Harman JBLDUETBT User Manual

DUET BT

DUET BT

What’s in the box

DUET BT x 1

Charging cable x 1

Detachable audio cable x 1

x1

x1

x1

Warranty card, QSG, Warning card

x1

DUET BT

Overview

a. Buttons & LEDs

b. Connections

3hr

DUET BT

Bluetooth Connection

3

a. To turn on the headphone

ON (Slide button)

5.0s

b. For the first time connection the headphone will enter pair mode

automatically 5 secs after power on

c. Connect via devices

JBL DUET BT

Choose “JBL DUET BT” to connect

DUET BT

Music control

4

Long press volume

up for next track

Long press volume

down for previous track

DUET BT

Phone call

5

Passive listening mode

6

Press

12

Long Press

Hang up
current call
and switch to
second call

Switch calls

DUET BT

7

Multi-point Connection

1. Pair and connect the headphone with the 1stdevice

JBL Duet BT

JBL Duet BT

2. Long press bluetooth button to enter pairing mode

3. Connect the headphone

JBL DUET BT

Choose “

JBL DUET BT

”toconnect

DUET BT

4. Go back to the 1stdevice and click Connect

JBL DUET BT

JBL DUET BT

5. Max. 2 devices to be connected at the same time

nd

device will be the main source of music and movie.

1. 2

st

2. If you want to change the 1
stopthemusic/movieon2
on the 1stdevice.

3. If there is phone call from either devices, phone call will take the

1st priority

4. There are maximum 2 devices can be connected at the same time.

device to be the main source,

nd

device, start the music/movie

DUET BT

8

LED behaviour

Power / charging

Device mode White Flash

Poweron+NoBTConnected

Bluetooth LED

Power on + BT Pairing

Power on + BT Connected

Lower battery + No BT Connected

Lower battery + BT Pairing

Lower battery + BT Connected

Charging Complete

Charging in Progress

FW Version LED Display*

Blue Flash

Yes

Power / charging

Red Flash

LED

OnYes

Fast

OnYes

LED

SlowYes

SlowYes

SlowYes

N/ANo

OnYes

FastYes

DUET BT

EN

• Driver size: 40mm

• Dynamic frequency response range: 20Hz-20kHz

• SPL @1kHz1mW: 96

• Maximum SPL @1V input: 111

• Microphone sensitivity @1kHz: -42

• Impedance: 32ohm

• Bluetooth transmitted power: 0-4dbm

• Bluetooth transmitted modulation: GFSK

• Bluetooth frequency: 2.402GHz-2.48GHz

• Bluetooth profiles: HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version: V4.0

• Battery type: GSP753030

• Charging time: 2hr

• Music play time with BT on: Up to 16hr

• Talk time with BT on: Up to 16hr

• Standby time: 1year

• DimensionWx HxL (mm)

• Weight (g)

ES

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

FR

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DE

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DUET BT

IT

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

NO

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

NL

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

FI

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DUET BT

SV

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

PL

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DA

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth profiles HFP v1.6, HSP v1.2, A2DP
v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

HU

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DUET BT

RU

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

ID

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

PT

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth profiles HFP v1.6, HSP v1.2, A2DP
v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

JP

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DUET BT

KO

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

CHT

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

CHS

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

HE

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• Talk time with BT on Up to 16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DUET BT

AR

• Driver size 40mm

• Dynamic frequency response range 20Hz-20kHz

• SPL @1kHz1mW 96

• Maximum SPL @1V input 111

• Microphone sensitivity @1kHz -42

• Impedance 32ohm

• Bluetooth transmitted power 0-4dbm

• Bluetooth transmitted modulation GFSK

• Bluetooth frequency 2.402GHz-2.48GHz

• Bluetooth pr

ofiles HFP v1.6, HSP v1.2, A2DP

v1.2, AVRCP v1.4

• Bluetooth version V4.0

• Battery type GSP753030

• Charging time 2hr

• Music play time with BT on Up to 16hr

• TalktimewithBTonUpto16hr

• Standby time 1year

• DimensionWx HxL (mm)

• Weight (g)

DUET BT

Торговаямарка: JBL
Назначение товара: Пользовательские наушники
Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед,США, 06901 Коннек тикут,
г.Стэмфорд,Атлантик Стрит 400, офис 1500
Страна происхождения: Китай
Импортер в Россию: OOO“ХАРМАН РУС СиАйЭс“,РОССИЯ, 127018, г.МОСКВА, УЛ. ДВИНЦЕВ, Д.12,
КОРПУС 1
Гарантийныйпериод: 1 год
Информация о сервисных центрах: www.harman.com/ru тел. [phone]
Срок службы: 2 года
Товарне подл ежитоб язательнойсертификации
Дата производства: Дата изготовления устройства определяется по двум буквенным
обозначениям из второй группы символов серийного номера изделия, следующих после
разделительного знака «-». Кодировка соответствует порядку букв латинскогоалфавита,
начиная с января 2010 года: 000000-MY0000000, где «M» - месяц производства (А - январь, B ­февраль, C - март и т.д.) и «Y» - годпроизводства (A - 2010, B - 2011, C - 2012 и т.д.).

Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em carater primario”

Este produto está homologado pela ANATEL, de acordo com os procedimentos
regulamentados pela Resolução 242/2000, e atende aos requisitos técnicos aplicados.

Para maiores informações, consulte o site da ANATEL - www.anatel.gov.br

3817-15-7120

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by HARMAN International Industries, Incorporated is under
license. Other trademarks and trade names are those of their respective owners.

TR03394_A
