Hawking Technology HNC210 User Manual
1
Step 1: Check Contents & Installati on Re quirements 3
Step 2: Physical Description 5
Step 3: Hardware Installation 7
Step 4: Run the Quick Setup Wizard 9
Step 5: Viewing & Tips 24
2
Congratulations on the purchase of your new Hawking Net-
TM
Vision
HNC210 Wired 10/100Mbps Network Camera. The
HNC210 is a high performance standalone camera system that
provides an ideal solution for remote mon itoring, surveillan ce, or
sending live video over the Internet. The camera offers a broad
array of applications and can be used to monitor various critical
locations such as homes, offices, and other industrial and public
areas. Please read this quick installation guide carefully before
beginning your installation.
General Installation:
3
4
g
y
y
Front Panel
Lens & Manual
Focus Rin
LED:
Link/Activit
LED:
Read
LEDs
- Link/Activity: Green when monitoring; flashing for video
transmission/reception
- Ready: Orange when device is powered on & ready for
access
5
p
Bottom Panel
Reset
Button
Power
In
ut
LAN
Port
6
1 Locate the network
cable connector (RJ-45
port) on the camera’s
bottom panel. Connect an
Ethernet cable to the port.
Connect the other end of
the cable to the network.
1
7
2 Locate the power input
connector on the camera’s
bottom panel, and attach
the external power
supply. Then, plug the
adapter into an available
outlet. Please check to see
that the orange “Ready”
LED located next to the
lens of the camera is lit to
ensure that the camera is
powered on. (To ensure
that there is a network
connection, please check
to see that the green
“Link/Activity” LED is lit
or flashing.)
2
