HARRIS TR 0101 E User Manual

Overview Manual

MM-015039-001

Rev. E, Sep/12

MASTR® V

Base Station

MM-015039-001, Rev. E

This product conforms to the European Union WEEE Directive 2002/96/EC. Do not dispose of this product in a

without any warranty. Improvements and changes to this manual

necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment,

ice. Such changes will be incorporated into new editions of

this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical,

Copyright © 2009-2012, Harris Corporation. All rights reserved.

MANUAL REVISION HISTORY

REV DATE REASON FOR CHANGE

B Jul/10 Updated LED indicator tables and graphics. Added equipment weights, dimensions, and

VIDA secure Information Assurance information.
C Mar/11 Updated product specifications.
D Jun/11 Updated VHF regulatory and product information.
E Sep/12 Added new DC distribution panels (EA-555019-003 and EA-555019-004), P25 Phase 2

information, and regulatory information for UHF band.
