PNEUMATIC PAINT SHAKER
Model
94605
ASSEMBLY AND OPERATION INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described
herein.
Copyright © 2006 by Harbor Freight Tools®. All rights reserved. No portion of
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
Revised 07g
SPECIFICATIONS
ITEM DESCRIPTION
Function Shakes and mixes paint in cans from one gallon to one quart.
Air Pressure Requirement 40 to 70 PSI
Air Consumption 3.2 CFM at 70 PSI
Can Jaws 3 to 11 inch adjustable, non-marring jaws
Speed 700 CPM (free speed - no load)
Air Inlet Size 1/4” - 18 NPT (female threads)
Air Hose 3/8 (ID) inch (recommended)
Load Capacity 11 lbs. (maximum)
Overall Dimensions 16-3/4 (L) x 9-1/8” (W) x 12-3/4 (H) inches
Weight 21.12 lbs.
Save This Manual
You will need the manual for the safety warnings and precautions, assembly
instructions, operating and maintenance procedures, parts list and diagram.
Keep your invoice with this manual. Write the invoice number on the inside of
the front cover. Keep the manual and invoice in a safe and dry place for future
reference.
SAFETY WARNINGS AND PRECAUTIONS
WARNING: When using tool, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools
in damp or wet locations. Don’t expose to rain. Keep work area well
lighted. Do not use electrically powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area.
Do not let them handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry
location to inhibit rust. Always lock up tools and keep out of reach of
children.
Page 2SKU 94605 For technical questions, please call 1-800-444-3353.
5. Use the right tool for the job. Do not attempt to force a small tool or
attachment to do the work of a larger industrial tool. There are certain
applications for which this tool was designed. It will do the job better
and more safely at the rate for which it was intended. Do not modify this
tool and do not use this tool for a purpose for which it was not intended.
6. Use eye protection. Always wear ANSI approved impact safety goggles
when using the Paint Shaker.
7. Dress properly. Do not wear loose clothing or jewelry as they can be
caught in moving parts. Protective, electrically non conductive clothes
and nonskid footwear are recommended when working. Wear restrictive
hair covering to contain long hair.
8. Verify that the paint containers are securely closed before shaking, to
avoid spilling or property damage.
9. Maintain tools with care. Keep tools clean for better and safer performance. Follow instructions for lubricating and changing accessories.
Inspect tool air hoses periodically and, if damaged, have them repaired
by an authorized technician. The handles must be kept clean, dry, and
free from oil and grease at all times.
10. Disconnect air line. Unplug air line from the tool when not in use. Only
use compressed air.
11. Avoid unintentional starting. Be sure the switch is in the Off position
when not in use and before plugging air line in. Do not carry any tool with
your finger on the trigger, whether it is plugged in or not.
12. Stay alert. Watch what you are doing, use common sense. Do not operate any tool when you are tired.
13. Check for damaged parts. Before using any tool, any part that appears
damaged should be carefully checked to determine that it will operate
properly and perform its intended function. Check for alignment and
binding of moving parts; any broken parts or mounting fixtures; and any
other condition that may affect proper operation. Any part that is damaged should be properly repaired or replaced by a qualified technician.
Do not use the tool if any switch does not turn On and Off properly.
14. Replacement parts and accessories. When servicing, use only identical
replacement parts. Use of any other parts will void the warranty. Only
use accessories intended for use with this tool. Approved accessories
are available from Harbor Freight Tools.
Page 3SKU 94605 For technical questions, please call 1-800-444-3353.
15. Do not operate tool if under the influence of alcohol or drugs. Read
warning labels if taking prescription medicine to determine if your judgment or reflexes are impaired while taking drugs. If there is any doubt,
do not operate the tool.
16. Make sure the place where you use this product is properly ventilated.
17. The brass components of this product contain lead, a chemical known
to the State of California to cause birth defects (or other reproductive
harm). (California Health & Safety code § 25249.5, et seq.)
18. Verify paint containers are securely closed before shaking.
19. Maintenance. For your safety, service and maintenance should be performed regularly by a qualified technician.
20. Verify the air pressure from compressor is between 40 and 70 PSI .
21. Follow the warnings and precautions in the manual for the air compressor being used.
The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must
be understood by the operator that common sense and caution are factors
which cannot be built into this product, but must be supplied by the operator.
UNPACKING
When unpacking, check to make sure that all the parts of the Pneumatic Paint
Shaker are included. Refer to the Assembly Drawing and Parts List at the end
of this manual. If any parts are missing or broken, please call Harbor Freight
Tools at the number on the cover of this manual.
INSTALLATION
1. Choose a workbench to mount the Paint Shaker on that is able to withstand the weight of the tool, full paint can, and steady vibration of the
mixing.
2. Locate the Paint Shaker on the workbench and mark drilling holes using the Base (1) mounting holes as a template.
Caution: Before drilling, verify that there are no obstructions or live wires be-
neath the table.
Page 4SKU 94605 For technical questions, please call 1-800-444-3353.
3. Move the Paint Shaker aside, and drill holes using a drill matching the
size of the Base (1) mounting holes.
4. Mount Paint Shaker to the workbench using supplied nuts and bolts
hardware. If the supplied hardware will not accommodate the workbench,
other hardware will need to be purchased.
Air Connection
1. Wrap a small amount of Teflon® joint tape (not supplied) around the
treads of the Control Valve (6), then screw it into
the Inlet Fitting (7) until secure. Do not overtighten. Thread on the Oiler (52) to the Control
Valve (6). fill the Oiler with oil. See page 6.
2. Attach the compressor air hose (not supplied)
to the Control Valve (6). Securely tighten.
3. Optional: Attach an air quick-coupler (not sup-
plied) between the air hose and Oiler (52) for fast disconnects.
4. Tighten all couplings and fittings.
AIR FILTER CONNECTION
Dirt, water, and the lack of pneumatic tool oil are major causes for tool wear.
Install an optional air filter (not supplied), as illustrated below for better performance.
Connect the Pneumatic Paint Shaker, air hose, filter, to the Compressor Air
Outlet as illustrated below.
The air filter (not supplied) is recommended but not mandatory for operation.
If the filter is not used, connect the air supply hose directly to the compressor
air inlet fitting. Use pipe thread seal or Teflon tape on all threaded connections.
Paint
Shaker
Page 5SKU 94605 For technical questions, please call 1-800-444-3353.
OPERATION
Warning: Verify that the paint containers are securely closed before shaking,
to avoid spilling or property damage. Make sure there is oil in Oiler (52)
BEFORE use. See page 6.
1. Place the paint can within the Jaws (48) and securely tighten Handle (38).
2. Verify that the Control Valve (6) is in the Off position (handle perpendicular
to air flow direction) as shown on page 4.
3. Turn on the air pressure at the air supply tank or compressor. Adjust
pressure to 40 PSI as read on the compressor pressure gauge.
4. Adjust the air pressure up to a maximum of 70 PSI for optimum tool
performance.
5. Turn the Control Valve (6) to the On position. Shaking will begin.
Caution: If the paint can appears to be slipping out from the Jaws (48) during
shaking, immediately turn off the Control Valve (6). Reset the can and retighten
the Jaws.
6. Shake the paint can for two to four minutes, depending on its size.
7. After mixing the paint, turn the Control Valve (6) to the Off
position, and wait for the movement to stop.
Handle (38)
8. Disconnect the air hose from the compressor.
9. Loosen Handle (38) and remove the paint can.
Lubricating The Paint Shaker
1. Disconnect the Pneumatic Paint Shaker from the air supply.
2. Locate the Oiler (52). There is a plug and a small screw on the Oiler that
must be removed. Using a small funnel, pour air tool oil into the fill hole
until the oiler is full. Replace the Fill Screw and plug. See photo page 5.
3. Connect the Pneumatic Paint Shaker to the Oiler (52). The oiler will
automatically spray a very small amount of oil into the Paint Shaker as
you use it. Make sure you keep oil in the Oiler (52) to avoid damaging
the Paint Shaker.
4. There is a zerk oil fitting (25) that feeds oil to a Bushing (21). Lubricate the
bushing at least once a month if heavily used. See diagram on page 9.
07j
Page 6SKU 94605 For technical questions, please call 1-800-444-3353.
MAINTENANCE
1. After each use, remove the air hose and wipe the tool with a clean cloth
to remove any dirt and grease buildup.
2. To maintain tool life, always lubricate the air line by adding a few drops of
pneumatic tool oil to the air line before each use. Or, install the automatic
oiler-filter system as previously illustrated.
3. Before each use, drain water out of the air compressor tank and condensation from the air lines. Refer to the Air Compressor Operator’s Manual.
TROUBLESHOOTING
Problem Probable Cause Possible Solution
Paint Shaker does not
tun on when Control
Valve (6) is opened.
Paint Shaker shakes
violently, abnormally.
1. Insufficient or no
air supply.
2. Problem or leak in
air hose.
1. Too much air pressure.
2. Mounting hardware loose.
1. Fill air tank or turn
compressor on.
2. Check air hose
connection.
1. Reduce pressure
to 45 PSI.
2. Tighten mounting
hardware.
07j
Page 7SKU 94605 For technical questions, please call 1-800-444-3353.
PARTS LIST
Part Description QTY
1 Base 1
2 Nut 2
3 Screw 1
4 Rubber defends & rises
cushion
5 Rubber Cushion 2
6 Control Valve 1
7 Air Inlet Fitting 1
8 Valve Body Screw 3
9 Lower Valve Body 1
10 Packing 1
11 Valve Piece 1
12 Screw 1
13 Upper Valve Body 1
14 Packing 1
15 Piston Screw 1
16 Wear Ring 1
17 Piston O-Ring 1
18 Piston 1
19 Cylinder Body 1
20 Clamp Shim 1
21 Bearing 2
22 Cylinder Rod 1
23 Crank Pin Retaining Ring 2
24 Bushing 1
25 Zerk Fitting 2
26 Crank Arm 1
27 Nut 1
2
Part Description QTY
28 Crank Pin 1
29 Main Shaft 1
30 L-Connecting 1
31 Ferrule 2
32 Weave Pipe 1
33 Screw 2
34 Spring Pad 2
35 Screw 1
36 Rocker Handle 1
37 Nut 1
38 Handle 1
39 Thrust Washer 1
40 Roll Pin 1
41 Roll Pin 1
42 Clamp Screw 1
43 Jaw Bolt 4
44 Jam nut 6
45 Clamp Nut (L) 1
46 Frame Weld Clamp 1
47 Clamp Nut (R) 1
48 Jaw 2
49 Rod Bearing 1
50 Rod Seal 1
51 Shin 2
52 Mini Oiler 1
53 Spring Pad 1
NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts.
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
07j
Page 8SKU 94605 For technical questions, please call 1-800-444-3353.
ASSEMBLY DRAWING
Page 9SKU 94605 For technical questions, please call 1-800-444-3353.
90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its
products meet high quality and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days
from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or
accidents, repairs or alterations outside our facilities, criminal
activity, improper installation, normal wear and tear, or to lack of
maintenance. We shall in no event be liable for death, injuries to
persons or property, or for incidental, contingent, special or consequential damages arising from the use of our product. Some
states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation of exclusion may
not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be
returned to us with transportation charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace the product at our election or we may elect
to refund the purchase price if we cannot readily and quickly
provide you with a replacement. We will return repaired products
at our expense, but if we determine there is no defect, or that the
defect resulted from causes not within the scope of our warranty,
then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA
93011 • (800) 444-3353
Page 10SKU 94605 For technical questions, please call 1-800-444-3353.
Loading...
