Hatco GRSBF-24-O Installation Manual

GLO-RAY

®

®

Heated Shelf

GRS, GRSB & GRSBF Series

Installation &

Operating Manual

I&W #07.05.047.00

ANAQUELES CALENTADOS INSERTABLES

Manual de Instalación y Operación

PIANI RISCALDATI

Manuale di installazione e funzionamento

WARMHALTERPLATEN
Installations- und Bedienungshandbuch

PLAQUES CHAUFFANTES
Installation et Fonctionnement

WARMHOUDPLATEN
Handleiding voor Installatie en Gebruik

Modelli: Glo-Ray

Modelo: Glo-Ray

Modell: Glo-Ray

Modèle: Glo-Ray

Model: Glo-Ray

® ®

®®

®

1

Form No. GRSCEM-0702

ILLUSTRATIONS

1

4

2

Glo-Ray Model GRS Glo-Ray Modèles GRS
Glo-Ray-Modell GRS Glo-Ray Modello GRS
Glo-Ray Modelo GRS Glo-Ray Model GRS

Glo-Ray Model GRSB & GRSBF
(GRSB Shown)
Glo-Ray-Modelle GRSB
und GRSBF (Modell GRSB gezeigt)
Glo-Ray Modelo GRSB y GRSBF
(GRSB mostrado)

3

A

B

C

D

E

A NEMA 5-15P A NEMA 5-15P
B NEMA 5-20P B NEMA 5-20P
C NEMA 6-15P C NEMA 6-15P
D CEE 7/7 Schuko D CEE 7/7 Schuko
E BS-1363 E BS-1363

A NEMA 5-15P A NEMA 5-15P
B NEMA 5-20P B NEMA 5-20P
C NEMA 6-15P C NEMA 6-15P
D CEE 7/7 Schuko D CEE 7/7 Schuko
E BS-1363 E BS-1363

A NEMA 5-15P A NEMA 5-15P
B NEMA 5-20P B NEMA 5-20P
C NEMA 6-15P C NEMA 6-15P
D CEE 7/7 Schuko D CEE 7/7 Schuko
E BS-1363 E BS-1363

Plug Configurations Configurations de prise
Steckerkonfigurationen Configurazione delle spine
Configuraciones del enchufe Stekkerconfiguraties

A

B

C

Note: All models listed are based on 50 cm (19-1/2") depth.

Additional depths available:
15 cm (6"), 20 cm (7-3/4"), 25 cm (9-3/4"),
31 cm (12"), 35 cm (13-3/4"), 39 cm (15-1/2"),
40 cm (15-3/4"), 45 cm (17-1/2"), 55 cm (21-1/2"),
60 cm (23-1/2") and 65 cm (25").

Anmerkung:

Alle aufgelisteten Modelle basieren auf einer Tiefe von
50 cm (19-1/2"). Folgende weitere Tiefenmaße sind
erhältlich:
15 cm (6"), 20 cm (7-3/4"), 25 cm (9-3/4"),
31 cm (12"), 35 cm (13-3/4"), 39 cm (15-1/2"),
40 cm (15-3/4"), 45 cm (17-1/2"), 55 cm (21-1/2"),
60 cm (23-1/2") und 65 cm (25").

Nota: Todos los modelos de la lista están basados en una

profundidad de 50 cm (19-1/2 pulg). Se pueden obtener
otras profundidades:
15 cm (6 pulg.), 20 cm (7-3/4 pulg.), 25 cm (9-3/4 pulg.),
31 cm (12 pulg.), 35 cm (13-3/4 pulg.),
39 cm (15-1/2 pulg.), 40 cm (15-3/4 pulg.),
45 cm (17-1/2 pulg.), 55 cm (21-1/2 pulg.),
60 cm (23-1/2 pulg.) y 65 cm (25 pulg.).

Remarque:

Tous les modèles listés sont basés sur une profondeur
de 50 cm (19-1/2"). Autres profondeurs disponibles:
15 cm (6"), 20 cm (7-3/4"), 25 cm (9-3/4"),
31 cm (12"), 35 cm (13-3/4"), 39 cm (15-1/2"),
40 cm (15-3/4"), 45 cm (17-1/2"), 55 cm (21-1/2"),
60 cm (23-1/2") et 65 cm (25").

Nota: Tutti i modelli indicati si basano su una profondità

di 50 cm (19-1/2"). Altre profondità disponibili:
15 cm (6"), 20 cm (7-3/4"), 25 cm (9-3/4"),
31 cm (12"), 35 cm (13-3/4"), 39 cm (15-1/2"),
40 cm (15-3/4"), 45 cm (17-1/2"), 55 cm (21-1/2"),
60 cm (23-1/2") e 65 cm (25").

Opmerking:

Alle vermelde modellen zijn gebaseerd op een diepte
van 50 cm (19-1/2"). Overige verkrijgbare dieptematen:
15 cm (6"), 20 cm (7-3/4"), 25 cm (9-3/4"),
31 cm (12"), 35 cm (13-3/4"), 39 cm (15-1/2"),
40 cm (15-3/4"), 45 cm (17-1/2"), 55 cm (21-1/2"),
60 cm (23-1/2") en 65 cm (25").

Glo-Ray Modèles GRSB &
GRSBF (GRSB montré)
Glo-Ray Modelli GRSB e GRSBF
(GRSB illustrato)

Glo-Ray model GRSB & GRSBF
(GRSB getoond)

Dimensions - Modèles GRS
Dimensioni - Modelli GRS
Afmetingen - GRS - modellen

Dimensions - GRS Models
Abmessungen - GRS-Modelle
Dimensiones - modelos GRS

2 Form No. GRSCEM-0702

ILLUSTRATIONS

Models GRSB & GRSBF Underside
Unterseite der GRSB- und GRSBF-Modelle
Parte inferior de modelos GRSB y GRSBF
Dessous des modèles GRSB et GRSBF
Fondo modelli GRSB & GRSBF
Modellen GRSB & GRSBF onderkant

Leg Installation
Anbringen der Füsse
Instalación de las patas

Leg Adjustment
Verstellen der Füsslänge
Ajuste de las patas

Remove and save these screws.
Entfernen Sie diese Schrauben, und heben Sie sie auf.
Retire y guarde estos tornillos.
Enlever et conserver ces vis.
Estrarre e conservare queste viti.
Verwijder en bewaar deze schroeven.

Adjust leg using a 14 mm (9/16") open-end wrench and turning

bottom of leg accordingly.

Verstelle Sie die Füsslänge durch entsprechendes Drehen

des Fußes mit einem 14 mm (9/16 Zoll)-Gabelschlüssel.

Ajuste la pata con una llave de boca de 14 mm (9/16 pulg.)

girando la parte inferior de la pata como corresponde.

Ajuster les pieds avec une clé de 14 mm (9/16 ème de pouce),

en tournant la base du pied dans le sens désiré.

Regolazione del piedino utilizzando una chiave a bocca

14 mm (9/16") e ruotando adeguatamente il fondo del piedino.

De poot bijstellen met een steeksleutel van 14 mm (9/16")

en de onderkant van de poot dienovereenkomstig draaien.

Installation des pieds
Installazione dei piedini
Installatie van de poten

Ajustement des pieds
Regolazione dei piedini
Bijstellen van de poten

5

6

Dimensions - GRSB Models
Abmessungen — GRSB-Modelle
Dimensiones - modelos GRSB

Dimensions - GRSBF Models
Abmessungen - GRSBF-Modelle
Dimensiones - modelos GRSBF

Dimensions - Modèles GRSBF
Dimensioni - Modelli GRSBF
Afmetingen - GRSBF-modellen

B

C

D

E

A

Note: All models listed are based on 50 cm (19-1/2") depth.
Anmerkung:

Alle aufgelisteten Modelle basieren auf einer Tiefe von
50 cm (19-1/2").

Nota: Todos los modelos de la lista están basados

en una profundidad de 50 cm (19-1/2 pulg).

Remarque:

Tous les modèles listés sont basés sur une profondeur
de 50 cm (19-1/2").

Nota: Tutti i modelli indicati si basano su una profondità

di 50 cm (19-1/2").

Opmerking:

Alle weergegeven modellen zijn gebaseerd
op 50 cm (19-12") diepte.

B

C

E

A

Note: All “S” models are based on 61 cm (24") depth. All “O”

models are based on 76 cm (30") depth. All “I” models
are based on 50 cm (19-1/2") depth.

Anmerkung:

Alle „S“-Modelle basieren auf einer Tiefe von 61 cm (24").
Alle „O“-Modelle basieren auf einer Tiefe von 76 cm (30").
Alle „I“-Modelle basieren auf einer Tiefe
von 50 cm (19-1/2").

Nota: Todos los modelos “S” están basados en una profundidad

de 61 cm (24 pulg). Todos los modelos “O” están basados
en una profundidad de 76 cm (30 pulg). Todos los modelos
“I” están basados en una profundidad
de 50 cm (19-1/2 pulg).

Remarque:

L’ensemble des modèles « S » sont basés sur une
profondeur de 61 cm (24 pouces). L’ensemble des modèles «
O » sont basés sur une profondeur de 76 cm
(30 pouces). L’ensemble des modèles « I » sont basés sur
une profondeur de 50 cm (19-1/2 pouces).

Nota: Tutti i modelli “S” si basano su una profondità di 61 cm

(24"). Tutti i modelli “O” si basano su una profondità
di 76 cm (30"). Tutti i modelli “I” si basano
su una profondità di 50 cm (19-1/2").

Opmerking :

Alle “S” modellen zijn gebaseerd op 61 cm (24") diepte.
Alle “O” modellen zijn gebaseerd op 76 cm (30") diepte.
Alle “I” modellen zijn gebaseerd op 50 cm (19-1/2") diepte.

D

7

8A

8B

Dimensions — Modèles GRSB
Dimensioni — Modelli GRSB
Afmetingen — GRSB-modellen

3

ILLUSTRATIONS

Form No. GRSCEM-0702

B

B

C

A

A Countertop A Comptoir
B Z-Bracket B Attache Z
C Four screws from underside C quatre vis du dessous

of unit de l’appareil

A Arbeitsplatte A Piano di lavoro
B Z-Klammer B staffa a Z
C Vier Schrauben von der C quattro viti dal fondo

Unterseite des Geräts dell’unità

A Mostrador A Toonbank
B Ménsula en Z B Z-steun
C Cuatro tornillos de la parte C Vier schroeven van de

inferior de la unidad onderkant van apparaat

GRSB & GRSBF Countertop Installation
Installation der GRSB- und GRSBF-Modelle in der Arbeitsplatte
Instalación del mostrador GRSB y GRSBF
Installation comptoir des modèles GRSB et GRSBF
Installazione del piano da lavoro GRSB & GRSBF
GRSB & GRSBF toonbankinstallatie

Operating Controls - GRSB & GRSBF (GRSB Shown)
Bedienungselemente - GRSB- und GRSBF-Modelle

(Modell GRSB gezeigt)
Controles de operación - GRSB y GRSBF (GRSB mostrado)
Contrôles de fonctionnement - GRSB et GRSBF (GRSB montré)
Comandi - GRSB & GRSBF (GRSB illustrato)
Bedieningsapparatuur - GRSB & GRSBF (GRSB getoond)

9

A

B

A

B

A Power On/Off Switch
B Shelf Thermostat

A Netzschalter ein/aus
B Thermostat

der Warmhalteplatte

A Interruptor de encendido/apagado
B Termostato del anaquel

A Interrupteur marche-arrêt
B Thermostat du rayonnage

A Interruttore

di alimentazione

B Termostato piano

A Stroomschakelaar

Aan/Uit

B Plaatthermostaat

A Power On/Off Switcht
B Shelf Thermostat

A Netzschalter ein/aus
B Thermostat der Warmhalteplatte

A Interruptor

de encendido/apagado

B Termostato del anaquel

A Interrupteur marche-arrêt
B Thermostat du rayonnage

A Interruttore di alimentazione

On/Off

B Termostato piano

A stroomschakelaar Aan/Uit
B plaatthermostaat

Operating Controls - GRS

Bedienungselemente - GRS-Modell
Controles de operación - GRS

10

11

Contrôles de fonctionnement ­GRS
Comandi - GRS
Bedieningsapparatuur ­GRS

4

ILLUSTRATIONS

Form No. GRSCEM-0702

A

B

C

D

E

F

G

F

A Panel A Panneau
B Recessed B Encastré
C Surface C Surface
D Under Counter D Sous le comptoir
E Top View E Vue de dessus
F Optional F Optionnel
G Standard G Standard

A Senkrecht auf einer Platte A Pannello
B In einer Platte B Incassato
C Auf einer Platte C Superficie
D Unterhalb der Theke D Sotto al banco
E Aufsicht E Vista top
F Optional F Optional
G Standard G Standard

A Panel A paneel
B Rebajada B ingebouwd
C Superficie C oppervlak
D Debajo del mostrador D onder de toonbank
E Vista superior E bovenaanzicht
F Opcional F optioneel
G Estándar G standaard

12

Use this arc to determine
approximate mounting
distances for semi-remote
controls.

Verwenden Sie diesen
Bogen, um die maximale
Entfernung, in der das
Steuerpult montiert werden
kann, zu bestimmen.

Utilice este arco para
determinar las distancias de
montaje aproximadas para
los controles semi remotos.

Utiliser cet arc pour
déterminer les distances de
montage approximatives
pour les contrôles semi­distants.

Utilizzare questo arco per
stabilire la distanza di
montaggio approssimativa
per i comandi semi-remoti.

Gebruik deze boog om de
geschatte montageafstanden
te bepalen voor semi­afstandbedieningen.

Maximum Remote Mounting Distance for Control Box
Maximale Entfernung, in der das Steuerpult montiert werden kann
Distancia máxima de montaje del control remoto para la caja de

control

Distance maximum pour montage distant du boîtier de contrôle
Distanza massima di montaggio della scatola di comando
Maximale montageafstand voor de regeldoos

5

Form No. GRSCEM-0702

CAUTIONS

Locate the unit at the proper counter height, in an area that
is convenient for use. The location should be level to prevent
the shelf or its contents from accidentally falling, and strong
enough to support the weight of the unit and food.

Some exterior surfaces on the unit will get hot. Use caution
when touching these areas to avoid injury.

WARNINGS

To avoid any injury, turn the power switch off, unplug
the unit from the power source and allow to cool before
performing any maintenance.

The Glo-Ray Heated Shelf is not waterproof. DO NOT
submerge in water. Do not operate if it has been submerged
in water.

Plug unit into a grounded electrical outlet of the correct
voltage, size and plug configuration. If the plug and
receptacle do not match, contact a qualified electrician
to determine the proper voltage and size, and install the
proper electrical outlet.

INTRODUCTION

This manual contains important safety information concerning
the maintenance, use and operation of this product. Failure
to follow the instructions contained in this manual may result
in serious injury. If you are unable to understand the contents
of this manual, please bring it to the attention of your supervisor.
Do not operate this equipment unless you have read and understood
the contents of this manual.

The Hatco Glo-Ray Heated Shelf is designed to keep prepared
foods hot at kitchen work areas, waitress pick-up stations
or customer serving points.

The Glo-Ray Heated Shelf keeps all foods at optimum serving
temperatures without affecting quality. This warmer has
a thermostat controlled heated base to extend the holding times
of most foods.

This manual provides the installation, safety and operating
instructions for the Glo-Ray Heated Shelf. We recommend
all installation, operating and safety instructions appearing in this
manual be read prior to installation or operation of your Glo-Ray
Heated Shelf. Safety instructions that appear in this manual after
a warning symbol and the words WARNING or CAUTION
printed in bold face are very important. WARNING means
there is the possibility of serious injury or death to yourself
or others. CAUTION means there is the possibility of minor
or moderate injury. CAUTION without the symbol signifies
the possibility of equipment or property damage only.

Glo-Ray Heated Shelves are a product of extensive research
and field testing. The materials used were selected for maximum
durability, attractive appearance and optimum performance. Every
unit is thoroughly inspected and tested prior to shipment.

IMPORTANT SAFETY INSTRUCTIONS

Illustrations ......................................................................................1

Introduction .....................................................................................5

Important Safety Instructions........................................................5

Model Descriptions..........................................................................6

GRS Model ..............................................................................6

GRSB & GRSBF Models........................................................6

Specifications ...................................................................................7

Electrical Rating Chart - GRS Models....................................7

Electrical Rating Chart - GRSB Models .................................8

Electrical Rating Chart - GRSBF Models ...............................9

Plug Configurations ...............................................................11

Dimensions GRS Models.......................................................11

Dimensions GRSB Models....................................................11

Dimensions GRSBF Models..................................................12

Installation .....................................................................................13

GRS Models...........................................................................13

GRSB & GRSBF Models......................................................13

Operation .......................................................................................15

All Models .............................................................................15

Maintenance...................................................................................15

Cleaning .................................................................................15

Accessories .....................................................................................15

Hatco Limited Warranty..............................................................16

Important Owner Information .....................................Back Cover

IMPORTANT! Read the following important safety instructions to avoid personal injury or death, and to avoid
damage to the equipment or property.

CONTENTS

The instructions in English begin on page.....................................................................................5

Deutsche Anweisungen beginnen auf Seite .................................................................................17

Las instrucciones en Espanol comienzan en la pagina ................................................................29

Les instructions en Francais commencent a la page ...................................................................41

Le istruzioni in Italiano iniziano dalla pagina .............................................................................53

Nederlandse instructies beginnen op bladzijde ...........................................................................65

6 Form No. GRSCEM-0702

IMPORTANT SAFETY INSTRUCTIONS

CAUTIONS

The National Sanitation Foundation (NSF) requires that
GRS Series units over 91 cm (36") in length or weighing
more than 36 kg (80 lbs.) to be either sealed or raised
on the installation surface. If this unit cannot be sealed
at the point of use, 10 cm (4") legs are included to allow
for proper cleaning access below unit. See Hatco Accessories
for installation instructions.

CAUTIONS

Damage to countertop material caused by heat generated
from Hatco equipment is not covered under the Hatco
warranty. Contact the manufacturer of the base material
for application information.

Use of excessive force when tightening mounting screws may
damage unit or countertop (GRSB & GRSBF units).

Abrasive cleaners could scratch the finish of your
Glo-Ray Heated Shelf.

WARNINGS

For safe and proper operation, the unit must be located
a reasonable distance from combustible walls and materials.
If safe distances are not maintained, discoloration
or combustion could occur.

This appliance is not of jet-proof construction. Do not use
jet-clean-spray to clean this appliance.

Do not lay unit on the side with the control panel or damage
to the unit could occur.

If service is required on this unit, contact your Authorized
Hatco Service Agent, or contact the Hatco Service
Department at 800-558-0607 or 414-671-6350;
fax [phone] or International fax [phone].

This product has no “user” serviceable parts. To avoid
damage to the unit or injury to personnel, use only
Authorized Hatco Service Agents and Genuine Hatco
Replacement Parts when service is required.

Genuine Hatco Replacement Parts are specified to operate
safely in the environments in which they are used. Some
aftermarket or generic replacement parts do not have the
characteristics that will allow them to operate safely
in Hatco equipment. It is essential to use Hatco Replacement
Parts when repairing Hatco equipment. Failure to use Hatco
Replacement Parts may subject operators of the equipment
to hazardous electrical voltage, resulting in electrical
shock or burn.

MODEL DESCRIPTIONS

GRS MODEL

The GRS Heated Shelf is ideal for pass-through areas, buffet lines
or as a heated work shelf. It features an on/off rocker switch with
indicator light, 60° to 82° C (140° to 180° F) adjustable thermostat
and 183 cm (6') cord with plug. Surface mounted foil elements
distribute heat under the entire stainless steel surface.

All GRS models are shipped from the factory completely assembled
and ready for use.

GRSB & GRSBF MODELS

The GRSB and GRSBF Drop-In Heated Shelves have
a hardcoat aluminum top and a blanket-type foil element
for uniform heat distribution. Ideal for server-to-customer pass
through areas, buffet and cafeteria lines and other self-service areas.
The GRSB model features a recessed top. The GRSBF model
incorporates a flat design top.

A 91 cm (3') flexible conduit channels the power lines from
the shelf to a remote control box. The control box comes with
a control thermostat with a range of 27° to 93° C (80° to 200° F),
an illuminated on/off switch and mounting brackets. The attached
control box can be located up to 91 cm (3') from the unit.

The Drop-In Heated Shelf has a 2 cm (3/4") flanged edge that
allows the unit to drop into a countertop opening. The shelf is easy
to clean with a soft damp cloth or non-abrasive cleaner. All GRSB
and GRSBF models are shipped from the factory completely
assembled and ready for use.

CAUTION
Abrasive cleaners could scratch the finish of your Glo-Ray
Heated Shelf.

CAUTION
The National Sanitation Foundation (NSF) requires that
GRS Series units over 91 cm (36") in length or weighing
more than 36 kg (80 lbs.) to be either sealed or raised
on the installation surface. If this unit cannot be sealed
at the point of use 10 cm (4") legs are included to allow
for proper cleaning access below unit. See Hatco
ACCESSORIES for installation instructions.

7

Form No. GRSCEM-0702

SPECIFICATIONS

† All GRS models listed are based on 50 cm (19-1/2") depths. Additional depths available.
* Models that accommodate multiple food pans: 76 cm (30") = 2 pans, 107 cm (42") = 3 pans,

137 cm (54") = 4 pans, 168 cm (66") = 5 pans.

The electrical information in the shaded areas pertains to Export models only.

ELECTRICAL RATING CHART - STANDARD GRS MODELS

Model

†

Voltage Watts Amps Plug Configuration Shipping Weights

GRS-18-I 100 240 2.4 NEMA 5-15P 7 kg (16 lbs.)

120 250 2.1 NEMA 5-15P 7 kg (16 lbs.)
220 228 1.0 CEE 7/7 Schuko 7 kg (16 lbs.)

240 272 1.1 BS-1363 7 kg (16 lbs.)
220-230 (CE) 228-250 1.0-1.1 CEE 7/7 Schuko 7 kg (16 lbs.)
230-240 (CE) 250-272 1.1 BS-1363 7 kg (16 lbs.)

GRS-24-I 100 300 3.0 NEMA 5-15P 9 kg (20 lbs.)

120 350 2.9 NEMA 5-15P 9 kg (20 lbs.)

220 320 1.5 CEE 7/7 Schuko 9 kg (20 lbs.)

240 380 1.6 BS-1363 9 kg (20 lbs.)
220-230 (CE) 320-350 1.5-1.6 CEE 7/7 Schuko 9 kg (20 lbs.)
230-240 (CE) 350-380 1.5-1.6 BS-1363 9 kg (20 lbs.)

GRS-30-I* 100 350 3.5 NEMA 5-15P 11 kg (25 lbs.)

120 450 3.8 NEMA 5-15P 11 kg (25 lbs.)

220 412 1.9 CEE 7/7 Schuko 11 kg (25 lbs.)

240 490 2.0 BS-1363 11 kg (25 lbs.)
220-230 (CE) 412-450 1.9-2.0 CEE 7/7 Schuko 11 kg (25 lbs.)
230-240 (CE) 450-490 2.0 BS-1363 11 kg (25 lbs.)

GRS-36-I 100 420 4.2 NEMA 5-15P 14 kg (30 lbs.)

120 550 4.6 NEMA 5-15P 14 kg (30 lbs.)

220 504 2.3 CEE 7/7 Schuko 14 kg (30 lbs.)

240 598 2.5 BS-1363 14 kg (30 lbs.)
220-230 (CE) 504-550 2.3-2.4 CEE 7/7 Schuko 14 kg (30 lbs.)
230-240 (CE) 550-598 2.4-2.5 BS-1363 14 kg (30 lbs.)

GRS-42-I* 100 540 5.4 NEMA 5-15P 15 kg (32 lbs.)

120 600 5.0 NEMA 5-15P 15 kg (32 lbs.)

220 548 2.5 CEE 7/7 Schuko 15 kg (32 lbs.)

240 652 2.7 BS-1363 15 kg (32 lbs.)
220-230 (CE) 548-600 2.5-2.6 CEE 7/7 Schuko 15 kg (32 lbs.)
230-240 (CE) 600-652 2.6-2.7 BS-1363 15 kg (32 lbs.)

GRS-48-I 100 600 6.0 NEMA 5-15P 16 kg (36 lbs.)

120 700 5.8 NEMA 5-15P 16 kg (36 lbs.)

220 640 3.0 CEE 7/7 Schuko 16 kg (36 lbs.)

240 760 3.2 BS-1363 16 kg (36 lbs.)
220-230 (CE) 640-700 3.0-3.1 CEE 7/7 Schuko 16 kg (36 lbs.)
230-240 (CE) 700-760 3.0-3.2 BS-1363 16 kg (36 lbs.)

GRS-54-I* 100 650 6.5 NEMA 5-15P 19 kg (42 lbs.)

120 800 6.7 NEMA 5-15P 19 kg (42 lbs.)

220 732 3.3 CEE 7/7 Schuko 19 kg (42 lbs.)

240 870 3.6 BS-1363 19 kg (42 lbs.)
220-230 (CE) 732-800 3.3-3.5 CEE 7/7 Schuko 19 kg (42 lbs.)
230-240 (CE) 800-870 3.5-3.6 BS-1363 19 kg (42 lbs.)

GRS-60-I 100 700 7.0 NEMA 5-15P 20 kg (44 lbs.)

120 900 7.5 NEMA 5-15P 20 kg (44 lbs.)

220 824 3.7 CEE 7/7 Schuko 20 kg (44 lbs.)

240 980 4.1 BS-1363 20 kg (44 lbs.)
220-230 (CE) 824-900 3.7-3.9 CEE 7/7 Schuko 20 kg (44 lbs.)
230-240 (CE) 900-980 3.9-4.1 BS-1363 20 kg (44 lbs.)

GRS-66-I* 100 770 7.7 NEMA 5-15P 23 kg (50 lbs.)

120 1000 8.3 NEMA 5-15P 23 kg (50 lbs.)

220 915 4.2 CEE 7/7 Schuko 23 kg (50 lbs.)

240 1088 4.5 BS-1363 23 kg (50 lbs.)
220-230 (CE) 915-1000 4.2-4.3 CEE-Schuko 23 kg (50 lbs.)
230-240 (CE) 1000-1088 4.3-4.5 BS-1363 23 kg (50 lbs.)

GRS-72-I 100 840 8.4 NEMA 5-15P 25 kg (56 lbs.)

120 1100 9.2 NEMA 5-15P 25 kg (56 lbs.)

220 1006 4.6 CEE 7/7 Schuko 25 kg (56 lbs.)

240 1196 5.0 BS-1363 25 kg (56 lbs.)
220-230 (CE) 1006-1100 4.6-4.8 CEE 7/7 Schuko 25 kg (56 lbs.)
230-240 (CE) 1100-1196 4.8-5.0 BS-1363 25 kg (56 lbs.)

8 Form No. GRSCEM-0702

SPECIFICATIONS

ELECTRICAL RATING CHART - STANDARD GRSB MODELS

† All GRSB models listed are only available in 50 cm (19-1/2") depth.
* Models that accommodate multiple food pans: 76 cm (30") = 2 pans, 107 cm (42") = 3 pans,

137 cm (54") = 4 pans, 168 cm (66") = 5 pans.

The electrical information in the shaded areas pertains to Export models only.

Model

†

Voltage Watts Amps Plug Configuration Shipping Weights

GRSB-24-I 100 550 5.5 NEMA 5-15P 10 kg (22 lbs.)

120 550 4.6 NEMA 5-15P 10 kg (22 lbs.)
220 550 2.5 CEE 7/7 Schuko 10 kg (22 lbs.)

240 550 2.3 BS-1363 10 kg (22 lbs.)
220-230 (CE) 550-601 2.5-2.6 CEE 7/7 Schuko 10 kg (22 lbs.)
230-240 (CE) 505-550 2.2-2.3 BS-1363 10 kg (22 lbs.)

GRSB-30-I* 100 665 6.7 NEMA 5-15P 11 kg (25 lbs.)

120 665 5.6 NEMA 5-15P 11 kg (25 lbs.)

220 665 3.0 CEE 7/7 Schuko 11 kg (25 lbs.)

240 665 2.8 BS-1363 11 kg (25 lbs.)
220-230 (CE) 665-727 3.0-3.2 CEE 7/7 Schuko 11 kg (25 lbs.)
230-240 (CE) 611-665 2.7-2.8 BS-1363 11 kg (25 lbs.)

GRSB-36-I 100 780 7.8 NEMA 5-15P 13 kg (29 lbs.)

120 780 6.5 NEMA 5-15P 13 kg (29 lbs.)

220 780 3.5 CEE 7/7 Schuko 13 kg (29 lbs.)

240 780 3.3 BS-1363 13 kg (29 lbs.)
220-230 (CE) 780-853 3.5-3.7 CEE 7/7 Schuko 13 kg (29 lbs.)
230-240 (CE) 716-780 3.1-3.3 BS-1363 13 kg (29 lbs.)

GRSB-42-I* 100 885 8.9 NEMA 5-15P 15 kg (33 lbs.)

120 885 7.4 NEMA 5-15P 15 kg (33 lbs.)

220 885 4.0 CEE 7/7 Schuko 15 kg (33 lbs.)

240 885 3.7 BS-1363 15 kg (33 lbs.)
220-230 (CE) 885-967 4.0-4.2 CEE 7/7 Schuko 15 kg (33 lbs.)
230-240 (CE) 813-885 3.5-3.7 BS-1363 15 kg (33 lbs.)

GRSB-48-I 100 1000 10.0 NEMA 5-15P 16 kg (36 lbs.)

120 1000 8.3 NEMA 5-15P 16 kg (36 lbs.)

220 1000 4.5 CEE 7/7 Schuko 16 kg (36 lbs.)

240 1000 4.2 BS-1363 16 kg (36 lbs.)
220-230 (CE) 1000-1093 4.5-4.7 CEE 7/7 Schuko 16 kg (36 lbs.)
230-240 (CE) 918-1000 4.0-4.2 BS-1363 16 kg (36 lbs.)

GRSB-54-I* 100 1110 11.1 NEMA 5-15P 19 kg (42 lbs.)

120 1110 9.3 NEMA 5-15P 19 kg (42 lbs.)

220 1110 5.0 CEE 7/7 Schuko 19 kg (42 lbs.)

240 1110 4.6 BS-1363 19 kg (42 lbs.)
220-230 (CE) 1110-1213 5.0-5.3 CEE 7/7 Schuko 19 kg (42 lbs.)
230-240 (CE) 1019-1110 4.4-4.6 BS-1363 19 kg (42 lbs.)

GRSB-60-I 100 1220 12.2 NEMA 5-15P 23 kg (50 lbs.)

120 1220 10.2 NEMA 5-15P 23 kg (50 lbs.)

220 1220 5.5 CEE 7/7 Schuko 23 kg (50 lbs.)

240 1220 5.1 BS-1363 23 kg (50 lbs.)
220-230 (CE) 1220-1333 5.5-5.8 CEE 7/7 Schuko 23 kg (50 lbs.)
230-240 (CE) 1120-1220 4.9-5.1 BS-1363 23 kg (50 lbs.)

GRSB-66-I* 120 1330 11.1 NEMA 5-15P 25 kg (54 lbs.)

220 1330 6.0 CEE 7/7 Schuko 25 kg (54 lbs.)

240 1330 5.5 BS-1363 25 kg (54 lbs.)
220-230 (CE) 1330-1454 6.0-6.3 CEE 7/7 Schuko 25 kg (54 lbs.)
230-240 (CE) 1221-1330 5.3-5.5 BS-1363 25 kg (54 lbs.)

GRSB-72-I 120 1440 12.0 NEMA 5-15P 26 kg (58 lbs.)

220 1440 6.5 CEE 7/7 Schuko 26 kg (58 lbs.)

240 1440 6.0 BS-1363 26 kg (58 lbs.)
220-230 (CE) 1440-1574 6.5-6.8 CEE 7/7 Schuko 26 kg (58 lbs.)
230-240 (CE) 1322-1440 5.8-6.0 BS-1363 26 kg (58 lbs.)

9

Form No. GRSCEM-0702

SPECIFICATIONS

† All GRSBF-I models listed are only available in 48 cm (19") depth.

All GRSBF-S models listed are only available in 61 cm (24") depth.
All GRSBF-O models listed are only available in 76 cm (30") depth.

The electrical information in the shaded areas pertains to Export models only.

ELECTRICAL RATING CHART - STANDARD GRSBF MODELS

Model

†

Voltage Watts Amps Plug Configuration Shipping Weights

GRSBF-24-I 100 550 5.5 NEMA 5-15P 10 kg (22 lbs.)

120 550 4.6 NEMA 5-15P 10 kg (22 lbs.)
220 550 2.5 CEE 7/7 Schuko 10 kg (22 lbs.)

240 550 2.3 BS-1363 10 kg (22 lbs.)
220-230 (CE) 550-601 2.5-2.6 CEE 7/7 Schuko 10 kg (22 lbs.)
230-240 (CE) 505-550 2.2-2.3 BS-1363 10 kg (22 lbs.)

GRSBF-24 S 120 700 5.8 NEMA 5-15P 11 kg (24 lbs.)
GRSBF-24-O 120 790 6.6 NEMA 5-15P 12 kg (26 lbs.)

240 790 3.3 BS-1363 12 kg (26 lbs.)

GRSBF-30-I 100 665 6.7 NEMA 5-15P 11 kg (25 lbs.)

120 665 5.6 NEMA 5-15P 11 kg (25 lbs.)

220 665 3.0 CEE 7/7 Schuko 11 kg (25 lbs.)

240 665 2.8 BS-1363 11 kg (25 lbs.)
220-230 (CE) 665-727 3.0-3.2 CEE 7/7 Schuko 11 kg (25 lbs.)
230-240 (CE) 611-665 2.7-2.8 BS-1363 11 kg (25 lbs.)

GRSBF-30-O 120 950 7.9 NEMA 5-15P 13 kg (29 lbs.)

240 1110 4.6 BS-1363 13 kg (29 lbs.)

GRSBF-36-I 100 780 7.8 NEMA 5-15P 13 kg (29 lbs.)

120 780 6.5 NEMA 5-15P 13 kg (29 lbs.)

220 780 3.5 CEE 7/7 Schuko 13 kg (29 lbs.)

240 780 3.3 BS-1363 13 kg (29 lbs.)
220-230 (CE) 780-853 3.5-3.7 CEE 7/7 Schuko 13 kg (29 lbs.)
230-240 (CE) 716-780 3.1-3.3 BS-1363 13 kg (29 lbs.)

GRSBF-36-S 120 950 7.9 NEMA 5-15P 15 kg (33 lbs.)

220 800 3.6 CEE 7/7 Schuko 15 kg (33 lbs.)

240 950 4.0 BS-1363 15 kg (33 lbs.)

GRSBF-36-O 120 1110 9.3 NEMA 5-15P 20 kg (44 lbs.)

220-230 (CE) 1110-1213 5.0-5.3 CEE 7/7 Schuko 20 kg (44 lbs.)
230-240 (CE) 1020-1110 4.4-4.6 BS-1363 20 kg (44 lbs.)

GRSBF-42-I 100 885 8.9 NEMA 5-15P 15 kg (32 lbs.)

120 885 7.4 NEMA 5-15P 15 kg (32 lbs.)

220 885 4.0 CEE 7/7 Schuko 15 kg (32 lbs.)

240 885 3.7 BS-1363 15 kg (32 lbs.)
220-230 (CE) 885-967 4.0-4.2 CEE 7/7 Schuko 15 kg (32 lbs.)
230-240 (CE) 813-885 3.5-3.7 BS-1363 15 kg (32 lbs.)

GRSBF-42-S 120 1100 9.2 NEMA 5-15P 16 kg (36 lbs.)
GRSBF-42-O 120 1270 10.6 NEMA 5-15P 18 kg (40 lbs.)
GRSBF-48-I 100 1000 10.0 NEMA 5-15P 15 kg (32 lbs.)

120 1000 8.3 NEMA 5-15P 15 kg (32 lbs.)

220 1000 4.5 CEE 7/7 Schuko 15 kg (32 lbs.)

240 1000 4.2 BS-1363 15 kg (32 lbs.)
220-230 (CE) 1000-1093 4.5-4.7 CEE 7/7 Schuko 15 kg (32 lbs.)
230-240 (CE) 918-1000 4.0-4.2 BS-1363 15 kg (32 lbs.)

GRSBF-48-S 120 1225 10.2 NEMA 5-15P 19 kg (41 lbs.)
GRSBF-48-O 120 1430 11.9 NEMA 5-15P 24 kg (54 lbs.)

240 1430 6.0 BS-1363 24 kg (54 lbs.)
220-230 (CE) 1430-1562 6.5-6.8 CEE 7/7 Schuko 24 kg (54 lbs.)
230-240 (CE) 1313-1430 5.7-6.0 BS-1363 24 kg (54 lbs.)

SPECIFICATIONS

† All GRSBF-I models listed are only available in 48 cm (19") depth.

All GRSBF-S models listed are only available in 61 cm (24") depth.
All GRSBF-O models listed are only available in 76 cm (30") depth.

The electrical information in the shaded areas pertains to Export models only.

ELECTRICAL RATING CHART - STANDARD GRSBF MODELS

10 Form No. GRSCEM-0702

Model

†

Voltage Watts Amps Plug Configuration Shipping Weights

GRSBF-60-I 100 1220 12.2 NEMA 5-15P 23 kg (50 lbs.)

120 1220 10.2 NEMA 5-15P 23 kg (50 lbs.)
220 1220 5.5 CEE 7/7 Schuko 23 kg (50 lbs.)

240 1220 5.1 BS-1363 23 kg (50 lbs.)
220-230 (CE) 1220-1333 5.5-5.8 CEE 7/7 Schuko 23 kg (50 lbs.)
230-240 (CE) 1120-1220 4.9-5.1 BS-1363 23 kg (50 lbs.)

GRSBF-60-S 120 1500 12.5 NEMA 5-20P 26 kg (58 lbs.)
GRSBF-60-O 120 1750 14.6 NEMA 5-20P 34 kg (75 lbs.)

240 1750 7.3 BS-1363 34 kg (75 lbs.)
220-230 (CE) 1750-1912 8.0-8.3 CEE 7/7 Schuko 34 kg (75 lbs.)
230-240 (CE) 1607-1750 7.0-7.3 BS-1363 34 kg (75 lbs.)

GRSBF-72-I 100 1440 14.4 NEMA 5-15P 26 kg (58 lbs.)

120 1440 12.0 NEMA 5-15P 26 kg (58 lbs.)

220 1440 6.5 CEE 7/7 Schuko 26 kg (58 lbs.)

240 1440 6.0 BS-1363 26 kg (58 lbs.)
220-230 (CE) 1440-1574 6.5-6.8 CEE 7/7 Schuko 26 kg (58 lbs.)
230-240 (CE) 1322-1440 5.8-6.0 BS-1363 26 kg (58 lbs.)

GRSBF-72-S 120 1750 14.6 NEMA 5-20P 30 kg (67 lbs.)
GRSBF-72-O 208 2070 10.0 NEMA 6-15P 40 kg (87 lbs.)

240 2070 8.6 NEMA 6-15P 40 kg (87 lbs.)
220-230 (CE) 2070-2262 9.4-9.8 CEE 7/7 Schuko 40 kg (87 lbs.)
230-240 (CE) 1901-2070 8.3-8.6 BS-1363 40 kg (87 lbs.)

11

Form No. GRSCEM-0702

SPECIFICATIONS

PLUG CONFIGURATIONS

Units are supplied from the factory with an electrical cord and plug
installed. Plugs are supplied according to the applications as shown
in 3 .

Plug unit into a grounded electrical outlet of the correct voltage,
size and plug configuration. If the plug and receptacle do not
match, contact a qualified electrician to determine the proper
voltage and size, and install the proper electrical outlet.

WARNING

DIMENSIONS - GRS MODELS SEE 4

Model Width (A) Depth (B) Height (C)

GRS-18-I 46 cm (18") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-24-I 61 cm (24") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-30-I 76 cm (30") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-36-I 91 cm (36") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-42-I 107 cm (42") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-48-I 122 cm (48") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-54-I 137 cm (54") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-60-I 152 cm (60") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-66-I 168 cm (66") 50 cm (19-1/2") 6 cm (2-1/4")

GRS-72-I 183 cm (72") 50 cm (19-1/2") 6 cm (2-1/4")

Model Width (A) Width (B) Depth (C) Depth (D) Height (E)

GRSB-24-I 65 cm (25-1/2") 61 cm (24") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-30-I 80 cm (31-1/2") 76 cm (30") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-36-I 95 cm (37-1/2") 91 cm (36") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-42-I 107 cm (42") 107 cm (42") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-48-I 126 cm (49-1/2") 122 cm (48") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-54-I 137 cm (54") 137 cm (54") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-60-I 156 cm (61-1/2") 152 cm (60") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-66-I 168 cm (66") 168 cm (66") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

GRSB-72-I 187 cm (73-1/2") 183 cm (72") 50 cm (19-1/2") 53 cm (21-1/2") 7 cm (2-3/4")

DIMENSIONS - GRSB MODELS SEE 5

SPECIFICATIONS

DIMENSIONS - GRSBF MODELS SEE 6

Model Width (A) Width (B) Depth (C) Depth (D) Height (E)

GRSBF-24-I 65 cm (25-1/2") 61 cm (24") 50 cm (19-1/2") 53 cm (21") 6 cm (2-1/4")

GRSBF-24-S 65 cm (25-1/2") 61 cm (24") 61 cm (24") 65 cm (25-1/2") 6 cm (2-1/4")

GRSBF-24-O 65 cm (25-1/2") 61 cm (24") 76 cm (30") 80 cm (31-1/2") 6 cm (2-1/4")

GRSBF-30-I 80 cm (31-1/2") 76 cm (30-3/32") 50 cm (19-1/2") 53 cm (21") 6 cm (2-1/4")

GRSBF-30-S 80 cm (31-1/2") 76 cm (30-3/32") 61 cm (24") 65 cm (25-1/2") 6 cm (2-1/4")

GRSBF-30-O 80 cm (31-1/2") 76 cm (30-3/32") 76 cm (30") 80 cm (31-1/2") 6 cm (2-1/4")

GRSBF-36-I 95 cm (37-1/2") 92 cm (36-3/32") 50 cm (19-1/2") 53 cm (21") 6 cm (2-1/4")

GRSBF-36-S 95 cm (37-1/2") 92 cm (36-3/32") 61 cm (24") 65 cm (25-1/2") 6 cm (2-1/4")

GRSBF-36-O 95 cm (37-1/2") 92 cm (36-3/32") 76 cm (30") 80 cm (31-1/2") 6 cm (2-1/4")

GRSBF-42-I 110 cm (43-1/2") 107 cm (42-3/32") 50 cm (19-1/2") 53 cm (21") 6 cm (2-1/4")

GRSBF-42-S 110 cm (43-1/2") 107 cm (42-3/32") 61 cm (24") 65 cm (25-1/2") 6 cm (2-1/4")

GRSBF-42-O 110 cm (43-1/2") 107 cm (42-3/32") 76 cm (30") 80 cm (31-1/2") 6 cm (2-1/4")

GRSBF-48-I 126 cm (49-1/2") 122 cm (48-3/32") 50 cm (19-1/2") 53 cm (21") 6 cm (2-1/4")

GRSBF-48-S 126 cm (49-1/2") 122 cm (48-3/32") 61 cm (24") 65 cm (25-1/2") 6 cm (2-1/4")

GRSBF-48-O 126 cm (49-1/2") 122 cm (48-3/32") 76 cm (30") 80 cm (31-1/2") 6 cm (2-1/4")

GRSBF-60-I 156 cm (61-1/2") 153 cm (60-3/32") 50 cm (19-1/2") 53 cm (21") 6 cm (2-1/4")

GRSBF-60-S 156 cm (61-1/2") 153 cm (60-3/32") 61 cm (24") 65 cm (25-1/2") 6 cm (2-1/4")

GRSBF-60-O 156 cm (61-1/2") 153 cm (60-3/32") 76 cm (30") 80 cm (31-1/2") 6 cm (2-1/4")

GRSBF-72-I 187 cm (73-1/2") 183 cm (72-3/32") 50 cm (19-1/2") 53 cm (21") 6 cm (2-1/4")

GRSBF-72-S 187 cm (73-1/2") 183 cm (72-3/32") 61 cm (24") 65 cm (25-1/2") 6 cm (2-1/4")

GRSBF-72-O 187 cm (73-1/2") 183 cm (72-3/32") 76 cm (30") 80 cm (31-1/2") 6 cm (2-1/4")

12 Form No. GRSCEM-0702

13

Form No. GRSCEM-0702

INSTALLATION

WARNING
For safe and proper operation, the unit must be located
a reasonable distance from combustible walls and materials.
If safe distances are not maintained, discoloration
or combustion could occur.

CAUTION
Locate the unit at the proper counter height, in an area that
is convenient for use. The location should be level to prevent
the shelf or its contents from accidentally falling, and strong
enough to support the weight of the unit and food.

CAUTION
The National Sanitation Foundation (NSF) requires that
GRS Series units over 91 cm (36") in length or weighing
more than 36 kg (80 lbs.) to be either sealed or raised
on the installation surface. If this unit cannot be sealed
at the point of use, 10 cm (4") legs are included to allow
for proper cleaning access below unit. See Hatco
ACCESSORIES for installation instructions.

GRS MODELS

1. Remove the unit from the carton and lay it upside down
on the cardboard.

2. Install the four metal feet into the corner holes on the base.
Tighten securely but do not overtighten.

NOTE: If 10 cm (4") legs are required, see ACCESSORIES
in this manual for installation instructions.

3. Place one rubber boot over each metal foot.

4. Turn unit upright and position warmer in desired location.

GRSB & GRSBF MODELS

1. Remove the unit from the carton and lay it upside down
on the cardboard.

2. Remove and save the four screws (8-32) from the underside
of the unit. See 7 .

NOTE: The control box may be moved to the most convenient
location on the underside of the unit. For semi-remote installations,
we recommend you leave the control in place until the unit is placed
into the countertop. See 12 .

CAUTION
Damage to countertop material caused by heat generated
from Hatco equipment is not covered under the Hatco
warranty. Contact the manufacturer of the base material

for application information.

3. Place the unit into the countertop opening. See 9
for recommended countertop cutout dimensions.

4. Assemble the Z-brackets to the underside of the unit using
the four screws removed in step 2.

NOTE: Units 122 cm (48") or longer require two additional
Z-brackets installed midway along the front and rear of the unit.

5. Adjust the 1/4-20 screws on the Z-brackets until the top flange
lies flat on the countertop.

CAUTION
Use of excessive force when tightening mounting screws may
damage unit or countertop (GRSB and GRSBF units).

6. If you wish to move the control box to a semi-remote location,
remove it from the bottom of the unit. If necessary, remove
the end brackets from the control box, rotate and reposition
them. The control box will require a hole mounting pattern
of 7-5/8" x 1" x 1/4" for #8 screws. See 12 for mounting
distances.

7. Once all components are secured, the unit may be plugged
in and turned on.

NOTE: A 183 cm (6') cord is supplied with this appliance; any
excess cord should be neatly routed so it does not hang down.

14 Form No. GRSCEM-0702

COUNTERTOP CUTOUT SEE 9

MODEL MINIMUM WIDTH MAXIMUM WIDTH MINIMUM DEPTH MAXIMUM DEPTH

GRSB-24-I 62 cm (24-1/2") 63 cm (24-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-30-I 77 cm (30-1/2") 78 cm (30-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-36-I 92 cm (36-1/2") 93 cm (36-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-42-I 108 cm (42-1/2") 109 cm (42-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-48-I 123 cm (48-1/2") 124 cm (48-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-54-I 138 cm (54-1/2") 139 cm (54-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-60-I 153 cm (60-1/2") 154 cm (60-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-66-I 169 cm (66-1/2") 170 cm (66-3/4") 51 cm (20") 52 cm (20-1/4")
GRSB-72-I 184 cm (72-1/2") 185 cm (72-3/4") 51 cm (20") 52 cm (20-1/4")

GRSBF-24-I 62 cm (24-1/2") 63 cm (24-3/4") 51 cm (20") 52 cm (20-1/4")
GRSBF-24-S 62 cm (24-1/2") 63 cm (24-3/4") 62 cm (24-1/2") 63 cm (24-3/4")
GRSBF-24-O 62 cm (24-1/2") 63 cm (24-3/4") 77 cm (30-1/2") 78 cm (30-3/4")

GRSBF-30-I 77 cm (30-1/2") 78 cm (30-3/4") 51 cm (20") 52 cm (20-1/4")
GRSBF-30-S 77 cm (30-1/2") 78 cm (30-3/4") 62 cm (24-1/2") 63 cm (24-3/4")
GRSBF-30-O 77 cm (30-1/2") 78 cm (30-3/4") 77 cm (30-1/2") 78 cm (30-3/4")

GRSBF-36-I 92 cm (36-1/2") 93 cm (36-3/4") 51 cm (20") 52 cm (20-1/4")
GRSBF-36-S 92 cm (36-1/2") 93 cm (36-3/4") 62 cm (24-1/2") 63 cm (24-3/4")
GRSBF-36-O 92 cm (36-1/2") 93 cm (36-3/4") 77 cm (30-1/2") 78 cm (30-3/4")

GRSBF-42-I 108 cm (42-1/2") 109 cm (42-3/4") 51 cm (20") 52 cm (20-1/4")
GRSBF-42-S 108 cm (42-1/2") 109 cm (42-3/4") 62 cm (24-1/2") 63 cm (24-3/4")
GRSBF-42-O 108 cm (42-1/2") 109 cm (42-3/4") 77 cm (30-1/2") 78 cm (30-3/4")

GRSBF-48-I 123 cm (48-1/2") 124 cm (48-3/4") 51 cm (20") 52 cm (20-1/4")
GRSBF-48-S 123 cm (48-1/2") 124 cm (48-3/4") 62 cm (24-1/2") 63 cm (24-3/4")
GRSBF-48-O 123 cm (48-1/2") 124 cm (48-3/4") 77 cm (30-1/2") 78 cm (30-3/4")

GRSBF-60-I 154 cm (60-1/2") 154 cm (60-3/4") 51 cm (20") 52 cm (20-1/4")
GRSBF-60-S 154 cm (60-1/2") 154 cm (60-3/4") 62 cm (24-1/2") 63 cm (24-3/4")
GRSBF-60-O 154 cm (60-1/2") 154 cm (60-3/4") 77 cm (30-1/2") 78 cm (30-3/4")

GRSBF-72-I 184 cm (72-1/2") 185 cm (72-3/4") 51 cm (20") 52 cm (20-1/4")
GRSBF-72-S 184 cm (72-1/2") 185 cm (72-3/4") 62 cm (24-1/2") 63 cm (24-3/4")
GRSBF-72-O 184 cm (72-1/2") 185 cm (72-3/4") 77 cm (30-1/2") 78 cm (30-3/4")

INSTALLATION

15

Form No. GRSCEM-0702

OPERATION

ALL MODELS

1. Plug cabinet into an electrical outlet of the correct voltage, size

and plug configuration. See SPECIFICATIONS for details.

2. Turn the Power Switch to the ON position. See 10 and 11 .

3. Turn the thermostat to the desired temperature settings.

4. Allow unit 15-20 minutes to reach operating temperature.

CAUTION
Some exterior surfaces on the unit will get hot. Use caution
when touching these areas to avoid injury.

MAINTENANCE

CLEANING

The Hatco Glo-Ray Heated Shelf units are designed for maximum
durability and performance, with minimum maintenance.

WARNING
To avoid any injury, turn the power switch off, unplug the unit
from the power source and allow to cool before performing
any maintenance.

WARNING
The Glo-Ray Heated Shelf is not waterproof. DO NOT
submerge in water. Do not operate if it has been submerged
in water.

WARNING
This appliance is not of jet-proof construction. Do not use
jet-clean-spray to clean this appliance.

To preserve the finish of the Glo-Ray Heated Shelf,
it is recommended that the surfaces be wiped daily with a damp
cloth. Stubborn stains may be removed with a good stainless steel
cleaner or a non-abrasive cleaner. Hard to reach areas should
be cleaned with a small brush and mild soap.

CAUTION
Abrasive cleaners could scratch the finish of your Glo-Ray
Heated Shelf.

WARNING
If service is required on this unit, contact your Authorized
Hatco Service Agent, or contact the Hatco Service Department
at 800-558-0607 or 414-671-6350; fax [phone]
or International fax [phone].

WARNING
This product has no “user” serviceable parts. To avoid damage
to the unit or injury to personnel, use only Authorized Hatco
Service Agents and Genuine Hatco Replacement Parts when
service is required.

WARNING
Genuine Hatco Replacement Parts are specified to operate
safely in the environments in which they are used. Some
aftermarket or generic replacement parts do not have
the characteristics that will allow them to operate safely
in Hatco equipment. It is essential to use Hatco Replacement
Parts when repairing Hatco equipment. Failure to use Hatco
Replacement Parts may subject operators of the equipment
to hazardous electrical voltage, resulting in electrical
shock or burn.

ACCESSORIES

10 CM (4") ADJUSTABLE LEGS
(GRS MODELS)

Carefully lay unit on its side. Install legs to bottom of unit as shown
in 8A and 8B . Hand tighten legs until snug. Do not overtighten.
Return unit to the upright position.

WARNING
Do not lay unit on the side with the control panel or damage
to unit could occur.

NOTE: Legs are adjustable for leveling the unit. Use
a 14 mm (9/16") open-end wrench to make leveling adjustments
once the unit is placed in final position.

16 Form No. GRSCEM-0702

1. PRODUCT WARRANTY

Hatco warrants the products that it manufactures (the “Products”)
to be free from defects in materials under normal use and service,
for a period of one (1) year from the date of purchase when
installed and maintained in accordance with Hatco’s written
instructions or 18 months from the date of shipment from Hatco.
Buyer must establish the product’s purchase date by returning
Hatco’s Warranty Registration Card or by other means satisfactory
to Hatco in its sole discretion.

Hatco warrants the following Product components to be free from
defects in materials from the date of purchase (subject to the
foregoing conditions) for the period(s) of time and on the conditions
listed below:

a) One (1) Year Parts PLUS One (1)

Additional Year Parts-Only Warranty:

Toaster Elements (metal sheathed)
Drawer Warmer Elements (metal sheathed)
Drawer Warmer Drawer Rollers and Slides
Food Warmer Elements (metal sheathed)
Infra-Black

®

Elements (metal sheathed)
Display Warmer Elements (metal sheathed air heating)
Holding Cabinet Elements (metal sheathed air heating)
Cook and Hold Oven Elements (metal sheathed)

b) One (1) Year Parts PLUS Four (4)

Additional Years Parts-Only Warranty on
pro-rated terms that Hatco will explain at
Buyer’s Request:

Powermite®Gas Booster Heater Tanks
Mini Compact Tanks (stainless steel)
3CS and FR Tanks

c) One (1) Year Parts PLUS Four (4)

Additional Years Parts-Only Warranty PLUS
Five (5) Year Parts-Only Warranty on
pro-rated terms that Hatco will explain at Buyer’s
Request:

Booster Heater Tanks (Castone

®

)

d) One (1) Year Parts-Only Warranty

for Accessory Components not installed by Hatco:

Accessory Components (including but not limited to valves,
gauges, remote switches and remote wiring).

THE FOREGOING WARRANTIES ARE EXCLUSIVE
AND IN LIEU OF ANY OTHER WARRANTY, EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR PATENT OR OTHER
INTELLECTUAL PROPERTY RIGHT INFRINGEMENT. Without
limiting the generality of the foregoing, SUCH WARRANTIES
DO NOT COVER: Coated incandescent light bulbs, fluorescent
lamps, lamp warmer heat bulbs, glass components or Product
failure in booster tank and fin tube heat exchanger caused by
liming, sediment buildup, chemical attack or freezing in tanks,
Product misuse, tampering or misapplication, improper installation,
application of improper voltage, or recalibration of thermostats
or high limit switches.

2. LIMITATION OF REMEDIES
AND DAMAGES

Hatco’s liability and Buyer’s exclusive remedy hereunder will
be limited solely, at Hatco’s option, to repair or replace defective
part or unit by a Hatco-authorized service agency with respect
to any claim made within the applicable warranty period. Hatco
reserves the right to accept or reject any such claim in whole
or in part. Hatco will not accept the return of any Product without
prior written approval from Hatco, and all such approved returns
shall be made at Buyer’s sole expense. HATCO WILL NOT BE
LIABLE, UNDER ANY CIRCUMSTANCES, FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, INCLUDING
BUT NOT LIMITED TO LABOR COSTS OR LOST PROFITS
RESULTING FROM THE USE OF OR INABILITY TO USE
THE PRODUCTS OR FROM THE PRODUCTS BEING
INCORPORATED IN OR BECOMING A COMPONENT
OF ANY OTHER PRODUCT OR GOODS.

HATCO EXPORT LIMITED WARRANTY

NOTES

77

Form No. GRSCEM-0702

NOTES

78 Form No. GRSCEM-0702

HATCO CORPORATION

P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A.

[phone] [phone]

Parts & Service Fax [phone] Int’l. Fax [phone]

www.hatcocorp.com

Part No. 07.04.231.00 Form No. GRSCEM-0702

Printed in U.S.A. July 2002

IMPORTANT OWNER INFORMATION

Record the model number, serial number, voltage and purchase date
of your unit in the spaces below. Please have this information
available when calling Hatco for service assistance.

Model No.______________________________________________

Serial No. ______________________________________________

Voltage ________________________________________________

Date of Purchase ________________________________________

Schreiben Sie die Modellbezeichnung, die Seriennummer,
die Spannung und das Kaufdatum in die folgenden Zeilen. Haben
Sie bitte dies Information zur Hand, wenn Sie Hatco wegen einer
Service-Unterstützung anrufen.

Modellbezeichnung ______________________________________

Seriennummer __________________________________________

Spannung ______________________________________________

Kaufdatum______________________________________________

Indicare il numero del modello, il numero di serie, la tensione
di alimentazione e la data di acquisto della propria unità negli spazi
di seguito. Queste informazioni dovranno essere fornite nel
momento in cui verrà richiesta l’assistenza Hatco.

N. del modello __________________________________________

N. di serie ______________________________________________

Tensione di alimentazione ________________________________

Data di acquisto ________________________________________

Noteer het modelnummer, serienummer, de spanning en de
aankoopdatum van uw apparaat in de ruimte onderaan. Zorg ervoor
dat u deze informatie ter beschikking hebt als u Hatco voor
service belt.

Modelnr. ______________________________________________

Serienr. ________________________________________________

Spanning ______________________________________________

Aankoopdatum __________________________________________

Anote el número de modelo, número de serie, voltaje y fecha
de compra de su unidad en los espacios a continuación. Por favor,
tenga esta información disponible cuando llame a Hatco para
recibir asistencia técnica.

Modelo No. ____________________________________________

Serie No. ______________________________________________

Voltaje ________________________________________________

Fecha de compra ________________________________________

Noter le numéro de modèle, le numéro de série, le voltage et
la date d’achat de votre appareil ci-dessous. Veuillez avoir cette
information à portée de la main si vous appelez Hatco pour
assistance.

Modèle No. ____________________________________________

Numéro de série ________________________________________

Voltage ________________________________________________

Date d’achat ____________________________________________
