Harman ENCHANT1300 User Manual

ENCHANT

1300

Quick Start Guide

For more information, please visit harmankardon.com

/ 1. WHAT’S IN THE BOX

Remote Control

Soundbar

VOL

Power Cables* (4ft, 1200mm)

Wall-Mount Brackets Product Information &

HDMI Cable (4ft, 1200mm)

AUX cable (4ft, 1200mm)

Optical Cable (4ft, 1200mm)

Wall-mounted guide

* Power cable quantities vary by region

/ 2. PLACE YOUR SOUNDBAR

2a. Place the soundbar on the table

2B. Wall mount the soundbar

Use tape to stick the wall-mounted paper guide on the wall, push a pen tip through the center to mark the wall-mounted bracket location and remove the paper.

WALLMOUNTED PAPER GUIDE

Using the appropriate anchors, screw the wall mount brackets on the pen mark; Fix the screws at the back of soundbar; then hook the soundbar on the wall.

/ 3. CONNECT YOUR SOUNDBAR

3a. Connect to your TV

Option 1 (Best):

HDMI

HDMI (ARC)

Option 2:

OPTICAL

OPTICAL OUT

3b. Connect to other devices

HDMI OUT

(TV ARC)

OPTICAL IN

HDMI 2HDMI 1 HDMI 3

/ 4. POWER YOUR SYSTEM

After the power cord is plugged in, the soundbar will take about 30 seconds to start up and then will enter standby mode, ready to use.

/ 5. CONNECT TO WIFI

2 3

Once the soundbar connects to the internet for the ﬁrst time, it may detect a software update to improve performance. This update may take a few minutes to complete.

HK ENCHANT 1300

/ 6. CONTROL YOUR SOUNDBAR

6a. Top Panel

Volume

Down

Volume

Up Source

Power

Display

6b. Back Panel

Subwoofer connection

button

6c. Remote control

1) Power

2) Source*

3) BT Pair

4) Previous

5) Dim level

6) Presets

7) Mute

8) Sound mode**

9) Volume +

10) Volume -

11) Audio Sync -

12) Bass +

13) Bass -

14) Audio Sync +

15) Shuﬄe

16) Night mode

17) Play / Pause

18) Next

19) Calibration

VOL

* Switch between HDMI ARC/ HDMI 1/ HDMI 2/ HDMI 3/ Optical/ AUX/ Bluetooth/

USB

** Switch between Standard/ music/ movie/ voice/ personal sound mode or press

and hold 5 seconds to reset default audio setting

/ 7. USING PRESETS

You can save any audio setting, such as Source, volume and sound mode. For example: HDMI1, Volume 10, Music Mode

To save any preset:

1. Select Any source

2. Change the volume, bass level or sound mode

3 s

3. Press and hold the preset button. for 3 seconds

/ 8. CONNECT TO BLUETOOTH®

8a.

VOL

PAIRING

8b.

CONNECTED

HK ENCHANT 1300

Press and hold Remote control Bluetooth button for 3 seconds if you want to pair another mobile device

/ 9. SET UP MULTIBEAM™ SURROUND SOUND

Automatic MultiBeam Calibration (AMC) will optimize the soundbar sound settings for a better surround sound experience.

* More details in our

Owner's manual

>3 s

/ 10. PRODUCT SPECIFICATIONS

Model No.: ENCHANT 1300 Audio Channels 13 Power Supply: 100-240V~50/60Hz Maximum Power 240 W RMS Power 120W Total Harmonic Distortion (THD) 1% Woofer Size 10 x 2" (50mm) Tweeter Size 1 x 0.75" (20mm) 2 x 1" (25mm) Max SPL 98dB SPL Frequency Response 71Hz-20kHz Audio inputs 1 Analog, 1 Optical, Bluetooth, USB, Wi-Fi HDMI Video Inputs 3 HDMI Video Output (with Audio

Return Channel) 1 HDMI HDCP Version 2.2 Bluetooth version 4.2 Bluetooth Proﬁle A2DP v1.3/AVRCP v1.5 Bluetooth Frequency Range 2402MHz-2480MHz Bluetooth Max Transmitting power Bluetooth Transmitter modulation GFSK, π/4 DQPSK , 8DPSK Wi-Fi network compatibility IEEE 802.11b/g/n/ac (2.4G/5G)

2.4G Wi-Fi Frequency Range 2412 – 2472MHz (2.4GHz ISM Band, USA

2.4G Max Transmitting power 18dBm (EIRP)

2.4G Wi-Fi modulation 5G Wi-Fi maximum transmitter power 5G Wi-Fi modulation OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,

5G Wi-Fi transmitter frequency range

2.4G short-range wireless frequency range 2402 – 2478MHz

2.4G short-range wireless maximum transmitter power 0dBm (EIRP)

2.4G short-range wireless modulation GFSK

Standby Power Consumption <2.0W Operating temperature 0°C - 45°C Dimensions(W x H x D) 44" x 2.6" x 4.9" (1120 x 65 x 125mm) Weight 12.5 lb (5.65kg) Packaging Dimensions (W x H x D) 47" x 7.5" x 7" (1200mm x 190mm x 180mm) Packaging Weight (Gross) 16.7 lb (7.6 kg)

9dBm (EIRP)

11 Channels, Europe and others 13 Channels)

OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM 18dBm (EIRP)

64QAM, 256QAM

5.150~5.350GHz, 5.470~5.725GHz, 5.725~5.825GHz

Note: The soundbar is intended to be used for streaming music. A consumer can stream Bluetooth audio to the soundbar. A consumer can connect their soundbar to the local Wi-Fi Network and stream music with Google Chromecast. In addition, the soundbar will work with Google Home. It is designed to be instantly on and ready to play music at a moment’s notice, therefore, the Bluetooth and Wi-Fi connection must remain active at all times to ensure proper operation. The soundbar is in compliance with the European Union energy legislation. The soundbar shall enter sleep mode (networked standby) through following: after 10min of inactivity in operational mode. (i.e. no user input and no audio/video input). The unit can be brought into operational mode from sleep mode via : pressing Power/Source keys on front panel or remote control, break in music from BT audio source, the audio signal input recovers in the source (e.g. Optical, aux) which is the system source before Auto-Standby, wakeup command from HDMI CEC command (e.g. One Touch Play and REQUEST_ARC_INITIATION, system audio mode request, active source) and Google Chromecast audio stream.

Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em carater primario” Este produto está homologado pela ANATEL, de acordo com os procedimentos regulamentados pela Resolução 242/2000, e atende aos requisitos técnicos aplicados. Para maiores informações, consulte o site da ANATEL - www.anatel.gov.br

Торговая марка: Harman/Kardon • Назначение товара: Активная акустическая система • Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит 400, офис 1500

• Страна происхождения: Китай • Импортер в Россию: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к 1 • Гарантийный период: 1 год • Информация о сервисных центрах: www.harman.com/ru тел. +7-800-700-0467 • Срок службы: 5 лет • Товар сертифицирован • Дата производства: Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы символов серийного номера изделия, следующих после разделительного знака «-». Кодировка соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000, где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства (A - 2010, B - 2011, C - 2012 и т.д.).

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by HARMAN International Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners. Manufactured under license from Dolby Laboratories. Dolby,Dolby Audio,Pro Logic and the double-D symbol are trademarks of Dolby Laboratories. The terms HDMI, HDMI High-Deﬁnition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. The Wi-Fi CERTIFIED Logo is a certiﬁcation mark of the Wi-Fi Alliance. For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Digital Surround is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved Harman Kardon may update the software on your device automatically once a new version or feature is available. These updates are scheduled at times that may cause the least disruption to you. If you have any questions please contact us at www.harmankardon.com. Google, Google Play, Chromecast built-in, Google Home and other related marks and logos are trademarks of Google LLC. Chromecast built-in may require subscription(s). This product contains open source software. For your convenience, the source code and relevant build instruction for software licensed under the GPL is available at http://www.harmankardon.com/ opensource. You may also obtain this information by contacting us at OpenSourceSupport@Harman.com FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from nearby persons. Cet équipement est conforme aux limites d’exposition aux radiationsFCC/ IC CNR-102 établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps.

Use Restriction: This device is restricted to indoor use when operating in the 5150 to 5350 MHz frequency range in following countries:

BE EL LT PT BG ES LU RO CZ FR HU SI DK HR

MT SK DE IT NL FI EE CY AT SE IE LV PL UK

Belgium (BE), Greece (EL), Lithuania (LT), Portugal (PT), Bulgaria (BG), Spain (ES), Luxembourg (LU), Romania (RO), Czech Republic (CZ), France (FR), Hungary (HU), Slovenia (SI), Denmark (DK), Croatia (HR), Malta (MT), Slovakia (SK), Germany (DE), Italy (IT ), Netherlands (NL), Finland (FI), Estonia (EE), Cyprus (CY), Austria (AT), Sweden (SE), Ireland (IE), Latvia (LV), Poland (PL) and United Kingdom (UK).
