Page 1

DS-PAN-110 Series Havis Rugged Mobile Docking Station For Panasonic CF-30

& CF-31 Toughbooks

www.havis.com 1-800-524-9900

Owner’s Manual

DS-PAN-111 DS-PAN-111-1 DS-PAN-111-2

DS-PAN-112 DS-PAN-112-1 DS-PAN-112-2

DS-PAN-113

Page 2

www.havis.com • 1-800-524-9900

DS-PAN-111 DS-PAN-111-1 DS-PAN-111-2

DS-PAN-112 DS-PAN-112-1 DS-PAN-112-2

DS-PAN-113

Before Beginning

(Original Instructions)

1 10

• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE AIRBAG DEPLOYMENT ZONE.

• DO NOT USE COMPUTER WHILE DRIVING.

• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.

• DO NOT MATE COMPUTER TO DOCKING STATION UNLESS COMPUTER’S DOCKING CONNECTOR ACCESS DOOR IS FULLY OPEN OR DAMAGE MAY RESULT.

Havis is pleased to provide this Owner’s Manual to aid in the proper installation and use of the DS-PAN-110 Series Docking Station for the Panasonic CF-30 & CF-31 laptop computers.

For questions regarding the set-up of your DS-PAN-110 Series Docking Station, please contact Havis at 1-800-524-9900 or visit www.havis.com/CF31 for additional product support and information.

This Owner’s Manual applies to the following Product Numbers:

• FOR PROPER SYSTEM FUNCTION, THIS DOCKING STATION SHOULD BE USED ONLY WITH PANASONIC CF-30 AND CF-31 MODEL COMPUTERS. PANASONIC CF-29 AND EARLIER MODELS ARE NOT COMPATIBLE.

• FOR PROPER SYSTEM FUNCTION, PANASONIC RECOMMENDS USING A 120W POWER SUPPLY (LPS-104 OPTIONAL) WITH A CF-31 HIGH POWER (2.5GHz) COMPUTER.

• FOR CF-31 MEDIUM (2.4GHz) AND LOW (2.2 GHz) POWER COMPUTERS, A 90W POWER SUPPLY (LPS-101 OPTIONAL) IS ACCEPTABLE, HOWEVER A 120W POWER SUPPLY (LPS-104 OPTIONAL) MAY ALSO BE USED.

Installation of Power Supply (LPS-101/LPS-104 - Optional)

1). Power oﬀ computer and ensure all cables are disconnected from computer.

2). Plug in both input and output cables (supplied with LPS-101/LPS-104) into the Power Supply brick.

3). With the Docking Station right side up, drop (4) #6-32 screws (supplied with LPS-101/LPS-104) through the holes in Docking Station as shown.

4). While supporting the (4) #6-32 screws, ip the Docking Station upside down and place (1) at washer over each of the (4) #6-32 screws.

5). Place the Power Supply brick over the (4) #6-32 screws ensuring that the screws pass through all of the bosses on the Power Supply brick and the cables are pointing in the direction shown.

6). Place the remaining (4) at washers over each of the #6-32 screws and hand start a #6-32 locking nut onto each of the screws.

7). Torque all (4) #6-32 locking nuts to 0.9 Nm (8.0 in-lbs) ±10% ensuring that the #6-32 screws stayed properly aligned with the bosses of the Power Supply brick.

8). Route the Power Supply output cable as shown and secure connector to power input port on Docking Station. Be sure to coil and strain relieve excess cabling.

9). Return to Installation & Cable Management Step #3 on Page 4.

NOTE: Refer to Page 1 to ensure that you have the appropriate Power Supply for your Specic computer model.

Page 3

Table of Contents

Specications

Parts Included

Port Replication Capability

Installation & Cable Management

Operation - Docking

Dock Indicator LED Diagnostics

Operation - Undocking

Zip Tie/Push Pin Information

Installation of Power Supply (LPS-101/LPS-104 - Optional)

Specications

Power Supply Input 15.6V DC-In

Dimensions* 12.4” ( 31.5 cm) W x 11.9” ( 30.2 cm ) D x 4.0” ( 10.2 cm ) H

Weight* 4.6 lbs ( 2.1 kg )

Operating Environment 5° C to 35° C ( 41° F to 95°F )

Storage Environment -20° C to 60° C ( -4° F to 140° F )

* DS-PAN-111

DECLARATION OF CONFORMITY FOR CE MARKING

Havis, Inc. declares that their DS-PAN-110 SERIES DOCKING STATIONS: Are classied within the following EU Directives:

EU Electromagnetic Compatibility Directive 2004/108/EC

And further conform with the following EU Harmonized Standards:

EN 55022 (2006) + A1 2007, EN 55024 (1998) + A2: 2003

Dated: August 19, 2010 Position of signatory: Chief Information Oﬃcer / Chief Financial Oﬃcer Name of signatory: Steve Ferraro

Signed:

• Do not place containers of liquid or metal objects on top of the Docking Station

• If a malfunction occurs, immediately unplug the Power Supply and remove the laptop

• Use only the specied Power Supply with this Docking Station

Recommended: Part # LPS-101 (90W) for CF-30, CF-31 Medium & Low Power Computers Recommended: Part # LPS-104 (120W) for CF-31 High Power Computers

• Do not store the Docking Station where water, moisture, steam, dust, etc. are present

• Do not connect cables into ports other than what they are specied for

• Do not leave the Docking Station in a high temperature environment for a long period of time

(greater than +60°C, 140°F)

Precautions

Page 4

www.havis.com • 1-800-524-9900

True Ethernet RJ45

USB 2.0 Ethernet

RJ45

Parts Included

3 8

Docking Station

Forward Exiting Connectivity

Mounting Bracket

Hardware Kit

This Hardware Kit includes:

1. Zip Ties/Push Pins (2)

2. Keys (2)

3. 1/4”-20 Screws (7)

4. Zip Ties (6)

Tools required for installation:

• 5/32” Hex Drive

(For securing 1/4”-20 Screws)

Port Replication Capability

Headphone

MicrophoneUSB 2.0 (4)

+ Front USB 2.0 (1)

Serial (2)VGA Wireless On/Oﬀ*

Power Input

Rearward Exiting Connectivity (Optional Single or Dual Antenna)

Antenna A Antenna B

5). For theft deterrence, secure computer by locking Docking Station with supplied key.

6). Power on computer. The Dock Indicator LED will light up green to indicate proper system function.

Operation - Docking (Continued)

Operation - Undocking

1). If previously locked, unlock Docking Station using supplied key.

2). Rotate Latch Handle clockwise to the “UNDOCK” position.

Latch Handle

Docking Connector

Brass Locator Pin

Front Hook

Brass Locator Tab

Front USB Port

Dock Indicator LED

Lock

Dock Indicator LED

GREEN: Computer docked, all ports ready for use. ORANGE: USB and LAN ports are not functioning. RED: Computer is not supported or a connection is not made. RED (Blinking): Firmware error has occurred. NOT LIT: Computer is not installed, is turned oﬀ, or in standby or sleep mode.

For CF-30 computers, WWAN pass-through can be controlled according to Wireless On/Oﬀ switch setting.

For CF-31 computers, WWAN will always function as pass-through regardless of switch setting.

* NOTE

Page 5

Installation & Cable Management

1). Install the Mounting Bracket to the Motion Device using (3) 1/4“-20 screws (Hardware Kit Item 3). Torque screws to 13.4Nm (120 in-lbs) ± 10%.

NOTE: Numerous hole patterns present in Mounting Bracket should accommodate most competitor’s motion devices.

1/4”-20 Screws

Mounting Bracket

Typical Motion Device Example

(not included)

2). Orient the Docking Station in a position that is comfortable to work with.

3). Install all cables that are necessary for computing needs.

NOTE: If mounting Power Supply to Docking Station, go to Page 10 before completing Step 3

4). Use Zip Ties (Hardware Kit Item 4) to strain relieve cables to the Strain Relief Loops at front of Docking Station.

NOTE:

Holes shown will

accept Zip Tie/Push Pins

(Hardware Kit Item 1)

for strain relieving

Antenna cables.

Page 6

www.havis.com • 1-800-524-9900

5 6

Installation & Cable Management (Continued) Installation & Cable Management (Continued)

7). Tilt the Motion Device to a position allowing you access to the back side of docking station and route cables out the side as shown.

8). Route cable bundle and tie oﬀ to Mounting Bracket with Zip Tie

(Hardware kit Item 4).

9). Create a service loop with cable bundle to ensure that no tension is on the connectors and to enable intended range of motion.

10). Tie oﬀ cables onto a stationary part of the mounting system.

11). Position Docking Station as desired for use inside mobile workspace.

5). Gather all strain relieved cables into a single bundle and secure with Zip Ties to facilitate routing in later installation steps.

6). Lower the Docking Station onto the Mounting Bracket as shown, being cautious not to pinch the cable bundle. Secure with (4) 1/4”-20 screws (supplied). Torque screws to 13.4 Nm (120 in-lbs) ± 10%.

NOTE: It is recommended to use a drop of medium strength (blue)

thread locking adhesive applied to the threads of all fasteners.

Tie oﬀ on stationary part of the mounting system

(not included)

1/4”-20 Screws

Page 7

7). Tilt the Motion Device to a position allowing you access to the back side of docking station and route cables out the side as shown.

8). Route cable bundle and tie oﬀ to Mounting Bracket with Zip Tie

(Hardware kit Item 4).

9). Create a service loop with cable bundle to ensure that no tension is on the connectors and to enable intended range of motion.

10). Tie oﬀ cables onto a stationary part of the mounting system.

11). Position Docking Station as desired for use inside mobile workspace.

Tie oﬀ on stationary part of the mounting system

(not included)

This loop must be large enough

to allow full range of expected

rotation and extension without

stressing connections.

Page 8

www.havis.com • 1-800-524-9900

1). Ensure Docking Station is unlatched by positioning the Latch Handle to the “UNDOCK” position.

2). With rear of computer elevated, load front of computer into Docking Station by aligning Front Hook with the appropriate recess in the computer case.

3). Lower back of computer onto Brass Locator Pins.

4). Apply light downward pressure over rear of computer as indicated by Arrow A and rotate Latch Handle counter-clockwise to the “DOCK” position.

7 4

Installation & Cable Management

1). Install the Mounting Bracket to the Motion Device using (3) 1/4“-20 screws (Hardware Kit Item 3). Torque screws to 13.4Nm (120 in-lbs) ± 10%.

NOTE: Numerous hole patterns present in Mounting Bracket should accommodate most competitor’s motion devices.

Operation - Docking

• DO NOT MATE COMPUTER TO DOCKING STATION UNLESS COMPUTER’S DOCKING CONNECTOR ACCESS DOOR IS FULLY OPEN OR DAMAGE MAY RESULT.

• DO NOT FORCE LAPTOP ONTO DOCKING STATION. IF THERE IS RESISTANCE, CHECK ALIGNMENT OF COMPUTER ON DOCKING STATION.

2). Orient the Docking Station in a position that is comfortable to work with.

3). Install all cables that are necessary for computing needs.

NOTE: If mounting Power Supply to Docking Station, go to Page 10 before completing Step 3

4). Use Zip Ties (Hardware Kit Item 4) to strain relieve cables to the Strain Relief Loops at front of Docking Station.

Page 9

5). For theft deterrence, secure computer by locking Docking Station with supplied key.

6). Power on computer. The Dock Indicator LED will light up green to indicate proper system function.

Operation - Docking (Continued)

Operation - Undocking

1). If previously locked, unlock Docking Station using supplied key.

2). Rotate Latch Handle clockwise to the “UNDOCK” position.

Dock Indicator LED

DOCK INDICATOR LED DIAGNOSTICS:

Page 10

www.havis.com • 1-800-524-9900

Table of Contents

Zip Tie/Push Pin Information

9 2

Specications

Parts Included

Port Replication Capability

Installation & Cable Management

Operation - Docking

Dock Indicator LED Diagnostics

Operation - Undocking

Zip Tie/Push Pin Information

Installation of Power Supply (LPS-101/LPS-104 - Optional)

Specications

Power Supply Input 15.6V DC-In

Dimensions* 12.4” ( 31.5 cm) W x 11.9” ( 30.2 cm ) D x 4.0” ( 10.2 cm ) H

Weight* 4.6 lbs ( 2.1 kg )

Operating Environment 5° C to 35° C ( 41° F to 95°F )

Storage Environment -20° C to 60° C ( -4° F to 140° F )

* DS-PAN-111

1). In the event that a strain relieved cable needs to be removed or replaced, do not attempt to remove entire Zip Tie/Push Pin. Cut Zip Tie as shown, taking care to not damage the cables.

2). Pull the cut Zip Tie through the Push Pin housing. Trim excess so sharp edge does not damage reinstalled cables.

Trim excess

3). Insert a new Zip Tie into the Push Pin housing and strain relieve cables.

Operation - Undocking (Continued)

3). Once unlatched grab both sides of computer and carefully lift out of Docking Station, rear end rst.

DECLARATION OF CONFORMITY FOR CE MARKING

Havis, Inc. declares that their DS-PAN-110 SERIES DOCKING STATIONS: Are classied within the following EU Directives:

EU Electromagnetic Compatibility Directive 2004/108/EC

And further conform with the following EU Harmonized Standards:

EN 55022 (2006) + A1 2007, EN 55024 (1998) + A2: 2003

Dated: August 19, 2010 Position of signatory: Chief Information Oﬃcer / Chief Financial Oﬃcer Name of signatory: Steve Ferraro

Signed:

• Do not place containers of liquid or metal objects on top of the Docking Station

• If a malfunction occurs, immediately unplug the Power Supply and remove the laptop

• Use only the specied Power Supply with this Docking Station

Recommended: Part # LPS-101 (90W) for CF-30, CF-31 Medium & Low Power Computers Recommended: Part # LPS-104 (120W) for CF-31 High Power Computers

• Do not store the Docking Station where water, moisture, steam, dust, etc. are present

• Do not connect cables into ports other than what they are specied for

• Do not leave the Docking Station in a high temperature environment for a long period of time

(greater than +60°C, 140°F)

Precautions
