E40BT
E40BT
Quick Start Guide
Guide de démarrage rapide
Cable connections
1
3 hr
E40BT
Quick Start Guide
Guide de démarrage rapide
Turn on/off power and pair
2
ON
0.5s
LED Status
Pairing mode
Power on
Low battery
JBL E40BT
LED
behaviors
Fast
Slow
OFF
0.5s
0.5s x4
Clear Previously Paired Devices
Effacer un appareil associé
Borrar los dispositivos emparejados anteriormente
Limpar dispositivos emparelhados anteriormente
Bereits abgestimmte Geräte löschen
Cancella dispositivi precedentemente accoppiati
Wis eerder gekoppelde apparaten
Fjerntidligereparedeenheter
Tyhjennä aiemmat laiteparit
Удалить ранее сопряженные устройства
Rensa tidigare parkopplade enheter
Slet tidligere parrede enheder
ペアリング済みデバイスの消去
장치페어링전에지우기
清除已配对的设备
JBL E40BT
E40BT
Quick Start Guide
Guide de démarrage rapide
Adjust volume
3
Multi-function Button (MFB) to control music
4
Press
Press x2
Press x3
Multi-function Button (MFB) to skip track
5
Play or Pause
Next track
Previous track
Press +
Press and hold
Press x2 +
Press and hold
Skip track forward
Skip track backward
E40BT
Quick Start Guide
Guide de démarrage rapide
Multi-function Button (MFB) to control calls
6
Press
Long Press
Multi-function Button (MFB) to manage second incoming call
7
Press
1 2
Long Press
Answer/reject second incoming call
Multi-function Button (MFB) to manage 2 calls at the same time
8
Press
1 2
Long Press
Answer call
Reject call
Hang up current call and
switch to second call
Switch calls
Hang up current call and
switch to second call
Switch calls
E40BT
Quick Start Guide
Guide de démarrage rapide
To use ShareMe™ function
9
ShareMe
2
™
FPO
1
ShareMe™ enables sharing your audio
with another set of JBL wireless
headphone features ShareMe
Step 1: Pair and connect the headphone to a source device.
Step 2: Pause music or disengage voice calls from the source device.
Step 3: Press ShareMe
behind the button starts blinking. This headphone is ready to
connect to the second headphone.
Step 4: Press ShareMe
LED behind the button starts blinking. LED stops blinking after
ShareMe
Two headphones are ready to share the music.
Press ShareMe
ShareMe
streaming from a device.
™
button once on the first headphone then LED
™
button twice on the second headphone then
™
connects. Play the music on the source device.
™
button once to disconnect.
™
connection ends in 10 minutes when no audio is
™
.
E40BT
Quick Start Guide
Guide de démarrage rapide
EN FR
• Advanced 40mm drivers
• Dynamic frequency response: 20-20kHz
• BT frequency range: 2.402-2.480GHz
• BT transmitter power: <4dBm
• BT transmitter modulation:
GFSK π/4 DQPSK 8-DPSK
• Support BT 3.0, A2DP v1.3, AVRCP v1.5,
HFP v1.6, HSP v1.2
• Maximum SPL: 115dB @ 30mW
• Rated power input: 30mW
• Microphone sensitivity:
-42dBV/Pa @ 1kHz
• Battery type: Lithium polymer
(3.7V,610mAh)
• Music playing time: 16 hours
• Talk time: 24 hours
• Advanced 40mm drivers
• Dynamic frequency response: 20-20kHz
• BT frequency range: 2.402-2.480GHz
• BT transmitter power: <4dBm
• BT transmitter modulation:
GFSK π/4 DQPSK 8-DPSK
• Support BT 3.0, A2DP v1.3, AVRCP v1.5,
HFP v1.6, HSP v1.2
• Maximum SPL: 115dB @ 30mW
FPO
• Rated power input: 30mW
• Microphone sensitivity:
-42dBV/Pa @ 1kHz
• Battery type: Lithium polymer
(3.7V,610mAh)
• Music playing time: 16 hours
• Talk time: 24 hours
ES
• Advanced 40mm drivers
• Dynamic frequency response: 20-20kHz
• BT frequency range: 2.402-2.480GHz
• BT transmitter power: <4dBm
• BT transmitter modulation:
GFSK π/4 DQPSK 8-DPSK
• Support BT 3.0, A2DP v1.3, AVRCP v1.5,
HFP v1.6, HSP v1.2
• Maximum SPL: 115dB @ 30mW
• Rated power input: 30mW
• Microphone sensitivity:
-42dBV/Pa @ 1kHz
• Battery type: Lithium polymer
(3.7V,610mAh)
• Music playing time: 16 hours
• Talk time: 24 hours
PT
• Advanced 40mm drivers
• Dynamic frequency response: 20-20kHz
• BT frequency range: 2.402-2.480GHz
• BT transmitter power: <4dBm
• BT transmitter modulation:
GFSK π/4 DQPSK 8-DPSK
FPOFPO
• Support BT 3.0, A2DP v1.3, AVRCP v1.5,
HFP v1.6, HSP v1.2
• Maximum SPL: 115dB @ 30mW
• Rated power input: 30mW
• Microphone sensitivity:
-42dBV/Pa @ 1kHz
• Battery type: Lithium polymer
(3.7V,610mAh)
• Music playing time: 16 hours
• Talk time: 24 hours
E40BT
Quick Start Guide
Guide de démarrage rapide
Торговая марка: JBL
Назначение товара: АКТИВНАЯ АКУСТИЧЕСКАЯ СИСТЕМА
Изготовитель: ХАРМАН ИНТЕРНЕШНЛ ИНДАСТРИЗ ИНКОРПОРЕЙТЕД, США,
06901 КОННЕКТИКУТ, г.СТЭМФОРД, АТЛАНТИК СТРИТ 400, ОФИС 1500
Страна происхождения: Китай
Импортер в Россию: OOO “ХАРМАН РУС СиАйЭс“, РОССИЯ, 123317, МОСКВА,
ПРЕСНЕНСКАЯ НАБ, Д.10
Гарантийный период: 1 год
Информация о сервисных центрах: http://ru.jbl.com, тел. +7-800-700-0467
Срок службы: 7 лет
Срок хранения: не ограничен
Условия хранения: Cтандартные при нормальных значениях климатических
факторов внешней среды
FPO
FPO
0890
XXX-XXXX-JBL_E40_on-ear_Headphone_QSG_A
