Harris RF Communications Division XG-100P00 User Manual

Operator’s Manual

10515-0372-4200

Rev. E, Oct/11

UNITY® XG-100P

Full-Spectrum Multiband Radio

10515-0372-4200, Rev. E

without any warranty. Improvements and changes to this manual neces sitated by typographical errors,

at any time and without notice.

n any form or by any means,

Copyright © 2009, 2010, 2011 Harris Corporation.

MANUAL REVISION HISTORY

REV. DATE REASON FOR CHANGE

B Mar/11 Added P25 Trunking and updated for R 2.
C Jul/11 Updated noise-cancelling information.
D Sep/11 Updated accessories.
E Oct/11 Updated acc essories.
