Maintenance Manual

MM101271V1 R2A

SitePro™ Controller

Shelf Assembly EA101209V1

ADDENDUM NUMBER 1 TO SITEPRO MAINTENANCE MANUAL

MM101271V1 R2A

This addendum adds an improved high-speed data (HSD) adjustment procedure to the following manuals:

• SitePro Controller Maintenance Manual MM101271V1 R2A

• SitePro Simulcast Controller Card Maintenance Manual MM101509V1 R1A

• GPS Simulcast Systems (with SIM and SitePro Controllers)

System Alignment and Field Testing Procedures MM101724V1 R1A

This improved procedure allows the adjustment to be made on-the-fly without the need to put the SitePro Controller into Test Mode. The adjustment range is the same as with the earlier procedure [two hexadecimal digits 00-FF]. The values entered will take effect immediately. By writing these values to EEprom they will persist through a reset. From a hyper-terminal connected to the SitePro Controller serial port following:

HIGH-SPEED DATA ADJUSTMENT PROCEDURE

Adjust HSD by modifying the pot setting. Once the correct level is found it must be stored in permanent memory.

1. Adjust the 'real time' high-speed level: SI2C 50 1 5 <rtn> sets slave device for all subsequent read/write operations (50 is EE pot)

perform the

2. Read current data from the HSD pot: RI2C A9 A9 <rtn> reads current data at specified address range (A9 is location of the HSD pot)

3. Write new values to the HSD pot. The value from step 2 provides an initial set point. The command to

write a value is:

WI2C A9 xx <rtn> were xx is the hexadecimal value written to the HSD pot. Write new values

until the desired deviation is achieved.

4. Store the new value which achieves the desired deviation into permanent memory (novRAM) using the

following commands:

SI2C A6 2 5 <rtn> sets slave device for all subsequent read/write operations (A6 is EEprom) WI2C 03 xx <rtn> writes new value of the HSD Pot in EEprom (03 is location of HS level) RI2C 03 03 <rtn> reads current value of the HSD Pot from EEprom (to check if written

correctly)

This procedure can also be performed through an ethernet port. Refer to the applicable manual for instructions.

NOTICE!

This manual covers products manufactured and sold by M/A-COM Private Radio Systems, Inc.

NOTICE!

Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs, alterations or substitution of recommended parts made by the user to this equipment not approved by the manufacturer could void the user's authority to operate the equipment in addition to the manufacturer's warranty.

NOTICE!

The software contained in this device is copyrighted reserved under the copyright laws of the United States.

M/A-COM Private Radio Systems, Inc. Unpublished rights are

This manual is published by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by

Systems, Inc

reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of

EDACS is a registered trademark, and Aegis, ProVoice, GETC and SitePro are trademarks of

., at any time and without notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be

M/A-COM Private Radio Systems, Inc

. without any warranty. Improvements and changes to this manual necessitated by

M/A-COM Private Radio Systems, Inc

M/A-COM Private Radio

2 MM101271V1 R2A
