Hawking Technology guarantees that every
H-CF30W CF 802.11b WLAN Card is free from
physical defects in material and workmanship
under normal use for two (2) years from the date of
purchase. If the product proves defective during
this two-year warranty period, call Hawking
Customer Service in order to obtain a Return
Authorization number. Warranty is for repair or
replacement only. Hawking Technology does not
issue any refunds. BE SURE TO HAVE YOUR
PROOF OF PURCHASE. RETURN
REQUESTS CAN NOT BE PROCESSED
WITHOUT PROOF OF PURCHASE. When
returning a product, mark the Return Authorization
number clearly on the outside of the package and
include your original proof of purchase.
IN NO EVENT SHALL HAWKING
TECHNOLOGY’S LIABILTY EXCEED THE
PRICE PAID FOR THE PRODUCT FROM
DIRECT, INDIRECT, SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THE
PRODUCT, ITS ACCOMPANYING
SOFTWARE OR ITS DOCUMENTATION.
Hawking Technology makes no warranty or
representation, expressed, implied or statutory,
with respect to its products or the contents or use
of this documentation and all accompanying
software, and specifically disclaims its quality,
performance, merchantability, or fitness for any
particular purpose. Hawking Technology
reserves the right to revise or updates its products,
software, or documentation without obligation to
notify any individual or entity. Please direct all
inquiries to:
techsupport@hawkingtech.com
REGULATORY STATEMENTS
FCC Certification
The United States Federal Communication Commission (FCC)
and the Canadian Department of Communications have
established certain rules governing the use of electronic
equipment.
Part15, Class B
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions:
1) This device may not cause harmful interface, and
2) This device must accept any interface received, including
interface that may cause undesired operation. This
equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
◗ Reorient or relocate the receiving antenna.
◗ Increase the distance between the equipment and receiver.
◗ Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
CAUTION:
1) To comply with FCC RF exposure compliance
requirements, a separation distance of at least 20 cm must
be maintained between the antenna of this device and all
persons.
2) This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Connect your PDA to your PC. Make sure you
have the Microsoft ActiveSync Utility installed
on your PC to make an active connection.
Caution: DO NOT insert the Wireless
CompactFlash Card into the PDA BEFORE
installing the configuration utility.
1. Insert the device driver CD into the CD-ROM
drive.
2. Open the WINCE3.0 folder.
3. Inside the WINCE3.0 folder, click on
PrismForPocketCE.
For Handheld PC users: Please select
PrismForHandHeldCE.
-
2 -
4. Click Next to continue.
5. Click OK.
6. Click Finish.
-
3 -
7. You can now insert the Wireless
CompactFlash Card into your PDA. Then
use the Settings on your Windows CE to
configure the network settings.
-
4 -
For PDAs
Insert the Wireless CF card into your Windows
CE-based PDA by aligning the Wireless CF card
toward the CF slot.
For Notebook PCs
1. Plug the Wireless CF card into the PCMCIA
Adapter. The Wireless CF card is then turned
into a conventional PCMCIA type II PC
Card.
2. Align the PC Card toward the PC Card slot
with the Hawking label facing upward, as
shown below.
-
5 -
Install your Wireless CF card into the PCMCIA
converter and place the install CD-ROM into
your notebook’s CD-ROM drive. Then place
the CF card with converter into your notebook’s
PCMCIA slot and Windows will ask you for the
location of the software driver. Please make
sure to have windows search your CD-Rom drive
to install the wireless navigator software. Once
software installation is complete, you will see a
wireless icon on your taskbar. If the navigator
detects a signal, it will display a green
“connected” icon on your taskbar. Please
configure your network adapter to accept the
wireless signal.
Please See Manual for complete Hardware and
Software Installation procedures.
-
6 -
Once the driver has been installed, you must
make some changes to your network settings.
1. Go to Start Æ Settings Æ Connections.
Click on Network Adapters.
Highlight PRISM 11Mbps Wireless LAN
2.
Adapter, click Properties.
-
7 -
3. ~ Use server-assigned IP address
If your network supports DHCP, select Use server-assigned IP address. The IP address
and other information will be automatically
assigned. Then click ok.
-
8 -
~Use server-assigned IP address
If your network does not support DHCP,
select Use specific IP address. You may
need to enter the IP address and other
information. When you have finished
entering settings, click OK.
If you forget to click OK, your settings will not
take effect!
4. A message as below may appear saying you
must remove and re-insert the Wireless
CompactFlash Card to have the changes take
affect. Click OK.
-
9 -
After installing the H-CF30W Wireless
CompactFlash Card’s driver successfully, go to
Start Æ Programs. Click on PRISM Settings,
the Network Status icon will appear in the task
bar.
-
10 -
Network Status Icon & Icon Menu
The Status Icon
Icon Link Status
Green indicates a strong link.
Yellow indicates a weak link.
Red indicates no or a very poor link.
Icon Menu
After clicking on the icon, the icon menu as
displayed below will prompt you to configure the
H-CF30W Wireless CompactFlash Card.
-
11 -
Items
Wireless Radio On
Wireless Radio Off
Remove Status Icon…
Wireless Network
Status
Advanced
Configuration…
WEP Encryption…
Version
Information…
Description
These two items allow you
to enable or disable the
wireless radio.
Removes the Utility icon
from the PDA’s system
tray. Each time you power
on your PDA, the icon will
reappear.
Clicking these items will
launch the Wireless
Settings window, as
described below.
All settings are categorized into 5 tabs:
Link
Configuration
Encryption
Site Survey
About
Link
The Link tab displays the status of the
H-CF30W.
-
12 -
Item Description
State It displays the connection state of
Current
Channel
Enable Radio
/ Disable Radio
Rescan
Current Tx
Rate
Throughput
the Wireless CompactFlash Card
with the wireless network.
It displays the selected channel
that is currently used. (There are
14 channels available, depends on
the country.)
Click this button to enable/disable
the wireless radio. The Wireless
CompactFlash Card will
connect/disconnect with the
wireless network.
Search for all available networks.
Clicking on the button, the device
will start to rescan.
It displays the current transfer
rate.
It displays the transferring (Tx)
and receiving (Rx) data rate in
bytes per second.
-
13 -
Item Description
Link Quality
Signal Strength
It displays the link quality of the
connection between the Wireless
CompactFlash Card and the
Access Point or Peer-to-Peer type
it connects.
It displays the signal strength of
the connection between the
Wireless CompactFlash Card and
the Access Point or Peer-to-Peer
type it connects.
Configuration
The Configuration tab allows you to set
parameters for the Wireless CompactFlash Card.
-
14 -
Item Description
Profile
Name
Network
Name
Network
Type
Peer-to-Peer
Channel
Transmit
Rate
Default Clicks the button to restore to the
Undo Click Undo to ignore the previous
Apply Click Apply to activate the settings.
ok Click OK to save your changes.
Saves values for all previous setting
parameters. The default values
contain the parameters configured at
installation.
Once the demands for switching
between different networking
environments are met, you can set the
additional profiles to reduce the
configuration time. To save the
current parameters, highlight the
Profile field, type a new name, and
click on the Apply button.
A specific name shared among
connected Wireless CompactFlash
Card, Access Points and other
wireless stations on the wireless
network. The name must be
identical for all devices and points
attempting to connect to the same
network. The default name is ANY.
To change the Network Name, simply
enter a new name in the field.
It displays the type of BSS.
Access Point: allows the Adapter to
communicate with a wired network
which employing an Access Point.
Peer-to-Peer: allows PC-to-PC,
station-to-station communication
without employing an Access Point.
To communicate with other Wireless
CompactFlash Card, you must specify
the same channel. Click the up and
down arrow at the right of the
Peer-to-Peer Channel to set the
desired channel.
It displays the current transmit rate.
1Mb, 2Mb, Auto 1 or 2 Mb, 5.5Mb,
11Mb or Fully Automatic)
default settings.
setting.
-
15 -
Encryption
WEP (Wired Equivalent Privacy) encryption
can be used to ensure the security of your
wireless network.
Item Description
Encryption
(WEP)
Create Keys
with Passphrase
Create Keys
Manually
WEP is a data privacy mechanism
based on a 64-bit/128-bit shared
key algorithm.
Under the drop-down box, you
can choose to have WEP
encryption Disabled, 64 bit, or
128 bit.
A Passphrase can be entered to
generate four keys used for WEP.
For the easiest configuration, the
Passphrase method is
recommended.
These four fields can be used to
enter WEP keys manually. The
method is required to match the
keys of other wireless devices on
the existing network.
-
16 -
~ Alphanumeric:
5 characters
~ Hexadecimal:
10 digits (0-9,
A-F)
Key 1:
Key 2:
Key 3:
Key 4:
Use WEP Key The default key field can be used
Apply Click Apply to activate the
Click Alphanumeric if you are
using an alphanumeric phrase.
Click Hexadecimal if you are
using a hexadecimal number.
This setting is the configuration
key used in accessing the wireless
network via WEP encryption.
for specifying which of the four
encryption keys to transmit data
on the wireless network.
settings.
You must use the same value/phrase and WEP
key settings for all wireless computers in order
for the wireless network to function properly.
-
17 -
Site Survey
The Site Survey tab shows all the available
Access Points or Peer-to-Peer types and their
features.
Item Description
Network
Name
BSSID A set of wireless stations is referred
Channel It shows the selected channel that is
Network
Type
The name must be identical for all
devices and points attempting to
connect to the same network.
to as a Basic Service Set (BSS).
Computers in a BSS must be
configured with the same BSS ID.
currently used.
It displays the type of BSS.
Access Point: allows the Adapter to
communicate with a wired network
which employing an Access Point.
Peer-to-Peer: allows PC-to-PC,
station-to-station communication
without employing an Access Point.
-
18 -
Item Description
WEP
Encryption
Signal Level It displays the signal strength of the
Rescan Search for all available networks.
Connect To connect with a new access point,
It displays the status of WEP
Encryption.
connection between the Wireless
CompactFlash Card and the Access
Point it connects.
Clicking on the button, the device
will start to rescan and list all
available sites.
highlights the desired one in the left
list box and clicks on the Connect
button. Wait a while and the
selected one will be marked as a
current used access point.
About
The About tab shows the version information of
the Configuration Utility.
-
19 -
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
