Harbor Freight Tools 94847 User Manual
PNEUMATIC PLANISHING HAMMER
94847
ASSEMBLY AND OPERATING INSTRUCTIONS
Due to continuing improvements, actual product may
differ slightly from the product described herein.
Distributed Exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
Copyright © 2006 by Harbor Freight Tools®. All rights reserved. No portion of
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353
Specications
Speed 875 - 1350 BPM
Operating Air Pressure 50 to 100 (maximum) PSI; 4 SCFM
Air Inlet 1/4”, 18 NPT, female
Overall Dimensions 23 (L) x 5-1/2 (W) x 24 (H) inches (C-frame and
Hammer)
Anvil-to-Hammer Opening 4 inches (maximum)
Anvil Height Adjustment 2-position anvil shaft mount with lock pin
3/8” to 1-1/4” opening (between head and anvil); 4-
position, stepped anvil micro-adjustment block 1/16”
height difference between each level
Anvil Sizes 1” Radius, 2” Radius and 3” Radius
Throat Depth 19-5/8 inches
Foot Pedal 7-1/4 (L) x 4 (W) x 3-1/2 (H) inches. Built-in air lter
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1.
2.
Keep work area clean. Cluttered areas invite injuries.
Observe work area conditions. Do not use machines or power tools in damp
or wet locations. Don’t expose to rain. Keep work area well lighted. Do not use
electrically powered tools in the presence of ammable gases or liquids.
3.
Keep children away. Children must never be allowed in the work area. Do not let
them handle machines, tools, or extension cords.
4.
Store idle equipment. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
5.
Use the right tool for the job. Do not attempt to force a small tool or attachment to
do the work of a larger industrial tool. There are certain applications for which this
tool was designed. It will do the job better and more safely at the rate for which it
was intended. Do not modify this tool and do not use this tool for a purpose for which
it was not intended.
6.
Use eye and ear protection. Always wear ANSI approved impact safety goggles.
Wear a full face shield if you are producing metal lings.
7.
Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid footwear
are recommended when working. Wear restrictive hair covering to contain long hair.
SKU 94847 For technical questions, please call 1-800-444-3353
REV 07j
Page 2
8.
Do not overreach. Keep proper footing and balance at all times. Do not reach over
or across running machines.
9.
10.
11.
12.
13.
14.
Maintain tools with care. Keep tools sharp and clean for better and safer
performance. Follow instructions for lubricating and changing accessories. Inspect
tool cords periodically and, if damaged, have them repaired by an authorized
technician. The handles must be kept clean, dry, and free from oil and grease at all
times.
Disconnect air supply. Unplug tool from air supply when not in use.
Remove adjusting keys and wrenches. Check that keys and adjusting wrenches
are removed from the tool or machine work surface before operation.
Stay alert. Watch what you are doing, use common sense. Do not operate any tool
when you are tired.
Check for damaged parts. Before using any tool, any part that appears damaged
should be carefully checked to determine that it will operate properly and perform
its intended function. Check for alignment and binding of moving parts; any broken
parts or mounting xtures; and any other condition that may affect proper operation.
Any part that is damaged should be properly repaired or replaced by a qualied
technician. Do not use the tool if any switch does not turn On and Off properly.
Replacement parts and accessories. When servicing, use only identical
replacement parts. Use of any other parts will void the warranty. Only use
accessories intended for use with this tool. Approved accessories are available from
Harbor Freight Tools.
15.
Do not operate tool if under the inuence of alcohol or drugs. Read warning
labels if taking prescription medicine to determine if your judgment or reexes are
impaired while taking drugs. If there is any doubt, do not operate the tool.
16.
Maintenance. For your safety, service and maintenance should be performed
regularly by a qualied technician.
17.
18.
Compressed air only. Never use combustible gas as a power source.
Protect hands and body from injuries. Always wear leather gloves and body
protection when handling metal for use on the Planishing Hammer. Keep hands,
ngers, and arms away from the hammer head and anvil during operation.
19.
Install this product on a proper surface. Locate on a at, level, and solid surface
that is capable of supporting the weight of the Planishing Hammer and the material
being hammered.
Warning: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors which cannot
be built into this product, but must be supplied by the operator.
SKU 94847
For technical questions, please call 1-800-444-3353
Page 3
