ELECTRIC MEAT GRINDER
99598
HEAVY-DUTY ELECTRIC MEAT
GRINDER
99599
CLEANING, ASSEMBLY, AND OPERATION INSTRUCTIONS
MODEL 99598 MODEL 99599
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright© 2008 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 09j
IMPORTANT SAFEGUARDS
When using electrical appliances, ba-1.
sic safety precautions should always
be followed, including the following:
Read all instructions.2.
ance is operating. Cut type injury may
result.
SAVE THESE
INSTRUCTIONS.
To protect against risk of electri-3.
cal shock, do not put Motor, Fan, or
Gearbox in water or other liquid.
Close supervision is necessary when 4.
any appliance is used by or near
children.
Unplug from outlet when not in use, 5.
before putting on or taking off parts,
and before cleaning.
Avoid contacting moving parts. Feed 6.
food by hand. Always use food pusher.
Do not operate any appliance with 7.
a damaged cord or plug or after the
appliance malfunctions, or is dropped
or damaged in any manner. Return
appliance to the nearest authorized
service facility for examination, repair
or electrical or mechanical adjustment.
The use of attachments not recom-8.
mended or sold by the manufacturer
may cause re, electric shock or
injury.
SAVE THIS MANUAL
Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning
procedures. Write the product’s serial
number in the back of the manual near the
assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and
dry place for future reference.
IMPORTANT SAFETY
INSTRUCTIONS
In this manual, on the labeling,
and all other information provided with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
Do not use outdoors. For Household 9.
Use Only.
Do not let cord hang over edge of 10.
table or counter.
Do not let cord contact hot surface, 11.
including stove.
Do not use ngers to scrape food 12.
away from discharge disc while appli-
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 2
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
Electrical Safety
1. To protect against electrical shock do not immerse
cord, plugs, or the main
unit in water or other
liquid. Only the removable
non-electrical parts of the unit may be
immersed for cleaning. Thoroughly
clean and dry these parts prior to rst
use and before every subsequent
use.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
READ AND UNDERSTAND ALL
INSTRUCTIONS
When using electrical appliances,
safety precautions should always
be followed including the following:
Work Area Safety
Do not use outdoors.1.
Do not place on or near a hot gas or 2.
electric burner, or in a heated oven.
Extreme caution must be used when 3.
moving appliance.
Keep the work area well lit. Make 4.
sure there is adequate surrounding
workspace. Keep the work area free
of obstructions and other debris.
This appliance has a polarized plug 2.
(one blade is wider than the other).
To reduce the risk of electric shock,
this plug is intended to t into a polarized outlet only one way. If the plug
does not t fully in the outlet, reverse
the plug. If it still does not t, contact
a qualied electrician. Do not change
the plug in any way.
Do not use this product in a damp or 3.
wet location.
Do not clean with metal scouring 4.
pads. Metal pieces can break off the
pads and touch electrical parts involving risk of shock.
Power Cord Safety
1. A short power supply cord is to be
provided to reduce risks resulting
from becoming entangled in or tripping over a longer cord.
2. Do not use with any type of extension
cord.
Hot Surface Safety
Do not operate the appliance near 1.
draperies, curtains, and walls. These
ammable materials may catch re
from this electric appliance.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 3
Provide adequate ventilation space 2.
on all sides of the appliance, especially near vents. Inadequate ventila-
tion may cause re or damage to the
appliance.
connect, turn any control to “off”, then
remove plug from wall outlet.
Always ensure Switch is off and all 2.
parts are dry before plugging in.
Keep multiple ABC class re extin-3.
guishers nearby. Monitor the appliance while in use.
Foodborne Illness Safety
Before every use, thoroughly clean 1.
the appliance (see “Cleaning” section
for instructions) EXCEPT for thoseparts that do not touch foods. Then
wash your hands.
Follow Food and Drug Administration 2.
(FDA) food safety recommendations
for cooking and food handling (www.
fda.gov). Also, refer to the following
safety information, taken from FDA’s
website:
Cooking times (if provided) are a.
estimated. Verify that all food is
properly cooked. Steam, roast, or
otherwise heat all pieces of meat
and eggs to an internal temperature
of at least 160° F1.
Keep hot food hot (above 140° F) b.
and cold food cold (below 40° F).
Do not let perishable food sit out
longer than 2 hours (1 hour in temperatures above 90° F).
General Safety
Attach plug to appliance rst, then 1.
plug cord into the wall outlet. To dis-
1 Poultry should be cooked to an internal
temperature of at least 165° F. For whole
poultry, temperature measurement should
be taken in the thigh. To gauge shellsh
doneness, refer to FDA food safety guidelines.
Do not continuously operate for lon-3.
ger than 20 minutes.
Do not use to grind hard foods such 4.
as bones and nuts.
Do not use to grind ginger and other 5.
materials with hard ber.
Do not adjust Cutting Blade and Cut-6.
ting Plate while using Kubbe (a meatstuffed dumpling) Attachments.
Do not apply excessive pressure or 7.
force during operating. This may
result in jamming.
If unit jams, turn off Meat Grinder 8.
immediately, unplug cord from outlet
and clean the unit.
Do not disassemble individual parts 9.
or repair unit without help of trained
service technician. If supply cord is
damaged, it must be replaced by
trained service technician to avoid
injury or damage.
Do not use appliance for other than 10.
intended use.
Maintain labels and nameplates on 11.
the appliance. These carry important
safety information. If unreadable or
missing, contact Harbor Freight Tools
for a replacement.
Do not store anything other than the 12.
manufacturer’s recommended accessories in this unit when not in use.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 4
This product is not a toy. Keep it out 13.
of reach of children when children are
not being closely supervised.
WARNING: Handling the cord on 14.
this product will expose you to lead,
a chemical known to the State of
California to cause cancer, and birth
defects or other reproductive harm.
Wash hands after handling. (California Health & Safety Code § 25249.5,
et seq.)
When carrying Meat Grinder, hold 15.
Motor Housing with both hands. Do
not carry by holding Hopper Plate.
The warnings, precautions, and in-16.
structions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator
that common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
SAVE THESE
INSTRUCTIONS.
SPECIFICATIONS
(FOR MODEL 99598)
Electrical
Requirements
Max. Capacity
Speed Setting Single Speed
Power Cord 3’ - 10” L
Accessories
HOUSEHOLD USE ONLY
120 V~ / 60 Hz / 250 W
2 lb. per minute / 1-1/2”
cube meat pieces
1 Feed Stick
1 Stainless Steel
Cutting Blade
3 Cutting Plates
1 4-Piece Sausage
Stufng Kit
1 2-Piece Kubbe
Attachment
SPECIFICATIONS
(FOR MODEL 99599)
Electrical
Requirements
Max. Capacity
Speed Setting Single Speed
Power Cord 3’ - 10” L
Accessories
HOUSEHOLD USE ONLY
120 V~ / 60 Hz / 350 W
2 lb. per minute / 1-1/2”
cube meat pieces
1 Feed Stick
1 Stainless Steel
Cutting Blade
3 Cutting Plates
1 4-Piece Sausage
Stufng Kit
1 2-Piece Kubbe
Attachment
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 5
UNPACKING
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please
call Harbor Freight Tools at the number
shown on the cover of this manual as soon
as possible.
CLEANING
Read the ENTIRE IMPORTANT
SAFEGUARDS section at
the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION OR ELECTRIC
SHOCK:
Before cleaning appliance,
make sure the appliance’s
switch is turned off, the cord
is unplugged, and the unit has
cooled completely.
Do not immerse motor/heating
element, cord, or plug in water
or any other liquid.
To prevent foodborne illness, wash 1.
the non-electrical parts of the unit before assembly in warm, soapy water,
taking care to rinse completely.
Dry with a soft cloth. Wipe the motor/2.
heating element housing with a soft
clean cloth or sponge.
Allow unit to dry completely before 3.
assembly or use.
After washing and drying, apply a 4.
small amount of salad oil (not includ-
ed) to Cutting Plates to keep them
lubricated.
WARNING!5. Do not use bleach, thin-
ners or benzines during clean. These
will damage or discolor Meat Grinder.
ASSEMBLY
(FOR 99598 MEAT GRINDER)
Read the ENTIRE IMPORTANT
SAFEGUARDS section at
the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION OR ELECTRIC
SHOCK:
Before appliance assembly or
adjustment, make sure the
appliance’s switch is turned
off, the cord is unplugged,
and the unit has cooled
completely.
Note: For additional information regarding
the parts listed in the following pages,
refer to the 99598 Assembly Diagram
on pages 10 and 11 of this manual.
Slide Head (12) into Housing Open-1.
ing (15). While holding Head, place
Locking Knob (22) into slot on Left
Motor Housing (21).
Turn Locking Knob clockwise until 2.
tight and Head is fastened securely to
housing.
Twist Feed Screw (100) long-end 3.
rst into Head. Continue twisting until
Feed Screw fastened into housing.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 6
Slide Cutting Blade (9) onto Feed 4.
Screw, making sure the edges of Cutting Blade face front of housing.
To make sausage, insert desired 4.
Sausage Maker (3, 4, or 5) into Sausage Adapter (2).
WARNING!5. Cutting Blade has sharp
blades. Wear gloves and use care
when installing Cutting Blade.
Slide selected Cutting Plate (6, 7, or 6.
8) over Cutting Blade, using the slot
along Plate edge as guide.
Screw Cap (1) into place on hous-7.
ing until secure. CAUTION! Do not
overtighten.
Slide Hopper Plate (13) onto top of 8.
Head until secure.
Set Grinder on at and stable counter 9.
space that does not block vents along
bottom of housing.
Cut foods into small pieces that can 10.
easily t into Hopper.
Place wide end of Sausage Adapter 5.
against the Head and in front of Cutting Blade.
Slide Cap over Sausage Maker and 6.
Adapter and turn clockwise until Sausage Adapter is fastened securely
against housing. CAUTION! Do not
overtighten.
For making Kubbe, place Kubbe At-7.
tachments (10, 11) onto Feed Screw
shaft. Slide down until the Attach-
ment tabs t into the slots.
Slide Cap over Attachments and turn 8.
clockwise until fastened securely
against housing. CAUTION! Do not
overtighten.
ASSEMBLY
OPERATION
(FOR 99598 MEAT GRINDER)
Read the ENTIRE IMPORTANT
SAFEGUARDS section at
the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
Once food is ready, plug in Power 1.
Cord (17) and press Switch (20) to
activate.
Feed food into Hopper Plate. Use 2.
Food Pusher (14) to press food down
Plate and into Head.
WARNING! Do NOT use ngers to 3.
push food into Grinder. Only use
Food Pusher.
(FOR 99599 MEAT GRINDER)
Read the ENTIRE IMPORTANT
SAFEGUARDS section at
the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION OR ELECTRIC
SHOCK:
Before appliance assembly or
adjustment, make sure the
appliance’s switch is turned
off, the cord is unplugged,
and the unit has cooled
completely.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 7
Note: For additional information regarding
the parts listed in the following pages,
refer to the 99599 Assembly Diagram
on pages 12 and 13 of this manual.
Slide Head (12) into Housing Open-1.
ing (15). While holding Head, place
Locking Knob (16) into slot on Left
side of Motor Housing (17).
Turn Locking Knob clockwise until 2.
tight and Head fastened securing to
housing.
Twist Feed Screw (100) into Head. 3.
Continue twisting until Feed Screw
Base (101) is fastened securely into
housing.
Slide Cutting Blade (11) onto Feed 4.
Screw, making sure the edges of Cutting Blade face front of housing.
WARNING!5. Cutting Blade has sharp
blades. Wear gloves and use care
when installing Cutting Blade.
Slide selected Cutting Plate (6, 7, or 6.
8) over Cutting Blade, using the slot
along Plate edge as guide.
Screw Cap (1) into place on hous-7.
ing until secure. CAUTION! Do not
overtighten.
Slide Hopper Plate (13) onto top of 8.
Head until secure.
Set Grinder on at and stable counter 9.
space that does not block vents along
bottom of housing.
OPERATION
(FOR 99598 MEAT GRINDER)
Read the ENTIRE IMPORTANT
SAFEGUARDS section at
the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
Once food is ready, remove the 1.
Power Cord (19) from the Cord Compartment (20) and plug Cord into
outlet. The red Power light will turn
on. Press On Key (35) to activate.
Feed food into Hopper Plate. Use 2.
Food Pusher (14) to press food down
Plate and into Head.
WARNING! Do NOT use ngers to 3.
push food into Grinder. Only use
Food Pusher.
Please note: While On Key is 4.
pressed, a beeping will sound and
the green ON light will activate.
To stop the Grinder, press the Off Key 5.
(33).
In case of a food blockage, press Off 6.
key and then Reverse Key (31). The
green reverse light will activate.
Please note: 7. To change from reverse
to forward direction, rst press Off for
at least three seconds before pressing On again. This will help prevent
damage to motor.
Cut foods into small pieces that can 10.
easily t into Hopper.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 8
CAUTION! 8. Machine should not be
run for longer than 20 continuous
minutes. The motor will deactivate
automatically after 1 hour of continuous running.
If the Grinder gets jammed, the over-9.
load light will ash and the beep-beep
alarm will sound.
When jammed, the Circuit Breaker 10.
(26) will trigger. Once jam is cleared
(Inspection And Maintenance), reset
Circuit Breaker switch.
TO PREVENT SERIOUS
INJURY FROM APPLIANCE
FAILURE:
Do not use damaged
appliances. If abnormal
noise or vibration occurs,
have the problem corrected
before further use.
To make sausage, insert desired 11.
Sausage Maker (3, 4, or 5) into Sausage Adapter (2).
Place wide end of Sausage Adapter 12.
against the Head and in front of Cutting Blade.
Slide Cap over Sausage Maker and 13.
Adapter and turn clockwise until Sausage Adapter is fastened securely
against housing. CAUTION! Do not
overtighten.
For making Kubbe, place Kubbe At-14.
tachments (9, 10) onto Feed Screw
shaft. Slide down until the Attach-
ment tabs t into the slots.
Slide Cap over Attachments and turn 15.
clockwise until fastened securely
against housing. CAUTION! Do not
overtighten.
INSPECTION AND
MAINTENANCE
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION OR ELECTRIC
SHOCK:
Before appliance inspection
or maintenance, make sure
the appliance’s switch is
turned off, the cord is
unplugged, and the unit has
cooled completely.
BEFORE EACH USE,1. inspect the
general condition of the appliance.
Check for loose screws, misalignment
or binding of moving parts, cracked or
broken parts, damaged electrical wiring, and any other condition that may
affect its safe operation.
To clear jams, switch off Grinder and 2.
remove power cord from outlet.
Unscrew Cap and remove Cutting 3.
Plate. CAUTION! Use screwdriver
(not included) to remove Cutting
Plate from Head. Do not remove with
ngers.
Remove clogged meat, wash parts 4.
in warm, soapy water, dry and reassemble.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS
PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER
THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO
THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE
ANY REPAIRS TO THE PRODUCT, OR THAT HE OR
SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE
PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS
AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN
BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT
BY THE BUYER. THE BUYER ASSUMES ALL RISK AND
LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 9
99598 PARTS LIST
99598 PARTS LIST
Part Description Q’ty
1. Cap 1
2. Sausage Maker Adapter 1
3. Small Sausage Maker 1
4. Medium Sausage Maker 1
5. Large Sausage Maker 1
6. Medium Cutting Plate 1
7. Fine Cutting Plate 1
8. Coarse Cutting Plate 1
9. Cutting Blade 1
10. Kubbe Attachment A 1
11. Kubbe Attachment B 1
12. Head 1
13. Hopper Plate 1
14. Food Pusher 1
15. Housing Opening 1
16. Rubber Half-Ring 2
17. Power Cord 1
18. Self-Tap Bolt (M4×16) 2
19. Switch Holder 1
20. Switch 1
21. Left Motor Housing 1
22. Locking Knob 1
23. Rubber Underlay 4
24. Right Motor Housing 1
25. Self-Tap Bolt (M4×20) 5
Part Description Q’ty
100. Feed Screw 1
101. Wire Loop 1
102. Washer (M14×0.8) 1
103. POM Washer 1
104. Washer (M14×0.2) 1
105. Feed Screw Base 1
200. Gearbox 1
201. Fan 1
202. Motor 1
203. Rear Gearbox 1
204. Washer (M5) 3
205. Spring Washer (M5) 3
206. Bolt (M5×12) 3
207. Washer (M8×0.2) 5
208. Gear C 1
209. Rubber Shroud 6
210. Small shaft 2
211. Front Gearbox 1
212. Nut (M8) 1
213. Self-Tap Bolt (M4×18) 4
214. Bushing A 1
215. Gear A 1
216. Washer (M12×0.2) 2
217. Gear B 1
218. Bushing B 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 10
99598 ASSEMBLY DIAGRAM
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 11
99599 PARTS LIST
99599 PARTS LIST
Part Description Q’ty
1. Cap 1
2. Sausage Maker Adapter 1
3. Large Sausage Maker 1
4. Medium Sausage Maker 1
5. Small Sausage Maker 1
6. Coarse Cutting Plate 1
7. Fine Cutting Plate 1
8. Medium Cutting Plate 1
9. Kubbe Attachment A 1
10. Kubbe Attachment B 1
11. Cutting Blade 1
12. Head 1
13. Hopper Plate 1
14. Food Pusher 1
15. Opening 1
16. Locking Knob 1
17. Motor Housing 1
18. Coping 1
19. Supply Cord 1
20. Cord Compartment Cover 1
21. Cord Connected Switch 1
22. Power Switch 1
23. Switch Seat 1
24. Cord Connected Breaker 2
25. Key Holder 1
26. Circuit Breaker 1
27. Breaker Fixer 1
28. Spring 1
29. Reset Key 1
30. Reset Transducer 1
31. Reverse Key 1
32. Reverse Transducer 1
33. Off Key 1
34. Off Transducer 1
35. On Key 1
36. On Transducer 1
37. Self-Tap Bolt (M3×8) 4
38. PCB 1
Part Description Q’ty
39. Self-Tap Bolt (M4×12) 4
40. Bolt Seat 6
41. PCB Box 1
42. PCB Cover 1
43. Self-Tap Bolt (M4×20) 10
44. Cord Compartment 1
45. Bottom Board 1
46. Rubber Underlay 4
100. Feed Screw 1
101. Feed Screw Base 1
102. Washer (M16×0.2) 2
103. POM Washer 1
104. Washer (M16×1.5) 1
105. Wire Loop 1
200. Gearbox 1
201. Fan 1
202. Motor 1
203. Quakeproof Washer 1
204. Insulated Washer 3
205. Bolt (M5×20) 3
206. Rear Gearbox 1
207. Washer (M10×0.5) 2
208. Shaft 1
209. Shaft Base 1
210. Washer (M8×0.5) 1
211. Bevel Wheel 1
212. Sleeve 1
213. Coupled Gear 1
214. Spring Ring (M12) 1
215. Gear Wheel 1
216. Washer (M12×0.5) 1
217. Washer (12×0.2) 2
218. Front Gearbox 1
219. Washer (M5) 3
220. Spring Washer (M5) 3
221. Bolt (M5×15) 3
222. Bushing (M12) 1
223. Shaft (M12) 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 12
99599 ASSEMBLY DIAGRAM
SKU 99598/99599 For technical questions, please call 1-800-444-3353. Page 13
Loading...
