Operating instructions
PRX U, PRX W, PRV U, PRV W
Operating instructions
Angular electrode and
U-shaped electrode
Static Line
Angular electrode and U-shaped electrode
Operating instructions angular electrode and U-shaped electrode
Types: PRX U; PRX W
PRV U; PRV W
Keep in a safe place for future reference!
Contents
1. Notes on operating instructions 5. Remedy of defects
2. Safety 6. Maintenance and repairs
3. Installation 7. Technical data
4. Application
1 Notes on operating instructions
In these operating instructions, the individual ionizing units are also referred to as "units" or
"ionizing units".
1.1 Pictorial markings used
In these operating instructions
In the operating instructions and on the unit
Caution!
Important instructions!
Danger!
High voltage!
Danger of fatal accidents!
Switch off the power pack before connecting
or disconnecting the coaxial connectors!
Danger!
High voltage!
Danger of fatal accidents!
Winkel- und U-Elektroden v02gb
Page 3
Operating instructions angular electrode and U-shaped electrode
2 Safety
The ionizing units of these series are operationally safe, provided that they are operated in
accordance with their intended use.
In case of misuse, dangers may result:
- for life and limb of the operator,
- for the unit and other assets.
Also note Chapter 3.1 (Important installation notes).
During operation of the units, small quantities of ozone will form.
In order to ensure adherence to maximum permitted ozone concentrations at the workplace,
make sure that the workplace is ventilated sufficiently during operation of the units.
2.1 Intended use
Ionizing units generate positive and negative ions. Their purpose is the elimination of electrostatic
charges (e.g. in paper, films and foils, textiles, glass, plastics etc.).
HAUG power packs only must be used for supplying the high voltage to the units.
For reasons of safety, unauthorized conversions and modifications of the unit are not permitted.
The installation and operating conditions indicated in these Operating Instructions must be
adhered to.
For operators with heart pacemakers special instructions should be
requested from the manufacturer!
The operator of the units must take care to ensure sufficient ventilation
during operation!
Do not install or use the units in areas
subject to explosion hazards.
2.2 Danger sources
Defective high-voltage plugs and cables may lead to danger of electric shocks. Shut down the
unit immediately in case of visible damage and suspected electrical defects.
Page 4
Danger!
High voltage!
Danger of fatal accidents!
Switch off the power pack before connecting
or disconnecting the coaxial connectors!
Winkel- und U-Elektroden v02gb
Operating instructions angular electrode and U-shaped electrode
2.3 Operator qualifications
The unit may be installed and put into operation by trained electricians only or by authorized and
persons informed about the potential dangers. The above mentioned persons must have read the
operating instructions and must follow the instructions, notes and safety advice.
3 Installation
The unit may be installed by trained electricians only and by authorized persons informed about
the potential dangers. The above mentioned persons must have read the operating instructions
and must follow the instructions, notes and safety advice.
3.1 Important installation instructions
The operation of the unit is not affected by the position in which it is installed.
3.2 Ionizing units
The numerals refer to the illustration at the end of these instructions.
- Example for ionizers.
Most favourable distance ionizing unit - material
Distance B to grounded machine part always greater than distance A.
Install ionizer so that no machine parts are located behind the material.
Never attach metal holders above the ionizing needles.
Install high-voltage cables without kinks. Smallest bending radius 50 mm.
- Examples of holders.
Do not connect the units to the power
pack until installation is completed.
Switch off the power pack before connecting
or disconnecting the coaxial connectors!
approx. 20 - 30 mm, min. 10 mm, max. 80 mm.
Winkel- und U-Elektroden v02gb
Page 5
Operating instructions angular electrode and U-shaped electrode
4 Application
The unit may be put into operation by trained electricians only or by persons instructed in the
potential dangers. The above mentioned persons must have read the operating instructions and
must follow the instructions, notes and safety advice.
Conditions:
The power pack and the ionizing unit must be connected correctly.
Ionizing units, in combination with HAUG power packs, are intended for the removal of
electrostatic charges (e.g. from paper, films and foils, textiles, glass, plastics etc.).
Example:
Figure 1: Unloading of weighing vessels of laboratory balances
Figure 1
The operator of the units must take care to ensure sufficient ventilation
during operation!
Page 6
Winkel- und U-Elektroden v02gb
Operating instructions angular electrode and U-shaped electrode
5 Remedy of defects
Any remedy of defects must be carried out by trained electricians only. The above mentioned
persons must have read the operating instructions and must follow the instructions, notes and
safety advice.
In case of defects regarding the power pack and the ionizing unit, please check for correct
installation first. If this does not solve the problem, please return the power pack together with the
ionizing unit for examination.
Danger!
High voltage!
Danger of fatal accidents!
Switch off the power pack before connecting
or disconnecting the coaxial connectors!
6 Maintenance and repairs
This unit does not include any parts which can be maintained or repaired by the operator.
Should the unit prove defective or if a defect is suspected, switch off unit immediately and secure
against subsequent reuse.
Danger!
High voltage!
Danger of fatal accidents!
6.1 Ionizing units
Clean at intervals of no more than 14 days using the special cleaning brush or the
special cleaning system (see Section 6.2 Accessories).
6.2 Accessories
PRX retaining plate 10.0400.001
Holder for angular electrode 10.0269.000
Holder for "U"-shaped electrode 10.0371.000
Special cleaning fluid 10.7220.000
Special cleaning brush 10.7218.000
Special cleaning system 10.7218.001
Circular brush for special cleaning system X – 6822
Winkel- und U-Elektroden v02gb
Page 7
Operating instructions angular electrode and U-shaped electrode
7 Technical data
7.1 Supply voltage
The ionizing units are provided with high voltage from HAUG power packs.
7.2 Ambient conditions
Ambient temperature:
Rated application range +5 °C to +45 °C
Extreme range for storage and transport -15 °C to +60 °C
Humidity:
Rated application range 20 % to 65 % RH
Extreme range for storage and transport 0 % to 85 % RH
7.3 Dimensions
Type Shape Cross-section
PRX W Angle (90°) 14 x 14,5 mm
PRX U “U” 14 x 14,5 mm
PRV W Angle (90°) 15 x 16 mm
PRV U “U” 15 x 16 mm
High tensions lead 2 m
Page 8
Winkel- und U-Elektroden v02gb
AB~ 20 - 30 mm
r > 50 mm
D – 0219
made by
HAUG GmbH & Co.KG
D-70771 Leinfelden-Echterdingen
E-Mail: haug@bluewin.ch
Friedrich-List-Straße 18
Telefon 07 11 / 94 98 - 0
Telefax 07 11 / 94 98 - 298
www.haug.de
E-Mail: info@haug.de
HAUG Biel AG
Postfach 52
CH-2500 Biel/ Bienne 6
Johann-Renfer-Strasse 60
CH-2500 Biel/ Bienne 6
Telefon 0 32 / 3 44 96 96
Telefax 0 32 / 3 44 96 97
www.haug.de
16.08.04
