HARRIS P-801T Users Manual

*
P-801 User’s Manual
Voice Terminal Radio
P-801 User’s Manual
Page 1
P-801 User’s Manual
g
g
Notices to the user
•Government law prohibits the operation of unlicensed transmitters within the territories under government control.
•Illegal operation is punishable by fine or imprisonment or both.
•Refer service to qualified technicians only.
•Do not operate your transceiver in explosive atmospheres (gases, dust, fumes, etc.)
FCC Warnin
Page 2
This equipment generates or uses radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to oper­ate this equipment id an unauthorized change or modification is made.
P-801 User’s Manual
Page 3
P-801 User’s Manual
Information to the digital device user required by the FCC
FCC limits
RF Interference
Page 4
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designe d to prov ide reasonable protection against harmful interference in a residential installation.
This equipment gen erates and uses radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipm ent do es cau se harm ful interference to radio or television reception, t he user is encouraged to try to correct the interference by one or more of the following measures.
•Re-orient or relocate the receiving antenna
•Increase the separation between the equipment and the receiver.
•Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
•Consult the a service center for technical assistance.
Accessory Installation
P-801 User’s Manual
Overview
The P-801 can be used with a variety of optional accessories including; batteries, antennas, and microphones. This section tells you how to install the accessories before your f irst use of the radio. refer to each accessory manual for specif ics on installation and operation.
Page 5
P-801 User’s Manual
Page 6
Installing the Battery Pack
P-801 User’s Manual
Preparation
Procedure
Your battery is not charged at the factory. Refer to the battery instructions and charge the battery before you install it.
Follow the steps in the facing table to install yo ur battery.
Continued on next page
Page 7
P-801 User’s Manual
Installing the Battery Pack (continued)
Step Action
1
2
3
Page 8
Match the four grooves on the battery pack with the corresponding catches on the back of the radio.
Slide the battery back along the grooves until that battery drops onto the catches.
Push the battery until the release latch on the base of the radio locks.
Installing the Antenna
P-801 User’s Manual
Procedure
Follow the steps below to install the radio antenna.
Step Action
1 2
Mate the antenna screw post with the connector on the top of the radio. Turn the antenna clockwise until the antenna base is flush with the top
of the radio.
insert figure
Page 9
P-801 User’s Manual
Installing the Belt Hook
Procedure
Follow the steps below to install you r rad io’s belt hook.
Step Action
1
2
Page 10
Align the holes on the belt hook with the mounting holes on the radio as shown.
Screw the belt hook in place using the two 3x6 mm screws.
Installing Universal Connector Accessories
P-801 User’s Manual
Overview
Procedure
The universal c onn ector is used to con nect several types of acces­sories.
Follow the steps in the table below to install accessories that use a universal connector
Step Action
1
2
Insert the tab on the end of accessory’s connector into the slot on radio’s connector.
Tighten the connector screw to secure the microphone in place. The connector should be flush with the hou sing to keep the radio water resistant.
Page 11
P-801 User’s Manual
Covering the Universal Connector
When to cover the connector
Procedure
If no accessory is used with the radio, cover the uni ver sal connec­tor with the cap to keep the radio water resistant
Follow the steps in the table below to cover the universal connector.
Step Action
1
2
Page 12
Insert the tab on the end of the cover connector into the slot on radio’s connector
Insert and tighten the 4x6 mm screw. The cover should be flush with the housing to keep the radio water resistant.
.
.
OpenSky Explained
Overview
Overview
The P-801 Voice Terminal Radio is a key component of the OpenSky network. This section gives an overview of the Open­Sky system and OpenSky features and benefits·
P-801 User’s Manual
OpenSky network
The P-801 Voice Terminal Radio is a part of the OpenSky net­work. The OpenSky netwo rk is an integrated voice and data com­munications system. The network provides a communication backbone that enables voice to be converted to digital informa­tion and then transmitted over a wireless network. Data applica­tions can be used simultaneous ly with voice over the same network.
Continued on next page
Page 13
P-801 User’s Manual
OpenSky Explained (continued)
OpenSky features and benefits
Page 14
OpenSky connects seamlessly with existing applications and provides significant user benefits. OpenSky:
•Provides one communication system to many users and agencies maximizing inter operability. One communication system eliminates the need for a user to carry more than one radio to communicate mission critical information.
•· Allows radios to automatically roam between base stations, relieving radio users of the task of switching channels when moving to a new coverage area.
•· Offers greater system availability by providing improved peak traffic for all voice and data information.
•· Allows voice commu nication while data is being sent or received without having to switch radio modes.
•· Locates users quickly and accurately in an emergency using radios equipped with the Global Positioning System (GPS) option.
•· Prio ritizes communications, eliminating non-essential information and preventing information overload .
OpenSky Terms and Concepts
y
Voice Features Explained
P-801 User’s Manual
Voice features overview
Radio Personalit
Voice profile
Each time you power up and access the OpenSky Network, v o ice features are loaded into your radio. The these features combined are known as your radio personality which establishes features such as:
· Who you will communicate with over the network
· What calls have priority over others
A radio personality is made up of up to 16 voice profiles. Voice profiles organize your radio personality into categories defined by your network administrators.
A collection of up to 16 voice groups.Of the 16 possible voice groups, only one is active at any given time.
Page 15
P-801 User’s Manual
p
p
Voice Features Explained (continued)
Voice Groups
Talk Grou
Listen grou
Page 16
Voice groups are used to further break down the voice profile. Voice groups are a subset of the users in a prof ile and are made up of a number of users who regularly need to communicate. There can be any amount of users in a voice group. Your OpenSky net­work administration personnel establish and organize voice groups.Voice groups are categorized as either talk groups or listen groups.
The primary voice group in a profile. This is the group of users you will talk with and listen to the most. The first voice group in each profile is designated as your talk group.
You normally hear the voice calls from the users in this group, but your voice does not transmit to them.
Continued on next page
Voice Features Explained (continued)
P-801 User’s Manual
Diagram
The figure below summarizes OpenSky Voice features.
Before You Start
Controls and Indicators
Side Views of radio
Page 17
P-801 User’s Manual
Page 18
insert top
P-801 User’s Manual
Page 19
P-801 User’s Manual
Page 20
Turning On the Radio
P-801 User’s Manual
Getting Started
Procedure
Follow the step below to turn your radio on.
Step Action
1
Ready state
Turn the Power/Volume switch clockwise un til it clicks.
The startup sequence lasts approximately 10 seconds. The radio is ready to use after this sequence.
Use the figure below to know how the radio will appear as it is ready for use.
Page 21
P-801 User’s Manual
Page 22
Shutting Off the Radio
P-801 User’s Manual
Procedure
Follow the step below to turn your radio off.
Step Action
1
Turn the Power/Volume switch counter clockw ise until it clicks.
Page 23
P-801 User’s Manual
Page 24
Adjusting the Volume
P-801 User’s Manual
Procedure:
Follow the steps below to adjust the radio’s volume.
Step Action
1 2
Turn the Power/Volume knob to adjust the volume Use the table below to determine your next step.
To... Turn...
Increase the volume Clockwise Decrease the volume Counter-clockwise
Page 25
P-801 User’s Manual
Listening to Voice Calls
Background
Process
Once the radio is turned on and active on your OpenSk y network, you may begin to hear voice calls.
The table below describes what happens when you receive a voice call.
StageDescription
1
2
3
Page 26
Your radio display changes briefly to show the name of the voice group that the call is coming from.
The LED indicator will turn green and blink while the call is being received.
At the end of the call, you will hear a single end tone. This lets you know that the person speaking is done with that portion of their transmission.
Making a Voice Call
P-801 User’s Manual
Background
Voice call
The steps for making a voice call are similar to those of a conventional radio.
Follow the steps below to make a voice call.
procedure
Step Action
1
If needed, turn the POWER knob to turn on the radio.
The radio will be ready to use following the startup sequence. When you see the primary voice profile displayed, you are ready to talk.
Continued on next page
Page 27
P-801 User’s Manual
Making a Voice Call (continued)
Step
Page 28
Action
2
3
4
Choose your next step from the table below.
If... Then...
No one is talking Continue to step 3 Someone is talking W ait to hear a single end
tone indicating they are done talking and continue to step 3.
Press the push-to- talk button and speak normally.
A blinking red LED tells you that you are transmitting. If you hear three low tones, the network is busy. Wait a few seconds and try you call again.
Release the push-to-talk button when you are tone talking.
Changing the Side Tone Setting
P-801 User’s Manual
Background
Side tones provide audio feedback when the MENU, or SEL buttons are pressed. The default setting is for side tones to be on.
Procedure
Follow the steps below to change the side tone setting.
Step Action
1
Press the MENU button until th e side tone menu shows.
Continued on next page
Page 29
P-801 User’s Manual
y
play
Changing the Side Tone Setting (continued)
Step
Page 30
Action
2
3
Use the table below to determine your next step.
ou want to… Press the SEL until the
If
dis
Hear side tones SIDE:ON
Disable side tones SIDE: OFF Result: You will have changed the side to ne setting. To return to the menu display, choose from the following table
To return… Then Immediately Push MENU After a brief wait Wait approximately 10
seconds
Result: The radio returns to the menu display.
shows...
Adjusting the Display Brightness
P-801 User’s Manual
Background
Procedure
You can adjust the brightness of the display to suit your needs.
Follow the steps below to change the brightness of the display.
Step Action
1
Press the MENU button until th e brightness menu shows.
Continued on next page
Page 31
P-801 User’s Manual
y
Changing the Display Brightness, continued
Step
Page 32
Action
2
3
Use the table below to determine your next step.
ou want to… Then press...
If
Increase brightness SEL Up button
Disable side tones SEL Down button Result: You will have changed the brightness setting. To return to the menu display, choose from the following table
To return… Then Immediately Push MENU After a brief wait Wait approximately 10
seconds
Result: The radio returns to the menu display.
Adjusting the Display Contrast
P-801 User’s Manual
Background
Procedure
You can adjust the contrast of the display to suit your needs.
Follow the steps below to change the contrast of the display.
Step Action
1
Press the MENU button until th e con trast menu shows.
Continued on next page
Page 33
P-801 User’s Manual
y
Changing the Display Contrast (continued)
Step
Page 34
Action
2
3
Use the table below to determine your next step.
ou want to… Then press...
If
Increase contrast SEL Up button
Decrease contrast SEL Down button Result: You will have changed the contrast setting. To return to the menu display, choose from the following table
To return… Then Immediately Push MENU After a brief wait Wait approximately 10
seconds
Result: The radio returns to the menu display.
Changing the Active Voice Profile
P-801 User’s Manual
Background
You can change the active profile of your radio from the default profile to any of the other profiles in your radio personality.
Making this change means that you are switching the list of talk groups and listen groups that you normally communicate with.
Procedure
Follow the steps below to change the active voice profile.
Step Action
1 2
Press MENU until the primary menu shows. Turn the Profile Selector to move to the desired profile.
Result:
The displayed profile is now active. The radio display will change to show the new profile number and the alias name for the talk group in the selected profile.
Advanced Operation
Page 35
P-801 User’s Manual
Increasing the Scanning Priority of a Voice Group
Background
Process
You can prioritize hearing transmissions from a specific voice
group over others in an active voice profile. When the priority is
increased, transmissions from other users in the priority voice
group will take precedence over the other voice groups in the
profile.
The table below describes the process for increasing a voice
group's scanning priority.
Stage Description
1 2 3
Page 36
The voice profile with the voice group to be prioritized is activated. The priority menu is accessed. The desired voice group is prioritized.
Continued on next page
P-801 User’s Manual
Increasing the Scanning Priority of a Voice Group, Continued
Procedure
Follow the steps below to increase the scanning priority of a
voice group.
Step Action
1 2
3 4
Press MENU until the primary menu shows. Press SEL to move to the voice profile that contains the voice group
you want to scan with a higher priority. Press MENU to access the priority menu.
Press SEL until the voice group you want to prioritize is displayed.
Result
: The selected voice group's transmission priority is increased
Continued on next page
Page 37
P-801 User’s Manual
Increasing the Scanning Priority of a Voice Group, Continued
Procedure (continued)
Step Action
5
Page 38
Use the table below to determine your next step.
T o return … Then... Immediately Push the MENU button After a brief wait Wai t approximately 10 seconds
Result: The radio will return to the menu display.
Notes:
•Changing the priority of a voice group does not impact which voice group in your profile is the talk group.
•You can prioritize one voice group in each of the profiles in your radio personality.
•Th e priority settings are reset to the default talk group when the radio is shut off.
Changing the Scanning Mode
g
P-801 User’s Manual
Scanning Modes
Normal scannin defined
Changing the scanning mode can broaden or narrow the span of your communications. There are three available scanning modes:
•· Normal scanning
•· Talkback Scanning, or
•· No scanning
Choosing one of the three changes the way your radio scan s all of the voice profiles for your radio personality.
The radio monitors calls and enables audio output when any voice group in its voice profile becomes active. If multiple voice groups in the radio's scan list are active, the radio listens to the one with the highest scan-priority. After a higher scan-priority call ends, the radio joins the next highest scan-priority in progress on a first- come, first-ser ved basis.
Continued on next page
Page 39
P-801 User’s Manual
g
Changing the Scanning Mode, continued
Talkback scannin defined
No scanning defined
Procedure
Page 40
Each voice group has an associated talkback timer that defines its talkback window. This window is the period of time from the end of a call to when you press your microphone key.
·If the talkback timer has not expired and the radio is configured for talk back scanning, the radio calls the last voice group, instead of its default talkgroup.· If the talkback timer expires, your call is placed on the default talk group
The radio only listens to the selected talk group.
The following table details the procedure for changing the scanning mode of the radio.
Continued on next page
Changing the Scanning Mode, continued
Step Action
1
Press MENU until the scanning menu appears.
P-801 User’s Manual
2
Choose the scanning mode:
To... Press SEL until…
Broaden transmissions beyond the active talkgroup
Use Normal Scanning Normal Scan is displayed Narrow your scanning
list to the active talkgroup only
Result: The scanning mode you chose is active for all the voice profiles in your radio personality.
Talkback SCN is displa yed
No Scanning is displayed
Page 41
P-801 User’s Manual
Changing the Operating Mode
Background
Procedure
The radio normally operates using OTP to provide the full features of a digital voice and data network. To interoperate with radios using other protocols such as Conventional FM, you can manually change the mode of operation to a different protocol.
The table below describes the steps to follow to change the operating mode of the radio.
Step Action
1 2
Page 42
Press MENU until the mode change menu appears. Press SEL to access the Change Mode 2 menu.
Continued on next page
P-801 User’s Manual
Changing the Operating Mode, continued
Step
3
Action
Choose your next step from the table below.
To... Turn...
Abort the mode change Menu
Result: The radio will display Aborted! and the change will be aborted.
Continue SEL until the
SEL2Sel Mode menu is displayed.
Continued on next page
Page 43
P-801 User’s Manual
Changing the Operating Mode, Continued
Procedure (continued)
Step Action
4 5 6
Page 44
Press SEL until t he desired mode is displa yed. Press MENU to change the mode.
Choose your next step from the table below.
To... Turn...
Abort the mode change Menu
Result: The radio will return to the primary menu without executing the change.
Continue SEL
Result: The radio powers down and reboots in the selected mode.
Loading...
