Hastech HB098 Users Manual

Bluetooth Keyboard for Android/Windows/IOS tablets & laptops

1. Cordless keyboard

2.

User manual

1. Built-in Broadcom Bluetooth 3.0 keyboard.

2. Modern slim keyboard backside with brushed steel.

3. Chocolate keycap with scissors structure, good touch feeling.

4. Suitable for Android/Windows/IOS tablets, laptops, desktops, and all smartphones.

5.6.Light weight, quiet keystrokes, water-proof, dust-proof.

Keyboard size: 281.7*135*4.3MM

1. Bluetooth 3.0 interface standard

2. Operating Distance to 10 meters

3. Modulating System: GFSK

4. Operation Voltage: 3.0-4.2V

5. Working Current: <2.5mA

6. Standby Current: 0.3-0.5mA

7. Sleeping Current：<40uA

8.9.Standby Time: >100 days

10.

11.

12.

Uninterrupted Working Time: > 64hours

Key Strength: 50g~80g

Key life: <3 million strokes

Operating Temperature:-10-+55 C

HB098

FCC ID:2AC9LHB098

Packing contents:

Bluetooth Keyboard Specification

Bluetooth Keyboard Specification and Pairing Instruction：

Bluetooth Keyboard Specification

Bluetooth Keyboard Pairing

Step 1: Turn on the power toggle switch. The state indicator light will be on for 10 seconds, and

then the light will go off.

Step2: Press on“FN+C”button together on keyboard, the indicator light will be blinking.

Step3: Turn on Bluetooth setting in your device, your device will automatically find “Bluetooth

3.0 Keyboard”, then connect it.

Step4: Device showed Bluetooth had connected, keyboard state indicator light will turn off.

Special Note:

1.Keep the item away from sharp objects.

2.Do not place heavy object on top of the keyboard.

3.Do not Microwave the item.

4.Do not force or distorted the keyboard

5.Keep away from oil.chemical or any other organic liquid.

1.Make sure the power switch is on.

2.Make sure the keyboard is within the operating distance.

3.4.Make sure your device Bluetooth setting is on.

5.

Make sure wireless keyboard is connected to your device.

Make sure wireless keyboard has been paired with your device.

For other Bluetooth enabled device, please verify the Bluetooth Standard&compatibility before

attempting to connect to the keyboard.

Energy Saving Sleep Mode

The keyboard will kick into sleep mode when it is inactive for 10 minutes and the keyboard

[power] indicator or light will go off. To activate from sleep mode, just press any key and wait

3seconds, the keyboard will come back on.

Safety Caution

Cleaning

Clean the silicone keyboard with water, alcohol or alcohol based disinfectant

Troubleshooting

A, Unable to connect
