Harman DP2USWC User Manual
Quick-Start Guide
Quick-Start Guide
3
Important!
WARNING: Operation of any feature of this device while driving could be dangerous. Always be careful and attentive to your vehicle and the
trac around you. Obey all trac laws and observe safe driving practices.
Do not connect or disconnect your portable music player or program the Drive + Play 2 system while driving. Always pull o the road and park
in a safe position before browsing your portable music player or adjusting the settings on the Drive + Play 2 system.
Do not use headphones while operating any vehicle. The Drive + Play 2 system audio output is not suitable for driving headphones and is
intended to output a signal appropriate for an audio system’s line-level input jack or FM antenna input.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment
has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
Quick-Start Guide
3
Cigarette Lighter Hub
Lighter Extension Cable
Hard-Wire Power Cable
Audio Cable
USB Adapter
iPod Cable
Display Screen
Display Cable
Display Mounting Base
Wired FM Transmitter Adapter
Wireless Control Knob
CR2032 Battery
Adhesive Mounting Pads (2)
Alcohol Cleaning Pads (2)
Mounting Screws (10)
Hex Keys (1.5mm and 3mm)
Quick-Start Guide
Warranty Card
Connecting the iPod®
Always hold the Drive + Play 2 system’s iPod dock connector by its sides and gently insert (or remove) the dock connector. Never use excessive force
to insert or remove the connector, or damage to your iPod may occur.
Lost Data
About Installation
IMPORTANT: The Drive + Play 2 system should be installed according to these instructions and relevant federal, state or local laws and regulations,
which the purchaser should determine prior to installation or use. For safety reasons, do not attempt to disable any safety function incorporated in
this device. Any alteration of this device may cause serious injury and shall void the warranty.
Although we recommend professional installation for your Harman Kardon Drive + Play 2 system, this product is also designed for do-it-yourself
installation, especially when using the wireless FM transmission method. The enclosed instructions explain how to install the Drive + Play 2 system in
a general sense, but they do not show the exact methods for your particular vehicle. After reading this guide, if you feel uncomfortable in performing
the necessary steps to install the product, consider asking your car-audio dealer about professional installation options.
Your Package Should Include:
Important!
Quick-Start Guide
5
Choose the Display Location
Change Display Base Mount
only if needed for your chosen
mounting location
The installation of this device between the driver and the windshield or otherwise in any manner that obstructs the driver’s clear view of the
road or trac conditions is dangerous and may be prohibited by law. Do not install this device in any manner that impairs the safe operation
of the vehicle.
The display should be positioned to eliminate glare and reections, and should be as close as possible to the driver’s normal line of sight, as long as such
positioning does not otherwise obstruct the driver’s view or impair the safe operation of the vehicle. Do not place device on the vehicle’s dashboard
unsecured. Do not install this device on any air bag panels or in the deployment eld of any air bags. For safety reasons, do not attempt to disable any safety
function incorporated in this device. Any alteration of this device may cause serious injury and shall void the warranty.
Select Display Mounting Location
Loosen 3mm screw in
center of the base.
Move base to the top
mounting hole.
Tighten screw again to
secure base.
See below
Quick-Start Guide
4
Quick-Start Guide
5
Stick adhesive pad to
base rst, then clean
surface of mounting
location with supplied
alcohol pad.
Mounting
Plate
Insert mounting plate
into display base and
tighten hex set screw.
Align mounting plate to
location and attach with 3
screws. Make sure the arrow
points toward the front of
the car.
Installing the Display
1
2
Mounting with Screws Mounting with Adhesive Pad
3
1
Tighten the hex screw to lock
the display base onto the
mounting plate.
2
Place display base onto
mounting plate and rotate
into desired position.
3
1
Mounting
Plate
Peel adhesive pad and
press display rmly
into desired location.
2
Base
Base
Adhesive
Pad
Plug cable
into display
After
Mounting
4
3
4
Hex Screw
Hex Screw
Quick-Start Guide
7
Installing the Wireless Control Knob
Install Control
Knob Battery
2
Mount Control Knob Base
1
2
CR2032/DL2032
Use a coin to remove
the bottom cover.
Push the knob down
onto the base, and
turn clockwise to lock
it into place. The knob
can be removed by
turning the bottom
counterclockwise.
3
Attach Control
Knob to Base
Orient the base so that the arrow is
facing the front of the car.
You can either screw the base to
the mounting location or use the
supplied adhesive pad.
If you use the adhesive pad, you
must FIRST CLEAN the surface with
the supplied alcohol cleaning pad.
3
4
Toward front of car
Select Control Knob Mounting Location
1
4
Quick-Start Guide
6
