Harbor Freight Tools 93830 User Manual

18V RECIPROCATING SAW

®

93830

ASSEMBLY AND OPERATING INSTRUCTIONS

Due to continuing improvements, actual product may differ slightly from the product described herein.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our Web site at http://www.harborfreight.com

TO PREVENT SERIOUS INJURY,

READ AND UNDERSTAND ALL WARNINGS

AND INSTRUCTIONS BEFORE USE.

Copyright© 2005 by Harbor Freight Tools® . All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the express
written consent of Harbor Freight Tools.

For technical questions and replacement parts, please call 1-800-444-3353.

Contents

UNPACKING.............................................................................. 2

PRODUCT SPECIFICATIONS................................................... 3

GENERAL SAFETY RULES ..................................................... 3

CHARGING THE BATTERY ..................................................... 10

OPERATION ............................................................................. 11

Reciprocating Saw ......................................................................... 11

INSPECTION, MAINTENANCE, AND CLEANING ................... 12

PARTS LISTS AND DIAGRAMS.............................................. 13

Parts List/Diagram - Reciprocating Saw ...................................... 13

UNPACKING

When unpacking, check to make sure all the parts shown on the Parts Lists at the

end of the manual are included. If any parts are missing or broken, please call Harbor

Freight Tools at the number shown on the cover of this manual as soon as possible.

Note: Before first use, the Batteries (47) will require charging. The first charge requires 8

hours charge time for each battery. See charging instructions on page 10.

SKU 93830 For technical questions, please call 1-800-444-3353. Page 2

PRODUCT SPECIFICATIONS

metInoitpircseD

zH06/CAV021:tupnI

retpadAregrahCCA

Am004,CDV42:tuptuO

egrahClaitinIruoH8;sruoH5ot3:emiTegrahC

piceR

waSgnitacor

seirosseccA retpadA/regrahCyrettaB;yettaBCDV81elbaegrahceR1

7

/

8

reggirTytefaS;MPS0032-0;ekortS"

Save This Manual

You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and assembly
diagram. Keep your invoice with this manual. Write the invoice number on the inside
of the front cover. Keep this manual and invoice in a safe and dry place for future
reference.

GENERAL SAFETY RULES

WARNING!

READ AND UNDERSTAND ALL INSTRUCTIONS

Failure to follow all instructions listed below may result in

electric shock, fire, and/or serious injury.

SAVE THESE INSTRUCTIONS

Work Area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite

accidents.

2. Do not operate power tools in explosive atmospheres, such as in the presence

of flammable liquids, gases, or dust. Power tools create sparks which may ignite

the dust or fumes.

SKU 93830 For technical questions, please call 1-800-444-3353. Page 3

3. Keep bystanders, children, and visitors away while operating a power tool.

Distractions can cause you to lose control. Protect others in the work area from

debris such as chips and sparks. Provide barriers or shields as needed. Do not

allow children to handle or play with these products.

Electrical Safety

4. Grounded tools must be plugged into an outlet properly installed and grounded

in accordance with all codes and ordinances. Never remove the grounding

prong or modify the plug in any way. Do not use any adapter plugs. Check

with a qualified electrician if you are in doubt as to whether the outlet is properly

grounded. If the tools should electrically malfunction or break down, grounding

provides a low resistance path to carry electricity away from the user.

5. Double insulated tools are equipped with a polarized plug (one blade is wider

than the other). This plug will fit in a polarized outlet only one way. If the plug

does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a

qualified electrician to install a polarized outlet. Do not change the plug in any

way. Double insulation eliminates the need for the three wire grounded power

cord and grounded power supply system.

6. Avoid body contact with grounded surfaces such as pipes, radiators, ranges,

and refrigerators. There is an increased risk of electric shock if your body is

grounded.

7. Do not expose power tools to rain or wet conditions. Water entering a power

tool will increase the risk of electric shock.

8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools or

pull the Plug from an outlet. Keep the Power Cord away from heat, oil, sharp

edges, or moving parts. Replace damaged Power Cords immediately. Damaged

Power Cords increase the risk of electric shock.

9. When operating a power tool outside, use an outdoor extension cord marked

“W-A” or “W”. These extension cords are rated for outdoor use, and reduce the risk

of electric shock.

Personal Safety

10. Stay alert. Watch what you are doing, and use common sense when operating

a power tool. Do not use a power tool while tired or under the influence of

drugs, alcohol, or medication. A moment of inattention while operating power

tools may result in serious personal injury.

11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep

your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry,

or long hair can be caught in moving parts.

SKU 93830 For technical questions, please call 1-800-444-3353. Page 4
