Installation Manual
MM102365V1
Rev. B, Jul-04
SkyLink® ISM Radio Network
ISM Radio and Backhaul Router
MM102365V1 Rev. B
MANUAL REVISION HISTORY
REV DATE REASON FOR CHANGE
R1A Feb. 2004 Original Release
B Jul. 2004 Updated Table 6-1: ISM Antennas and added antenna installation caution.
M/A-COM Technical Publications would particularly appreciate feedback on any errors found in this document and suggestions on how
the document could be improved. Submit your comments and suggestions to:
Wireless Systems Business Unit
M/A-COM, Inc.
Technical Publications
221 Jefferson Ridge Parkway
Lynchburg VA, 24501
fax your comments to: (434) 455-6851
e-mail us at: techpubs@tycoelectronics.com
This manual and the hardware and software it describes are copyright © 2004 M/A-COM, Inc. All rights are
reserved under the copyright laws of the United States and Canada and other laws. Without limiting the rights
under copyright, no part of this document may be reproduced, stored in or introduced into a retrieval system, or
transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for
any purpose, without the express written permission of M/A-COM, Inc.
The contents of this manual are not intended to and do not constitute a warranty of any sort. M/A-COM, Inc and
Tyco Electronics specifically disclaim any implied warranties of merchantability or fitness for any particular
purpose resulting from this manual.
Information in this document is subject to change without notice. M/A-COM, Inc. reserves the right to revise and
make changes to this manual (and to the product and software) from time to time without obligation to notify any
person of, or to provide any person with, such revisions or changes.
M/A-COM, Inc. and/or Tyco Electronics may have patents, patent applications, trademarks, copyrights, or other
intellectual property rights covering subject matter in this document. Except as expressly provided in any written
license agreement from M/A-COM, the furnishing of this document does not give any license to these patents,
trademarks, copyrights, or other intellectual property.
Windows and Windows95 are registered trademarks of Microsoft Corporation.
All other brand and product names are trademarks, registered trademarks, or service marks of their respective
holders.
Notice of Copyright
Copyright ©2004 M/A-COM, Incorporated.
All rights reserved.
Notice of Trademark
The name M/A-COM, the OpenSky and SkyLink product names, and the M/A-COM and OpenSky logos are all trademarks of
M/A-COM, Inc.
M/A-COM, Inc.
1011 Pawtucket Blvd.
Lowell, MA 01853
Phone: 978.442.4000
Printed in the United States of America.
2
MM102365V1 Rev. B
TABLE OF CONTENTS
Page
1. REGULATORY AND SAFETY INFORMATION......................................................................... 8
1.1 REGULATORY INFORMATION........................................................................................................... 8
1.2 SAFETY DURING INSTALLATION AND SERVICE.......................................................................... 9
1.3 SAFETY SYMBOLS.............................................................................................................................. 10
2. SPECIFICATIONS ......................................................................................................................... 11
2.1 ISM TOWER TOP RADIO .................................................................................................................... 11
2.1.1 Transmit........................................................................................................................................ 11
2.1.2 Receive ......................................................................................................................................... 11
2.1.3 Physical......................................................................................................................................... 12
2.1.4 Environmental .............................................................................................................................. 12
2.1.5 Power............................................................................................................................................ 12
2.2 BACKHAUL ROUTER.......................................................................................................................... 12
2.2.1 Interfaces ...................................................................................................................................... 12
2.2.2 Fiber Optic Interface..................................................................................................................... 12
2.2.3 Physical......................................................................................................................................... 13
2.2.4 Environmental .............................................................................................................................. 13
2.2.5 Power............................................................................................................................................ 13
3. INTRODUCTION ............................................................................................................................ 14
3.1 PRODUCT DESCRIPTION ................................................................................................................... 14
3.2 COMPONENTS...................................................................................................................................... 14
3.2.1 ISM Radio .................................................................................................................................... 14
3.2.2 Backhaul Router ........................................................................................................................... 14
3.3 SUB-SYSTEM COMMUNICATION LINKS........................................................................................ 15
3.4 RADIO OPERATING MODES: MASTER AND SLAVE.................................................................... 15
3.4.1 Master ........................................................................................................................................... 15
3.4.2 Slave ............................................................................................................................................. 15
3.5 ISM NETWORK CONFIGURATION ................................................................................................... 15
3.5.1 Networked Master/Slave .............................................................................................................. 16
3.5.2 Packet Path To The Tower Site .................................................................................................... 16
3.5.3 Packet Path to the Backhaul Router.............................................................................................. 16
3.5.4 Packet Path to the Cell Site ISM Radios....................................................................................... 16
3.6 OPENSKY APPLICATIONS ................................................................................................................. 17
3.6.1 Standalone Repeater Operation .................................................................................................... 17
3.6.2 Cell-Drop-and-Repeat Operation ................................................................................................. 17
3.7 TECHNICAL ASSISTANCE ................................................................................................................. 18
4. UNPACKING AND CHECKING EQUIPMENT ......................................................................... 19
4.1 UNPACKING EQUIPMENT ................................................................................................................. 19
4.2 INSPECTING AND INVENTORYING EQUIPMENT......................................................................... 19
5. PRE-INSTALLATION CONSIDERATIONS ............................................................................... 20
5.1 CHECKLIST........................................................................................................................................... 20
3
MM102365V1 Rev. B
TABLE OF CONTENTS
5.2 BACKHAUL ROUTER INSTALLATION CHECKLIST ..................................................................... 20
5.3 PREPARATION FOR FIELD INSTALLATION................................................................................... 21
5.4 SAFETY RECOMMENDATIONS......................................................................................................... 21
5.5 HAZARD WARNINGS.......................................................................................................................... 21
5.6 ELECTROSTATIC DISCHARGE ......................................................................................................... 22
5.7 CABLING CONSIDERATIONS............................................................................................................ 22
5.7.1 Ethernet Connections.................................................................................................................... 22
5.7.2 ISM Radio Power/Fiber Optic Connections .................................................................................22
5.7.3 Maintenance Port Connection....................................................................................................... 22
6. INSTALLATION.............................................................................................................................. 24
6.1 TOWER TOP ISM RADIO ENCLOSURE INSTALLATION .............................................................. 24
6.1.1 Power and Grounding Requirements............................................................................................ 24
6.1.2 Lightning Protection ..................................................................................................................... 24
6.1.3 ISM Radio Co-Located with the Backhaul Router ....................................................................... 25
6.1.4 Connect Radio to Another ISM Device ........................................................................................26
Page
6.2 ANTENNA SYSTEM INSTALLATION ............................................................................................... 26
6.2.1 Antenna Installation...................................................................................................................... 26
6.2.2 Antenna RF Cable Installation...................................................................................................... 27
6.2.3 Antenna System Testing ............................................................................................................... 27
6.3 POWER/FIBER OPTIC CABLE INSTALLATION .............................................................................. 28
6.3.1 Installing the Power/Fiber Optic Cable Assembly........................................................................ 29
6.4 BACKHAUL ROUTER INSTALLATION ............................................................................................ 31
6.4.1 Front Panel Features .....................................................................................................................31
6.4.2 Rear Panel Features ...................................................................................................................... 32
6.4.3 Mounting the Backhaul Router..................................................................................................... 33
6.4.4 Power Cable Installation ............................................................................................................... 33
6.4.5 Ethernet Connection ..................................................................................................................... 34
6.4.6 Fiber Optic Connection................................................................................................................. 34
6.5 MAINTENANCE AND TEST CONNECTIONS................................................................................... 35
6.5.1 Connecting an ISM Radio to a PC or Terminal ............................................................................ 35
6.5.2 Connecting Backhaul Router to a PC or Terminal........................................................................ 35
6.5.3 Maintenance Port Settings ............................................................................................................37
7. NETWORK CONFIGURATION ................................................................................................... 38
7.1 INTRODUCTION................................................................................................................................... 38
7.2 ROUTING TABLES ............................................................................................................................... 38
7.3 CONFIGURING THE BACKHAUL ROUTER..................................................................................... 39
7.3.1 Step 1 – Configure Backhaul ISM and IP Network Addresses ....................................................39
7.3.2 Step 2 – Setup Backhaul Routing Table ....................................................................................... 39
7.4 CONFIGURING THE TOWER TOP RADIO........................................................................................ 40
7.4.1 Step 1 – Configure the Tower Top Radio Topology ....................................................................40
7.4.2 Step 2 – Configure the Tower Top Radio Routing Table............................................................. 40
7.4.3 Step 3 – Configure the Tower Top Radio RF Table..................................................................... 41
7.4.4 Step 4 – Configure the Tower Top Radio Frequency List Table.................................................. 41
7.4.5 Step 5 – Verification Configuration.............................................................................................. 41
4
MM102365V1 Rev. B
TABLE OF CONTENTS
Page
7.5 CONFIGURING THE CELL SITE ISM RADIO................................................................................... 42
7.5.1 Step 1 – Configure Cell Site Radio Topology.............................................................................. 42
7.5.2 Step 2 – Configure Cell Site Radio Routing Table....................................................................... 42
7.5.3 Step 3 – Configure Cell Site Radio RF Table............................................................................... 42
7.5.4 Step 4 – Configure Cell Site Radio Frequency List Table ........................................................... 43
7.5.5 Step 5 – Connect Test Antenna .................................................................................................... 43
7.5.6 Step 6 – Verify Configuration ...................................................................................................... 43
8. SAMPLE ISM NETWORK CONFIGURATION ......................................................................... 44
8.1 CONFIGURATION PROCEDURE. ......................................................................................................45
8.1.1 Configure Backhaul Router .......................................................................................................... 46
8.1.2 Configure Tower Radio................................................................................................................ 47
8.1.3 Verification Commands................................................................................................................ 48
8.1.4 Configure Cell Site Radio 3.......................................................................................................... 48
8.1.5 Configure Cell Site Radio 4.......................................................................................................... 49
8.1.6 Configure Cell Site Radio 5.......................................................................................................... 50
8.1.7 Verification Commands................................................................................................................ 50
9. AT COMMAND SET....................................................................................................................... 51
9.1 USING HELP COMMAND ................................................................................................................... 51
9.1.1 Accessing the Function Displays.................................................................................................. 51
9.1.2 Accessing Verbose Information ................................................................................................... 54
9.1.3 Displaying Configuration Information ......................................................................................... 55
9.2 SETTING DEVICE PARAMETERS ..................................................................................................... 55
9.2.1 Network Administration ............................................................................................................... 55
9.2.2 Changing the ISM Address........................................................................................................... 55
9.2.3 Changing the IP Address .............................................................................................................. 56
9.2.4 Displaying Backhaul MAC Address ............................................................................................56
9.2.5 Changing the UDP Port Address.................................................................................................. 56
9.2.6 Changing Default ISM Destination .............................................................................................. 57
9.2.7 Changing RF Slot Interval Timer ................................................................................................. 57
9.2.8 Changing RF Packets per Interval ................................................................................................ 57
9.2.9 Changing RF Transmit Delay....................................................................................................... 58
9.2.10 Changing Mode of Operation....................................................................................................... 58
9.2.11 Changing Network Port Assignment............................................................................................ 59
9.2.12 Enabling +15 VDC on Port A or B .............................................................................................. 59
9.3 MANAGING THE ROUTING TABLE ................................................................................................. 60
9.3.1 Saving the Routing Table ............................................................................................................. 60
9.3.2 Routing Table Entries................................................................................................................... 60
9.3.3 Adding a Routing Table Entry...................................................................................................... 61
9.3.4 Removing a Routing Table Entry................................................................................................. 62
9.3.5 Displaying Routing Table Entries ................................................................................................ 62
9.3.6 NMS Trap Target Entries ............................................................................................................. 63
9.4 MANAGING THE RF CONFIGURATION TABLE ............................................................................ 65
9.4.1 Saving the RF Configuration Table.............................................................................................. 65
9.4.2 RF Configuration Table Entries ................................................................................................... 65
9.4.3 Adding an RF Configuration Entry .............................................................................................. 67
9.4.4 Displaying RF Configuration Table Entries ................................................................................. 67
9.4.5 Removing an RF Configuration Table Entry................................................................................ 68
5
MM102365V1 Rev. B
TABLE OF CONTENTS
9.5 MANAGING THE FREQUENCY LIST TABLE .................................................................................. 69
9.5.1 Saving the Frequency List Table ..................................................................................................69
9.5.2 Adding a Frequency List Entry..................................................................................................... 69
9.5.3 Displaying a Frequency List Table ............................................................................................... 70
9.5.4 Removing Frequency List Entry................................................................................................... 70
9.6 SAVING CONFIGURATION AND PARAMETER CHANGES.......................................................... 71
9.6.1 Saving Configuration Changes ..................................................................................................... 71
9.6.2 Saving Parameters Permanently.................................................................................................... 71
10. TROUBLESHOOTING ................................................................................................................... 73
10.1 OVERVIEW............................................................................................................................................ 73
10.2 EQUIPMENT REQUIRED..................................................................................................................... 73
10.3 REMOTE TROUBLESHOOTING ......................................................................................................... 73
10.4 ON SITE TROUBLESHOOTING .......................................................................................................... 74
11. INSTALLATION CHECKSHEETS............................................................................................... 78
Page
12. DIAGRAMS ...................................................................................................................................... 81
12.1 APPLICATION DIAGRAMS................................................................................................................. 81
TYPICAL CELL SITE ANTENNA SYSTEM WITH GROUNDING ..................................................81
TYPICAL CELL SITE ANTENNA ASSEMBLY ................................................................................. 82
TYPICAL ISM MASTER ANTENNA ASSEMBLY............................................................................. 83
12.2 ASSEMBLY DIAGRAMS...................................................................................................................... 84
ISM RADIO IN MINI-CELL ENCLOSURE .........................................................................................84
ISM RADIO IN TTR ENCLOSURE ......................................................................................................85
AC POWERED BACKHAUL ROUTER ............................................................................................... 86
DC POWERED BACKHAUL ROUTER ............................................................................................... 87
12.3 INTERCONNECT DIAGRAMS ............................................................................................................88
ISM RADIO IN MINI_CELL ENCLOSURE......................................................................................... 88
ISM RADIO IN RTT ENCLOSURE ......................................................................................................89
12.4 CABLE DIAGRAMS.............................................................................................................................. 90
POWER/FIBER OPTIC CABLE ............................................................................................................ 90
POWER/FIBER OPTIC CABLE ............................................................................................................ 91
6
MM102365V1 Rev. B
TABLE OF FIGURES
Page
IGURE 3-1: TOWER AND CELL SITE ISM RADIOS .......................................................................................................... 16
F
IGURE 3-2: ISM REPEATER CELL-CONFIGURATION SETUPS ......................................................................................... 17
F
IGURE 6-1: ISM TOWER TOP RADIO ENCLOSURE ......................................................................................................... 25
F
IGURE 6-2: FIBER CABLE MOUNTED IN TOWER TOP RADIO ENCLOSURE ......................................................................29
F
IGURE 6-3: WIRING THE POWER/FIBER OPTIC CABLE ASSEMBLY ................................................................................. 30
F
IGURE 6-4: BACKHAUL ROUTER – FRONT PANEL.......................................................................................................... 31
F
IGURE 6-5: BACKHAUL ROUTER – REAR PANEL (DC) .................................................................................................. 32
F
IGURE 6-6: BACKHAUL ROUTER – OUTPUT CONNECTIONS ...........................................................................................34
F
IGURE 6-7: RS-232 CABLE FOR CONNECTING PC TO ISM RADIO................................................................................. 35
F
IGURE 6-8: MAINTENANCE PORT (TEST) SERIAL I/O................................................................................................... 36
F
IGURE 6-9: ISM RADIO I/O CONNECTORS .................................................................................................................... 36
F
TABLE OF TABLES
Page
ABLE 5-1: EIA/TIA-232 BAUD FOR DISTANCE RATES ................................................................................................ 23
T
ABLE 6-1: ISM ANTENNAS .......................................................................................................................................... 26
T
ABLE 6-2: ANTENNA RF CABLES................................................................................................................................. 27
T
ABLE 6-3: POWER/FIBER OPTIC CABLE ASSEMBLY LENGTHS...................................................................................... 28
T
ABLE 6-4: BACKHAUL ROUTER FRONT PANEL INDICATORS......................................................................................... 31
T
ABLE 6-5: RJ-45 TO DB-9 CONNECTIONS.................................................................................................................... 36
T
ABLE 7-1: ISM AND IP NETWORK ADDRESSES............................................................................................................ 39
T
ABLE 7-2: BACKHAUL ROUTING TABLE....................................................................................................................... 39
T
ABLE 7-3: TOWER TOP RADIO CONFIGURATION .......................................................................................................... 40
T
ABLE 7-4: TOWER TOP RADIO ROUTING TABLE CONFIGURATION ............................................................................... 40
T
ABLE 7-5: TOWER TOP RADIO RF ENTRIES ................................................................................................................. 41
T
ABLE 7-6: TOWER RADIO FREQUENCY LIST CONFIGURATION ..................................................................................... 41
T
ABLE 7-7: VERIFY CONFIGURATION............................................................................................................................. 41
T
ABLE 7-8: CELL SITE RADIO CONFIGURATION............................................................................................................. 42
T
ABLE 7-9: CELL SITE RADIO ROUTING TABLE CONFIGURATION.................................................................................. 42
T
ABLE 7-10: CELL SITE RADIO RF TABLE CONFIGURATION.......................................................................................... 42
T
ABLE 7-11: CELL SITE RADIO FREQUENCY LIST CONFIGURATION............................................................................... 43
T
ABLE 7-12: VERIFY CONFIGURATION........................................................................................................................... 43
T
ABLE 9-1: COMMAND STRINGS AND RADIO/BACKHAUL ROUTER FUNCTIONS............................................................. 52
T
7
MM102365V1 Rev. B
1. REGULATORY AND SAFETY INFORMATION
1.1 REGULATORY INFORMATION
These devices generate RF electromagnetic energy during transmit mode. They are
designed for and classified as “Occupational Use Only” meaning they must be used only
during the course of employment by individuals aware of the hazards and the ways to
minimize such hazards. These devices are NOT intended for use by the “General
Population” in an uncontrolled environment.
x This device complies with Part 15 of the Federal Communications Commission (FCC) Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference; and (2) this device must accept any interference received, including interference that
may cause undesired operation.
x The FCC does not require the user to obtain a station license for this radio equipment before
operating it.
x This is a professionally installed device with a fixed power level. Only antennas listed on the grant
must be used. Shorter cable lengths or cable types with less gain must not be substituted as a
replacement other than those tested and listed in this manual.
The antenna(s) used for this transmitter must be installed by a professional to provide a
separation distance of at least 32 cm from all persons and must not be co-located or
CAUTION
x The operator is responsible at all times for the proper operation and maintenance of the equipment.
x No FCC license is required for personnel maintaining the equipment.
x FCC regulations state that the frequency, deviation, and power of a radio transmitter must be
maintained within specified limits. It is therefore recommended that the power level be checked
before the station is placed in service.
Use of this radio as described below will result in user exposure substantially below the FCC
recommended limits for human exposure to Radio Frequency Electromagnetic energy.
Before operating this radio:
operating in conjunction with any other antenna or transmitter.
x Do not operate this radio if any of the RF connectors are not secure or if open connections are not
properly terminated.
x Do not operate this radio near electrical blasting caps or in an explosive atmosphere.
8
NOTE
NOTE
MM102365V1 Rev. B
Changes or modifications not expressly approved could void the user's authority to
operate this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
x Reorient or relocate the receiving antenna.
x Increase the separation between the equipment and receiver.
x Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
x Consult the dealer or an experienced radio/TV technician for help.
1.2 SAFETY DURING INSTALLATION AND SERVICE
The radio and antennas must be installed by experienced installation professionals. During the installation
of directional antennas, the installer must not point the main beam of the antenna at locations occupied by
persons and must warn others to maintain a minimum distance of 4 meters from the antenna. Failure to
follow these instructions will void the product warranty and may expose the end user and others to
excessive Radio Frequency hazards. All antennas are intended to be installed outdoors and at distances
from personnel well beyond the minimum allowable distance.
Proper grounding is necessary, not only for correct functionality and maximum performance, but to
minimize damage that may occur from lightning strikes. The ISM radio includes lightning-protection
devices, but they are only effective if the connections are made as the design intended. Follow the
installation instructions to ensure a properly grounded unit.
The radio must be serviced and installed by qualified technicians only. Be sure that the radio is properly
grounded according to the installation instructions.
This equipment generates or uses radio frequency energy. Changes or modifications may cause harmful
interference unless the modifications are expressly approved in the instruction manual. The user could
lose the authority to operate this equipment if an unauthorized change or modification is made.
9
MM102365V1 Rev. B
1.3 SAFETY SYMBOLS
The following conventions are used throughout this manual to alert the user to general safety precautions
that must be observed during all phases of operation, service, and repair of this product. Failure to comply
with these precautions or with specific warnings elsewhere in this manual violates safety standards of
design, manufacture, and intended use of the product. M/A-COM, Inc. assumes no liability for the
customer's failure to comply with these standards.
The WARNING symbol calls attention to a procedure, practice, or the like, which, if not
correctly performed or adhered to, could result in personal injury. Do not proceed beyond a
WARNING
CAUTION
WARNING symbol until the conditions identified are fully understood or met.
The CAUTION symbol calls attention to an operating procedure, practice, or the like,
which, if not performed correctly or adhered to, could result in damage to the equipment or
severely degrade the equipment performance.
NOTE
The NOTE symbol calls attention to supplemental information, which may improve
system performance or clarify a process or procedure.
The ESD symbol calls attention to procedures, practices, or the like, which could expose
equipment to the effects of Electro-Static Discharge. Proper precautions must be taken to
prevent ESD when handling circuit modules.
10
MM102365V1 Rev. B
2. SPECIFICATIONS
1
2.1 ISM TOWER TOP RADIO
2.1.1 Transmit
Frequency Range 2400-2480 MHz
First Transmit Frequency 2412 MHz
Last Transmit Frequency 2468 MHz
Modulation DBPSK
Spreading Modulation Direct Sequence Spread Spectrum
Sequence Length 11-15 chips, Software Configurable
Tuning Step Size 1.0 MHz
Frequency Control PLL Synthesizer
RF output Impedance 50 Ohms
Power Output -4 dBm to 28 dBm (630 mw) in 1 dB steps
Transmitter Duty Cycle 50%
Spurious & Harmonic Emissions Meets FCC requirements CFR47 Part 15
2.1.2 Receive
Frequency Range 2400-2480 MHz
First Receive Frequency 2412 MHz
Last Receive Frequency 2468 MHz
Tuning Step Size 1.0 MHz
Frequency Control PLL Synthesizer
Sensitivity -90 dBm for 10
Adjacent Channel Rejection 25 dB
Intermodulation 42 dB
-5
Bit Error Rate AWGN
1
These specifications are intended primarily for the use by the service technician. Refer to the appropriate Specifications
Sheet for the complete specifications.
11
MM102365V1 Rev. B
2.1.3 Physical
Height x Width x Depth 16 x 12 x 8 in. (40.5 x 30.5 x 20.5 cm)
Weight 17 lbs (including environmental enclosure)
2.1.4 Environmental
Operating
Non-operating
Humidity 5% to 95% Relative Humidity at 50°C
2.1.5 Power
DC Power +12 to +16 VDC
Power Dissipation 12 Watts max
FCC ID BV8MTT-A025
2.2 BACKHAUL ROUTER
2.2.1 Interfaces
Ethernet Interface IEEE 802.3 10Base-T (10 Mbit/s)
RS-422 Interface 9-pin D-type Connector
Maintenance Port EIA/TIA-232asynchronous Serial Interface at 19.2K
-30qC to 60qC to 15,000 ft Altitude
-40qC to 70qC to 30,000 ft Altitude
baud. Uses RJ-45 Connector
12
2.2.2 Fiber Optic Interface
Connector Type ST
Wavelength 820 nm Nominal
Fiber Type
Transmit Power Level
Receiver Sensitivity
Bit Rate 1.25 Mbit/s
Coding Manchester
62.5/125 Pm Multimode
-15 dBm peak @ 25q C, with 1 meter cable length
-26dBm @ 25q C with 1 meter cable length
2.2.3 Physical
Height (2 rack units) 3.50 in. (8.9 cm)
Width Standard 19 in. rack (48.3 cm)
Depth 14 in. (35.6 cm)
Weight 13 lbs
2.2.4 Environmental
MM102365V1 Rev. B
Operating
Non-operating
Humidity 5% to 90% relative humidity non-condensing
2.2.5 Power
Voltage (DC) Nominal -48 VDC
Voltage (AC) Nominal 110 VAC (optional)
Power 50 Watts maximum
0 qC to 60 qC to 15,000 ft altitude
-20 qC to 70 qC to 30,000 ft altitude
13
MM102365V1 Rev. B
3. INTRODUCTION
This manual describes how to install an ISM Radio Network consisting of the ISM Tower Top Radio and
the optional Backhaul Router. Because each installation is unique, this manual is designed only as a guide
for installing these products.
3.1 PRODUCT DESCRIPTION
The ISM Radio System extends the reach and signal strength of the overall OpenSky® network and
provides essential connectivity to ISM devices.
The ISM Network provides:
x Extended reach without high profile towers.
x Point-to-multipoint connectivity to extend the coverage area.
x Low-latency links with minimal impact on OpenSky network performance.
x Serial Line Internet Protocol (SLIP) and Internet Protocol (IP) packet processing.
Data and voice network controllers for the OpenSky network are located at the Operation Center. From
the Operation Center, voice and data packets are routed:
x Locally to other ISM devices.
x To another Operation Center.
x Through Interoperability Gateways to non-OpenSky networks.
Each tower site can be equipped with an ISM radio for one-hop communication directly to cell sites. In
addition, to enable the radio to function as a repeater where a link between a cell site and a tower site
cannot be made with a single hop, an additional ISM radio can be connected via fiber to an existing link.
For additionally supported configurations, refer to the ISM Radio Network Design Guide.
Cell sites are an extension of a tower site’s network of OpenSky Base Stations.
3.2 COMPONENTS
3.2.1 ISM Radio
The Tower Top ISM radio communicates with an ISM radio operating at each cell site. The Cell Site ISM
radio provides an interface to the OpenSky Base Station co-located at the cell site.
14
3.2.2 Backhaul Router
The Backhaul Router performs the protocol processing and enables an ISM radio to communicate to an
industry standard Network Access Router using an Ethernet 10base-T connection.
The Network Access Router connection (a T1 Point-to-Point microwave link) terminates at the Operation
Center.
3.3 SUB-SYSTEM COMMUNICATION LINKS
The ISM radio is a Direct Sequence Spread Spectrum (DSSS) radio compliant with the FCC Part 15.247
regulations. It operates in the unlicensed ISM frequency band available for public use, between 2.400-
2.4835 GHz.
The radio operates as a subsystem within the OpenSky network to provide point-to-multipoint
communication links between tower sites and cell sites.
The ISM link extends a tower site’s coverage area beyond the devices it can reach directly. Areas poorly
served by high profile tower sites due to budgetary constraints, remote location or topographical
challenges can be affordably and reliably served from a cell site with optional ISM repeater site(s) in an
ISM subsystem.
3.4 RADIO OPERATING MODES: MASTER AND SLAVE
The ISM radio can be configured to operate in either of two modes: Master or Slave.
MM102365V1 Rev. B
3.4.1 Master
A radio in Master mode controls the RF communications path of up to six radios configured in Slave
mode. A Master operating in Time Division Multiplexed (TDM) order initiates all RF communications.
In short, the Master radio addresses all associated Slave radios in round-robin fashion, giving each in turn
the opportunity to transmit or receive ISM addressed voice and data packets.
3.4.2 Slave
A radio in Slave mode transmits and receives segmented IP packets encapsulated with ISM headers only
when addressed by its associated ISM Master radio. The Slave radio buffers data received from its SLIP
(or fiber optic) interface until granted the time slot to transmit to its respective Master. A Slave radio has a
maximum amount of data that is transmitted in any given time slot provided by the Master.
It should be noted that an ISM Master radio is also capable of communicating with
NOTE
another ISM Master radio depending on the system design.
3.5 ISM NETWORK CONFIGURATION
Figure 3-1 shows an ISM Tower Top radio supporting six cell site ISM radios. In this configuration, the
tower site is equipped with several DCX Base Station Units and a Backhaul Router with a single Master
ISM radio acting as a hub.
15
MM102365V1 Rev. B
3.5.1 Networked Master/Slave
The Master radio communicates with up to six Cell Site (or repeater, or Slave) radios. Each operates at
2.4 GHz and burst transfers the data using a 1 Mbps half duplex air link. The Master radio manages a
Time Division Duplex (TDD) protocol to service each Slave.
3.5.2 Packet Path To The Tower Site
The tower site functions as a relay. IP packets destined for a cell site OpenSky Base Station are routed to
the appropriate tower site using the T1 Point-to-Point Microwave link in a manner identical to packets
destined for OpenSky DCX Base Stations at that tower site.
ISM
Master
Cell Site 1
Cell
Site
1
Cell
Site
2
Intranet
DCX
Network
Port
Access Router
Tower Site
Backhaul
Router
10BaseT
Network
Cell
Site
Cell
Site
4
5
Cell
Site
6
Cell
Site
3
ISM Radio
(Slave)
OpenSky
Base Station
Cell Sites
Cell Site 3
SLIP
Cell
Figure 3-1: Tower and Cell Site ISM Radios
3.5.3 Packet Path to the Backhaul Router
The Network Access Router at the tower site routes ISM IP streams to the Backhaul Router for protocol
conversion and forwarding to the Master radio via the ISM network interface port.
16
The Network Access Router is a component that includes a Cisco 3600 or other Ethernet
NOTE
10Base-T Router.
3.5.4 Packet Path to the Cell Site ISM Radios
The Master radio, in turn, routes the IP packets to the appropriate Slave radio. The Slave radio then passes
the IP stream to the associated OpenSky Base Station unit co-located at the cell site via an EIA-232 SLIP
interface.
The TDM system has the capacity to deliver bi-directional SLIP data at 38.4 Kbps to each Slave radio.
3.6 OPENSKY APPLICATIONS
Depending on network configuration requirements, ISM radios can operate as Standalone Repeaters or as
part of a Cell-Drop-and-Repeat setup.
3.6.1 Standalone Repeater Operation
x Two radios are used in a Repeater configuration, whether in Repeater or Cell-Drop-and-Repeat.
x Regardless of the setup, radios are always configured in Master/Slave combinations.
x A Master radio (whether at a primary tower site, repeater site or Cell-Drop-and-Repeat) can always be
configured as a multipoint radio.
3.6.2 Cell-Drop-and-Repeat Operation
In a Cell-Drop-and-Repeat setup, one radio operates as a standard Slave in communication with the
primary tower site. A second radio at a repeater site or Cell-Drop-and-Repeat site is configured as a
Master radio similar to a tower site.
MM102365V1 Rev. B
ISM
Master
Network
Port
Air link
(2.4GHz)
ISM
Slave
Fiber Interface
ISM
Master
Air link
(2.4GHz)
Cell Site 1
Repeater Site
Backhaul
Intranet
DCX
Router
10BaseT
Network
Access Router
Cell Site 2
Fiber Interface
Cell Drop &
ISM
Master
Cell Site 3
Cell Site 4
ISM Radio
(Slave)
SLIP
OpenSky
Base Station
Cell
Repeat Site
Tower Site
Cell Sites
Figure 3-2: ISM Repeater Cell-Configuration Setups
The interface between the repeater radios uses the fiber optic network port for data communications.
17
MM102365V1 Rev. B
3.7 TECHNICAL ASSISTANCE
The Technical Assistance Center's (TAC) resources are available to help with overall system operation,
maintenance, upgrades and product support. TAC is the point of contact when answers are needed to
technical questions.
Product specialists, with detailed knowledge of product operation, maintenance and repair provide
technical support via a toll-free (in North American) telephone number. Support is also available through
mail, fax and e-mail.
For more information about technical assistance services, contact your sales representative, or call the
Technical Assistance Center directly at:
North America: 800-528-7711
International: 434-385-2400
FAX: 434-455-6712
e-mail: tac@tycoelectronics.com
18
MM102365V1 Rev. B
4. UNPACKING AND CHECKING EQUIPMENT
Before unpacking, installing or operating the ISM Network equipment, read this section of the manual
thoroughly. It contains details pertinent to unpacking and handling instructions, and safety precautions to
protect users and equipment.
4.1 UNPACKING EQUIPMENT
The ISM radio and Backhaul Router are each shipped in separate transit packages. The associated cabling
and accessories for each unit, if any, are shipped in separate containers.
When unpacking the equipment, check the contents against the packing list. Contact your M/A-COM
OpenSky representative and the carrier if any discrepancies are noted.
Save the shipping cartons and packing materials in case the equipment needs to be shipped
NOTE
back to the M/A-COM for service.
The radio contains ESD sensitive components. Only qualified personnel should open the
chassis door.
4.2 INSPECTING AND INVENTORYING EQUIPMENT
Carefully unpack the equipment and examine each item. If there is any damage to the equipment, contact
the carrier immediately and have their representative verify the damage. If you fail to report the shipping
damages immediately, you may forfeit any claim against the carrier.
After removal from the carton, examine the radio and backhaul router for broken,
damaged, loose or missing parts. Examine the RF connector(s), circular power connector
and ground lug for cracks, bent or damaged threads, or damage to any paint or seals. If any
are noted, contact OpenSky Customer Service immediately to discuss and arrange the
CAUTION
return of the equipment to M/A-COM for replacement. Any unauthorized attempts to
repair or modify this equipment will void the warranty and could create a safety hazard.
19
MM102365V1 Rev. B
5. PRE-INSTALLATION CONSIDERATIONS
Do not proceed with installation until earlier sections of this manual have been studied
and safety precautions and hazard warnings read and understood.
CAUTION
Failure to follow installation guidelines could pose physical danger along with the risk of
permanently disabling equipment.
Qualified professional technicians must install this equipment.
5.1 CHECKLIST
Prior to installation, ensure the following are at hand:
x Backhaul Router with latest software
x ISM radio to be configured as a Tower Top radio with latest software
x ISM radios to be configured as Cell Site radios with latest software
x Power/Fiber Optic Cables
x Antenna System for the Tower Top Radio
x Antenna System (one for each slave site)
See Section 6.2.1or the ISM Network Design Guide for antenna recommendations.
NOTE
5.2 BACKHAUL ROUTER INSTALLATION CHECKLIST
The Backhaul Router Installation Checklist (shown in Section Error! Reference source not found.)
documents each router’s pertinent data and lists the procedures for initial hardware installation of a new
Backhaul Router.
x Photocopy this checklist prior to installation.
x Annotate the checklist as each action is completed.
x If a Site Log is kept, include a copy of this checklist for each Backhaul Router at the site.
20
5.3 PREPARATION FOR FIELD INSTALLATION
Prior to actual field installation, installers should be provided an outline of the ISM network design. The
ISM and IP address of each ISM device and the IP address of the Base Station/DCX at each cell site
should also be obtained. This information should be recorded on the ISM Network Design forms found in
Section Error! Reference source not found..
x Photocopy the ISM Network Design form prior to installation.
x Enter the data for each radio or cell site on the form.
x Once data is collected, it is possible to set up the ISM network in a test lab, prior to field deployment.
5.4 SAFETY RECOMMENDATIONS
The guidelines should be studied prior to working on the Backhaul Router or any equipment powered by
electricity.
x Locate the emergency power-off switch. In the event of an electrical accident, it is necessary to turn
off the power quickly.
x Power should be turned off and cord unplugged to eliminate all chance of an electrical accident
before installing or removing a chassis or working near the power supplies.
MM102365V1 Rev. B
x Installers should not work alone if potentially hazardous conditions exist.
Jewelry must be removed (including rings, necklaces, and watches) before working on
equipment connected to power lines. Metal objects will heat up when connected to power
CAUTION
and ground and can cause serious burns or weld the metal object to the terminals.
5.5 HAZARD WARNINGS
Dangerous Voltages. The Backhaul Router uses –48 VDC or 110 VAC power. These voltages are
dangerous and can cause severe electrical shock. The following precautions must be observed when
operating or maintaining this equipment.
x Never alter or disconnect the ground connection on the unit or the power cord.
x Never connect an AC source if connected to –48 VDC.
x Never operate this equipment with the covers removed.
An electrical shock hazard exists if this device is connected to 230 VAC mains where both
sides of the AC line are floating above ground. The circuit breaker protects only one side
of the AC input line. Even if the circuit breaker opens because of high current, the other
WARNING
side of the line in a floating system is still energized.
21
MM102365V1 Rev. B
5.6 ELECTROSTATIC DISCHARGE
ElectroStatic Discharge (ESD) can damage equipment and impair electrical circuitry. It occurs when
electronic components are handled without adequate precautions or proper earth grounding and can result
in complete or intermittent failures.
ESD-prevention procedures must be followed when removing and replacing components.
x Ensure that the chassis is electrically connected to earth ground.
x Installers must wear an ESD-preventive wrist strap and ensure it makes good skin contact. To
properly guard against ESD damage and shocks, the wrist strap and cord must operate effectively.
x The clip must be connected to an unpainted surface of the chassis frame to safely channel unwanted
ESD voltages to ground.
x If no wrist strap is available, grounding can be achieved by touching the metal part of the chassis.
5.7 CABLING CONSIDERATIONS
When planning the installation of the Backhaul Router to a Network Access Router, it is necessary to
consider distance limitations and potential ElectroMagnetic Interference (EMI) as defined by the
Electronic Industries Association (EIA).
Each installation connection must be planned to accommodate the following unique distance limitations.
5.7.1 Ethernet Connections
The distance limitations for Ethernet 10Base-T indicate a maximum segment distance of 328 feet
(100 m).
5.7.2 ISM Radio Power/Fiber Optic Connections
The distance limitations for the ISM radio power and fiber optic cable indicate a maximum cable length
of 600 feet (183 m). The distance is limited primarily to the voltage drop due to current resistance loss in
the power cable.
5.7.3 Maintenance Port Connection
The maintenance port interface is the EIA/TIA-232 (RS-232C). Travel distance for EIA/TIA-232 signals
is determined by bit rate. Generally, the slower the data rate, the greater the distance a signal can travel.
Table 5-1 shows the standard relationship between baud rate and maximum distance.
22
MM102365V1 Rev. B
Table 5-1: EIA/TIA-232 Baud for Distance Rates
DATA RATE (BAUD) DISTANCE (FEET) DISTANCE (METERS)
2,400 200 60
4,800 100 30
9,600 50 15
19,200 50 15
38,400 50 15
NOTE: The baud rate for the maintenance port is fixed at 19,200 baud, so the maximum
cable limit shall not exceed 50 feet or 15 meters.
23
MM102365V1 Rev. B
6. INSTALLATION
6.1 TOWER TOP ISM RADIO ENCLOSURE INSTALLATION
The Tower Top ISM Radio Enclosure is designed for mounting outdoors on rooftops and poles, building
sides and the sides of telecommunications towers. It must be properly mounted, cabled, dressed and tied
off, and all grounding cables and interconnections must follow the instructions provided.
Do not proceed with installation until earlier sections of this manual have been studied and
safety precautions and hazard warnings read and understood.
Failure to follow installation guidelines could pose physical danger along with the risk of
CAUTION
Cable clamps, mounting brackets, ground clamps and cables for both the radio and Backhaul Router must
follow the specifications set out in this manual as regards the following:
x Chassis ground cables for Tower Top ISM Radio Enclosure, #6 AWG or larger, 7 strands or larger.
permanently disabling equipment.
Qualified professional technicians should install this equipment only.
x Grounding of outer conductor on RF cable, clamps to use, grounding cable to use.
x Rack grounding cable Backhaul Router.
x Lightning protection device on DC power grounding specifications.
x Fiber Optic cable clamps: what to use, where to tie off and how many feet apart.
x Brackets, bolts etc for mounting radio.
x Termination of antenna port if not used.
6.1.1 Power and Grounding Requirements
The radio operates using +12 VDC to +16 VDC input voltage. Its maximum power requirement is 12
Watts. DC Power is provided via the Fiber Optic Cable assembly (MAIROS0002-XXXXX).
The Enclosure has a grounding lug on the bottom of the chassis. This grounding lug must be connected to
a ground reference using #6 AWG stranded wire or heavier gauge.
6.1.2 Lightning Protection
The Tower Top ISM Radio Enclosure contains integral lightning protection. For tower top installations,
or any installation in which the radio is not co-located with a Backhaul Router, no additional precautions
should be required to protect against lightning.
24
MM102365V1 Rev. B
Figure 6-1: ISM Tower Top Radio Enclosure
6.1.3 ISM Radio Co-Located with the Backhaul Router
The ISM radio requires DC power in the range of +12 VDC to +16 VDC. The Backhaul Router provides
+15 VDC on its rear panel. When the Backhaul Router is present, it is the preferred power source for the
ISM radio.
Because it is often co-located with a Backhaul Router in a ground-level enclosure, special care must be
taken to protect the Backhaul Router and other co-located equipment from lightning surges and spikes.
25
MM102365V1 Rev. B
A lightning suppressor should be well grounded and mounted at the egress point to the building (or
enclosure) that houses the Backhaul Router.
A Polyphasor (part number IS-17 VDC-30A-FG) or comparable component may be used to provide
lightning protection on the +15 VDC power lines.
6.1.4 Connect Radio to Another ISM Device
The devices that constitute the ISM network are ISM Master radios, ISM Slave radios, and Backhaul
Routers. An ISM radio can be connected to another ISM device via the RF link, the Network Port, or the
SLIP port. Additionally, the radio uses its SLIP port to connect to an OpenSky Base Station Refer to the
Assembly Diagram in Section 12.2.
Where two ISM Cell radios reside at the same site, only the first radio requires an RF link to
NOTE
A Master radio is typically located in a tower, physically connected to a co-located Backhaul Router via
the fiber optic port.
the master. The second radio links to the first via the fiber optic connection.
6.2 ANTENNA SYSTEM INSTALLATION
This section covers installing the antenna system, including RF cables from the antennas to the ISM radio
enclosure.
Crews trained and equipped for working on antenna towers generally install antenna systems. As a result,
this manual assumes these skilled personnel will be working on the towers and installing the antenna
cables and the Antenna Systems.
6.2.1 Antenna Installation
Factors to consider when choosing the appropriate antenna(s) for your installation include distances to be
covered, number of cells the radio will support, desired link margin, wind load and terrain.
Table 6-1 is a list of antennas that have been tested and approved for use with the ISM radio.
Table 6-1: ISM Antennas
PART NUMBER MANUFACTURER ANTENNA
TYPE
SSB-2424GD SSB ELECTRONIC Directional 24 dBi 23.5 x 39.25 x 15 in. 5.4 lbs
ANAD-159W-A-10-SM M/A-COM Directional 16 dBi 12 x 12 in. 1.8 lbs
MFB24006 MAXRAD Omni 6 dBi 11.5 in. 0.38 lbs
GAIN SIZE WEIGHT
26
MFB24008 MAXRAD Omni 8 dBi 20 in. 0.5 lbs
MFB24010 MAXRAD Omni 10 dBi 36 in. 0.65 lbs
SP2-2.4NS RADIO WAVES, INC. Directional 21.3 dBi 24 in. 22 lbs
G3-2.4NF RADIO WAVES, INC. Directional 24.5 dBi 28.8 in. 25 lbs
WRO2400-135H WINNCOM
TECHNOLOGIES CORP
Omni 13.5 dBi 29.2 in. 2.5 lbs
MM102365V1 Rev. B
Follow the Antenna manufacturers assembly instructions when assembling the antennas.
Care should be taken that the reflector is installed in the proper direction with the reflector
NOTE
matching the polarity of the system.
6.2.2 Antenna RF Cable Installation
Depending on the length of cable required for your installation, cable loss, the associated antenna,
budgetary restraints and other factors, either of the cables in Table 6-2 may be used with a 2.4 GHz ISM
Radio System.
Table 6-2: Antenna RF Cables
CABLE PART
NUMBER
LDF4.5 ANDREW 5/8 in. RF cable 2.65
LDF5 ANDREW 7/8 in. RF Cable 2.02
MANUFACTURER DESCRIPTION LOSS DB/100’ @
2.484GHZ
When installing RF cables, always adhere to the minimum bending requirements provided by the
manufacturer. For Andrew Products, the values are:
CABLE SIZE BENDING RADIUS
5/8-inch 8-inch (200 mm)
7/8-inch 10-inches (250 mm)
Install hoisting grips and cable hangers as required by the System Installation Diagrams provided by the
System Engineer.
Ensure antenna system is properly grounded in accordance with all local and state codes. The
Application Diagrams in Section 12.1 illustrate typical grounding methods.
6.2.3 Antenna System Testing
Upon completion of the antenna system installation, the antenna lines should be tested with a Frequency
Domain Reflectometer (FDR) similar to the Anritsu Site Master model S332C.
1. Disconnect the antenna cable “N” connector from the top of the ISM Radio enclosure.
2. Connect the FDR to the antenna cable “N” connector.
3. Setup the FDR to make sweeps over the band from 2.400 to 2.485 GHz.
4. The output of the sweeps should be archived and left with the customer, installer and project
documentation for future reference when troubleshooting the system.
27
Loading...
