Harbor Freight Tools 94088 User Manual
BatterBatter
®
Batter
BatterBatter
y Charger/Ty Charger/T
y Charger/T
y Charger/Ty Charger/T
esterester
ester
esterester
12 V12 V
12 V
12 V12 V
oltolt
olt
oltolt
94088
ASSEMBLY AND OPERATING INSTRUCTIONS
3491 MISSION OAKS BL V D ., CAMARILLO, CA 93011
VISIT OUR WEB SITE AT HTTP://WWW.HARBORFREIGHT.COM
TO HELP PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
Copyright© 2005 by Harbor Freight Tools®. All rights reserved. No portion of this manual
or any artwork contained herein may be reproduced in any shape or form without the express
written consent of Harbor Freight T ools.
For technical questions and replacement parts, please call 1-800-444-3353.
snoitacificepS
metInoitpircseD
noitpmusnoCrewoPzH06,CAV011
droCrewoPgulpgnorp-2htiwteefxiS
tuptuOCDstloV21taspma5.5ro2
rotacidnIegrahCyrettaBstloV6.21-3.21
yticapaCregrahC)egrahC.niMtloV4(hA09-51
snoisnemiDllarevO)H("11x)W("8/7-6x)L("8/3-4
thgieW.sbl1.6
IMPORTANT SAFEGUARDS
IMPORTANT SAFETY INSTRUCTIONS
1. “SAVE THESE INSTRUCTIONS” - This manual contains important safety and operating
instructions for battery charger Model: 94088.
2. Do not expose charger to rain or snow.
3. Use of an attachment not recommended or sold by the battery charger manufacturer may
result in a risk of fire, electric shock, or injury to persons.
4. To reduce r isk of damage to electric plug and cord, pull by plug rather than cord when
disconnecting charger. An extension cord should not be used unless absolutely
necessary.
5. Use of improper extension cord could result in a
risk of fire and electric shock. If extension cord must
be used, make sure:
(a) That pins on plug of extension cord are the
same number, siz e, and shape as those of plug
on charger.
(b) That extension cord is properly wired and in
good electrical condition.
(c) That wire size is large enough for AC ampere
rating of charger .
6. Do not operate this charger with a damaged cord or
plug – replace the cord or plug immediately.
7. Do not operate charger if it has received a sharp
blow, been dropped, or otherwise damaged in any
way; take it to a qualified serviceman.
MINIMUM A WG WIRE SIZE FOR
EXTENSION CORDS FOR THIS
BATTERY CHARGER
tupniCAm,drocfohtgneL
A,ItnerruCdrocfoezisGWA
5205001051
0< 2<I81818161
2< 3<I81816141
3< 4<I81816141
4< 5<I81814121
5< 6<I81614121
6< 8<I81612101
8< 01<I81412101
01< 21<I6141018
8. Do not disassemble charger; take it to a qualified
serviceman when service or repair is required.
21< 41<I6121018
41< 61<I6121018
Incorrect reassembly may result in a risk of electric
shock or fire.
SKU 94088 For technical questions, please call 1-800-444-3353. Page 2
9. To reduce risk of electric shock, unplug charger from outlet before attempting any
maintenance or cleaning.
10. WARNING - RISK OF EXPLOSIVE GASES.
(a) Working in the vicinity of a lead-acid battery is dangerous. Batteries generate
explosive gases during normal battery operation. For this reason, it is of utmost
importance that each time before using your charger, you read this and follow the
instructions exactly.
(b) To reduce the risk of the battery explosion, follow these instructions and those
published by battery manufacturer and manufacturer of any equipment you intend to
use in vicinity of battery. Review cautionary markings on these products and on
engine.
11. PERSONAL PRECAUTIONS
(a) Someone should be within range of your voice, or close enough to come to your aid,
when you work near a lead-acid battery.
(b) Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing,
or eyes.
(c) Wear complete eye protection and clothing protection. Avoid touching eyes while
working near battery .
(d) If battery acid contacts skin or clothing, wash immediately with soap and water. If
acid enters eye, immediately flood with running cold water for at least 10 minutes
and get medical attention immediately.
(e) NEVER smoke or allow a spark or flame in vicinity of battery or engine.
(f ) Be extra cautious to reduce risk of dropping a metal tool onto battery. It might spark
or short-circuit battery or other electrical part that may cause an explosion.
(g) Remove personal metal items such as rings, bracelets, necklaces, and watches
when working near a lead-acid battery. A lead-acid battery can produce a short-
circuit current high enough to weld a ring or the like to metal, causing a severe burn.
(h) Use this charger for charging LEAD-ACID batteries only. It is not intended to supply
power to a low voltage electrical system other than in an automotive application. Do
not use battery charger for charging dry-cell batteries that are commonly used with
home appliances. These batteries may burst and cause injury to persons and
damage to property .
(i) NEVER charge a frozen battery .
12. PREPARING TO CHARGE BATTERY
(a) If it becomes necessary to remove the battery from the vehicle to charge, always
remove grounded terminal from battery first. Make sure all accessories in the vehicle
are off, so as not to cause an arc.
(b) Be sure area around battery is well ventilated while battery is being charged. Gases
can be forcefully blown away, by using a piece of cardboard or other non-metallic
material such as a paper/wood fan.
(c) Clean battery terminals. Be careful to keep corrosion from coming in contact with
eyes.
SKU 94088 For technical questions, please call 1-800-444-3353. Page 3
