AGES 5 & UP
MODEL 88-316
883160001IWTI-02
INSTRUCTION
The Darth Maul Compact Phone is a fully functional phone that features
the face of Darth Maul when in the closed position and, when opened
reveals the true master of the dark side, Darth Sidious.
TELEPHONE CONTROLS AND FEA TURES
1
1
7
7
5
5
2
2
4
4
11
11
1. EAR PIECE/SPEAKER
2. MICROPHONE
3. REDIAL BUTTON
- redials the last number called
4. FLASH BUTTON
- lets you retrieve a dial tone after ending a call
5. TALK ON/OFF SWITCH
- turns phone on and off
6. DIALING KEYS
7. VOLUME CONTROL
- controls the reception volume
8. RINGER VOLUME SELECTOR
- controls ringer volume with three settings: OFF, LOW or HIGH
9. PHONE CORD CONNECTION
10. TONE/PULSE
- use to select the tone or pulse dialing method.
11. SOUND EFFECT BUTTONS
INSTALLATION
9
9
6
6
3
3
10
10
8
8
Dialing a Call
Pick up the handset, slide the talk switch to ON (talk), and wait for a dial
tone. Press the numeric keypad (dialing keys) for the numebr you want.
KEY FEAT URES
Sound Effects
There are two sound effects buttons that activate Darth Maul and Darth
Sidious phrases from the movie. Push a button anytime when you want to
insert one into your conversation.
Redial
If the line is busy when you call someone, or you want to call someone you
just called, there is no need to dial the number again manually. When
pressed, the REDIAL button automatically dials the previous number. Slide
the talk switch to ON. When you hear a dial tone, press REDIAL instead of
dialing the number.
Ringer Volume Selector
The Darth Maul Phone features a harmonic ringer which can be adjusted
to a loud (HIGH) or soft (LOW) sound level. When you do not want to be
disturbed by incoming calls, slide the switch to the OFF position. You can
still make outgoing calls without being disturbed by incoming calls.
Flash
The FLASH button is used to switch from one call to another call if you
subscribe to call waiting with your phone service (this service is provided by
your local phone company and is not a feature of the phone itself). To
switch from one call to another, briefly press FLASH and then release the
button. You can switch back to the first call in the same manner.
Volume Control
Your Darth Maul Compact Phone features a dial control to regulate the
volume of the reception. If you are having trouble hearing the person you
are talking to, increase the volume until it is at a desirable level. If the
reception is too loud, decrease the volume level until it is at a desired level.
TROUBLESHOOTING
No Dial Tone
Check all modular plug connections to make sure they are securely
connected.
Problem with the wiring. Try another phone jack. If the phone works on
another jack, you may have a problem with your wiring. Contact your
local phone company.
Redial Function Does Not Operate
Check if the last number you dialed was the number you intended to call
with the redial feature.
Phone Does Not Ring
Check to see if the ringer switch is set correctly. Make sure RINGER
VOLUME SELECTOR is in either the LOW or HIGH position.
Too many telephones may be installed on the same line. Contact your
local telephone company to determine the maximum number of
extensions for your calling area.
Sound Volume Is Too Low
Check the VOLUME CONTROL DIAL to make sure it is not turned down
too low.
Another extension may be off the hook. Hang up extension.
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
(Figure 2)
(Figure 1)
Line Cord Connection
With a modular telephone system, connect the 10 feet of straight telephone
line cord included with the phone to the modular jack located on the bottom
of the handset (Fig. 1). Insert the other end of the cord into a modular wall
jack (Fig. 2). Make sure all plugs snap firmly in place.
Receiving a Phone Call
When the phone rings, pick up the handset and open the phone. Slide the
switch to ON (talk) position and it will work like any basic telephone. Slide
the switch to OFF to “hang-up” the telephone when you have completed
your conversation.
Read and understand all instructions.
Follow all warnings and instructions marked on the product.
Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Do not use this product near water, for example, near a bathtub, wash
bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming
pool.
Do not place this product on an unstable cart, stand, or table. The product
may fall causing serious damage to the product.
Slots and openings in the cabinet and the back or bottom are provided for
ventilation, to protect from overheating. These openings must not be
blocked or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product should
never be place near or over a radiator or heat register. This product should
not be placed in a built-in installation unless proper ventilation is provided.
![](/html/91/9162/9162679f36ccb273e16549e3bfd57939593c01a3447c8e4d85079c06e0d254a3/bg2.png)
Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short out parts that could result
in a risk of fire or electric shock. Never spill liquid of any kind on the
product.
To reduce the risk of electric shock, do not disassemble this product, but
take it to a qualified service person when some service or repair work is
required. Opening or removing covers may expose you to dangerous
voltages or other risks. Incorrect re-assembly can cause electric shock
when the appliance is subsequently used.
Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions.
When the power supply cord is damaged or frayed.
If liquid has been spilled into the product.
If the product has been exposed to rain or water.
If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, because improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to normal operation.
If the product has been dropped or the cabinet has been damaged.
If the product exhibits a distinct change in performance.
Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a risk of remote electric shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
SAVE THESE INSTRUCTIONS
FCC REQUIREMENTS
This equipment complies with Part 68 of the FCC Rules. On the base unit
of this equipment is a label that contains, among other information, the FCC
Registration Number and Ringer Equivalence Number (REN) for this
equipment. If requested, this information must be given to the telephone
company.
The REN is useful to determine the quantity of devices you may connect to
your telephone line and still have all of those devices ring when your
telephone number is called. In most, but not all areas, the sum of the
REN’s of all devices connected to one line should not exceed five (5.0). To
be certain of the number of devices you may connect to your line, as
determined by the REN, you should contact your local telephone company
to determine the maximum REN for your calling area.
of $18.00. Payment must be by check or money order payable to Tiger
Electronics, Ltd.
The foregoing states the purchaser’s sole and exclusive remedy for
any breach of warranty with respect to the product.
All products returned must be shipped prepaid and insured for loss or
damage to:
Tiger Electronics, Ltd.
980 Woodlands Parkway
Vernon Hills, Illinois 60061 U.S.A.
The product should be carefully packed in the original box or other packing
materials sufficient to avoid damage during shipment. Include a complete
written description of the defect, a check if product is beyond the 90-day
warranty period, and your printed name, address and telephone number.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES AND NO
OTHER REPRESENTATIONS OR CLAIMS OF ANY NATURE SHALL BE
BINDING ON OR OBLIGATE TIGER IN ANY WAY. ANY IMPLIED
WARRANTIES APPLICABLE TO THIS PRODUCT, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE NINETY (90) DAY
PERIOD DESCRIBED ABOVE. IN NO EVENT WILL TIGER BE LIABLE
FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM POSSESSION, USE, OR MALFUNCTION OF THIS
TIGER PRODUCT.
Some states do not allow limitations as to how long an implied warranty
lasts and/or exclusions or limitations of incidental or consequential
damages, so the above limitations and/or exclusions of liability may not
apply to you. This w arranty gives you specific rights, and you may also
have other rights which vary form state to state.
For more information about Tiger Electronics, our products and
special promotions, please visit our web site at www.tigertoys.com.
If your equipment causes harm to the telephone network the telephone
network, the telephone company may discontinue your ser vice tempor arily.
If possible, they will notify you in advance. But if advance notice isn’t
practical, you will be notified as soon as possible. You will be informed of
your right to file a complaint with the FCC. Your telephone company may
make changes in its facilities, equipment, operations or procedures that
could effect the proper functioning of your equipment. If they do, you will
be notified in advance to give you an opportunity to maintain uninterrupted
telephone service.
The telephone company may ask that you disconnect this equipment from
the network until the problem has been corrected or until you are sure that
the equipment is not malfunctioning.
This equipment may not be used on coin service provided by the
telephone company. Connection to party lines is subject to state
tariffs.
If you experience trouble with this telephone equipment, please contact the
following address and phone number for information on obtaining service or
repairs.
Company: Tiger Electronics, Ltd., Repair Dept.
Address: 980 Woodlands Parkway
Vernon Hills, IL 60061, U.S.A.
Tel. No.: 847-913-8100
This equipment is hearing aid compatible.
90-DAY LIMITED WARRANTY
Tiger Electronics, Ltd. (Tiger), warrants to the original consumer purchaser
of this product that the product will be free of defects in material or
workmanship for 90 days from the date for original purchase. This warranty
does not cover damages resulting from accident, negligence, improper
service or use or other causes not arising out of defects in materials or
workmanship.
During this 90-day warranty period, the product will either be repaired or
replace (at Tiger’s option) without charge to the purchaser, when returned
with proof of the date of purchase to either the dealer or to Tiger.
Product returned to Tiger without proof of date of purchase or after the 90day warranty period has expired, but prior to one year from the original date
or purchase, will be repaired or replace (at Tiger’s option) for a service fee
© Lucasfilm Ltd. & TM. All rights reserved.
Used under authorization.
®, TM, & © 1999 Tiger Electronics, Ltd.
All rights reserved.
980 Woodlands Parkway,
Vernon Hills, Illinois 60061 U.S.A.
Visit the Tiger Electronics, Ltd. web site: http://www.tigertoys.com
Printed in China
