Owner’s Manual
Care and Operation
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Models:
Twilight-II-B
TwilightLP-II-B
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from
a neighbor’s phone. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer’s
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
WARNING
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and shall be installed.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Para obtener un ejemplar en Español de este
Manual del propietario, visite www.heatnglo.com/translations
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com/translations.
1
1
Welcome
1
Read this manual before operating this appliance.
Please retain this Owner Manual for future reference.
Read the Installation Manual before making any installation or fi nishing changes.
A. Congratulations
Congratulations on selecting an Outdoor LifeStyles gas
fi replace, an elegant and clean alternative to wood burning
fi replaces. The Outdoor LifeStyles gas fi replace you have
selected is designed to provide the utmost in safety,
reliability, and effi ciency.
As the owner of a new fi replace, you’ll want to read and
carefully follow all of the instructions contained in this
owner’s manual. Pay special attention to all cautions and
warnings.
This owner’s manual should be retained for future
reference. We suggest that you keep it with your other
important documents and product manuals.
The information contained in this owner’s manual, unless
noted otherwise, applies to all models and gas control
systems.
Your new Outdoor LifeStyles gas fi replace will give you
years of durable use and trouble-free enjoyment. Welcome
to the Hearth & Home Technologies family of fi replace
products!
Local Dealer Information
DEALER: Fill in
your name, address,
phone and email
information here and
appliance information
below.
Appliance Information:
Brand: ________________________________________________ Model Name: ___________________________
Dealer Name: ________________________________________________________
Address: ____________________________________________________________
____________________________________________________________
Phone: _____________________________________________________________
Email: _____________________________________________________________
Serial Number: __________________________________________ Date Installed: __________________________
Listing Label Information/Location
The model information regarding your specifi c fi replace can be found on
the rating plate usually located in the control area of the fi replace.
Model Number
Serial Number
Type of Gas
Gas and Electric
Information
Outdoor Lifestyles, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
Not Not for for use use with with solid solid fuel.fuel.
doit
((Ne Ne doit pas pas entre entre utilise utilise avec avec un un combustible combustible solide).solide).
Type Type of of Gas Gas (Sorte (Sorte De De Gaz)Gaz)::
NNAATURALTURAL GASGAS
Minimum Minimum Permissible Permissible Gas Gas Supply Supply for for Purposes Purposes of of Input Input Adjustment.Adjustment.
Approved Approved Minimum Minimum (De (De Gaz) Gaz) AcceptableAcceptable 0.00.0 in in w.c.w.c. (Po. (Po. Col. Col. d’eau)d’eau)
Maximum Maximum Pressure Pressure (Pression)(Pression) 0.00.0 in in w.c.w.c . (Po. (Po. Col. Col. d’eau)d’eau)
Maximum Maximum Manifold Manifold Pressure Pressure (Pression)(Pression) 0.00.0 in in w.c.w.c . (Po. (Po. Col. Col. d’eau)d’eau)
Minimum Minimum Manifold Manifold Pressure Pressure (Pression)(Pression) 0.00.0 in in w.c.w.c . (Po. (Po. Col. Col. d’eau)d’eau)
Total Total Electrical Electrical Requirements: Requirements: 000Vac, 000Vac, 00Hz., 00Hz., less less than than 00 00 AmperesAmperes
ALTITUDE:ALTITUDE: 0-0000 0-0000 FT.FT. 0000-0000FT.0000-0000FT.
MAX. MAX. INPUT INPUT BTUH:BTUH: 00,00000,000 00,00000,000
MIN. MIN. INPUT INPUT BTUH:BTUH: 00,00000,000 00,00000,000
ORIFICE ORIFICE SIZE:S IZE: #XXXXX#XXXXX #XXXXX#XXXXX
This This appliance appliance must must be be installed installed in in accordance accordance with with local local codes, codes, if if any; any; if if not, not, follow follow ANSI ANSI Z22 3.1Z223.1
in in the the USA USA or or CAN/CGA CAN/CGA B149 B149 installation installation codes. codes. (Installer (Installer l’appareil l’appareil selon selon les les codes codes ou ou reglementsreglements
locaux locaux ou, ou, en en l’absence l’absence de de tels tels reglements, reglements, selon selon les les codes codes d’installation d’installation CAN/CGA-B149.)CAN/CGA-B149.)
ANSI ANSI Z21XX-XXXX Z21XX-XXXX · · CSA CSA 2.XX-MXX 2.XX-MX
IN IN CANADACANADA
Model:Model:
(Modele):(Modele):
SerialSerial
(Serie):(Serie):
MADE MADE IN IN USAUSA
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
2
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
Table of Contents
1 Welcome
A. Congratulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
B. Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Product Specifi c Information
A. Appliance Certifi cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
B. Glass Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
C. Thermal Performance Data . . . . . . . . . . . . . . . . . . . . . . . . 6
D. Air Infi ltration, Water Resistance and Structural Tests . . . 6
E. BTU Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Important Safety and Operating Information
A. Appliance Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
B. General Operating Parts . . . . . . . . . . . . . . . . . . . . . . . . . . 8
C. Fuel Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
D. Before Lighting Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . 8
E. Lighting Instructions (IPI) . . . . . . . . . . . . . . . . . . . . . . . . . . 9
F. Appliance Break-In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
G. Heat Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
H. Detailed Component Operating Instructions . . . . . . . . . . 10
4 Maintenance and Service
A. Maintenance: Frequency and Tasks . . . . . . . . . . . . . . . . 11
B. Maintenance Tasks: Homeowner . . . . . . . . . . . . . . . . . . 11
C. Maintenance Tasks: Qualifi ed Service Technician . . . . . 14
5 Troubleshooting and Frequently Asked Questions
A. Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . 15
B. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6 Reference Materials
A. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
B. Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
C. Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
= Contains updated information.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
3
B. Limited Lifetime Warranty
Outdoor Lifestyles by Hearth & Home Technologies™
Limited Warranty
Hearth & Home Technologies (“HHT”) extends the following warranty for all Outdoor Lifestyles by HHT™
brand products (“Products”) that are purchased from an HHT authorized dealer.
WARRANTY COVERAGE:
HHT warrants to the original owner of the Product at the site of installation, and to any transferee taking
ownership of the Product at the site of installation within one year following the date of original purchase,
that the Product will be free from defects in materials and workmanship at the time of manufacture. After
installation, if covered components manufactured by HHT are found to be defective in materials or
workmanship during the applicable warranty period, HHT will, at its option, repair or replace the covered
components. This warranty is subject to conditions, exclusions and limitations as described below.
WARRANTY PERIOD:
The warranty period runs for one year, beginning on the earlier of: (i) the date of invoice for the Product;
(ii) in the case of new home construction, the date of first occupancy of the residence or six months after
the date of sale of the Product by an HHT authorized dealer, whichever occurs first; or (iii) the date 24
months following the date of Product shipment from HHT, regardless of the invoice or occupancy date.
WARRANTY CONDITIONS:
• This warranty only covers Products that are purchased through an HHT authorized dealer or
distributor. A list of HHT authorized dealers is available on the HHT branded websites.
• This warranty is only valid while the Product remains at the site of original installation.
• Contact your installing dealer for warranty service. If the installing dealer is unable to provide
necessary parts, contact the nearest HHT authorized dealer or supplier. Additional service fees
may apply if you are seeking warranty service from a dealer other than the dealer from whom
you originally purchased the Product.
• Check with your dealer in advance for any costs to you when arranging a warranty call. Travel
and shipping charges for parts are not covered by this warranty.
WARRANTY EXCLUSIONS:
This warranty does not cover the following:
• Changes in surface finishes as a result of normal use. As a heating appliance, some changes in
color of interior and exterior surface finishes may occur; this is not a flaw and not covered under
warranty.
• Damage to printed, plated, or enameled surfaces caused by fingerprints, accidents, misuse,
scratches, melted items, or other external sources and residues left on surfaces from the use of
abrasive cleaners or polishes.
• Repair or replacement of parts that are subject to normal wear and tear during the warranty
period. These parts include: paint, firebricks, grates, flame guides and the discoloration of glass.
• Minor expansion, contraction, or movement of certain parts causing noise. These conditions are
normal and complaints related to this noise are not covered by this warranty.
Outdoor Lifestyles Warranty - 2108-975B - 2/15/13 - page 1
4
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
B. Limited Lifetime Warranty (continued)
• Damages resulting from: (1) failure to install, operate, or maintain the Product in accordance with
the installation instructions, operating instructions, and listing agent identification label furnished
with the Product; (2) failure to install the Product in accordance with local building codes; (3)
shipping or improper handling; (4) improper operation, abuse, misuse, continued operation with
damaged, corroded or failed components, accident, or incorrectly performed repairs; (5) inadequate ventilation, negative pressure or environmental conditions, including, without limitation:
hail, snow, ice, fallen branches, flooding, water damage and fading of color; (6) use of fuels other
than those specified in the operating instructions; (7) installation or use of components not
supplied with the Product or any other components not expressly authorized and approved by
HHT; (8) modification of the Product not expressly authorized and approved by HHT in writing;
and/or (9) interruptions or fluctuations of electrical power supply to the Product.
• Non-HHT venting components, hearth components or other accessories used in conjunction with
the Product.
• Any part of a pre-existing fireplace system in which an insert or a decorative gas appliance is
installed.
• The Product’s capability to heat the desired space. Information is provided to assist the consumer
and the dealer in selecting the proper appliance for the application. Consideration must be given
to the Product’s location and configuration and environmental conditions.
This warranty is void if:
• The Product has been over-fired or operated in atmospheres contaminated by chlorine, fluorine,
or other damaging chemicals. Over-firing can be identified by, but not limited to, warped plates or
tubes, rust colored cast iron, bubbling, cracking and discoloration of steel or enamel finishes and
cracking or spalling of refractory or cementitious materials.
• The Product is subjected to prolonged periods of dampness, condensation, ice or snow.
• There is any damage to the Product or other components due to water or weather damage which
is the result of, but not limited to, improper chimney or venting installation.
LIMITATIONS OF LIABILITY:
Repair or replacement in accordance with the provisions of this warranty will be the owner’s exclusive
remedy for and will constitute HHT’s sole obligation under this warranty, under any other warranty
(express or implied), or in contract, tort or otherwise; provided, however, that if HHT is unable to provide
repair or replacement in an expedient and cost effective manner, HHT may discharge all such obligations
by refunding the purchase price of the Product. No employee, agent, dealer, or other person is authorized
to give any warranty on behalf of HHT. TO THE EXTENT ALLOWED BY LAW, HHT MAKES NO OTHER
WARRANTY, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. HHT WILL NOT BE LIABLE FOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGES ARISING OUT OF DEFECTS IN OR USE OF THE PRODUCTS. Some
states do not allow exclusions or limitation of incidental or consequential damages, so these limitations
may not apply to you. This warranty gives you specific rights; you also may have other rights, which vary
from state to state. The duration of any implied warranty is limited to the duration of the warranty period
specified herein.
Outdoor Lifestyles Warranty - 2108-975B - 2/15/13 - page 2
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
5
2
Product Specifi c Information
2
A. Appliance Certifi cation
MODEL: Twilight-II-B
LABORATORY: Underwriters Laboratories, Inc. (UL)
TYPE: Direct Vent Gas Appliance
STANDARD: ANSI Z21.50-2003 • CSA2.22-M03 • UL307B
This product is listed to ANSI standards for “Vented Gas
Appliances” and applicable sections of “Gas Burning
Heating Appliances for Manufactured Homes and Recreational Vehicles”, and “Gas Fired Appliances for Use at
High Altitudes”.
NOTICE: This installation must conform with local codes.
In the absence of local codes you must comply with the
National Fuel Gas Code, ANSI Z223.1-latest edition in
the U.S.A. and the CAN/CGA B149 Installation Codes in
Canada.
NOT INTENDED FOR USE AS A PRIMARY HEAT SOURCE.
This appliance is tested and approved as either supplemental room heat or as a decorative appliance. It should not be
factored as primary heat in residential heating calculations.
B. Glass Specifi cations
C. Thermal Performance Data
Model: Twilight-II-B
Sound Transmission
Class (STC)
27 0.8hr-sq ft-ºF/BTU 1.25 BTU-in/hr-sq ft-ºF
Thermal Resistance
(R Value)
Thermal Conductivity
(K Value)
D. Air Infi ltration, Water Resistance and
Structural Tests
The Hearth & Home Technologies Twilight-II-B Indoor/
Outdoor Appliance unit was tested to the following ASTM
standards at the Stork Twin City Testing laboratory.
Air infi ltration test ASTM:E283-(04). The sample was test-
ed at 1.57 psf (equivalent to a 25-mph windload). Water
resistance test ASTM:E331-00. The test specimen was
tested at the requested test pressures of 8.0 & 25.0 psf.
Structural test ASTM:E330-02. The unit was tested to a
design pressure of 50-psf, a test pressure of 75-psf.
Test Results
Model
Twilight-II-B
Indoor/Outdoor
Air Infi ltration
(ASTM E283)
0.07CFM/ft2
Water Resistance
(ASTM E331)
No leakage
@ 8psf & 25psf
Structural Load
(ASTM E330)
No Blowout
@ 75psf
Tempered Glass (Interior Glass)
Hearth & Home Technologies appliances manufactured
with tempered glass may be installed in hazardous locations such as bathtub enclosures as defi ned by the
Consumer Product Safety Commission (CPSC). The
tempered glass has been tested and certifi ed to the re-
quirements of ANSI Z97.1 and CPSC 16 CFR 1202
(Safety Glazing Certifi cation Council SGCC# 1595 and
1597. Architectural Testing, Inc. Reports 02-31919.01
and 02-31917.01).
This statement is in compliance with CPSC 16 CFR Sec-
tion 1201.5 “Certifi cation and labeling requirements”
which refers to 15 U.S. Code (USC) 2063 stating “…Such
certifi cate shall accompany the product or shall otherwise
be furnished to any distributor or retailer to whom the
product is delivered.”
Some local building codes require the use of tempered
glass with permanent marking in such locations. Glass
meeting this requirement is available from the factory.
Please contact your dealer or distributor to order.
Ceramic Glass (Exterior Glass)
This appliance is equipped with 5 mm ceramic glass. Replace glass only with 5 mm ceramic glass. Please contact
your dealer for replacement glass.
E. BTU Specifi cations
Model
U.S. (0-2000 FT) or
Canada (2000-4500 FT)
Twilight-II-B (NG)
Twilight-II-B (LP)
US
CAN
US
CAN
Input
BTU/h
38,000 32
34,200 33
36,000 50
33,300 51
Orifi ce Size
(DMS)
6
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
3
3
Important Safety and Operating Information
A. Appliance Safety
WARNING! DO NOT operate fi replace before reading
and understanding operating instructions. Failure
to operate fi replace according to operating instructions
could cause fi re or injury.
WARNING
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
• Keep children away.
• CAREFULLY SUPERVISE children in same room
as fi replace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
• Clothing, furniture, draperies, and other fl ammable
materials must not be placed on or near the
appliance.
• Consider not using the fi replace when children will be
present.
Contact your dealer for more information, or visit: www.
hpba.org/safety-information.
To prevent unintended operation when not using your fi re-
place for an extended period of time (summer months,
vacations, trips, etc):
• Remove batteries from remote controls.
• Turn off wall controls.
• Unplug 3 volt adapter plug (IPI) and remove batteries on
IPI models.
Clear Space
WARNING! DO NOT place combustible objects in front
of the fi replace or block louvers. High temperatures may
start a fi re. See Figure 3.1.
Avoid placing candles and other heat-sensitive objects on
mantel or hearth. Heat may damage these objects.
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and
shall be installed. DO NOT operate the appliance with
the barrier removed. If the barrier becomes damaged,
the barrier shall be replaced with the manufacturer’s
barrier for this appliance.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
Young children should be carefully supervised when they
are in the same room as the appliance. Toddlers, young
children and others may be susceptible to accidental
contact burns.
• A physical barrier is recommended if there are at risk
individuals in the house.
• To restrict access to a fi replace or stove, install an
adjustable safety gate to keep toddlers, young children
and other at risk individuals out of the room and away
from hot surfaces.
• Install a switch lock or a wall/remote control with child
protection lockout feature.
• Keep remote controls out of reach of children.
• Never leave children alone near a hot fi replace, whether
operating or cooling down.
• Teach children to NEVER touch the fi replace.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
CLEAR SPACE
3 FT. IN
FRONT OF
FIREPLACE
Figure 3.1 Clear Space
Over Firing
The appliance is considered to be over fi ring if the fl ames
are contacting the top of the fi rebox. Call a qualifi ed service
technician to service the appliance
7
B. General Operating Parts
Figure 3.2 references the general operating parts of the
appliance and the section of this manual in which they are
discussed.
DECORATIVE DOORS
(NOT SHOWN)
SECTION 6.A
FIXED GLASS ASSEMBLY
(NOT SHOWN)
SECTION 4.B
FAN KIT
SECTION 6.A
HEARTH
CLEAR SPACE
SECTION 3.A.
Figure 3.2 General Operating Parts
C. Fuel Specifi cations
WARNING! Risk of Fire or Explosion! Appliance must
be set up for compatible gas type!
• This appliance is designed to operate on either natural
gas or propane. Make sure the appliance is compatible
with gas type selected for installation site.
• Conversions must be made by a qualified service
technician using Hearth & Home Technologies specifi ed
and approved parts.
MANTEL
D. Before Lighting Appliance
Before operating this fi replace for the fi rst time, have a
qualifi ed service technician:
• Verify all shipping materials have been removed from
inside and/or underneath the fi rebox.
• Review proper placement of logs, ember material and/or
other decorative materials.
• Check the wiring.
• Check the air shutter adjustment.
• Ensure that there are no gas leaks.
• Ensure that the glass is sealed and in the proper position
and that the integral barrier is in place.
WARNING! Risk of Fire or Asphyxiation! DO NOT operate fi replace with fi xed glass assembly removed.
Determine if this fi replace has a standing pilot or an
Intellifi re ignition system. Ask your dealer or open control
access panel, look at gas valve assembly.
8
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
E. Lighting Instructions (IPI)
The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery
life, remove them when using the transformer.
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING: If you do not follow these instructions exactly, a fi re or explosion
may result causing property damage, personal injury or loss of life.
A. This appliance is equipped with an
intermittent pilot ignition (IPI) device
which automatically lights the burner. DO NOT try to light the burner by
hand.
B. BEFORE LIGHTING, smell all around
the appliance area for gas. Be sure to
smell next to the fl oor because some
gas is heavier than air and will settle
on the fl oor.
WHAT TO DO IF YOU SMELL GAS
• DO NOT try to light any appliance.
• DO NOT touch any electric switch; do
not use any phone in your building.
WARNING:
DO NOT CONNECT LINE VOLTAGE (110/120 VAC OR 220/240
VAC) TO THE CONTROL VALVE.
Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to the owner’s information manual
provided with this appliance.
This appliance needs fresh air for
safe operation and must be installed
so there are provisions for adequate
combustion and ventilation air.
If not installed, operated, and maintained in accordance with the manufacturer’s instructions, this product could
expose you to substances in fuel or
fuel combustion which are known to the
State of California to cause cancer, birth
defects, or other reproductive harm.
Keep burner and control compartment
clean. See installation and operating
instructions accompanying appliance.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fi re department.
C. DO NOT use this appliance if any
part has been under water. Immediately call a qualifi ed service tech-
nician to inspect the appliance and
to replace any part of the control
system and any gas control which
has been under water.
CAUTION:
Hot while in operation. DO NOT touch.
Keep children, clothing, furniture, gasoline and other liquids having fl ammable
vapors away.
DO NOT operate the appliance with
fi xed glass assembly removed, cracked
or broken. Replacement of the fi xed
glass assembly should be done by a
licensed or qualifi ed service person.
NOT FOR USE
WITH SOLID FUEL
For use with natural gas and propane.
A conversion kit, as supplied by the
manufacturer, shall be used to convert
this appliance to the alternate fuel.
Also Certifi ed for Installation in a
Bedroom or a Bedsitting Room.
For assistance or additional information, consult a qualifi ed installer, ser-
vice agency or the gas supplier.
LIGHTING
INSTRUCTIONS (IPI)
1. This appliance is equipped with an ignition
device which automatically lights the burner.
DO NOT try to light the burner by hand.
GAS
VALVE
2. Wait fi ve (5) minutes to clear out any gas.
Then smell for gas, including near the fl oor. If
you smell gas, STOP! Follow “B” in the Safety
Information located on the left side of this label. If you do not smell gas, go to next step.
3. To light the burner:
Equipped with wall switch: Turn ON/OFF switch
to ON.
Equipped with remote or wall control: Press
ON or FLAME button.
Equipped with thermostat: Set temperature to
desired setting.
4. If the appliance does not light after three tries,
call your service technician or gas supplier.
TO TURN OFF
GAS TO APPLIANCE
1. Equipped with wall switch: Turn ON/OFF switch
to OFF.
Equipped with remote or wall control: Press
OFF button.
Equipped with thermostat: Set temperature to
lowest setting.
2. Service technician should turn off electric
power to the control when performing service.
593-913G
Hearth & Home Technologies fi replace, please refer to www.fi replaces.com.
For additional information on operating your
Final inspection by
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
9
F. Appliance Break-In
Initial Break-in Procedure
• The fireplace should be run three to four hours
continuously on high.
• Turn the fi replace off and allow it to completely cool.
• Remove fi xed glass assembly. See Section 4.
• Clean fi xed glass assembly. See Section 4.
• Replace the fi xed glass assembly and run continuously
on high an additional 12 hours.
This cures the materials used to manufacture the fi re-
place.
NOTICE! Open windows for air circulation during fi re-
place break-in.
• Some people may be sensitive to smoke and odors.
• Smoke detectors may activate.
G. Heat Management
Burn Rate
The TWILIGHT-II-B has a constant burn rate which is
controlled by the gas valve. Therefore the fl ame height is
not adjustable.
H. Detailed Component Operating
Instructions
IntelliFire™ Ignition System
IntelliFire™, an ignition system exclusively featured in
Heatilator, Heat & Glo & Quadra-Fire products, is an
energy-saving pilot ignition system for gas fi replaces and
inserts. It provides an ignition fl ame only when needed
and has a battery backup system that supplies power to
spark the ignition fl ame in the event of a power outage.
Intellifi re™ is an intermittent pilot ignition, which is an
electronic system. The term Intermittent is used because
the pilot burner fl ame is only present when the main
burner is operating. When the main burner is off the pilot
is also off.
NOTICE: Batteries should not be placed in the battery
pack while using the transformer. Remove batteries before
using the transformer, and unplug the transformer before
installing the batteries. Battery polarity must be correct or
module damage will occur.
Appliance ON/OFF:
If an optional remote control or wall control is installed,
it should be used to control the ON/OFF function of the
appliance. Follow instructions included with the installed
control.
TO CEILING
120°F
FIREPLACE
OPENING
160°F
180°F
200°F
Figure 3.3. Maximum Interior Wall Surface Temperatures Above
Appliance
18 in.
12 in.
6 in.
MEASUREMENTS FROM
TOP EDGE OF THE OPENING
APPLIA NCE FRONT
150°F
140°F
24 in.
130°F
48 in.
42 in.
36 in.
30 in.
To operate the appliance without a wall control or remote
control, use the ON/OFF switch located inside the control
cavity of the appliance. See Figure 3.4.
Access to the ON/OFF switch may vary depending on the
choice of decorative front. In some cases a louver may
need to be opened. In other cases, the decorative front
may need to be removed.
CAUTION! Risk of Electric Shock! Avoid touching wires
and electrical components in appliance control cavity.
ON/OFF
SWITCH
10
Figure 3.4. ON/OFF Switch Location
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
4
4
Maintenance and Service
Any safety screen or guard removed for servicing must be
replaced prior to operating the fi replace.
When properly maintained, your fi replace will give you
many years of trouble-free service. Contact your dealer
to answer questions regarding proper operation, troubleshooting and service for your appliance. Visit www.
heatnglo.com to locate a dealer. We recommend annual
service by a qualifi ed service technician.
A. Maintenance: Frequency and Tasks
The matrix below is an overview of maintenance tasks to
be performed on the appliance. Sections B and C give
details and instructions needed to assist the appropriate
person in performing the tasks.
Task Frequency To be completed by
Glass Cleaning Seasonally
Doors/Fronts/
Surrounds
Remote Control Seasonally
Exhaust
Termination
Gasket Seal
and Glass
Inspection
Log Inspection Annually
Firebox
Inspection
Control
Compartment &
fi rebox Top
Burner Ignition
& Operation
Annually
Seasonally
Annually
Annually
Annually
Annually
Homeowner
Qualifi ed Service
Technician
Glass Cleaning
Frequency: Seasonally
By: Homeowner
Tools Needed: Protective gloves, glass cleaner, drop
cloth and a stable work surface.
CAUTION! Handle fi xed glass assembly with care.
Glass is breakable.
• Avoid striking, scratching or slamming glass
• Avoid abrasive cleaners
• DO NOT clean glass while it is hot
• Prepare a work area large enough to accommodate fi xed
glass assembly and door frame by placing a drop cloth
on a fl at, stable surface.
Note: Fixed glass assembly and gasketing may have residue that can stain carpeting or fl oor surfaces.
• Remove door or decorative front from fi replace and set
aside on work surface.
WARNING! Risk of Asphyxiation! Handle fi xed glass
assembly with care. Inspect the gasket to ensure it is
undamaged and inspect the glass for cracks, chips or
scratches.
• DO NOT operate fi replace with glass removed, cracked,
broken or scratched.
• Replace as a complete assembly.
• Remove fi xed glass assembly from appliance. See
instructions below for removing and replacing interior
and exterior glass assemblies.
• Clean glass with a non-abrasive commercially available
cleaner.
- Light deposits: Use a soft cloth with soap and water
- Heavy deposits: Use commercial fireplace glass
cleaner (consult with your dealer)
• Replace fi xed glass assembly.
• Reinstall door or decorative front.
B. Maintenance Tasks: Homeowner
Installation and repair should be done by a qualifi ed service
technician only. The fi replace should be inspected before
use and at least annually by a professional service person.
The following tasks may be performed annually by the
homeowner. If you are uncomfortable performing any of
the listed tasks, please call your dealer for a service appointment.
More frequent cleaning may be required due to lint from
carpeting or other factors. Control compartment, burner
and circulating air passageway of the fi replace must be
kept clean.
CAUTION! Risk of Burns! The fi replace should be
turned off and cooled before servicing.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
Removing Fixed Glass Assembly- Interior
• Loosen two wing nuts on bottom glass retainer bracket.
• Loosen and remove two wing nuts on top glass retainer
bracket. Remove glass retainer bracket. See Figure 4.1
• Lift glass assembly off of glass retainer bracket.
Replacing Fixed Glass Assembly - Interior
• Position glass assembly on bottom glass retainer bracket.
Tighten wing nuts on bottom glass retainer bracket.
• Position top of glass assembly, position top glass retainer
bracket and secure with two wing nuts.
11
GLASS RETAINER BRACKET
WING NUT ON THREADED STUD
GLASS LATCH
GLASS RETAINER
WING NUT LOCATIONS
4.1 Glass Assembly - Interior Side
GLASS LATCHES
4.3 Glass Latch Locations - Exterior Side
Removing Fixed Glass Assembly- Exterior
• Remove vanity panel from appliance to expose glass
latches.
• Pull glass latch out to release. Grasp glass assembly on
sides and pull bottom toward you. Slide glass assembly
down and out from under glass retainer.
GLASS LATCH
GLASS RETAINER BRACKET
WING NUT ON THREADED STUD
4.2 Glass Assembly Detail - Interior Side
12
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
4.4 Glass Latch Detail - Exterior Side
Replacing Fixed Glass Assembly - Exterior
• Slide top of glass assembly into position under glass
retainer. Position bottom of glass assembly and secure
latches.
• Replace vanity panel.
Doors, Surrounds, Fronts
Frequency: Annually
By: Homeowner
Tools needed: Protective gloves, stable work surface
• Assess condition of screen and replace as necessary.
• Inspect for scratches, dents or other damage and repair
as necessary.
• Check that louvers are not blocked.
• Vacuum and dust surfaces as necessary.
• Unplug 3 volt adapter plug on IPI models.
Remote Control
Frequency: Seasonally
By: Homeowner
Tools needed: Replacement batteries and remote con-
trol instructions.
• Locate remote control transmitter and receiver.
• Verify operation of remote. Refer to remote control
operation instructions for proper calibration and setup
procedure.
• Place batteries as needed in remote transmitters and
battery-powered receivers.
• Place remote control out of reach of children.
If not using your fi replace for an extended period of time
(summer months, vacations/trips, etc), to prevent unintended operation:
• Remove batteries from remote controls.
Exhaust Termination
Frequency: Seasonally
By: Homeowner
Tools needed: Protective gloves and safety glasses.
• Inspect exhaust termination for blockage or obstruction
such plants, bird nests, leaves, snow, debris, etc.
• Verify exhaust termination clearance to subsequent construction (building additions, decks, fences, or sheds).
See Installation Manual.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
13
C. Maintenance Tasks: Qualifi ed Service
Technician
The following tasks must be performed by a qualifi ed ser-
vice technician.
Gasket Seal and Glass Assembly Inspection
Frequency: Annually
By: Qualifi ed Service Technician
Tools needed: Protective gloves, drop cloth and a stable
work surface.
• Inspect gasket seal and its condition.
• Inspect fi xed glass assembly for scratches and nicks that
can lead to breakage when exposed to heat.
• Confi rm there is no damage to glass or glass frame.
Replace as necessary.
• Verify that fi xed glass assembly is properly retained and
attachment components are intact and not damaged.
Replace as necessary.
Logs
Frequency: Annually
By: Qualifi ed Service Technician
Tools needed: Protective gloves.
• Inspect for damaged or missing logs. Replace as necessary.
Refer to Installation Manual for log placement instructions.
• Verify correct log placement and no fl ame impingement
causing sooting. Correct as necessary.
Firebox
Frequency: Annually
By: Qualifi ed Service Technician
Tools needed: Protective gloves, sandpaper, steel wool,
cloths, mineral spirits, primer and touch-up paint.
• Inspect for paint condition, warped surfaces, corrosion
or perforation. Sand and repaint as necessary.
• Replace fi replace if fi rebox has been perforated.
Burner Ignition and Operation
Frequency: Annually
By: Qualifi ed Service Technician
Tools needed: Protective gloves, vacuum cleaner, whisk
broom, fl ashlight, voltmeter, indexed drill bit set, and a
manometer.
• Verify burner is properly secured and aligned with pilot
or igniter.
• Clean off burner top, inspect for plugged ports, corrosion
or deterioration. Replace burner if necessary.
• Replace Glowing embers with new dime-size pieces.
DO NOT block ports or obstruct lighting paths. Refer to
Installation Manual for proper ember placement.
• Verify batteries have been removed from battery back-up
IPI systems to prevent premature battery failure or
leaking.
• Check for smooth lighting and ignition carryover to all
ports. Verify that there is no ignition delay.
• Inspect for lifting or other fl ame problems.
• Verify air shutter setting is correct. See Installation
Manual for required air shutter setting. Verify air shutter
is clear of dust and debris.
• Inspect orifi ce for soot, dirt and corrosion. Verify orifi ce
size is correct. See Service Parts List for proper orifi ce
sizing.
• Verify manifold and inlet pressures. Adjust regulator as
required.
• Inspect pilot fl ame pattern and strength. See Figure 4.5
for proper pilot fl ame pattern. Clean or replace orifi ce
spud as necessary.
• Inspect IPI fl ame sensing rod for soot, corrosion and
deterioration. Polish with fi ne steel wool or replace as
required.
• Verify that there is not a short in fl ame sense circuit by
checking continuity between pilot hood and fl ame sense
rod. Replace pilot as necessary.
Control Compartment and Firebox Top
Frequency: Annually
By: Qualifi ed Service Technician
Tools needed: Protective gloves, vacuum cleaner, dust
cloths
• Vacuum and wipe out dust, cobwebs, debris or pet hair.
Use caution when cleaning these areas. Screw tips that
have penetrated the sheet metal are sharp and should
be avoided.
• Remove all foreign objects.
• Verify unobstructed air circulation.
14
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
Figure 4.5 IPI Pilot Flame Patterns
5
Troubleshooting and Frequently Asked Questions
5
A. Frequently Asked Questions
ISSUE SOLUTIONS
Condensation on the glass
Blue fl ames
Odor from fi replace
Film on the glass
Metallic noise
Is it normal to see the pilot fl ame burn
continually?
Contact your dealer for additional information regarding operation and troubleshooting. Visit www.heatnglo.com to
locate a dealer.
This is a result of gas combustion and temperature variations. As the fi replace warms, this
condensation will disappear.
This is a result of normal operation and the fl ames will begin to yellow as the fi replace is al-
lowed to burn for 20 to 40 minutes.
When fi rst operated, this fi replace may release an odor for the fi rst several hours. This is
caused by the curing of materials from manufacturing. Odor may also be released from fi nish-
ing materials and adhesives used near the fi replace. These circumstances may require ad-
ditional curing related to the installation environment.
This is a normal result of the curing process of the paint and logs. Glass should be cleaned
within 3 to 4 hours of initial burning. A non-abrasive cleaner such as gas appliance glass
cleaner may be necessary. See your dealer.
Noise is caused by metal expanding and contracting as it heats up and cools down, similar to
the sound produced by a furnace or heating duct. This noise does not affect the operation or
longevity of the fi replace.
In an intermittent pilot ignition system (IPI), the pilot fl ame should turn off when appliance is
turned off. Some optional control systems available with IPI models may allow pilot fl ame to
remain lit.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
15
B. Troubleshooting
With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do
experience a problem, this troubleshooting guide will assist a qualifi ed service technician in the diagnosis of a problem and
the corrective action to be taken. This troubleshooting guide can only be used by a qualifi ed service technician. Contact
your dealer to arrange a service call by a qualifi ed service technician.
Symptom Possible Cause Corrective Action
1. Pilot won’t light.
The ignitor/module
makes noise, but no
spark.
2. Pilot won’t light,
there is no noise or
spark.
A. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor are
connected to correct terminals on module and pilot assembly.
B. Loose connections or electrical
shorts in the wiring.
C. Ignitor gap is too large. Verify gap of igniter to right side of pilot hood. The gap should be
D. Module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove
A. No power or transformer installed
incorrectly.
B. A shorted or loose connection in
wiring confi guration or wiring har-
ness.
Verify no loose connections or electrical shorts in wiring from module to pilot assembly. Verify connections underneath pilot assembly are tight; also verify connections are not grounding out to metal
chassis, pilot burner, pilot enclosure, mesh screen if present, or any
other metal object.
approximately .17 in. or 1/8 in. (3 mm).
ignitor wire “I” from module. Place a grounded wire about 3/16 in. (5
mm) away from “I” terminal on module. Place ON/OFF rocker switch
or wall switch in ON position. If there is no spark at “I” terminal module
must be replaced. If there is a spark at “I” terminal, module is fi ne.
Inspect pilot assembly for shorted sparker wire or cracked insulator
around electrode. Replace pilot if necessary.
Verify that transformer is installed and plugged into module. Check
voltage of transformer under load at spade connection on module
with ON/OFF switch in ON position. Acceptable readings of a good
transformer are between 3.2 and 2.8 volts AC.
Remove and reinstall the wiring harness that plugs into module.
Verify there is a tight fi t. Verify pilot assembly wiring to module. Re-
move and verify continuity of each wire in wiring harness. Replace
any damaged components.
3. Pilot sparks, but
Pilot will not light.
16
C. Improper wall switch wiring. Verify that 110/VAC power is “ON” to junction box.
D. Module not grounded. Verify black ground wire from module wire harness is grounded to
metal chassis of appliance.
E. Module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove
ignitor wire “I” from module. Place ON/OFF rocker switch or wall
switch in ON position. If there is no spark at “I” terminal module
must be replaced. If there is a spark at “I” terminal, module is fi ne.
Inspect pilot assembly for shorted sparker wire or cracked insulator
around electrode.
A. Gas supply. Verify that incoming gas line ball valve is “open”. Verify that inlet
pressure reading is within acceptable limits.
B. Ignitor gap is too large. Verify gap of igniter to right side of pilot hood. The gap should be
approximately .17 in. or 1/8 in. (3 mm).
C. Module is not grounded. Verify module is securely grounded to metal chassis of appliance.
D. Module voltage output / Valve/Pilot
solenoid ohms readings.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
Verify battery voltage is at least 2.7 volts. Replace batteries if voltage is below 2.7.
Troubleshooting (continued)
Symptom Possible Cause Corrective Action
4. Pilot lights but continues to spark, and main
burner will not ignite.
(If the pilot continues
to spark after the
pilot fl ame has been lit,
fl ame rectifi cation has
not occurred.)
A. A shorted or loose connection in fl ame
sensing rod.
B. Poor fl ame rectifi cation or contaminated
fl ame sensing rod.
C. Module is not grounded. Verify module is securely grounded to metal chassis of ap-
D. Damaged pilot assembly or contami-
nated fl ame sensing rod.
E. Module. Turn ON/OFF rocker switch or wall switch to OFF position.
Verify all connections to wiring diagram in manual. Verify
connections underneath pilot assembly are tight. Verify connections are not grounding out to metal chassis, pilot burner, pilot enclosure or screen if present, or any other metal
object.
With fi xed glass assembly in place, verify that fl ame is en-
gulfi ng fl ame sensing rod on left side of pilot hood. Flame
sensing rod should glow shortly after ignition. Verify correct pilot orifi ce is installed and gas inlet is set to pressure
specifi cations. Polish fl ame sensing rod with fi ne steel wool
to remove any contaminants that may have accumulated on
fl ame sensing rod.
pliance. Verify that wire harness is fi rmly connected to the
module.
Verify that ceramic insulator around the fl ame sensing rod
is not cracked, damaged, or loose. Verify connection from
fl ame sensing rod to white sensor wire. Polish fl ame sens-
ing rod with fi ne steel wool to remove any contaminants
that may have accumulated on fl ame sensing rod. Verify
continuity with a multimeter with ohms set at lowest range.
Replace pilot if any damage is detected.
Remove ignitor wire “I” from module. Place ON/OFF rocker
switch or wall switch in ON position. If there is no spark at “I”
terminal module must be replaced. If there is a spark at “I”
terminal, module is fi ne.
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
17
6
Reference Materials
6
A. Accessories
Install approved accessories per instructions included
with accessories. Contact your dealer for a list of approved accessories.
WARNING! Risk of Fire and Electric Shock! Use ONLY
Hearth & Home Technologies-approved optional accessories with this appliance. Using non-listed accessories
could result in a safety hazard and will void the warranty.
Once installed, operate per instructions included with accessories.
Fan Kit (optional)
If desired, a fan kit may be added. Contact your dealer to
order the correct fan kit.
Remote Controls, Wall Controls and Wall
Switches
Follow the instructions supplied with the control installed
to operate your fi replace:
For safety:
• Install a switch lock or a wall/remote control with child
protection lockout feature.
• Keep remote controls out of reach of children.
See your dealer if you have questions.
Decorative Doors and Fronts
WARNING! Risk of Fire! Install ONLY doors or fronts
approved by Hearth & Home Technologies. Unapproved
doors or fronts may cause fi replace to overheat.
This fireplace has been supplied with an integral
barrier to prevent direct contact with the fi xed glass
panel. DO NOT operate the fi replace with the barrier
removed.
Contact your dealer or Hearth & Home Technologies if
the barrier is not present or help is needed to properly
install one.
For more information refer to the instructions supplied with
your decorative door or front.
18
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
B. Service Parts
Service Parts
TWILIGHT-II-B
Log Set Assembly
3
2
4
5
36” Indoor/Outdoor See-thru
Gas Fireplace - DV
8
1
6
10
11
12
9
7
Beginning Manufacturing Date: Jan 2006
Ending Manufacturing Date: Active
16
15
13
14
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model
number and serial number when requesting service parts from your dealer or distributor.
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Assembly /Burner Assembly Pre SN #0021355692
Log Set Assembly
Log 1
1
Log 2
2
Log 3
3
Log 4
4
Log 5
5
Log 6
6
Log Set Assembly /Burner Assembly Pre SN #0021355692
7
Burner Assembly
Refractory, Side
8
Grate Assembly
9
10
11
12
13
14
15 Outdoor Glass Assembly
16 Mesh Assembly
Additional service part numbers appear on following page.
Indoor Glass Assembly
Hood - Interior Side
Glass Clip
Junction Box
Junction Box Shield
Post SN # 0021355692
Post SN # 0021355692
Pre 0023001898
Post 0023001898
SRV2087-004 Y
LOGS-MSR Y
SRV2005-701
SRV2005-700
SRV2005-702
SRV2005-703
SRV2005-704
SRV2005-705
SRV2087-004 Y
2087-004 Y
SRV2005-730
2005-012
GLA-6TROC Y
SRV60-143-BK
2087-121
4021-013 Y
2087-149
GLA-OUTDOOR2
TWI-II-MESH Y
MESH-TWI-EXT Y
Stocked
in Depot
11/ 13
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
19
Service Parts
TWILIGHT-II-B
Beginning Manufacturing Date: Jan 2006
Ending Manufacturing Date: Active
17.8
17.11
17.13
17.14
17.7
17.2
17.3
17.4
17.5
17.6
17.9
17.10
17.1
17.19
17.18
17.17
17.16
17.15
#17 Valve Assembly
17.12
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model
number and serial number when requesting service parts from your dealer or distributor.
ITEM DESCRIPTION COMMENTS PART NUMBER
17.1
17.2
17.3
17.4
17.5
17.6
17.7
17.8
17.9
17.10
17.11
17.12
17.13
17.14
17.15
17.16
17.17
17.18
17.19
Additional service part numbers appear on following page.
20
Burner Orifi ce (NG) (#32C) 582-832 Y
Burner Orifi ce (LP) (#50C) 582-850 Y
12” Flex Tube Assembly 383-302A Y
Burner Neck Gasket 438-407
Bracket, Pilot Support Assembly 385-120
Pilot Assembly NG 2090-012 Y
Pilot Assembly LP 2090-013 Y
Pilot Tube SRV485-301 Y
Orifi ce Bracket Gasket 2087-110
Orifi ce Bracket 2087-109
Valve Plate Gasket 2087-112
Valve L Bracket 674-168
Valve Bracket 2087-117
Valve Bracket 2087-116
Flex Ball Valve Assembly 302-320A Y
ON/OFF Rocker Switch 060-521A Y
Valve NG 593-500 Y
Valve LP 593-501 Y
Wire Assembly 593-590A Y
Control Module 593-592 Y
Wall Switch Wire 2118-170 Y
Jumper Wire 2155-033 Y
3-Hole Grommet 2118-420
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
Stocked
in Depot
Service Parts
Beginning Manufacturing Date: Jan 2006
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor. Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
ITEM DESCRIPTION COMMENTS PART NUMBER
Battery Pack 593-594A Y
Power Supply 593-593A Y
Glass Latch Assembly Pkg of 2
Lava Rock Bag
Mineral Wool
Non-Combustible Boards (set only)
Touch Up Paint
Trim Kit, Black
Cover Panel
Defl ector Panel
Flashing
Hood-Exterior Side
Outdoor Surround
Wind Screen Assembly
Exterior
Interior
No longer available
All Others
TWILIGHT-II-B
Ending Manufacturing Date: Active
33858/2 Y
2005-790
050-721
2108-030
SRV2087-999-A12
TUP-GBK-12
TL-TRIM-BK
2086-149
2086-114MBK
2086-136MBK
2087-159
2086-113MBK
2086-130MBK
Stocked
in Depot
Wind Screen Assembly
2086-004MBK
2086-022
(No longer available)
Conversion Kit NG NGK-TWI
Conversion Kit LP LPK-TWI
Pilot Orifi ce NG 593-528
Pilot Orifi ce LP 593-527
Regulator NG NGK-DXF
Regulator LP LPK-DXF
Y
Y
Y
Y
Y
Y
Outdoor Lifestyles by Hearth & Home Technologies • Twilight-II-B Owner’s Manual • 2108-971 Rev. E • 11/13
21
C. Contact Information
Please contact your Hearth & Home Technologies dealer with any questions or concerns.
For the location of your nearest Hearth & Home Technologies dealer, please visit www.hearthnhome.com.
Hearth & Home Technologies
7571 215th St, Lakeville, MN 55044
- NOTES -
