Harman S400BT User Manual

S400BT

Bluetooth stereo headset

User’s manual

Welcome to use this Bluetooth stereo headset, S400BT. Please read this user’s manual carefully before use.

 Brief introduction

1. Bluetooth wireless communication technology

Bluetooth is a standard of close range wirel ess communication technology that was drawn up by Ericsson, IBM, Intel, Nokia and Toshiba. With Bluetooth technology, we can achieve the highest transmission rate amon g cell phones, computers, printers, PDAs and other devices. The max transmission range of class II is 10 meters while the max transmission ranges of class I can reach up to 100 meters.

2. About S400BT

S400BT is a Bluetooth V3.0 stereo headset. It supports the following Bluetooth profiles: HSP —— Headset Profile HFP —— Hands-free Profile A2DP—— Advanced Audio Distribution Profile AVRCP——Audio/Video Remote Control Profile

You can enjoy music wirelessly by using S400BT. It has the following features:

1) Pairing with a Bluetooth cell phone or PDA supporting HFP profile.

 Answer a call, end a call and reject a call  Redial last number  Voice dial  Adjust the volume  Call transfer between the headset and your Bluetooth cell phone  Microphone mute

2) Pairing with a Bluetooth cell phone or Bluetooth transmitter supporting A2DP profile.

 Enjoy music wirelessly  Adjust the volume  Remote control pause/play  Remote control previous/next track

3) Easy to switch between the call and music, you will not miss the

incoming call during listening to music.

4) Every time the headset is turned on, it will connect to last connected device automatically.

Note: In order to complete above function, the Bluetooth profiles o f paired device must be same as the headset. And even though the paired device and the headset support the same Bluetooth profiles, functions may vary due to specification differences of the paired devices.

 Before use

Overview

1 2

3 4 5 6 7 8

1 LED indicator 5 Built-in microphone 2 Bluetooth paring button 6 Multi-functions Touch panel

3 Charging/aux-in port 7 Right speaker 4 Power button 8 Left speaker

(Volume down/up, next/previous song, pause /play)

2. Charging for headset

The headset comes with a built-in rechargeable battery, prior to using it, it is recommended to charge the battery fully for the first time. When the headset is low power, the headset emits five “Dong” tones every 5 minutes and the red LED flashes instead of blue LED. Please recharge the battery of the headset.

The way of charging as following:

Using USB cable

1. Plug t he special charging clip into t he charging jack of headset, make it

clip the headset as pictures shown :

2. Plug another side of cable to the USB port of PC

Red light on: Charging Red light off: Finish charging

3. It will takes about 2 hours to finish charging

Remarks:

1) The battery is recyclable.

2) Batteries (battery pack or batteries installed) shall not be exposed to

 Getting started

1. Turning on/off the headset

Functions Operation LED indicator

Turning on Single press power button to Turning off Press power button and hold to

Remark: In order to save power, the headset will turn off automatically if no devices can be connected after 5 minutes.

2. Pairing the headset with Bluetooth devices

1) How to enter pairing mode Functions Operation LED indicator

Entering pairing mode

excessive heat place, such as sunshine, fire or the like.

turn on the unit, turn off the unit

When in BT Active mode, single press to enter the BT paring mode, press and hol d 2 seconds to exit

aring mode.

White on one secon Red LED on one

secon

Red and White LED flash alternately

for
