GLO-RAY
®
Designer
Heated
Display Cases
REPLACEMENT
PARTS LIST
GRCD-1P
GRCD-1PD
GRCDH-1P
GRCDH-1PD
GRCD-2P
GRCD-2PD
GRCDH-2P
GRCDH-2PD
GRCD-3P
GRCD-3PD
GRCDH-3P
GRCDH-3PD
GRCD Series
Page 2
Form No. GRCDRP-1001 2 Printed in U.S.A.
HATCO GLO-RAY
®
DESIGNER
HEATED DISPLAY CASES
GRCD SERIES
Model Designation
GRCD-XPD
G= Glo
R= Ray
C= Curved
D= Display
X= Full Size Pan Capacity
on Bottom Shelf
P= Pan
D= Dual Shelf
CAUTION - Use of replacement parts
other than those supplied by Hatco
Corporation may result in damage to the
unit or injury to personnel.
28
23
30
4
31
32
34
34
22
3
5
14
16
11
21
2
6
33
7
19
17
10
1
18
20
8A, 8B
9A, 9B
8A, 8B
29
GRCD-1P & GRCDH-1P
MODELS ONLY
Page 3
HATCO GLO-RAY
®
DESIGNER HEATED DISPLAY CASES
GRCDH SERIES
Model Designation
GRCDH-XPD
G= Glo
R= Ray
C= Curved
D= Display
H= Humidified
X= Full Size Pan Capacity on
Bottom Shelf
P= Pan
D= Dual Shelf
Form No. GRCDRP-1001 3 Printed in U.S.A.
CAUTION - Use of replacement parts
other than those supplied by Hatco
Corporation may result in damage to the
unit or injury to personnel.
24
28
29
5
14
16
6
25
34
34
12
11
17
10
1
9A, 9B
22
4
31
32
3
7
7
20
18
19
2
33
21
26
GRCD-1P & GRCDH-1P
MODELS ONLY
8A, 8B
8A, 8B
Page 4
Form No. GRCDRP-1001 4 Printed in U.S.A.
1 Terminal Block, 8-Pole 02.15.012.00 1
2 Thermostat, Base 02.16.030.00 1
3 Light Socket, Single 02.30.044.00 1-2
4 Light Socket, Dual 02.30.045.00 1-2
PARTS COMMON TO ALL GRCD/GRCDH MODELS
5 Legs 05.30.007.00 4
6 Knob, Thermostat 05.30.018.00 1
7 Knob, Infinite Switch 05.30.043.00 1-3
ITEM DESCRIPTION PART NO. QTY.
ITEM DESCRIPTION PART NO. QTY.
Page 5
Shaded area reflects export models only.
* Not Shown
Form No. GRCDRP-1001 5 Printed in U.S.A.
PARTS SPECIFIC TO MODEL GRCD-1P
ITEM DESCRIPTION
8A Glass Door
8B Glass Door, Mirror
9A Glass Door
9B Glass Door, Mirror
10 Relay
11 Heating Element, Base
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 8)
31 Heating Element, Upper
32 Wire Guard
33 Infinite Control Switch
34 Hinge Kit
Electrical Drawing
R04.40.129.00
R04.40.138.00
---
---
---
02.05.293.00
---
---
---
--R02.18.030.00
R02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.105.00
R04.40.127.00
05.06.039.00
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4741
R04.40.129.00
R04.40.138.00
---
---
---
02.05.293.00
---
---
---
--R02.18.030.00
R02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.105.00
R04.40.127.00
05.06.039.00
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4741
R04.40.129.00
R04.40.138.00
---
---
---
02.05.294.00
---
---
---
---
02.18.077.00
R02.19.008A.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.105.00
R04.40.127.00
05.06.039.00
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4742
R04.40.129.00
R04.40.138.00
---
---
---
02.05.294.00
---
---
---
---
02.18.066.00
R02.19.008A.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.105.00
R04.40.127.00
05.06.039.00
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4743
R04.40.129.00
R04.40.138.00
---
---
---
02.05.294.00
---
R02.15.030.00
---
---
02.18.077.00
R02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.105.00
R04.40.127.00
05.06.039.00
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5149
R04.40.129.00
R04.40.138.00
---
---
---
02.05.294.00
---
R02.15.030.00
---
---
02.18.066.00
R02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.105.00
R04.40.127.00
05.06.039.00
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5150
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Page 6
PARTS SPECIFIC TO MODEL GRCD-1PD
ITEM DESCRIPTION
8A Glass Door
8B Glass Door, Mirror
9A Glass Door
9B Glass Door, Mirror
10 Relay
11 Heating Element, Base
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 8)
31 Heating Element, Upper (Qty. 3)
32 Wire Guard (Qty. 2)
33 Infinite Control Switch (Qty. 2)
34 Hinge Kit
Electrical Drawing
R04.40.130.00
R04.40.139.00
---
---
---
02.05.293.00
---
---
---
--R02.18.030.00
R02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.091.00
R04.40.128.00
05.06.039.00
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4748
R04.40.130.00
R04.40.139.00
---
---
---
02.05.293.00
---
---
---
--R02.18.030.00
R02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.091.00
R04.40.128.00
05.06.039.00
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4748
R04.40.130.00
R04.40.139.00
---
---
---
02.05.294.00
---
---
---
---
02.18.077.00
R02.19.008A.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.091.00
R04.40.128.00
05.06.039.00
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4749
R04.40.130.00
R04.40.139.00
---
---
---
02.05.294.00
---
---
---
---
02.18.066.00
R02.19.008A.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.091.00
R04.40.128.00
05.06.039.00
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4750
R04.40.130.00
R04.40.139.00
---
---
---
02.05.294.00
---
R02.15.030.00
---
---
02.18.077.00
R02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.091.00
R04.40.128.00
05.06.039.00
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5153
R04.40.130.00
R04.40.139.00
---
---
---
02.05.294.00
---
R02.15.030.00
---
---
02.18.066.00
R02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.364.00
04.22.400.00
---
---
04.22.357.00
04.40.091.00
R04.40.128.00
05.06.039.00
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5154
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
Form No. GRCDRP-1001 6 Printed in U.S.A.
* Not Shown
Page 7
PARTS SPECIFIC TO MODEL GRCDH-1P
ITEM DESCRIPTION
8A Glass Door
8B Glass Door, Mirror
9A Glass Door
9B Glass Door, Mirror
10 Relay
11 Heating Element, Base
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail
31 Heating Element, Upper
32 Wire Guard
33 Infinite Control Switch (Qty. 2)
34 Hinge Kit
Electrical Drawing
R04.40.129.00
R04.40.138.00
---
---
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
R02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.105.00
R04.40.127.00
---
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4744
R04.40.129.00
R04.40.138.00
---
---
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
R02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.105.00
R04.40.127.00
---
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4744
R04.40.129.00
R04.40.138.00
---
---
02.01.180.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.077.00
R02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.105.00
R04.40.127.00
---
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4745
R04.40.129.00
R04.40.138.00
---
---
02.01.105.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.066.00
R02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.105.00
R04.40.127.00
---
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4746
R04.40.129.00
R04.40.138.00
---
---
02.01.180.00
02.05.294.00
02.05.296.00
R02.15.030.00
R02.16.036.00
02.16.071.00
02.18.077.00
R02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.105.00
R04.40.127.00
---
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5151
R04.40.129.00
R04.40.138.00
---
---
02.01.105.00
02.05.294.00
02.05.296.00
R02.15.030.00
R02.16.036.00
02.16.071.00
02.18.066.00
R02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.105.00
R04.40.127.00
---
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5152
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
Form No. GRCDRP-1001 7 Printed in U.S.A.
* Not Shown
Page 8
Form No. GRCDRP-1001 8 Printed in U.S.A.
PARTS SPECIFIC TO MODEL GRCDH-1PD
ITEM DESCRIPTION
8A Glass Door
8B Glass Door, Mirror
9A Glass Door
9B Glass Door, Mirror
10 Relay
11 Heating Element, Base (Qty. 2)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail
31 Heating Element, Upper (Qty. 3)
32 Wire Guard
33 Infinite Control Switch (Qty. 3)
34 Hinge Kit
Electrical Drawing
R04.40.130.00
R04.40.139.00
---
---
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
R02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.091.00
R04.40.128.00
---
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4751
R04.40.130.00
R04.40.139.00
---
---
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
R02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.091.00
R04.40.128.00
---
R02.08.258.00
04.08.113.00
R02.19.018.00
R00.01.0115.00
HS2-4751
R04.40.130.00
R04.40.139.00
---
---
02.01.180.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.077.00
R02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.091.00
R04.40.128.00
---
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4752
R04.40.130.00
R04.40.139.00
---
---
02.01.105.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.066.00
R02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.091.00
R04.40.128.00
---
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-4753
R04.40.130.00
R04.40.139.00
---
---
02.01.180.00
02.05.294.00
02.05.296.00
R02.15.030.00
R02.16.036.00
02.16.071.00
02.18.077.00
R02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.091.00
R04.40.128.00
---
R02.08.038.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5155
R04.40.130.00
R04.40.139.00
---
---
02.01.105.00
02.05.294.00
02.05.296.00
R02.15.030.00
R02.16.036.00
02.16.071.00
02.18.066.00
R02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
---
04.22.357.00
04.40.091.00
R04.40.128.00
---
R02.08.261.00
04.08.113.00
R02.19.019.00
R00.01.0115.00
HS2-5156
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
* Not Shown
Page 9
PARTS SPECIFIC TO MODEL GRCD-2P
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 2)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 3)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 12)
31 Heating Element, Upper
32 Wire Guard
33 Infinite Control Switch
Electrical Drawing
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
---
02.05.293.00
---
---
---
---
R02.18.030.00
02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.105.00
04.40.106.00
05.06.039.00
R02.08.202.00
04.08.112.00
R02.19.018.00
HS2-3538
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
---
02.05.293.00
---
---
---
---
R02.18.030.00
02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.105.00
R04.40.106.00
05.06.039.00
R02.08.202.00
04.08.112.00
R02.19.018.00
HS2-3538
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
---
02.05.294.00
---
---
---
---
02.18.077.00
02.19.006.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.105.00
R04.40.106.00
05.06.039.00
R02.08.250.00
04.08.112.00
R02.19.019.00
HS2-3542
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
---
02.05.294.00
---
---
---
---
02.18.066.00
02.19.006.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.105.00
R04.40.106.00
05.06.039.00
R02.08.251.00
04.08.112.00
R02.19.019.00
HS2-3542
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.077.00
02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.105.00
R04.40.106.00
05.06.039.00
R02.08.250.00
04.08.112.00
R02.19.019.00
HS2-4159
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.066.00
02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.105.00
R04.40.106.00
05.06.039.00
R02.08.251.00
04.08.112.00
R02.19.019.00
HS2-4160
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
Form No. GRCDRP-1001 9 Printed in U.S.A.
* Not Shown
Page 10
PARTS SPECIFIC TO MODEL GRCD-2PD
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 2)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 3)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 12)
31 Heating Element, Upper (Qty. 3)
32 Wire Guard (Qty. 3)
33 Infinite Control Switch (Qty. 2)
Electrical Drawing
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
---
02.05.293.00
---
---
---
---
R02.18.030.00
02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.091.00
R04.40.095.00
05.06.039.00
R02.08.222.00
04.08.112.00
R02.19.018.00
HS2-3314
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
---
02.05.293.00
---
---
---
---
R02.18.030.00
02.19.016.00
02.19.154.00
---
---
---
02.20.212.00
02.30.043.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.091.00
R04.40.095.00
05.06.039.00
R02.08.222.00
04.08.112.00
R02.19.018.00
HS2-3314
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
---
02.05.294.00
---
---
---
---
02.18.077.00
02.19.006.00
02.19.151.00
---
---
---
02.20.206.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.091.00
R04.40.095.00
05.06.039.00
R02.08.232.00
04.08.112.00
R02.19.019.00
HS2-3420
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
---
02.05.294.00
---
---
---
---
02.18.068.00
02.19.006.00
02.19.151.00
---
---
---
02.20.206.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.091.00
R04.40.095.00
05.06.039.00
R02.08.232.00
04.08.112.00
R02.19.019.00
HS2-3422
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.077.00
02.19.006.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.091.00
R04.40.095.00
05.06.039.00
R02.08.232.00
04.08.112.00
R02.19.019.00
HS2-4167
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.068.00
02.19.006.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.030.00
04.22.400.00
---
04.22.406.00
---
04.40.091.00
R04.40.095.00
05.06.039.00
R02.08.265.00
04.08.112.00
R02.19.019.00
HS2-4170
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
Form No. GRCDRP-1001 10 Printed in U.S.A.
* Not Shown
Page 11
PARTS SPECIFIC TO MODEL GRCDH-2P
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 2)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red (Qty. 2)
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 3)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail
31 Heating Element, Upper
32 Wire Guard
33 Infinite Control Switch (Qty. 2)
Electrical Drawing
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.105.00
R04.40.106.00
---
R02.08.202.00
04.08.112.00
R02.19.018.00
HS2-3544
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.105.00
R04.40.106.00
---
R02.08.202.00
04.08.112.00
R02.19.018.00
HS2-3544
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
02.01.180.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.105.00
R04.40.106.00
---
R02.08.250.00
04.08.112.00
R02.19.019.00
HS2-3546
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
02.01.105.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.066.00
02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.105.00
R04.40.106.00
---
R02.08.251.00
04.08.112.00
R02.19.019.00
HS2-3548
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
02.01.180.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.105.00
R04.40.106.00
---
R02.08.250.00
04.08.112.00
R02.19.019.00
HS2-4163
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
02.01.105.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.066.00
02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.105.00
R04.40.106.00
---
R02.08.251.00
04.08.112.00
R02.19.019.00
HS2-4164
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
R00.01.0026.00
R00.01.0034.00
R00.01.0025.00
R00.01.0033.00
02.01.088.00
02.05.507.00
02.05.508.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
R02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.105.00
R04.40.106.00
---
R02.08.560.00
04.08.112.00
R02.19.160.00
HS2-5825
Shaded area reflects export models only.
Form No. GRCDRP-1001 11 Printed in U.S.A.
* Not Shown
Page 12
Form No. GRCDRP-1001 12 Printed in U.S.A.
PARTS SPECIFIC TO MODEL GRCDH-2PD
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 2)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 6)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 12)
31 Heating Element, Upper (Qty. 3)
32 Wire Guard (Qty. 3)
33 Infinite Control Switch (Qty. 3)
Electrical Drawing
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.091.00
R04.40.095.00
---
R02.08.222.00
04.08.112.00
R02.19.018.00
HS2-3313
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.083.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.212.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.091.00
R04.40.095.00
---
R02.08.222.00
04.08.112.00
R02.19.018.00
HS2-3313
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
02.01.180.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.006.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.091.00
R04.40.095.00
---
R02.08.232.00
04.08.112.00
R02.19.019.00
HS2-3419
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
02.01.105.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.068.00
02.19.006.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.091.00
R04.40.095.00
---
R02.08.232.00
04.08.112.00
R02.19.019.00
HS2-3421
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
02.01.180.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.006.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.091.00
R04.40.095.00
---
R02.08.232.00
04.08.112.00
R02.19.019.00
HS2-4171
R00.01.0030.00
R00.01.0038.00
R00.01.0029.00
R00.01.0037.00
02.01.105.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.068.00
02.19.006.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
---
04.40.091.00
R04.40.095.00
---
R02.08.232.00
04.08.112.00
R02.19.019.00
HS2-4172
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
* Not Shown
Page 13
Form No. GRCDRP-1001 13 Printed in U.S.A.
PARTS SPECIFIC TO MODEL GRCD-3P
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 3)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 3)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 16)
31 Heating Element, Upper
32 Wire Guard
33 Infinite Control Switch
Electrical Drawing
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
---
02.05.293.00
---
---
---
---
R02.18.030.00
02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
05.06.039.00
R02.08.216.00
04.08.102.00
R02.19.018.00
HS2-3539
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
---
02.05.293.00
---
---
---
---
R02.18.030.00
02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
05.06.039.00
R02.08.216.00
04.08.102.00
R02.19.018.00
HS2-3539
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
---
02.05.294.00
---
---
---
---
02.18.077.00
02.19.006.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
05.06.039.00
R02.08.253.00
04.08.102.00
R02.19.019.00
HS2-3541
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
---
02.05.294.00
---
---
---
---
02.18.066.00
02.19.006.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
05.06.039.00
R02.08.254.00
04.08.102.00
R02.19.019.00
HS2-3543
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.077.00
02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
05.06.039.00
R02.08.253.00
04.08.102.00
R02.19.019.00
HS2-4161
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.068.00
02.19.008A.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
05.06.039.00
R02.08.254.00
04.08.102.00
R02.19.019.00
HS2-4162
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
* Not Shown
Page 14
PARTS SPECIFIC TO MODEL GRCD-3PD
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 2)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 6)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 16)
31 Heating Element, Upper (Qty. 3)
32 Wire Guard (Qty. 3)
33 Infinite Control Switch (Qty. 2)
Electrical Drawing
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
---
02.05.293.00
---
---
---
---
R02.18.030.00
02.19.016.00
02.19.154.00
---
---
---
02.20.206.00
02.30.043.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
05.06.039.00
R02.08.217.00
04.08.131.00
R02.19.018.00
HS2-3312
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
---
02.05.293.00
---
---
---
---
R02.18.083.00
02.19.016.00
02.19.154.00
---
---
---
02.20.212.00
02.30.043.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
05.06.039.00
R02.08.217.00
04.08.131.00
R02.19.018.00
HS2-3312
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
---
02.05.294.00
---
---
---
---
02.18.077.00
02.19.006.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
05.06.039.00
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-3423
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
---
02.05.294.00
---
---
---
---
02.18.068.00
02.19.006.00
02.19.151.00
---
---
---
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
05.06.039.00
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-3425
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.077.00
02.19.006.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
05.06.039.00
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-4169
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
---
02.05.294.00
---
02.15.030.00
---
---
02.18.068.00
02.19.006.00
---
---
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
04.22.031.00
04.22.400.00
---
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
05.06.039.00
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-4170
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V 220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Shaded area reflects export models only.
Form No. GRCDRP-1001 14 Printed in U.S.A.
* Not Shown
Page 15
PARTS SPECIFIC TO MODEL GRCDH-3P
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 3)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red (Qty. 2)
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 3)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass (Qty. 2)
29 Curved Glass, Front
30 Rubber Foot, Pan Rail
31 Heating Element, Upper
32 Wire Guard
33 Infinite Control Switch (Qty. 2)
Electrical Drawing
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
---
R02.08.216.00
04.08.102.00
R02.19.018.00
HS2-3545
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
---
R02.08.216.00
04.08.102.00
R02.19.018.00
HS2-3545
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
02.01.180.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
---
R02.08.253.00
04.08.102.00
R02.19.019.00
HS2-3547
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
02.01.105.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.066.00
02.19.008A.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
---
R02.08.254.00
04.08.102.00
R02.19.019.00
HS2-3549
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
02.01.180.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
---
R02.08.253.00
04.08.102.00
R02.19.019.00
HS2-4165
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
02.01.105.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.066.00
02.19.008A.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
---
R02.08.254.00
04.08.102.00
R02.19.019.00
HS2-4166
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
R00.01.0028.00
R00.01.0036.00
R00.01.0027.00
R00.01.0035.00
02.01.088.00
02.05.507.00
02.05.508.00
---
R02.16.036.00
02.16.071.00
R02.18.030.00
R02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.206.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.105.00
R04.40.107.00
---
R02.08.567.00
04.08.102.00
R02.19.160.00
HS2-5850
Shaded area reflects export models only.
Form No. GRCDRP-1001 15 Printed in U.S.A.
* Not Shown
Page 16
PARTS SPECIFIC TO MODEL GRCDH-3PD
ITEM DESCRIPTION
8A Glass Door, Inner
8B Glass Door, Inner, Mirror
9A Glass Door, Outer
9B Glass Door, Outer, Mirror
10 Relay
11 Heating Element, Base (Qty. 3)
12 Heating Element, Water
13 Terminal Block, 3-Pole*
14 High Limit, Automatic
15 High Limit, Manual*
16 Power Cord with Plug
17 On/Off Switch
18 Indicator Light, Red
Indicator Light, Yellow
19 Indicator Light, Green
20 Rubber Boot, Toggle Switch
21 Strain Relief
22 Light Bulb (Qty. 6)
23 Pan Rail
24 Pan Divider (optional)
25 Water Trough
26 Pan Enclosure, 2 Pan (optional)
27 Pan Enclosure, 1 Pan*
28 End Glass
29 Curved Glass, Front
30 Rubber Foot, Pan Rail (Qty. 16)
31 Heating Element, Upper (Qty. 3)
32 Wire Guard (Qty. 3)
33 Infinite Control Switch (Qty. 3)
Electrical Drawing
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.083.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.212.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
---
R02.08.217.00
04.08.131.00
R02.19.018.00
HS2-3311
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
02.01.088.00
02.05.293.00
02.05.295.00
---
R02.16.036.00
02.16.071.00
R02.18.039.00
02.19.016.00
02.19.154.00
---
02.19.155.00
---
02.20.209.00
02.30.043.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
---
R02.08.217.00
04.08.131.00
R02.19.018.00
HS2-3311
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
02.01.180.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.006.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
---
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-3424
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
02.01.105.00
02.05.294.00
02.05.296.00
---
R02.16.036.00
02.16.071.00
02.18.068.00
02.19.006.00
02.19.151.00
---
02.19.150.00
---
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
---
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-3426
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
02.01.180.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.077.00
02.19.006.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
---
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-4173
R00.01.0032.00
R00.01.0039.00
R00.01.0031.00
R00.01.0040.00
02.01.105.00
02.05.294.00
02.05.296.00
02.15.030.00
R02.16.036.00
02.16.071.00
02.18.068.00
02.19.006.00
---
02.19.152.00
02.19.150.00
02.20.040.00
02.20.212.00
02.30.058.00
---
04.22.400.00
04.22.403.00
04.22.406.00
04.22.407.00
04.40.091.00
R04.40.096.00
---
R02.08.265.00
04.08.131.00
R02.19.019.00
HS2-4174
230-240V
CE
220-230V
CE
240V
120V
CSA
120V
100V
220V
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
---
Form No. GRCDRP-1001 16 Printed in U.S.A.
Shaded area reflects export models only.
* Not Shown
Page 17
NOTES
Form No. GRCDRP-1001 17 Printed in U.S.A.
Page 18
NOTES
Form No. GRCDRP-1001 18 Printed in U.S.A.
Page 19
NOTES
Form No. GRCDRP-1001 19 Printed in U.S.A.
Page 20
HATCO CORPORATION
P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A.
(800) 558-0607 (414) 671-6350
Parts & Service Fax (800) 690-2966 Int’l. Fax (414) 671-3976
www.hatcocorp.com
HATCO AUTHORIZED PARTS DISTRIBUTORS
ALABAMA
Jones McLeod Appl. Svc.
Birmingham 205-251-0159
ARIZONA
Auth. Comm. Food Equip.
Phoenix 602-234-2443
Byassee Equipment Co.
Phoenix 602-252-0402
CALIFORNIA
Industrial Electric
Huntington Beach 714-379-7100
Chapman Appl. Service
San Diego 619-298-7106
P & D Appliance
S. San Francisco 650-635-1900
COLORADO
All City Service
Denver 303-454-9500
Hawkins Commercial Appliance
Englewood 303-781-5548
DELA
WARE
Food Equipment Service
Wilmington 302-996-9363
FLORIDA
Whaley Foodservice Repair
Jacksonville 904-725-7800
Nass Service Co., Inc.
Orlando 407-425-2681
B.G.S.I.
Pompano Beach 954-971-0456
Comm. Appliance Service
Tampa 813-663-0313
GEORGIA
Southeastern Rest. Svc.
Norcross 770-446-6177
HA
WAII
Burney’s Comm. Service, Inc.
Honolulu 808-848-1466
Food Equip Parts & Service
Honolulu 808-847-4871
ILLINOIS
Parts Town
Broadview 708-865-7278
Eichenauer Elec. Service
Decatur 217-429-4229
Midwest Elec. Appl. Service
Elmhurst 630-279-8000
Cone’s Repair Service
Moline 309-797-5323
INDIANA
Comm. Parts & Service, Inc.
Indianapolis 317-545-9655
IOW
A
Electric Motor Service Co.
Davenport 319-323-1823
KENTUCKY
Comm. Parts & Service, Inc.
Louisville 502-367-1788
LOUISIANA
Chandlers Parts & Service
Baton Rouge 225-272-6620
LOUISIANA (Continued)
Bana Comm. Parts, Inc.
Shreveport 318-631-6550
MAR
YLAND
Electric Motor Service
Baltimore 410-467-8080
GCS Service, Inc.
Silver Spring 301-585-7550
MASSACHUSETTS
Ace Service Co., Inc.
Needham 781-449-4220
MICHIGAN
Commercial Kitchen Service
Bay City 517-893-4561
Bildons Appliance Service
Detroit 248-478-3320
Midwest Food Equip. Service
Grandville 616-261-2000
MINNESOT
A
GCS Service
Minneapolis 612-546-4221
MISSOURI
GCS Service, Inc.
Kansas City 816-920-5999
Commercial Kitchen Services
St. Louis 314-890-0700
Kaemmerlen Parts & Service
St. Louis 314-535-2222
NEBRASKA
Anderson Electric
Omaha 402-341-1414
NEV
ADA
Burney’s Commercial
Las Vegas 702-736-0006
Hi. Tech Commercial Service
N. Las Vegas 702-649-4616
NEW JERSEY
Jay Hill Repair
Fairfield 973-575-9145
Service Plus
Flanders 973-691-6300
NEW YORK
Acme American Repairs, Inc.
Brooklyn 718-456-6544
Alpro Service Co.
Brooklyn 718-386-2515
Appliance Installation
Buffalo 716-884-7425
Northern Parts Dist.
Plattsburgh 518-563-3200
J. B. Brady, Inc.
Syracuse 315-422-9271
NORTH CAROLINA
Authorized Appliance
Charlotte 704-377-4501
OHIO
Akron/Canton Comm. Svc. Inc.
Akron 330-753-6635
Certified Service Center
Cincinnati 513-772-6600
GCS Service
Columbus 614-476-3225
OHIO (Continued)
Electrical Appl. Repair Service
Independence 216-459-8700
E. A. Wichman Co.
Toledo 419-385-9121
OKLAHOMA
Hagar Rest. Service, Inc.
Oklahoma City 405-235-2184
Krueger, Inc.
Oklahoma City 405-528-8883
OREGON
Bressie Electric Co.
Portland 503-231-7171
Ron’s Service, Inc.
Portland 503-624-0890
PENNSYL
V
ANIA
Authorized Factory Service
Coraopolis 412-262-2330
FAST Comm. Appl. Service
Philadelphia 215-288-4800
GCS Service, Inc.
Pittsburgh 412-787-1970
K & D Service Co.
Harrisburg 717-236-9039
Elmer Schultz Services
Philadelphia 215-627-5401
Electric Repair Co.
Reading 610-376-5444
RHODE ISLAND
Marshall Electric Co.
Providence 401-331-1163
SOUTH CAROLINA
Whaley Foodservice Repair
W. Columbia 803-791-4420
TENNESSEE
Camp Electric
Memphis 901-527-7543
TEXAS
City Kitchen Service Co.
Austin 512-719-4445
Stove Parts Supply
Fort Worth 817-831-0381
Armstrong Repair Service
Houston 713-666-7100
Commercial Kitchen Repair Co.
San Antonio 210-735-2811
San Antonio Rest. Equip.
San Antonio 210-532-1660
UT
AH
Peterson’s Commercial Parts & Svc.
Salt Lake City 801-487-3653
VIRGINIA
Daubers
Norfolk 757-855-4097
Daubers
Springfield 703-866-3600
W
ASHINGTON
Restaurant Appl. Service
Seattle 206-524-8200
WISCONSIN
A.S.C., Inc.
Madison 608-246-3160
A.S.C., Inc.
Milwaukee 414-543-6460
Form No. GRCDRP-1001 October 2001 Printed in U.S.A.
Loading...
