Form No. FRRP - 0201 3 Printed in U.S.A.
1 On/Off Power Switch 02.19.008A.00 1
2 Control, Thermostat
192°F (89°C) 02.16.016.00 1
3 Knob, Thermostat Control 05.30.021.00 1
4 Thermostat, High Limit
210°F (99°C) 02.16.025A.00 1
5 Control, Low Water Cut Off
(Optional) 02.01.002.00 1
6 Probe, Low Water
(Optional) 02.40.001.00 1
7 Indicator Light, Green 02.19.150.00 1
8 Mounting Bolts, Elements 05.04.062.00 4-8
9 Gasket, Element 05.06.005.00 1-2
10 Ball Valve,Thread Fitting
(Old Style) 03.02.001.00 1
11 Ball Valve, Sweat Fitting
(New Style)* 03.02.002.00 1
PARTS COMMON TO ALL FR MODELS
12 Handle, Sump Drain 03.02.001B.00 1
13 Drain Cap,
Heating Compartment R03.40.014.00 1
14 Grommets, Black Molded
Rubber 05.06.008.00 2
15 Rubber Stopper 05.06.026.00 1
16 Flush Hose with Adaptor 05.06.010.00 1
17 Sink Strainer Assembly Kit R05.30.009.00 2
18 Strainer Gasket Kit † R00.05.0002.00 1
19 Brass Locknut 05.30.009A.00 1
20 Union Gasket 05.06.009.00 1
21 Drain Screen Plug, 1" 02.20.026.00 1
22 Mounting Bracket,
Terminal Block 04.20.002.00 1
ITEM DESCRIPTION PART NO. QTY. ITEM DESCRIPTION PART NO. QTY.
*Changed to New Style in 1989
† Includes all gaskets for both strainers
Shaded area in parts lists on the following pages reflects export models only.
Note: S.S. is an abbreviation for stainless steel on the following pages.
