
should be connected. Power supply with higher voltage may damage the splitter.
ⅲ). Turn on the power switch.
ⅳ). When all input and outputs are connected and turned on, the corresponding LED will light.
Attention: Insert and Extract cable gently.
. FAQ:Ⅴ
ⅰ). The splitter doesn’t appear to be functioning.
Firstly, check if the LED lights, the power supply is connected and the power switch is turned on.
Secondly, make sure all cables are well connected, and are in good condition. Thirdly, make sure the
Page 5
length of the cables is within the MAX supported length of this splitter. Lastly, please try to connect the
input device to the display directly to see if it display normally.
ⅱ). If the maximum resolution the four displays supported is not the same, what resolution will be
displayed?
After an EDID process, the splitter will choose the lowest one and output to all displays
Ⅵ. BOX CONTENTS:
Item Qty Remark
1×4 HDMI splitter 1pcs
Power supply 1pcs DC 5V@2A
User Manual 1pcs English
