Page 1
Exhibit 8: OEM Interface Manual
OEM INTERFACE MANUAL
DM-10
©1999 Ericsson Inc. Page 1 of 16
Page 2
Exhibit 8: OEM Interface Manual
CONTENTS – OEM INTERFACE MANUAL
1. DM10 TRANSCEIVER MODULE OUTLINE DRAWING.......................................................... 3
1.1. MECHANICAL.............................................................................................................................4
1.2. ELECTRICAL..............................................................................................................................5
1.2.1. ELECTRICAL PERFORMANCE ............................................................................................... 5
1.2.2. MOBILE STATION POWER CLASS.........................................................................................6
1.3. POWER CONSUMPTION..............................................................................................................6
1.3.1. TRANSMIT/TALK MODE ......................................................................................................6
1.3.2. STANDBY MODE ................................................................................................................. 6
1.3.3. SLEEP MODE (MINIMUM DC POWER CONSUMPTION) ..........................................................6
2. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 7
3. SAFETY .......................................................................................................................................... 8
3.1. EXPOSURE TO RADIO FREQUENCY ENERGY.............................................................................8
3.2. MODULE OPERATION ................................................................................................................8
3.3. POSTED FACILITIES...................................................................................................................8
3.4. ELECTRONIC DEVICES...............................................................................................................8
3.5. BLASTING AREAS.......................................................................................................................9
3.6. POTENTIALLY EXPLOSIVE ATMOSPHERES ...............................................................................9
3.7. VEHICLES...................................................................................................................................9
3.8. FOR VEHICLES EQUIPPED WITH AN AIRBAG..............................................................................9
3.9. RESPONSIBLE USE .....................................................................................................................9
4. TECHNICAL SPECIFICATIONS ............................................................................................... 12
4.1. GENERAL .................................................................................................................................12
4.2. RECEIVER SECTION.................................................................................................................12
4.3. TRANSMITTER SECTION ..........................................................................................................13
4.4. CONNECTORS...........................................................................................................................13
4.4.1. 30-PIN INTERFACE CONNECTIONS ..................................................................................... 13
4.4.2. RF INTERFACE CONNECTOR.............................................................................................. 14
4.4.3. DETAILED SIGNAL DESCRIPTIONS ..................................................................................... 14
4.4.4. SYSTEM CONNECTOR CMOS INTERFACE LEVELS ............................................................. 16
4.4.5. ACCESSORY CONNECTOR..................................................................................................16
4.4.6. SYSTEM CONNECTOR.......................................................................................................16
©1999 Ericsson Inc. Page 2 of 16
Page 3
Exhibit 8: OEM Interface Manual
1. DM10 Transceiver Module Outline Drawing
©1999 Ericsson Inc. Page 3 of 16
Page 4
Exhibit 8: OEM Interface Manual
1.1. Mechanical
©1999 Ericsson Inc. Page 4 of 16
Page 5
Exhibit 8: OEM Interface Manual
1.2. Electrical
The diagram below shows an overview of the electrical interface between the DM-10 module and a typical application.
DM-10 Electrical Interface
Power
User Interface
DTE
External Audio
Interface
Customer Application
HW
Voltage Regulator
Control Processor
Voice & Data Processing
Ÿ Echo Cancelling
Ÿ Noise Cancelling
Ÿ Audio Power AMP
Ÿ Data Conversion
Power & GND
10
Serial Interface 6 1
1
Analog Audio Interface
3
SIM Device
4
Clock REF
Wake
Option
PCM Audio Interface
Antenna
DM-10
Module
5
1.2.1. Electrical Performance
Electrical performance parameters are valid only when the terminating impedance at the output of the antenna connector exhibits a VSWR of less than 2:1 for all phase angles in the frequency band of operation. High VSWR loads at the antenna connector adversely affect current consumption, linearity, and power efficiency of the module and may prevent operation or cause internal damage.
The RF performance of the DM-10 fully meets the following specifications:
IS-136 TDMA Cellular mode – Per IS-137 specification
553 AMPS Cellular mode – Per IS-19 specification
©1999 Ericsson Inc. Page 5 of 16
Page 6
Exhibit 8: OEM Interface Manual
CDPD Mode – Per Cellular Digital Packet Data (CDPD) System Specification, Release
1.1, 19 January 1995 (CDPD will be supported in a future release of the DM10).
1.2.2. Mobile Station Power Class
The module is able to operate in several modes and different output power levels. Typical applications require output power levels similar to those in a handheld cellular phone (600-mW nominal) which is considered a power class IV unit for dual mode operation. It is possible to increase the output power level to that of a class I unit (4 W nominal) during the 5 second analog burst data mode. The table below shows the nominal output power levels (Effective Radiated Power, assuming an antenna system gain of 1 dBd (3.15 dBi) [2.5 dBd (4.65 dBi) antenna gain with 1.5 dB cable loss)).
Mobile Station Nominal Power Levels
Mobile Station Power Level (dBW)
0 1 2 3 4 5 6 7 8 9 10
Class I 6 2 -2 -6 -10 -14 -18 -22 -22 -22 -22
Class IV -2 -2 -2 -6 -10 -14 -18 -22
*Note: Output power levels maintained within range of +2 / -4 dB unless otherwise
noted Power levels 8-10 valid for digital mode only
-27±3 -32±4 -37±5
1.3. Power Consumption
1.3.1. Transmit/Talk Mode
DC current in mA AMPS Mode IS-136 Mode CDPD Mode
Peak 617 590 590600 mWatt RMS 617 355 355
3 W Burst Peak 1810 - -
1.3.2. Standby Mode
DC current in mA AMPS Mode IS-136 Mode CDPD Mode
RMS 36 15 15
1.3.3. Sleep Mode (Minimum DC Power consumption)
A power down or "sleep mode" is available in which the module is placed in a low power consumption state under control of the host application. In this mode, the unit consumes approximately TBD uA of current as measured from the VCC_6V supply input on pin 1 of the system connector. A logic level "0" on pin 19 of the system connector returns the unit to full operation although there may be a significant delay while the module reestablishes registration with the cellular network
©1999 Ericsson Inc. Page 6 of 16
Page 7
Exhibit 8: OEM Interface Manual
2. Absolute Maximum Ratings
Parameter Rating Units
Supply voltage
6.0 volts 5.2-6.8 Volts
13.6 volts 10.88-16.32 Volts Operating temperature -40 to +70 °C Storage temperature -40 to +85 °C
©1999 Ericsson Inc. Page 7 of 16
Page 8
Exhibit 8: OEM Interface Manual
3. Safety
3.1. Exposure to Radio Frequency Signals
This OEM module is a low power radio transmitter and receiver. The module is not designed as or to be configured as a hand held device. Use as a portable transmitter will require separate FCC approval for SAR compliance. Typical usage of this OEM module includes:
remote electrical meter reading
telematic communication for vehicles
fixed wireless terminals
Warning:
1. At no time is the antenna to be located closer than 20 centimeters to a normally
occupied location.
2. At no time should an antenna system with greater than 1.0 dB gain be used with this
module in any normally occupied area. The recommended antenna system configuration is a standard automotive antenna with 2.5 dB antenna gain and 1.5 dB cable loss.
3.2. Module Operation
Safe and efficient use of this module requires a properly terminated antenna. DO NOT operate the module with a damaged or missing antenna, replace a damaged or missing antenna immediately otherwise damage to the module may result and could violate FCC regulations. DO NOT operate this device within 8 inches (20 cm) of a person unless proper shielding from the antenna is installed.
3.3. Posted Facilities
Do not operate this device where posted notices require wireless devices to be turned off.
3.4. Electronic Devices
Most electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded properly against RF signals.
Pacemakers
The Health Industries Manufacturers Association recommends that a minimum separation of six (6) inches be maintained between a wireless transmitter and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research and recommendations of Wireless Technology Research. Persons with Pacemakers should always keep the antenna/module more than 6 inches from their pacemaker when the module is on; if you have a reason to suspect that interference is taking place, turn off the module immediately.
©1999 Ericsson Inc. Page 8 of 16
Page 9
Exhibit 8: OEM Interface Manual
Hearing Aids
Some digital wireless devices may interfere with some hearing aids.
Other Medical Devices
If you use any other type of personal medical device in the presence of this transceiver, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.
3.5. Blasting Areas
To avoid interfering with blasting operations, turn your module off when in a “blasting area” or in areas posted: “Turn off two-way radio”. Obey all signs and instructions.
3.6. Potentially Explosive Atmospheres
Turn your module off when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include such areas as gasoline stations; below deck on boats; fuel or chemical storage or transfer facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain dust or metal powders; and any other area where you would normally be advised to turn off your vehicle engine.
3.7. Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.
3.8. For Vehicles Equipped with an Airbag
An airbag inflates with a great force. Do not place objects including both installed or portable wireless equipment in the area over the airbag or in the airbag deployment area. If in-vehicle wireless equipment is improperly installed and the airbag inflates, serious injury could result.
3.9. Responsible Use
OEM Manufacturers providing telematic devices for vehicular use are encouraged to incorporate the following CTIA guidance for safe and responsible wireless phone use into their user’s manuals:
A Guide to Safe and Responsible Wireless Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY TAKE ADVANTAGE OF THE UNIQUE COMBINATION OF CONVENIENCE, SAFETY AND VALUE
©1999 Ericsson Inc. Page 9 of 16
Page 10
Exhibit 8: OEM Interface Manual
DELIVERED BY THE WIRELESS TELEPHONE. QUITE SIMPLY, THE WIRELESS PHONE GIVES PEOPLE THE POWERFUL ABILITY TO COMMUNICATE BY VOICE--ALMOST ANYWHERE, ANYTIME--WITH THE BOSS, WITH A CLIENT, WITH THE KIDS, WITH EMERGENCY PERSONNEL OR EVEN WITH THE POLICE. EACH YEAR, AMERICANS MAKE BILLIONS OF CALLS FROM THEIR WIRELESS PHONES, AND THE NUMBERS ARE RAPIDLY GROWING.
But an important responsibility accompanies those benefits, one that every wireless phone user must uphold. When driving a car, driving is your first responsibility. A wireless phone can be an invaluable tool, but good judgment must be exercised at all times while driving a motor vehicle--whether on the phone or not.
The basic lessons are ones we all learned as teenagers. Driving requires alertness, caution and courtesy. It requires a heavy dose of basic common sense---keep your head up, keep your eyes on the road, check your mirrors frequently and watch out for other drivers. It requires obeying all traffic signs and signals and staying within the speed limit. It means using seatbelts and requiring other passengers to do the same.
But with wireless phone use, driving safely means a little more. This brochure is a call to wireless phone users everywhere to make safety their first priority when behind the wheel of a car. Wireless telecommunications is keeping us in touch, simplifying our lives, protecting us in emergencies and providing opportunities to help others in need. When it comes to the use of wireless phones, safety is your most important call.
Wireless Phone "Safety Tips"
Below are safety tips to follow while driving and using a wireless phone, which should be easy to remember.
1. Get to know your wireless phone and its features such as speed dial and redial.
Carefully read your instruction manual and learn to take advantage of valuable features most phones offer, including automatic redial and memory. Also, work to memorize the phone keypad so you can use the speed dial function without taking your attention off the road.
2. When available, use a hands free device. A number of hands free wireless phone
accessories are readily available today. Whether you choose an installed mounted device for your wireless phone or a speaker phone accessory, take advantage of these devices if available to you.
3. Position your wireless phone within easy reach. Make sure you place your
wireless phone within easy reach and where you can grab it without removing your eyes from the road. If you get an incoming call at an inconvenient time, if possible, let your voice mail answer it for you.
4. Suspend conversations during hazardous driving conditions or situations. Let
the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions. Rain, sleet, snow and ice can
©1999 Ericsson Inc. Page 10 of 16
Page 11
Exhibit 8: OEM Interface Manual
be hazardous, but so is heavy traffic. As a driver, your first responsibility is to pay attention to the road.
5. Do not take notes or look up phone numbers while driving. If you are reading an
address book or business card, or writing a "to do" list while driving a car, you are not watching where you are going. It's common sense. Don't get caught in a dangerous situation because you are reading or writing and not paying attention to the road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place calls when you are not
moving or before pulling into traffic. Try to plan your calls before you begin your trip or attempt to coincide your calls with times you may be stopped at a stop sign, red light or otherwise stationary. But if you need to dial while driving, follow this simple tip--dial only a few numbers, check the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that may be distracting.
Stressful or emotional conversations and driving do not mix--they are distracting and even dangerous when you are behind the wheel of a car. Make people you are talking with aware you are driving and if necessary, suspend conversations, which have the potential to divert your attention from the road.
8. Use your wireless phone to call for help. Your wireless phone is one of the greatest
tools you can own to protect yourself and your family in dangerous situations--with your phone at your side, help is only three numbers away. Dial 9-1-1 or other local emergency number in the case of fire, traffic accident, road hazard or medical emergency. Remember that it is a free call on your wireless phone!
9. Use your wireless phone to help others in emergencies. Your wireless phone
provides you a perfect opportunity to be a "Good Samaritan" in your community. If you see an auto accident, crime in progress or other serious emergency where lives are in danger, call 9-1-1 or other local emergency number, as you would want others to do for you.
10. Call roadside assistance or a special wireless non-emergency assistance number when necessary. Certain situations you encounter while driving may
require attention but are not urgent enough to merit a call for emergency services. But you still can use your wireless phone to lend a hand. If you see a broken-down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.
Careless, distracted individuals and people driving irresponsibly represent a hazard to everyone on the road. Since 1984, the Cellular Telecommunications Industry Association and the wireless industry have conducted educational outreach to inform wireless phone users of their responsibilities as safe drivers and good citizens. As we approach a new century, more and more of us will take advantage of the benefits of wireless telephones. And, as we take to the roads, we all have a responsibility to drive safely.
©1999 Ericsson Inc. Page 11 of 16
Page 12
Exhibit 8: OEM Interface Manual
4. Technical Specifications
4.1. General
All ratings @12V supply unless otherwise specified
Parameter Conditions Min Typ Max Unit
Frequency range Transmit 834.390 835.620 MHz
Receive 879.390 880.620 MHz Channel spacing 30 kHz Number of channels 42 Supply voltage +8.5 +18 Volts Supply voltage ripple 10 Hz to 200 kHz 200 mV Supply current Sleep
Operating Temperature -40 +60 °C Antenna port impedance 50 Ohms
1
Standby
Transmit
2
3
25 50 mAmps
1300 1800 mAmps
12 15 mAmps
ÜÜ Notes
1. In sleep mode neither the receiver nor the transmitter is operating. The communications interface is completely operational.
2. When receiving a relatively strong signal (>-100 dBm), the typical current is approximately 25 mA. When the signal strength is less than -100 dBm, the operating current is approximately 45 mA.
3. Typical operating current during transmit mode is approximately 1300 mA. The current required in this mode is sensitive to the quality of the antenna termination impedance. With a poorly matched antenna, the operating current can approach 2 Amps. Note that a transmission lasts approximately 118 milliseconds.
4.2. Receiver Section
Parameter Conditions Min Typ Max Units
Sensitivity Adjacent channel rejection 16 dB Alternate channel rejection 60 dB Intermod rejection 65 dB RSSI range (digital) -116 -60 dBm RSSI accuracy (digital) +/- 3 dB RSSI range (analog) 0.75 1.75 volts
1
-116 dBm
ÜÜ Notes
1
Sensitivity is measured with respect to an analog test point after demodulation of the received
signal. External filtering is applied to make the test consistent with sensitivity tests typically
©1999 Ericsson Inc. Page 12 of 16
Page 13
Exhibit 8: OEM Interface Manual
performed on cellular telephones (as per IS-19B). The criteria for this test is > 12 dB SINAD for a 1 kHz audio tone modulating the carrier to 8 kHz peak deviation.
4.3. Transmitter Section
Parameter Min Typ Max Units
Power output Transmission duty cycle 2.5 % Peak Deviation +/- 8 kHz Frequency Stability - 2.5 + 2.5 ppm Carrier switching time 2 msec Channel switching time 40 msec Power levels (per CMAC) 8 (pwr levels 0-7)
ÜÜ Notes
1
The actual power output is controlled by the AMPS system via the CMAC register in the
overhead control message. Per EIA/TIA-553, the output power varies from +8 dBm to +36 dBm, in 4 dB steps.
1
0.0063 3 Watts (nom)
4.4. Connectors
4.4.1. 30-pin Interface Connections
Pin Signal Name Description TYPE
1 GND Chassis Ground ­2 GND/AD_in Chassis Ground (optionally A/D input) -/I 3 AFMS Audio from module O 4 GND Chassis Ground ­5 AGND Analog ground ­6 ATMS Audio to module I 7 OUT2 * Reserved O 8 WAKE Switches the main voltage regulator on/off I 9 IN2 * Reserved I 10 OUT1 * Reserved O/I 11 VDD * Logic reference O 12 IN1 * Reserved I 13 PCMCLK PCM Clock output O 14 PCMSYNC PCM Frame sync O 15 PCMULD PCM Voice input I 16 PCMDLD PCM Voice output O 17 GND Chassis Ground ­18 GND Chassis Ground ­19 DCD/VppFlash Data Carrier Detect and Flash Programming Voltage Input O/I 20 REF_CLK 19.44 MHz reference clock output O
©1999 Ericsson Inc. Page 13 of 16
Page 14
Exhibit 8: OEM Interface Manual
Pin Signal Name Description TYPE
21 CTS Clear to send O 22 DTR Data Terminal Ready I 23 TD Serial data to module I 24 RTS Request to Send I 25 VCC_12V 12 vdc supply (needed only for 3 Watt burst applications) I 26 RD Serial data from module O 27 VCC_12V 12 vdc supply (needed only for 3 Watt burst applications) I 28 VCC_12V 12 vdc supply (needed only for 3 Watt burst applications) I 29 VCC_6V 6 vdc regulated supply voltage I 30 VCC_6V 6 vdc regulated supply voltage I
* Pin used for SIM Interface in GSM based products. Pin function reserved for future use by U.S. products.
ÜÜ Notes
In modem mode, pin 8 is configured as an output and indicates whether a message is stored in the output buffer. In standalone mode, pin 8 is configured as an input and is used to warn the transceiver of an impending power failure.
4.4.2. RF Interface Connector
Radio frequency (RF) signals from the module to the external, customer-supplied antenna are made through a surface mount, microminiature snap-on M/A-COM connector. A wide variety of compatible mating connectors is available. A Pigtail assembly and the inter-series cable assembly from M/A-COM are two options. Since the mating connector can rotate through 360o, the application developer has maximum flexibility for routing the RF coax assembly. The total height of the mated M/A-COM RF connectors is 0.12 inches.
4.4.3. Detailed Signal Descriptions
DGND This is the supply voltage return (VCC_6V and VCC_12V) A/D_in
Minimum Maximum Input voltage for 0000 0000 word 0.05V Input voltage for 1111 1111 word 3.25V Linearity
± 0.5 LSB
Absolute accuracy -10mV +10mV Conversion time to within 0.5 bit
Input impedance
5µ sec
1M
External source impedance
©1999 Ericsson Inc. Page 14 of 16
Page 15
Exhibit 8: OEM Interface Manual
AFMS
Module audio output Output Impedance (active state) Output Impedance (inactive state) Output Impedance (pwr down state) Drive capacity into 50 Drive capacity into 5 k
External Device audio input Input
(0.3 – 3.5 kHz) Zout < 10 in series with ≥3.3
uF (-20%) Zout < 10 to VDD/2 Zout > 30 k
1.1 V
2.0 V
min.
P-P
min./ 4.0 V
P-P
P-P
max.
Zin > 50
Impedance
Volume control
± 12 dB from nominal > - 40
dB (mute)
Levels to external audio input 28 mVrms nominal 450
mVrms max.
ATMS
All sources must be AC coupled except for a microphone device. External audio source should be DC coupled in order for module to supply DC power to microphone. External audio source
Output impedance (active state) Output impedance (inactive state)
Zout 100 Zout > 10 k
Module audio input
Input impedance Output DC level unloaded for external
Zin > 2 k
2.0 V min.
audio source power Levels from external audio source HGA = 0 Audio input signal is amplified an
45 mVrms nominal 340 mVrms max.
1.5 mVrms nominal additional 32 db and a DC bias is provided to the microphone when HGA = 1
OUT1, OUT2 CMOS open drain output with 1 mA drive (See Section 4.3.4) WAKE
TTL compatible active low input (WAKE pin is tied to VDD through 51k resistor, recommend open collector/drain transistor)
I_01, I_03 CMOS bi-directional, tri-state output with 2mA drive (See Section 4.3.4) VDD 2.7 Vdc min 3.4 Vdc nominal 5.5 Vdc max PCMCLK (See Section 4.3.4) PCMSYNC (See Section 4.3.4) PCMULD (See Section 4.3.4) PCMDLD (See Section 4.3.4)
(See Section 4.3.4)DCD/VppFlash VppFlash programming voltage. Capability =
11.8 – 12.2 Vdc
60 ma min
REF_CLK
Frequency 19.44 MHz this output is switchable Output Level 0.7 min 1.0 typ 1.4 max volts
-P2P
Harmonic Content -10dBc max
RTS, CTS, DTR (See Section 4.3.4)
©1999 Ericsson Inc. Page 15 of 16
Page 16
Exhibit 8: OEM Interface Manual
RD,TD (See Section 4.3.4) VCC_12V VCC_6V
13.6 volt ± 20%, 1.5 A max 6 volt ± 13.3% regulated, 1A max
4.4.4. System Connector CMOS Interface Levels
LimitsQuantity Symbol
Min Typ Max High level output voltage (IOH= rated) V Low level output voltage (IOL= rated) V High level input voltage V Low level input voltage V
OH OL
IH IL
0.9 *VDD VDD Volts 0 0.1.*VDD Volts
0.8 *VDD VDD Volts 0 0.2 *VDD Volts
4.4.5. Accessory Connector
Connections to an optional accessory board are made through a 14-pin accessory connector. Add-on accessories under consideration include a GPS receiver, a Bluetooth transceiver, and a CeBus transceiver
16-Pin Accessory Connector Functions
Connector / Pin Signal Name Description X353 / 1 VCC_6V 6 VDC supply input
X353 / 2 GND Digital ground X353 / 3 CLKREQ Request from accessory to keep providing reference clock X353 / 4 ARESET Reset signal to accessory X351 / 1 ASYNC Request from accessory for frame sync X351 / 2 TBD SPARE X351 / 3 IU3T DTMS X351 / 4 IU3R DFMS X351 / 5 ADATAUP Data to accessory (PCM link) X351 / 6 APCMSYNC Sync line (PCM link) X351 / 7 APCMCLK Clock line (PCM link) X351 / 8 ADATDOWN Data from accessory board (PCM link) X351 / 9 ASYSCLK 19.44 MHz reference clock to accessory X351 / 10 AWAKE Wake-up signal to accessory X351 / 11 IU2T IU2T X351 / 12 IU2R IU2R
Units
4.4.6. System Connector
External interfaces to the module are made primarily through a 30-pin, standard 0.050 inch pitch, ODU header shown.
©1999 Ericsson Inc. Page 16 of 16
Loading...
