Page 1
GLO-RAY
®
Multi-Staging Warmer
GRMW Series
Installation &
Operating Manual
I&W #07.05.157.00
This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you’re unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.
Page 2
Form No. GRMWM-0107
i
CONTENTS
INTRODUCTION
The Hatco Glo-Ray®GRMW Series Warmers are
perfect for holding prepared foods at kitchen work
areas. These warmers hold hot prepared food
products and keep them at optimum serving
temperatures without affecting quality. Prefocused
infrared heat from above and a thermostatically
controlled heated base extends the holding times of
the food product. The upper infrared heating
element is guaranteed against burnout and
breakage for two years and the base blanket
heating element for one year.
This manual provides the installation, safety
and operating instructions for the Glo-Ray MultiStaging Warmer. We recommend all installation,
operating and safety instructions appearing in this
manual be read prior to installation or operation of
your Hatco Multi-Staging Warmer. Safety
instructions that appear in this manual after a
warning symbol and the words WARNING or
CAUTION printed in bold face are very important.
WARNING means there is the possibility of
serious injury or death to yourself or others.
CAUTION means there is the possibility of minor
or moderate injury. CAUTION without the symbol
signifies the possibility of equipment or property
damage only.
Hatco Glo-Ray Multi-Staging Warmers are a product
of extensive research and field testing.
The materials used were selected for maximum
durability, attractive appearance and optimum
performance. Every unit is thoroughly inspected
and tested prior to shipment.
Important Owner Information...............................i
Introduction ...........................................................i
Important Safety Information ..............................1
Model Descriptions..............................................2
All Models........................................................2
GRMW-.5 ........................................................2
GRMW-3 .........................................................2
GRMW-4 .........................................................2
Specifications.......................................................3
Plug Configuration...........................................3
Electrical Rating Chart ....................................3
Dimensions......................................................3
Installation............................................................4
Unpacking .......................................................4
Location...........................................................4
Operation..............................................................5
General............................................................5
Two-Product Electronic Timer.........................5
Drawer Operation............................................5
Maintenance .........................................................6
General............................................................6
Timer Programming.........................................6
Thermostat Adjustment ..................................7
Drawer Removal Procedure ............................8
Drawer Slide Removal Procedure...................8
Cleaning..........................................................8
Hatco Limited Warranty.......................................9
Authorized Parts Distributors............Back Cover
IMPORTANT OWNER INFORMATION
Business 8:00 a.m. to 5:00 p.m.
Hours: Central Standard Time
(Summer Hours: June to September –
8:00 a.m. to 5:00 p.m. C.D.T.
Monday through Thursday
8:00 a.m. to 2:30 p.m. C.D.T. Friday)
Telephone: (800) 558-0607; (414) 671-6350
Fax: (800) 690-2966 (Parts & Service)
(414) 671-3976 (International)
Additional information can be found by visiting our
web site at www.hatcocorp.com
24-Hour 7-Day Parts & Service
Assistance available in the United
States and Canada by calling
(800) 558-0607.
Record the model number, serial number
(identification decal located on the lower right hand
side, front corner of the unit), voltage and purchase
date of your Glo-Ray
®
Multi-Staging Warmer in the
spaces below. Please have this information
available when calling Hatco for service assistance.
Model No. ________________________________
Serial No. ________________________________
Voltage __________________________________
Date of Purchase __________________________
Page 3
Form No. GRMWM-0107
1
IMPORTANT SAFETY INFORMATION
IMPORTANT! Read the following important safety information to avoid personal injury or
death, and to avoid damage to the equipment or property.
WARNINGS
Genuine Hatco Replacement Parts are
specified to operate safely in the
environments in which they are used. Some
aftermarket or generic replacement parts do
not have the characteristics that will allow
them to operate safely in Hatco equipment. It
is essential to use Hatco Replacement Parts
when repairing Hatco equipment. Failure to
use Hatco Replacement Parts may subject
operators of the equipment to hazardous
electrical voltage, resulting in electrical
shock or burn.
CAUTIONS
To avoid any injury or damage locate the unit
at the proper counter height, in an area that is
convenient for use. The location should be
level to prevent the unit or its contents from
accidentally falling, and strong enough to
support the weight of the unit and food.
Unit is not weatherproof. For safe and proper
operation the unit must be located indoors
where the ambient air temperature is
a minimum of 70°F (21°C) and a maximum of
85°F (29°C).
CAUTIONS
Use only non-abrasive cleaners. Abrasive
cleaners could scratch the finish of your unit
marring its appearance and making it
susceptible to soil accumulation.
WARNINGS
Plug unit into a properly grounded electrical
outlet of the correct voltage, size and plug
configuration. If the plug and receptacle do
not match, contact a qualified electrician to
determine the proper voltage and size and
install the proper electrical outlet.
To avoid any injury, turn the power switch
OFF, unplug the unit from the power source
and allow to cool completely before
performing any maintenance or cleaning.
For safe and proper operation, the unit must
be located a reasonable distance from
combustible walls and materials. If safe
distances are not maintained, discoloration
or combustion could occur.
To avoid electrical shock or personal injury,
do not steam clean or use excessive water on
the unit.
Some exterior surfaces on the unit will get
hot. Use caution when touching these areas
to avoid injury.
Unit is not waterproof. DO NOT submerge in
water. Do not operate if it has been
submerged in water.
To avoid any injury or damage to the unit do
not pull unit by power cord.
To prevent any injury, discontinue use if
power cord is frayed or worn.
To avoid any injury or damage to the unit,
thermostat adjustments must only be
performed by authorized personnel.
If service is required on this unit, contact your
Authorized Hatco Service Agent, or contact
the Hatco Service Department at 800-5580607 or 414-671-6350; fax 800-690-2966 or
International fax 414-671-3976.
This product has no “user” serviceable parts.
To avoid damage to the unit or injury to
personnel, use only Authorized Hatco Service
Agents and Genuine Hatco Parts when
service is required.
Page 4
Form No. GRMWM-0107
2
MODEL DESCRIPTIONS
ALL MODELS
All models are constructed of aluminum and
stainless steel, featuring a power on/off switch, a
thermostatically controlled hardcoated heated base,
infrared upper heating element, polycarbonate front
access door, and a 6' (1829 mm) cord and plug set.
GRMW-.5 MODEL
The GRMW-.5 model features a sliding pullout
drawer assembly and comes with a pan holder
equipped to hold one half-size pan, 2-1/2" (64 mm)
deep.
GRMW-3 MODEL
The GRMW-3 series features a sliding pullout
drawer and comes equipped with two pan dividers
designed to hold up to three 1/3 size pans, 2-1/2"
(64 mm) deep. An optional Two-Product Electronic
Timer with several programmable settings is
available.
NOTE: The Two-Product Electronic Timer is not
available for retrofit and only available with the
GRMW-3 model.
GRMW-4 MODEL
The GRMW-4P model features a sliding pullout
drawer and comes equipped with three pan dividers
designed to hold up to four 1/3 size pans, 2-1/2"
(64 mm) deep.
Figure 1. Glo-Ray GRMW-4
NOTE: Pans not supplied by Hatco. Pans must be
suitable for high temperature applications.
Page 5
Form No. GRMWM-0107
3
SPECIFICATIONS
Model Voltage Watts Amps Plug Configuration Shipping Weight
GRMW-.5 120 450 3.7 NEMA 5-15P 48 lbs. (22 kg)
GRMW-3 120 710 5.9 NEMA 5-15P 50 lbs. (23 kg)
GRMW-4 120 900 7.5 NEMA 5-15P 55 lbs. (25 kg)
ELECTRICAL RATING CHART
PLUG CONFIGURATION
Units are supplied from the factory with an electrical
cord and plug installed. Plugs are supplied
according to the applications. (See Figure 2.)
WARNING
Plug unit into a properly grounded electrical
outlet of the correct voltage, size and plug
configuration. If the plug and receptacle do not
match, contact a qualified electrician to
determine the proper voltage and size and
install the proper electrical outlet.
NEMA 5-15P
Figure 2. Plug Configuration
Width Depth Height
Model (A) (B) (C)
GRMW-.5 15-7/8" 17-7/8" 15-1/8"
(403 mm) (454 mm) (384 mm)
GRMW-3 26-5/8" 17-7/8" 15-1/8"
(676 mm) (454 mm) (384 mm)
GRMW-3
* 26-5/8" 18-1/4" 16-1/2"
(676 mm) (464 mm) (419 mm)
GRMW-4 34-1/2" 17-3/8" 15-1/8"
(876 mm) (441 mm) (384 mm)
DIMENSIONS
Figure 3. Dimensions
A
C
B
NOTE: Shipping weight includes packaging.
* GRMW-3 with Two-Product Electronic Timer
*
*Receptacle not supplied by Hatco.
Page 6
Form No. GRMWM-0107
4
INSTALLATION
UNPACKING
Glo-Ray®Multi-Staging Warmers are shipped with
most components pre-assembled. Care should be
taken when unpacking shipping carton to avoid
damage to unit and components enclosed.
1. Remove unit from box.
2. Remove information packet. To prevent delay
in obtaining warranty coverage, fill out and
mail in the warranty card.
3. Remove tape and protective packaging from
all surfaces of unit.
4. The GRMW-3 and GRMW-4 series units are
supplied with pan dividers. To install them, place
the dividers in the channels provided.
(See Figure 4.)
LOCATION
NOTE: Unit must be transported in the upright
position.
For proper operation and maximum performance,
locate the Multi-Staging Warmer in an area where
the ambient air temperature is constant and is
a minimum of 70°F (21°C). Areas which are
susceptible to active air movements or currents
should be avoided, i.e., near exhaust fans, hoods
and air conditioning ducts.
CAUTION
Unit is not weatherproof. For safe and proper
operation the unit must be located indoors
where the ambient air temperature is a minimum
of 70°F (21°C) and a maximum of 85°F (29°C).
Figure 4. Installing Pan Dividers
WARNING
For safe and proper operation, the unit must
be located a reasonable distance from
combustible walls and materials. If safe
distances are not maintained, discoloration or
combustion could occur.
CAUTION
To avoid any injury or damage locate the unit at
the proper counter height, in an area that is
convenient for use. The location should be level
to prevent the unit or its contents from
accidentally falling, and strong enough to
support the weight of the unit and food.
Page 7
Form No. GRMWM-0107
5
OPERATION
GENERAL
1. Plug unit into a properly grounded electrical
outlet of the correct voltage, size and plug
configuration (see SPECIFICATIONS for
details).
2. To begin operation, place the ON/OFF toggle
switch in the ON position. Allow 20-30 minutes
for the unit to reach operating temperatures.
WARNING
To avoid any injury or damage to the unit do not
pull unit by power cord.
WARNING
To prevent any injury, discontinue use if power
cord is frayed or worn.
WARNING
Some exterior surfaces on the unit will get hot.
Use caution when touching these areas to avoid
injury.
NOTE: The unit comes equipped with a thermostat
that is factory preset. If an adjustment is necessary
please follow the THERMOSTAT ADJUSTMENT
PROCEDURE.
TWO-PRODUCT ELECTRONIC TIMER
The Two-Product Timer is optional only on the
GRMW-3 and is not available for retrofit. Read and
keep these instructions for future reference.
NOTE: Always stand and face the side of the
warmer with the timer panel when reviewing the
timer instructions.
1. Turn power to unit on. LED lights on timer control
panel turn solid red.
2. Press the desired Arrow button. The LED light for
the pressed timer button turns solid green. Timer
begins to count down from preset time values.
With 3 minutes remaining (preset time value) the
green LED light starts blinking and the buzzer
sounds indicating the hold time will expire soon.
3. Press the Arrow button closest to the blinking
LED light to turn off the buzzer.
After time elapses to zero the buzzer sounds
again and the blinking green LED light turns red
and continues blinking advising that time has
expired.
4. Press the Arrow button closest to the blinking
LED light to turn off the buzzer. LED light
changes from blinking red to solid red.
NOTE: To view or edit current electronic timer
settings, see TIMER PROGRAMMING in the
maintenance section.
DRAWER OPERATION
1. Open product holding drawer by gently pulling
drawer handle outward. As the drawer moves out
the access door automatically opens.
2. The access door stays completely open by itself
when the drawer is pulled all of the way out.
Loading and unloading of food product should
be done when the drawer is completely open.
3. To close door, gently push handle until drawer
is securely shut.
HATCO CORP.
MILWAUKEE, WI U.S.A.
TIMER 2TIMER 1
GLO-RAY
FOODWARMER
Figure 5. Two-Product Electronic Timer Control Panel
LED Light
Time Value Display
Time Value Display
Left Pan Arrow
LED Light
Right Pan Arrow
Page 8
3. Press either Arrow button so 01 or 02 displays on
the left. Display 01 to change the total hold time
value. Display 02 to change the time the expired
warning signals appear.
4. Press and hold the RIGHT Arrow button for three
seconds, red LED for the selected pan will blink.
5. Press LEFT Arrow button to increase or RIGHT
Arrow button to decrease to the desired setting.
6. When the desired setting is displayed, press and
hold the RIGHT Arrow button for three seconds.
The red LED will turn solid and the desired
setting will be saved.
7. Repeat steps 2 - 6 to change setting for other
pan if desired.
8. Press BOTH Arrow buttons simultaneously to
exit programming mode and save settings. The
unit is now set for normal mode operation.
Form No. GRMWM-0107
6
GENERAL
Glo-Ray®Multi-Staging Warmers are designed for
maximum durability and performance, with minimum
maintenance.
WARNING
To avoid any injury, turn the power switch OFF,
unplug the unit from the power source and allow
to cool completely before performing any
maintenance or cleaning.
WARNING
To avoid electrical shock or personal injury, do
not steam clean or use excessive water on the
unit.
WARNING
Unit is not waterproof. DO NOT submerge in
water. Do not operate if it has been submerged
in water.
TIMER PROGRAMMING
To view or edit the preset time values of either the
Left Pan Arrow or the Right Pan Arrow follow steps
1 - 8. (See Figure 6.)
1. Turn the unit on, then simultaneously press
BOTH Arrow buttons for five seconds. The red
LED for the selected pan will turn on and both
displays will show number values.
2. Press BOTH Arrow buttons simultaneously to
toggle between the pans until the desired pan is
selected.
MAINTENANCE
HATCO CORP.
MILWAUKEE, WI U.S.A.
TIMER 2TIMER 1
GLO-RAY
FOODWARMER
Figure 6. Two-Product Electronic Timer Control Panel
LED Light
Time Value Display
Time Value Display
Left Pan Arrow
LED Light
Right Pan Arrow
Page 9
THERMOSTA T ADJUSTMENT
(GRMW-3 and GRMW-4 Only) (See Figure 7)
WARNING
To avoid any injury or damage to the unit
thermostat adjustments must only be performed
by authorized personnel.
1. Place the power switch on the OFF position
and unplug the unit from the power source.
2. Allow unit to cool for 20-30 minutes.
3. Loosen, but do not remove, “middle” screw
for proper access to thermostat adjustment slide.
Place slide in up position.
4. Using a small, straight blade screwdriver
positioned in the access hole, turn the
adjustment screw clockwise to increase the
temperature and counterclockwise to decrease.
5. Plug unit into power supply and place the toggle
switch in the ON position. The unit will reach
operating temperature in 20-30 minutes.
Front Door
“Middle” Screw/Slide
Adjustment Screw
Form No. GRMWM-0107
7
MAINTENANCE
Figure 7. Thermostat Adjustment Procedure
(GRMW-3 and GRMW-4 only)
Page 10
Form No. GRMWM-0107
8
MAINTENANCE
Figure 8. Disconnecting Drawer from Door
Door Linkage
Door Linkage
DRAWER REMOVAL PROCEDURE
To remove the drawer for cleaning, follow these
steps.
1. Pull drawer all the way out until access door
stays open.
2. While supporting door, disconnect door linkages
from drawer by lifting up outer sleeve of linkage
and gently pulling away from connection.
(See Figure 8.)
3. Lift drawer up and out of slides to remove.
DRAWER SLIDE REMOVAL
PROCEDURE
To remove drawer slides for cleaning, follow these
steps.
1. Support access door.
2. Push slides all the way into the warmer cavity.
3. Gently twist slide outward from the bottom and lift
off.
CLEANING
CAUTION
Use only non-abrasive cleaners. Abrasive
cleaners could scratch the finish of your unit
marring its appearance and making it
susceptible to soil accumulation.
To preserve the bright finish of the Glo-Ray MultiStaging Warmer, it is recommended that the exterior
and interior surfaces be wiped daily with a damp
cloth. Stubborn stains may be removed with a good
non-abrasive cleaner. Hard to reach areas should
be cleaned with a soft brush and mild soap.
Wipe off the polycarbonate front door using a soft,
clean, damp cloth. Do not use glass cleaner.
Glass cleaner may scratch or crack the
polycarbonate surface.
WARNING
If service is required on this unit, contact your
Authorized Hatco Service Agent, or contact the
Hatco Service Department at 800-558-0607 or
414-671-6350; fax 800-690-2966 or International
fax 414-671-3976.
WARNING
This product has no “user” serviceable parts. To
avoid damage to the unit or injury to personnel,
use only Authorized Hatco Service Agents and
Genuine Hatco Parts when service is required.
WARNING
Genuine Hatco Replacement Parts are specified
to operate safely in the environments in which
they are used. Some aftermarket or generic
replacement parts do not have the
characteristics that will allow them to operate
safely in Hatco equipment. It is essential to use
Hatco Replacement Parts when repairing Hatco
equipment. Failure to use Hatco Replacement
Parts may subject operators of the equipment to
hazardous electrical voltage, resulting in
electrical shock or burn.
Page 11
Form No. GRMWM-0107
9
HATCO LIMITED WARRANTY
1. PRODUCT WARRANTY
Hatco warrants the products that it manufactures
(the “Products”) to be free from defects in
materials and workmanship, under normal
use and service, for a period of one (1) year from
the date of purchase when installed and
maintained in accordance with Hatco’s written
instructions or 18 months from the date of
shipment from Hatco. Buyer must establish the
product’s purchase date by returning Hatco’s
Warranty Registration Card or by other means
satisfactory to Hatco in its sole discretion.
Hatco warrants the following Product components
to be free from defects in materials and
workmanship from the date of purchase (subject
to the foregoing conditions) for the period(s) of
time and on the conditions listed below:
a) One (1) Year Parts and Labor PLUS One
(1) Additional Year Parts-Only Warranty:
Toaster Elements (metal sheathed)
Drawer Warmer Elements (metal sheathed)
Drawer Warmer Drawer Rollers and Slides
Food Warmer Elements (metal sheathed)
Display Warmer Elements (met al sheathed
air heating)
Holding Cabinet Elements (metal sheathed
air heating)
b) One (1) Year Parts and Labor PLUS Four
(4) Years Parts-Only Warranty on
pro-rated terms that Hatco will explain
at Buyer’s request:
3CS and FR Tanks
c) One (1) Year Parts and Labor PLUS Nine
(9) Years Parts-Only Warranty on:
Electric Booster Heater Tanks
Gas Booster Heater Tanks
THE FOREGOING WARRANTIES ARE
EXCLUSIVE AND IN LIEU OF ANY OTHER
WARRANTY, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE
OR PATENT OR OTHER INTELLECTUAL
PROPERTY RIGHT INFRINGEMENT. Without
limiting the generality of the foregoing, SUCH
WARRANTIES DO NOT COVER: Coated
incandescent light bulbs, fluorescent lights, lamp
warmer heat bulbs, glass components, Product
failure in booster tank, fin tube heat exchanger, or
other water heating equipment, caused
by liming, sediment buildup, chemical attack or
freezing, Product misuse, tampering or
misapplication, improper installation or application of
improper voltage.
2. LIMITATION OF REMEDIES AND
DAMAGES
Hatco’s liability and Buyer’s exclusive remedy
hereunder will be limited solely, at Hatco’s option,
to repair or replacement by a Hatco-authorized
service agency (other than where Buyer is
located outside of the United States, Canada,
United Kingdom or Australia in which case
Hatco’s liability and Buyer’s exclusive remedy
hereunder will be limited solely to replacement of
part under warranty) with respect to any claim
made within the applicable warranty period
referred to above. Hatco reserves the right to
accept or reject any such claim in whole or in part.
Hatco will not accept the return of any Product
without prior written approval from Hatco, and all
such approved returns shall be made at Buyer’s
sole expense. HATCO WILL NOT BE LIABLE,
UNDER ANY CIRCUMSTANCES, FOR
CONSEQUENTIAL OR INCIDENTAL
DAMAGES, INCLUDING BUT NOT LIMITED TO
LABOR COSTS OR LOST PROFITS
RESUL TING FROM THE USE OF OR INABILITY
TO USE THE PRODUCTS OR FROM THE
PRODUCTS BEING INCORPORATED IN OR
BECOMING A COMPONENT OF ANY OTHER
PRODUCT OR GOODS.
Page 12
HATCO CORPORATION
P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A.
(800) 558-0607 (414) 671-6350
Parts & Service Fax (800) 690-2966 Int’l. Fax (414) 671-3976
www.hatcocorp.com
HATCO AUTHORIZED PARTS DISTRIBUTORS
Printed in U.S.A. January 2007
ALABAMA
Jones McLeod Appl. Svc.
Birmingham 205-251-0159
ARIZONA
Auth. Comm. Food Equip.
Phoenix 602-234-2443
Byassee Equipment Co.
Phoenix 602-252-0402
CALIFORNIA
Industrial Electric
Commercial Parts & Service, Inc.
Huntington Beach 714-379-7100
Chapman Appl. Service
San Diego 619-298-7106
P & D Appliance
Commercial Parts & Service, Inc.
S. San Francisco 650-635-1900
COLORADO
Hawkins Commercial Appliance
Englewood 303-781-5548
FLORIDA
Whaley Foodservice Repair
Jacksonville 904-725-7800
Universal Restaurant Services
Miami 305-593-5488
Nass Service Co., Inc.
Orlando 407-425-2681
B.G.S.I.
Pompano Beach 954-971-0456
Comm. Appliance Service
Tampa 813-663-0313
GEORGIA
TWC Services
Smyrna 770-438-9797
Heritage Service Group
Norcross 866-388-9837
Southeastern Rest. Svc.
Norcross 770-446-6177
HA
WAII
Burney’s Comm. Service, Inc.
Honolulu 808-848-1466
Food Equip Parts & Service
Honolulu 808-847-4871
ILLINOIS
Parts Town
Lombard 708-865-7278
Eichenauer Elec. Service
Decatur 217-429-4229
Midwest Elec. Appl. Service
Elmhurst 630-279-8000
Cone’s Repair Service
Moline 309-797-5323
INDIANA
GCS Service
Indianapolis 317-545-9655
IOW
A
Electric Motor Service Co.
Davenport 319-323-1823
Goodwin Tucker Group
Des Moines 515-262-9308
KENTUCKY
Certified Service Center
Lexington 859-254-8854
Certified Service Center
Louisville 502-964-7007
LOUISIANA
Chandlers Parts & Service
Baton Rouge 225-272-6620
MAR
YLAND
Electric Motor Service
Baltimore 410-467-8080
GCS Service
Silver Spring 301-585-7550
MASSACHUSETTS
Ace Service Co., Inc.
Needham 781-449-4220
MICHIGAN
Commercial Kitchen Service
Bay City 517-893-4561
Bildons Appliance Service
Detroit 248-478-3320
Midwest Food Equip. Service
Grandville 616-261-2000
MINNESOT
A
GCS Service
Minneapolis 612-546-4221
MISSOURI
General Parts
Kansas City 816-421-5400
Commercial Kitchen Services
St. Louis 314-890-0700
Kaemmerlen Parts & Service
St. Louis 314-535-2222
NEBRASKA
Anderson Electric
Omaha 402-341-1414
NEV
ADA
Burney’s Commercial
Las Vegas 702-736-0006
Hi. Tech Commercial Service
N. Las Vegas 702-649-4616
NEW JERSEY
Jay Hill Repair
Fairfield 973-575-9145
Service Plus
Flanders 973-691-6300
NEW
YORK
Acme American Repairs, Inc.
Brooklyn 718-456-6544
Alpro Service Co.
Brooklyn 718-386-2515
Appliance Installation
Buffalo 716-884-7425
Northern Parts Dist.
Plattsburgh 518-563-3200
J.B. Brady, Inc.
Syracuse 315-422-9271
NORTH CAROLINA
Authorized Appliance
Charlotte 704-377-4501
OHIO
Akron/Canton Comm. Svc. Inc.
Akron 330-753-6635
Certified Service Center
Cincinnati 513-772-6600
Commercial Parts and Service
Columbus 614-221-0057
Electrical Appl. Repair Service
Independence 216-459-8700
E. A. Wichman Co.
Toledo 419-385-9121
OKLAHOMA
Hagar Rest. Service, Inc.
Oklahoma City 405-235-2184
Krueger, Inc.
Oklahoma City 405-528-8883
OREGON
Ron’s Service, Inc.
Portland 503-624-0890
PENNSYL
VANIA
Elmer Schultz Services
Philadelphia 215-627-5401
FAST Comm. Appl. Service
Philadelphia 215-288-4800
Appliance Installation & Service
Pittsburgh 412-809-0244
K & D Service Co.
Harrisburg 717-236-9039
Electric Repair Co.
Reading 610-376-5444
RHODE ISLAND
Marshall Electric Co.
Providence 401-331-1163
SOUTH CAROLINA
Whaley Foodservice Repair
W. Columbia 803-791-4420
TENNESSEE
Camp Electric
Memphis 901-527-7543
TEXAS
GCS Service
Fort Worth 817-831-0381
Armstrong Repair Service
Houston 713-666-7100
Commercial Kitchen Repair Co.
San Antonio 210-735-2811
UT
AH
La Monica’s Rest. Equip. Service
Murray 801-263-3221
VIRGINIA
Daubers
Norfolk 757-855-4097
Daubers
Springfield 703-866-3600
W
ASHINGTON
Restaurant Appl. Service
Seattle 206-524-8200
WISCONSIN
A.S.C., Inc.
Madison 608-246-3160
A.S.C., Inc.
Milwaukee 414-543-6460
CANADA
ALBERTA
Key Food Equipment Service
Edmonton 780-438-1690
BRITISH COLUMBIA
Key Food Equipment Service
Vancouver 604-433-4484
MANIT
OBA
Air Rite, Inc.
Winnepeg 204-895-2300
N
EW BRUNSWICK
EMR Services, Ltd.
Moncton 506-855-4228
ONT
ARIO
R.G. Henderson Ltd.
Toronto 416-422-5580
Choquette CKS
Ottawa 613-739-8458
QUÉBEC
Choquette CKS
Montreal 514-722-2000
Choquette CKS
Québec City 418-681-3944
Part No. 07.04.384.00 Form No. GRMWM-0107
Loading...
